Figure A-12
WS-AO-5D16060
Specifications
Table A-7 WS-AO-5D16060 Specifications
Specification
Frequency
Gain:
Port H
Port V
VSWR
Polarization
Elevation Beamwidth
Azimuth Beamwidth
Port H
Port V
Elevation Null Fill Below Horizon
1st Null
2nd Null
Cross Polarization
WS-AO-5D23009 Elevation Radiation Pattern Midband Freq. 5.47 GHz
-30
-45
-60
-75
-90
-105
-120
-135
-150
-165
Value
5.15 – 5.875 GHz
15 dBi
16 dBi (min.)
1.7:1 (max)
Dual vertical and horizontal
10° ±4°
ETSI EN 302 085 V1.1.2 CS1-CS3 13 dBi 60° ±4
ETSI EN 302 085 V1.1.2 CS1-CS3 12 dBi -4/ +7
ETSI EN 302 085 V1.1.2 CS1-CS3
-15 dB (min.) @ 10°
-25 dB (min.) @ 20°
ETSI EN 302 085 V1.1.2 CS1-CS3 -24 dB (max)
Enterasys Wireless AP External Antenna Site Preparation and Installation Guide A-11
External Antennas for Use with Outdoor APs
0
-15
15
30
150
165
180
45
60
75
-20
90
105
120
135
