2.2 Block Diagram
2.3 Hardware Features
2.3.1 MSPM0L1306 MCU
The
MSPM0L1306
device provides up to 64KB embedded flash program memory with up to 4KB SRAM.
The devices incorporate a high speed on-chip oscillator with an accuracy of ±1%, eliminating the need for an
external crystal. Additional features include a 3-channel DMA, 16 and 32-bit CRC accelerator, and a variety
of high-performance analog peripherals such as one 12-bit 1MSPS ADC with configurable internal voltage
reference, one high-speed comparator with built-in reference DAC, two zero-drift zero-crossover op-amps with
programmable gain, one general-purpose amplifier, and an on-chip temperature sensor. These devices also
offer intelligent digital peripherals such as four 16-bit general purpose timers, one windowed watchdog timer,
and a variety of communication peripherals including two UARTs, one SPI, and two I2C. These communication
peripherals offer protocol support for LIN, IrDA, DALI, Manchester, Smart Card, SMBus, and PMBus. Device
feature include:
•
1.62 V to 3.6 V operation
•
Arm 32-bit Cortex-M0+, up to 32 MHz
•
64KB of flash and 4KB SRAM
•
12-bit 1-Msps ADC
•
Two zero-drift, zero-crossover chopper op-amps
•
Four 16-bit general purpose timers
•
Internal 4- to 32-MHz oscillator with ±1% accuracy (SYSOSC)
•
28 GPIOs
SLAU869D – OCTOBER 2022 – REVISED NOVEMBER 2023
Submit Document Feedback
Micro-B
LED
USB
Red,Green
ESD
Debug
Protection
MCU
External
Debug,
Out
Power, UART, SWD to
Target
External
Debug, In
40-Pin
LaunchPad
Target device
Standard
MSPM0L1306
headers
Light sensor
Thermistor
Figure 2-2. Block Diagram
Copyright © 2023 Texas Instruments Incorporated
Reset
Button
Energy
Trace
Technology
User Interface:
Buttons and Red
LED
RGB LED
MSPM0L1306 LaunchPad Development Kit (LP
Hardware
‑ MSPM0L1306)
7
