MSP430FG461x, MSP430CG461x Mixed-Signal Microcontrollers
1 Device Overview
1.1 Features
1
• Low Supply-Voltage Range: 1.8 V to 3.6 V
• Ultra-Low Power Consumption
– Active Mode: 400 µA at 1 MHz, 2.2 V
– Standby Mode: 1.3 µA
– Off Mode (RAM Retention): 0.22 µA
• Five Power-Saving Modes
• Wakeup From Standby Mode in Less Than 6 µs
• 16-Bit RISC Architecture, Extended Memory,
125‑ns Instruction Cycle Time
• Three-Channel Internal DMA
• 12-Bit Analog-to-Digital Converter (ADC) With
Internal Reference, Sample-and-Hold and
Autoscan Feature
• Three Configurable Operational Amplifiers
• Dual 12-Bit Digital-to-Analog Converters (DACs)
With Synchronization
• 16-Bit Timer_A With Three Capture/Compare
Registers
• 16-Bit Timer_B With Seven Capture/Compare-
With-Shadow Registers
• On-Chip Comparator
• Supply Voltage Supervisor and Monitor With
Programmable Level Detection
• Serial Communication Interface (USART1), Select
Asynchronous UART or Synchronous SPI by
Software
1.2 Applications
• Portable Medical Applications
1.3 Description
The TI MSP430™ family of ultra-low-power microcontrollers consists of several devices featuring different
sets of peripherals targeted for various applications. The architecture, combined with five low-power
modes, is optimized to achieve extended battery life in portable measurement applications. The device
features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to
maximum code efficiency. The digitally controlled oscillator (DCO) allows the device to wake up from low-
power modes to active mode in less than 6 µs.
The MSP430xG461x series are microcontroller configurations with two 16-bit timers, a high-performance
12-bit ADC, dual 12-bit DACs, three configurable operational amplifiers, one universal serial
communication interface (USCI), one universal synchronous/asynchronous communication interface
(USART), DMA, 80 I/O pins, and a segment liquid crystal display (LCD) driver with regulated charge
pump.
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Sample &
Product
Buy
Folder
MSP430FG4619, MSP430FG4618, MSP430FG4617, MSP430FG4616
MSP430CG4619, MSP430CG4618, MSP430CG4617, MSP430CG4616
Tools &
Technical
Software
Documents
• Universal Serial Communication Interface
– Enhanced UART Supports Automatic Baud-
Rate Detection
– IrDA Encoder and Decoder
– Synchronous SPI
2
– I C
• Serial Onboard Programming, Programmable
Code Protection by Security Fuse
• Brownout Detector
• Basic Timer With Real-Time Clock (RTC) Feature
• Integrated LCD Driver up to 160 Segments With
Regulated Charge Pump
• Section 3 Summarizes the Available Family
Members
– MSP430FG4616, MSP430FG4616
92KB+256B of Flash or ROM
4KB of RAM
– MSP430FG4617, MSP430CG4617
92KB+256B of Flash or ROM
8KB of RAM
– MSP430FG4618, MSP430CG4618
116KB+256B of Flash or ROM
8KB of RAM
– MSP430FG4619, MSP430CG4619
120KB+256B of Flash or ROM
4KB of RAM
• For Complete Module Descriptions, see the
MSP430x4xx Family User's Guide (SLAU056)
• E-Meter Applications
Support & Reference
Community
Design
SLAS508J – APRIL 2006 – REVISED JUNE 2015
