- Page 1 742S 742i SC742 CHASSIS USER'S GUIDE 1.0b...
- Page 2 Santa Clara County in the State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
-
Page 3: Table Of Contents
Table of Contents Chapter I: Safety Information and Technical Specifi cations ... 1-4 1-1. Safety Information ... 1-4 1-2. Technical Specifi cations ... 1-6 742 SATA Back Panel ... 1-6 B. SCA742-E2 SCSI Dual Channel Back Panel (w/GEM318) ... 1-8 C. -
Page 4: Safety Information
All images and graphics shown in this manual were based upon the latest chas- sis Revision available at the time of publishing. The chassis you’ve received may or may not look exactly the same as the ones shown in this manual. -
Page 5: Chapter I: Safety Information And Technical Specifi Cations
3. Use the original screws or fasteners to install the covers to the chassis. 4. Be sure to lock to the chassis or the system to prevent unauthorized access. 5. For proper cooling, enclose the chassis with covers before operating the system. -
Page 6: 1-2 Technical Specifi Cations
SC742 Chassis User’s Guide 1-2 Technical Specifi cations 742 SATA Back Panel A-1 Connector/Jumper Locations 4 - P i n 4 - P i n JP10 JP13 A-2 Connectors D3: Overheat LED Indicator J5: SATA #0 J6: SATA#1 J7: SATA #2... - Page 7 Chapter 1: Safety Information and Technical Specifi cations A-3 Jumpers JP18: Buzzer Reset JP25: Overheat LED A-4 Connector/LED Indicator Locations (Rear Side) Rear View (*Not drawn to scale) A-5 Activity LED Indicators...
-
Page 8: Sca742-E2 Scsi Dual Channel Back Panel (W/Gem318)
SC742 Chassis User’s Guide B. SCA 74-E2 SCSI Dual Channel Back Panel (W/GEM318) Front View B-1 Connector/Jumper Locations B-2 Connectors JP10/JP15: 4-Pin PWR Connectors B-3 Jumpers JP18: Buzzer Reset SCSI Channel A Jumpers (*Not Drawn to Scale) 4-Pin PWR Connectors... - Page 9 Chapter 1: Safety Information and Technical Specifi cations B-4 Connector/LED Indicator Locations (Rear) Rear View (*Not drawn to scale) B-5 LED Indicators (Rear) SCSI Drive Fail LED Indicators SCSI Drive Activity LED Indicators...
-
Page 10: Sca 742 Scsi Single Channel Back Panel (W/Gem359)
SC742 Chassis User’s Guide C. SCA 742 SCSI Single Channel Back Panel (w/GEM359) Front View C-1 Connector/Jumper Locations C-2 Connectors JP10/JP26: 4-Pin PWR Connectors C-3 Jumpers JP19: Buzzer Reset (*Not Drawn to Scale) 4-Pin PWR Connectors Pin Definitions Ground Ground... - Page 11 Chapter 1: Safety Information and Technical Specifi cations C-4 Connector/LED Indicator Locations (Rear) Rear View (*Not drawn to scale) C-5 LED Indicators (Rear) SCSI Drive Fail LED Indicators SCSI Drive Activity LED Indicators 1-11...
-
Page 12: Scsi (Super) Gem Driver Installation (*For The Windows Os)
6) Click “Next” 2 times, uncheck both “Floppy disk drives” and “CD-ROM drives”. Then, select the item- “Specify a location,” and choose “Next”. 7) Click on “Browse” and choose D drive or wherever Supermicro Setup CD is in. 8) Choose “Qlogic” folder and click on “Open”. - Page 13 Chapter 1: Safety Information and Technical Specifi cations Important!!! The chassis handles are for sliding the chassis in and out of the racks only. Do not carry the chassis by the STOP handles to avoid system damage or bodily injury.
