Power Sources That Can Be Used - Jeep AVENGER 2023 Owner's Handbook Manual

The estimated driving range per hour
of recharging (4)
WARNING
219) In order to reduce the risk of electric
shock or damage to the device, special
care should be taken when cleaning:
ALWAYS unplug the device from the
domestic power supply socket and car
ports.
220) The safety and suitability of the
domestic system for charging through the
domestic mains are primary and are under
the Customer's responsibility.
221) In case of impact, even light,
against the charging flap, do not use it.
Do not dismantle or modify the charging
connector - risk of electrocution and/or
fire! Contact a Jeep Dealership.
IMPORTANT
102) Do not charge if the external
temperature is -30 ° C or lower, as charging
is likely to take longer and the charging
device may be damaged.
103) In cold temperatures, the charging
cable may become stiff. Therefore, be
careful not to apply excessive force to the
charging cable as it may be damaged.
104) Do not use personal generators to
charge the high-voltage battery. This may
cause fluctuations in charging and the
voltage may be insufficient, resulting in
damage to the car system.
105) Charging the high-voltage battery
using incorrect or damaged sockets, or
charging cables and not following the
prescribed charging procedures may
cause short circuits, fire and potential risk
of damage to the electrical system of the
car.
106) Avoid leaving the high-voltage
battery for several days with the charge
indicator at or near zero. The high-voltage
battery may be damaged.
107) You do not need to wait until
the high-voltage battery level is low
to recharge. The performance of the
high-voltage battery is optimal when it is
charged regularly.
108) Charging the high-voltage battery
may take longer if the temperature of the
high-voltage battery is high or low.
109) During charging, especially with fast
charging, high-voltage battery cooling
components may be voltage activated.
Therefore, it is normal to hear noises
during this operation.
POWER SOURCES THAT
CAN BE USED
222) 223) 224) 225) 226) 227) 228) 229) 230) 231) 232)
233) 234) 235) 236) 237) 238) 239) 240) 241) 242) 243)
CHARGING TYPES
There are different types of charging the
vehicle's high-voltage battery.
Charging at wallboxes
228
229
A wallbox is a charging unit for private
households. It provides a charging
cable which has to be connected to the
vehicle's charging port. Some wallboxes
do not provide a charging cable. In
this case, a separate charging cable is
required which has to be connected to
JJ000228
JJ000371
169
