Proline t-mass F 500 HART Table of contents Table of contents Mounting the measuring device ... 27 About this document ....6 5.2.1...
Page 4 Table of contents Proline t-mass F 500 HART 7.4.3 Establishing a connection ..62 Protecting settings from unauthorized access 124 7.4.4 Logging on ....64 9.8.1...
Page 5 12.2 Measuring and test equipment ... 166 12.3 Endress+Hauser services ....166 Repair ......167 13.1 General information .
Page 6: About This Document
About this document Proline t-mass F 500 HART About this document Document function These Operating Instructions contain all the information required in the various life cycle phases of the device: from product identification, incoming acceptance and storage, to installation, connection, operation and commissioning, through to troubleshooting, maintenance and disposal.
Page 7: Tool Symbols
Proline t-mass F 500 HART About this document Symbol Meaning Light emitting diode is on. Light emitting diode is flashing. 1.2.4 Tool symbols Symbol Meaning Torx screwdriver Phillips head screwdriver Open-ended wrench 1.2.5 Symbols for certain types of information Symbol...
Page 8: Documentation
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. 1.3.1 Document function...
Page 9: Safety Instructions
Proline t-mass F 500 HART Safety instructions Safety instructions Requirements for the personnel The personnel for installation, commissioning, diagnostics and maintenance must fulfill the following requirements: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task.
Page 10: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.
Page 11: Security
Proline t-mass F 500 HART Safety instructions IT security Our warranty is valid only if the product is installed and used as described in the Operating Instructions. The product is equipped with security mechanisms to protect it against any inadvertent changes to the settings.
Page 12: Access Via Web Server
Safety instructions Proline t-mass F 500 HART • User-specific access code Protect write access to the device parameters via the local display, web browser or operating tool (e.g. FieldCare, DeviceCare). Access authorization is clearly regulated through the use of a user-specific access code.
Page 13: Access Via Service Interface (Cdi-Rj45)
Proline t-mass F 500 HART Safety instructions 2.7.4 Access via service interface (CDI-RJ45) The device can be connected to a network via the service interface (CDI-RJ45). Device- specific functions guarantee the secure operation of the device in a network. The use of relevant industrial standards and guidelines that have been defined by national and international safety committees, such as IEC/ISA62443 or the IEEE, is recommended.
Page 14: Product Description
Product description Proline t-mass F 500 HART Product description The measuring system consists of a transmitter and a sensor. The transmitter and sensor are mounted in physically separate locations. They are interconnected by connecting cables. Product design 3.1.1 Proline 500 – digital Signal transmission: digital Order code for "Integrated ISEM electronics", option A "Sensor"...
Page 15: Incoming Acceptance And Product
Is the envelope present with accompanying documents? • If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • The Technical Documentation is available via the Internet or via the Endress+Hauser Operations app: Product identification→  16.
Page 16: Transmitter Nameplate
• The "Additional standard documentation on the device" and "Supplementary device- dependent documentation" sections • The Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations app: Enter the serial number from the nameplate or scan the DataMatrix code on the nameplate. 4.2.1 Transmitter nameplate Proline 500 –...
Page 17: Sensor Nameplate
Proline t-mass F 500 HART Incoming acceptance and product identification 4.2.2 Sensor nameplate Order code: Ser.no.: Ext. ord.cd.: Date: A0041923  3 Example of sensor nameplate Name of sensor Order code Serial number Extended order code Flow; nominal diameter of sensor; pressure rating; nominal pressure; system pressure; medium temperature range;...
Page 18: Symbols On The Device
Incoming acceptance and product identification Proline t-mass F 500 HART 4.2.3 Symbols on the device Symbol Meaning WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Please consult the documentation for the measuring device to discover the type of potential danger and measures to avoid it.
Page 19: Packaging Disposal
Proline t-mass F 500 HART Incoming acceptance and product identification A0029214 Measuring devices with lifting lugs CAUTION Special transportation instructions for devices with lifting lugs ‣ Only use the lifting lugs fitted on the device or flanges to transport the device.
Page 20: Mounting
Mounting Proline t-mass F 500 HART Mounting Mounting requirements • The recommended inlet and outlet specifications must be observed. • The piping system and the device must be installed according to good engineering practice. • Ensure the correct alignment and orientation of the sensor.
Page 21 Proline t-mass F 500 HART Mounting Pipes The measuring device must be professionally installed, and the following points must be observed: • Weld pipes professionally. • Use seals of the correct size. • Align flanges and seals correctly. A0023496 • Following installation, the pipe must be free from dirt and particles in order to avoid damage to the sensors.
Page 22 Mounting Proline t-mass F 500 HART Inlet pipe internal diameter [in] [in] Sch40 Sch80 3.30 3.07 4.22 4.03 3.82 Order code for "Process connection", option RAA "R thread EN10226-1 / ISO 7-1" Order code for "Process connection", option NPT "MNPT thread, ASME"...
Page 23 Proline t-mass F 500 HART Mounting A0039507  10 The additional measured error to be expected without flow conditioners depending on the disturbance type and inlet run Additional measured error (%) Inlet run (DN) 2 × 90 ° elbow, 3-dimensional Expansion 2 ×...
Page 24 Mounting Proline t-mass F 500 HART 5...10 × DN 2 × DN A0039425  11 Recommended inlet and outlet runs when using a flow conditioner Flow conditioner In the case of bidirectional sensors, also observe the inlet run in the opposite direction.
Page 25: Environment And Process Requirements
‣ If operating outdoors: Avoid direct sunlight, particularly in warm climatic regions. You can order a weather protection cover from Endress+Hauser→  169. System pressure Pressure-reducing valves and some compressor systems can generate significant process pressure variations that can distort the flow profile. This can produce an additional measured error.
Page 26 Mounting Proline t-mass F 500 HART NOTICE Electronics overheating on account of thermal insulation! ‣ Recommended orientation: horizontal orientation, sensor connection housing pointing downwards. ‣ Do not insulate the sensor connection housing. ‣ Maximum permissible temperature at the lower end of the sensor connection housing: 80 °C (176 °F)
Page 27: Special Mounting Instructions
Proline t-mass F 500 HART Mounting Vibrations NOTICE Strong vibrations can damage the measuring device. Can result in damage to the measuring device or the fastening units. ‣ Pay attention to information on the vibration and shock resistance →  187 5.1.3...
Page 28: Mounting The Measuring Device
Mounting Proline t-mass F 500 HART 5.2.3 Mounting the measuring device WARNING Danger due to improper process sealing! ‣ Ensure that the inside diameters of the gaskets are greater than or equal to that of the process connections and piping.
Page 29 Proline t-mass F 500 HART Mounting ø TX 25 20…70 ø ( 0.79…2.75) SW 10 A0029051  16 Engineering unit mm (in) Wall mounting Required tools: Drill with drill bit ⌀ 6.0 mm 17 (0.67) 5.8 (0.23) 5.8 (0.23) 149 (5.85) A0029054 ...
Page 30: Post-Installation Check
Mounting Proline t-mass F 500 HART 5. Tighten the fixing screws. Post-installation check Is the device undamaged (visual inspection)?  Does the measuring device conform to the measuring point specifications? For example: • Process temperature →  189  • Process pressure (refer to the "Pressure-temperature ratings" section of the "Technical Information"...
Page 31: Electrical Connection
Proline t-mass F 500 HART Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage.
Page 32 Electrical connection Proline t-mass F 500 HART Relay output Standard installation cable is sufficient. Current input 0/4 to 20 mA Standard installation cable is sufficient Status input Standard installation cable is sufficient Cable diameter • Cable glands supplied: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) •...
Page 33 Proline t-mass F 500 HART Electrical connection A: Connecting cable between sensor and transmitter: Proline 500 – digital Standard cable A standard cable with the following specifications can be used as the connecting cable. Design 4 cores; uninsulated stranded CU wires; with common shield Shielding Tin-plated copper braid, optical cover ≥...
Page 34: Terminal Assignment
Electrical connection Proline t-mass F 500 HART Cross-section Cable length [max.] Termination 2 x 2 x 0.50 mm 50 m (150 ft) 2 x 2 x 0.50 mm (AWG 20) (AWG 20) BN WT YE GN • +, – = 0.5 mm •...
Page 35: Preparing The Measuring Device
Proline t-mass F 500 HART Electrical connection Transmitter and sensor connection housing: connecting cable The sensor and transmitter, which are mounted in separate locations, are interconnected by a connecting cable. The cable is connected via the sensor connection housing and the transmitter housing.
Page 36: Connecting The Measuring Device: Proline 500 - Digital
Electrical connection Proline t-mass F 500 HART Connecting the measuring device: Proline 500 – digital NOTICE An incorrect connection compromises electrical safety! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations.
Page 37 Proline t-mass F 500 HART Electrical connection Connecting the sensor connection housing via terminals For the device version with the order code for "Sensor connection housing": • Option A "Aluminum coated" • Option L "Cast, stainless" 10 (0.4) 3 mm...
Page 38 Electrical connection Proline t-mass F 500 HART Connecting the connecting cable to the transmitter TX 20 TX 20 10 (0.4) 22 mm 24 mm A0029597 1. Loosen the 4 fixing screws on the housing cover. 2. Open the housing cover.
Page 39: Connecting The Signal Cable And The Supply Voltage Cable
Proline t-mass F 500 HART Electrical connection 6.3.2 Connecting the signal cable and the supply voltage cable A0028200 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output Terminal connection for connecting cable between sensor and transmitter Terminal connection for signal transmission, input/output;...
Page 40: Potential Equalization
Electrical connection Proline t-mass F 500 HART WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. WARNING Excessive tightening torque applied to the fixing screws! Risk of damaging the plastic transmitter.
Page 41: Special Connection Instructions
Proline t-mass F 500 HART Electrical connection Special connection instructions 6.5.1 Connection examples Current output 4 to 20 mA HART 4...20 mA A0029055  19 Connection example for 4 to 20 mA HART current output (active) Automation system with current input (e.g. PLC) Ground cable shield at one end.
Page 42 Electrical connection Proline t-mass F 500 HART HART input 4...20 mA A0028763  21 Connection example for HART input with a common negative (passive) Automation system with HART output (e.g. PLC) Active barrier for power supply (e.g. RN221N) Ground cable shield at one end. The cable shield must be grounded at both ends to comply with EMC requirements;...
Page 43 Proline t-mass F 500 HART Electrical connection Pulse/frequency output 12345 A0028761  24 Connection example for pulse/frequency output (passive) Automation system with pulse/frequency input (e.g. PLC with 10 kΩ pull-up or pull-down resistor) Power supply Transmitter: observe input values →  179...
Page 44: Ensuring The Degree Of Protection
Electrical connection Proline t-mass F 500 HART Current input A0028915  27 Connection example for 4 to 20 mA current input Power supply Terminal box External measuring device (to read in pressure or temperature, for instance) Transmitter Status input A0028764 ...
Page 45: Degree Of Protection Ip68, Type 6P Enclosure, With "Cust-Potted" Option
Proline t-mass F 500 HART Electrical connection 5. To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap").  A0029278 6. The cable glands supplied do not ensure housing protection when not in use. They must therefore be replaced by dummy plus corresponding to the housing protection.
Page 46: Operation Options
Operation options Proline t-mass F 500 HART Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370...
Page 47: Structure And Function Of The Operating Menu
Proline t-mass F 500 HART Operation options Structure and function of the operating menu 7.2.1 Structure of the operating menu For an overview of the operating menu for experts: see the "Description of Device Parameters" document supplied with the device...
Page 48: Operating Philosophy
Operation options Proline t-mass F 500 HART 7.2.2 Operating philosophy The individual parts of the operating menu are assigned to certain user roles (e.g. operator, maintenance etc.). Each user role contains typical tasks within the device life cycle. Menu/parameter User role and tasks...
Page 49: Access To Operating Menu Via Local Display
Proline t-mass F 500 HART Operation options Access to operating menu via local display 7.3.1 Operational display X X X X X X X 1120.50 kg/h A0029348 Operational display Device tag Status area Display area for measured values (up to 4 lines) Operating elements →...
Page 50 Operation options Proline t-mass F 500 HART Heat flow • Density • Reference density Energy flow Flow velocity Calorific value Temperature The number and display format of the measured variables can be configured via the Format display parameter (→  102).
Page 51: Navigation View
Proline t-mass F 500 HART Operation options 7.3.2 Navigation view In the submenu In the wizard /../Operation 0091-1 /../Select medium Access stat.disp Select medium Operator Locking status Display A0013993-EN A0041841-EN Navigation view Navigation path to current position Status area Display area for navigation Operating elements →...
Page 52 Operation options Proline t-mass F 500 HART Setup Appears: • In the menu next to the "Setup" selection • At the left in the navigation path in the Setup menu Diagnostics Appears: • In the menu next to the "Diagnostics" selection •...
Page 53: Editing View
Proline t-mass F 500 HART Operation options 7.3.3 Editing view Numeric editor +0.000 Xx – A0034250  30 For entering values in parameters (e.g. limit values) Entry display area Input screen Confirm, delete or reject entry Operating elements Text editor...
Page 54 Operation options Proline t-mass F 500 HART Operating key Meaning Enter key • Pressing the key briefly confirms your selection. • Pressing the key for 2 s confirms your entry. Escape key combination (press keys simultaneously) Close the editing view without accepting a change.
Page 55: Operating Elements
Proline t-mass F 500 HART Operation options 7.3.4 Operating elements Operating key Meaning Minus key In menu, submenu Moves the selection bar upwards in a picklist. With a wizard Confirms the parameter value and goes to the previous parameter. In the text and numeric editor Move the entry position to the left.
Page 56 Operation options Proline t-mass F 500 HART Calling up and closing the context menu The user is in the operational display. 1. Press the  and  keys for longer than 3 seconds.  The context menu opens. XXXXXXXXXX Setup Conf.backup...
Page 57: Navigating And Selecting From List
Proline t-mass F 500 HART Operation options 7.3.6 Navigating and selecting from list Different operating elements are used to navigate through the operating menu. The navigation path is displayed on the left in the header. Icons are displayed in front of the individual menus.
Page 58: Calling Up Help Text
Operation options Proline t-mass F 500 HART The direct access code consists of a 5-digit number (at maximum) and the channel number, which identifies the channel of a process variable: e.g. 00914-2. In the navigation view, this appears on the right-hand side in the header of the selected parameter.
Page 59: User Roles And Related Access Authorization
Proline t-mass F 500 HART Operation options Ent. access code Invalid or out of range input value Min:0 Max:9999 A0014049-EN For a description of the editing view - consisting of the text editor and numeric editor - with symbols →  53, for a description of the operating elements →  55 7.3.10...
Page 60: Enabling And Disabling The Keypad Lock
Operation options Proline t-mass F 500 HART 2. Enter the access code.  The -symbol in front of the parameters disappears; all previously write- protected parameters are now re-enabled. 7.3.12 Enabling and disabling the keypad lock The keypad lock makes it possible to block access to the entire operating menu via local operation.
Page 61: Requirements
Proline t-mass F 500 HART Operation options 7.4.2 Requirements Computer hardware Hardware Interface CDI-RJ45 WLAN Interface The computer must have a RJ45 The operating unit must have a WLAN interface. interface. Connection Standard Ethernet cable Connection via Wireless LAN. Screen Recommended size: ≥12"...
Page 62: Establishing A Connection
Operation options Proline t-mass F 500 HART Measuring device: Via CDI-RJ45 service interface Device CDI-RJ45 service interface Measuring device The measuring device has an RJ45 interface. Web server Web server must be enabled; factory setting: ON  For information on enabling the Web server →  66...
Page 63 Proline t-mass F 500 HART Operation options NOTICE Note the following to avoid a network conflict: ‣ Avoid accessing the measuring device simultaneously from the same mobile terminal via the service interface (CDI-RJ45) and the WLAN interface. ‣ Only activate one service interface (CDI-RJ45 or WLAN interface).
Page 64: Logging On
Operation options Proline t-mass F 500 HART 2. Enter the IP address of the web server in the address line of the web browser: 192.168.1.212  The login page appears. 2 3 4 A0029417 Picture of device Device name Device tag (→  80)
Page 65: User Interface
Proline t-mass F 500 HART Operation options 7.4.5 User interface A0029418 Function row Local display language Navigation area Header The following information appears in the header: • Device name • Device tag • Device status with status signal →  146 •...
Page 66: Disabling The Web Server
Operation options Proline t-mass F 500 HART Working area Depending on the selected function and the related submenus, various actions can be performed in this area: • Configuring parameters • Reading measured values • Calling up help text • Starting an upload/download 7.4.6...
Page 67: Access To The Operating Menu Via The Operating Tool
Proline t-mass F 500 HART Operation options Access to the operating menu via the operating tool The structure of the operating menu in the operating tools is the same as for operation via the local display. 7.5.1 Connecting the operating tool Via HART protocol This communication interface is available in device versions with a HART output.
Page 68 Operation options Proline t-mass F 500 HART A0028746  34 Options for remote operation via HART protocol (passive) Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with web browser (e.g.
Page 69 Proline t-mass F 500 HART Operation options Via WLAN interface The optional WLAN interface is available on the following device version: Order code for "Display; operation", option G "4-line, illuminated; touch control + WLAN" Function WLAN: IEEE 802.11 b/g (2.4 GHz) Encryption WPA2-PSK AES-128 (in accordance with IEEE 802.11i)
Page 70: Field Xpert Sfx350, Sfx370
FieldCare Function range FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser. It can configure all smart field units in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition.
Page 71: Devicecare
DeviceCare Function range Tool for connecting and configuring Endress+Hauser field devices. The fastest way to configure Endress+Hauser field devices is with the dedicated "DeviceCare" tool. Together with the device type managers (DTMs) it presents a convenient, comprehensive solution. Innovation brochure IN01047S Source for device description files →...
Page 72: Ams Device Manager
Operation options Proline t-mass F 500 HART 7.5.5 AMS Device Manager Function range Program from Emerson Process Management for operating and configuring measuring devices via the HART protocol. Source for device description files →  73 7.5.6 Field Communicator 475...
Page 73: System Integration
Proline t-mass F 500 HART System integration System integration Overview of device description files 8.1.1 Current version data for the device Firmware version 01.00.zz • On the title page of the Operating Instructions • On the transmitter nameplate →  15 •...
Page 74: Device Variables
System integration Proline t-mass F 500 HART Dynamic variables Measured variables (HART device variables) Primary dynamic variable (PV) Mass flow Secondary dynamic variable (SV) Totalizer Tertiary dynamic variable (TV) Volume flow Quaternary dynamic variable (QV) Corrected volume flow The assignment of the measured variables to the dynamic variables can be modified and...
Page 75: Other Settings
Proline t-mass F 500 HART System integration Allocation Device variables Temperature Totalizer 1 Totalizer 2 Totalizer 3 Other settings Burst mode functionality in accordance with HART 7 Specification: Navigation "Expert" menu → Communication → HART output → Burst configuration → Burst configuration 1 to n ‣...
Page 76 System integration Proline t-mass F 500 HART Parameter overview with brief description Parameter Description Selection / User entry Burst mode 1 to n Activate the HART burst mode for burst message X. • Off • On Burst command 1 to n Select the HART command that is sent to the HART master.
Page 77 Proline t-mass F 500 HART System integration Parameter Description Selection / User entry Min. update period Enter the minimum time span between two burst commands of Positive integer burst message X. Max. update period Enter the maximum time span between two burst commands of Positive integer burst message X.
Page 78: Commissioning
Commissioning Proline t-mass F 500 HART Commissioning Post-mounting and post-connection check Before commissioning the device: ‣ Make sure that the post-installation and post-connection checks have been performed successfully. • Checklist for "Post-mounting" check→  30 • Checklist for "Post-connection check" →  45 Switching on the measuring device ‣...
Page 79: Configuring The Measuring Device
Proline t-mass F 500 HART Commissioning Configuring the measuring device The Setup menu with its guided wizards contains all the parameters needed for standard operation. X X X X X X X 20.50 Main menu 0104-1 Display language English Display/operat.
Page 80: Defining The Tag Name
Commissioning Proline t-mass F 500 HART ‣ Relay output 1 to n →  100 ‣ Display →  101 ‣ →  104 Low flow cut off ‣ Advanced setup →  105 9.4.1 Defining the tag name To enable fast identification of the measuring point within the system, you can enter a unique designation using the Device tag parameter and thus change the factory setting.
Page 81 Proline t-mass F 500 HART Commissioning Mol% Air →  82 →  83 Mol% Ar Mol% C2H4 →  83 Mol% C2H6 →  83 Mol% C3H8 →  83 Mol% CH4 →  83 Mol% Cl2 →  83 Mol% CO →...
Page 82 Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry / User interface Measurement application – Select measurement • Air or compressed – application. • Gas or gas mixture • Energy Select gas type –...
Page 83 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Mol% Ar – Enter amount of substance for 0 to 100 % – the gas mixture. Ar = Argon Mol% C2H4 – Enter amount of substance for 0 to 100 % –...
Page 84: Configuring Reference Conditions
Commissioning Proline t-mass F 500 HART Parameter Prerequisite Description Selection / User Factory setting entry / User interface Mol% Ne – Enter amount of substance for 0 to 100 % – the gas mixture. Ne = neon Mol% NH3 – Enter amount of substance for 0 to 100 % –...
Page 85: Sensor Adjustment
Proline t-mass F 500 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User entry Reference conditions – Select reference conditions for • 1013.25 mbara, 0 °C calculation of the corrected volume • 1013.25 mbara, 15 °C flow. • 1013.25 mbara, 20 °C •...
Page 86: Setting The System Units
Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Description Selection / User entry Installation direction Set sign of flow direction to match the direction of the arrow on • Flow in arrow direction the sensor. • Flow against arrow direction...
Page 87 Proline t-mass F 500 HART Commissioning Length unit →  88 Date/time format →  88 Parameter overview with brief description Parameter Description Selection Factory setting Mass flow unit Select mass flow unit. Unit choose list Depends on country: • kg/h •...
Page 88: Displaying The I/O Configuration
Commissioning Proline t-mass F 500 HART Parameter Description Selection Factory setting Length unit Select length unit for nominal diameter. Unit choose list Country-specific: • mm • in Date/time format Select date and time format. • dd.mm.yy hh:mm – • dd.mm.yy hh:mm am/pm •...
Page 89: Configuring The Current Input
Proline t-mass F 500 HART Commissioning 9.4.7 Configuring the current input The "Current input" wizard guides the user systematically through all the parameters that have to be set for configuring the current input. Navigation "Setup" menu → Current input ‣...
Page 90: Configuring The Status Input
Commissioning Proline t-mass F 500 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry 20 mA value – Enter 20 mA value. Signed floating-point Depends on country number and nominal diameter Failure mode – Define input behavior in alarm • Alarm –...
Page 91: Configuring The Current Output
Proline t-mass F 500 HART Commissioning Parameter Description Selection / User interface / User entry Active level Define input signal level at which the assigned function is • High triggered. • Low Response time status input Define the minimum amount of time the input signal level must 5 to 200 ms be present before the selected function is triggered.
Page 92 Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Assign current output 1 to n – Select process variable for • Off – current output. • Temperature • Mass flow •...
Page 93 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Damping output 1 to n A process variable is selected Set reaction time for output 0.0 to 999.9 s – in the Assign current output signal to fluctuations in the parameter (→...
Page 94: Configuring The Pulse/Frequency
Commissioning Proline t-mass F 500 HART 9.4.10 Configuring the pulse/frequency/switch output The Pulse/frequency/switch output wizard guides you systematically through all the parameters that can be set for configuring the selected output type. Navigation "Setup" menu → Advanced setup → Pulse/frequency/switch output ‣...
Page 95 Proline t-mass F 500 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting interface / User entry Operating mode – Define the output as a pulse, • Pulse – frequency or switch output. • Frequency • Switch Terminal number –...
Page 96 Commissioning Proline t-mass F 500 HART Assign frequency output →  96 Minimum frequency value →  96 →  97 Maximum frequency value Measuring value at minimum →  97 frequency Measuring value at maximum →  97 frequency Failure mode →...
Page 97 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Maximum frequency value The Frequency option is Enter maximum frequency. 0.0 to 10 000.0 Hz – selected in the Operating mode parameter (→  94) and a process variable is...
Page 98 Commissioning Proline t-mass F 500 HART Configuring the switch output Navigation "Setup" menu → Pulse/frequency/switch output ‣ Pulse/frequency/switch output 1 to n Operating mode →  98 Terminal number →  98 Signal mode →  98 Switch output function →...
Page 99 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch output function The Switch option is selected Select function for switch • Off – in the Operating mode output. • On parameter. • Diagnostic behavior •...
Page 100: Configuring The Relay Output
Commissioning Proline t-mass F 500 HART Parameter Prerequisite Description Selection / User Factory setting interface / User entry Switch-off delay • The Switch option is Define delay for the switch-off 0.0 to 100.0 s – selected in the Operating of status output. mode parameter.
Page 101: Configuring The Local Display
Proline t-mass F 500 HART Commissioning Parameter overview with brief description Parameter Prerequisite Description User interface / Factory setting Selection / User entry Terminal number – Shows the terminal numbers • Not used – used by the relay output • 24-25 (I/O 2) module.
Page 102 Commissioning Proline t-mass F 500 HART Navigation "Setup" menu → Display ‣ Display Format display →  102 Value 1 display →  102 →  103 0% bargraph value 1 100% bargraph value 1 →  103 Value 2 display →...
Page 103 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry 0% bargraph value 1 A local display is provided. Enter 0% value for bar graph Signed floating-point – display. number 100% bargraph value 1 A local display is provided.
Page 104: Configuring The Low Flow Cut Off
Commissioning Proline t-mass F 500 HART 9.4.13 Configuring the low flow cut off The Low flow cut off wizard systematically guides the user through all the parameters that must be set to configure low flow cut off. Navigation "Setup" menu → Low flow cut off ‣...
Page 105: Advanced Settings
Proline t-mass F 500 HART Commissioning Advanced settings The Advanced setup submenu with its submenus contains parameters for specific settings. Navigation to the "Advanced setup" submenu The number of submenus and parameters can vary depending on the device version. Certain submenus and parameters in these submenus are not described in the Operating Instructions.
Page 106 Commissioning Proline t-mass F 500 HART Totalizer operation mode →  106 Failure mode →  106 →  106 Assign gas Parameter overview with brief description Parameter Prerequisite Description Selection Factory setting Assign process variable – Select process variable for •...
Page 107: Carrying Out Additional Display Configurations
Proline t-mass F 500 HART Commissioning 9.5.3 Carrying out additional display configurations In the Display submenu you can set all the parameters associated with the configuration of the local display. Navigation "Setup" menu → Advanced setup → Display ‣ Display Format display →...
Page 108 Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Prerequisite Description Selection / User Factory setting entry Format display A local display is provided. Select how measured values • 1 value, max. size – are shown on the display.
Page 109 Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry Decimal places 3 A measured value is specified Select the number of decimal • x – in the Value 3 display places for the display value. • x.x parameter.
Page 110: Wlan Configuration
Commissioning Proline t-mass F 500 HART 9.5.4 WLAN configuration The WLAN Settings submenu guides the user systematically through all the parameters that have to be set for the WLAN configuration. Navigation "Setup" menu → Advanced setup → WLAN settings ‣...
Page 111: Configuration Management
Proline t-mass F 500 HART Commissioning Parameter Prerequisite Description Selection / User Factory setting entry / User interface Network security – Select the security type of the • Unsecured – WLAN network. • WPA2-PSK • EAP-PEAP with MSCHAPv2 • EAP-PEAP MSCHAPv2 no server authentic.
Page 112 Commissioning Proline t-mass F 500 HART Navigation "Setup" menu → Advanced setup → Configuration backup ‣ Configuration backup Operating time →  112 Last backup →  112 →  112 Configuration management Backup state →  112 Comparison result →...
Page 113: Using Parameters For Device Administration
Proline t-mass F 500 HART Commissioning Options Description Compare The device configuration saved in the device memory is compared with the current device configuration of the HistoROM backup. Clear backup data The backup copy of the device configuration is deleted from the memory of the device.
Page 114: In-Situ Adjustment
Reset access code to factory settings. Character string comprising numbers, letters and special characters  For a reset code, contact your Endress+Hauser service organization. The reset code can only be entered via: • Web browser • DeviceCare, FieldCare (via CDI-RJ45 service interface) •...
Page 115 Proline t-mass F 500 HART Commissioning In-situ adjustment can lead to better measurement results in the following cases: • Process-specific facility conditions / installation effects • If the flow profile is distorted • For unfavorable inlet and outlet conditions • If the gas is unknown •...
Page 116 Commissioning Proline t-mass F 500 HART 5. Select the entry method for the reference value: Expert → Sensor → In-situ adjustment → Input type reference value  If "Manual" is selected, the operator must enter the flow value manually via the display (or other operating interface).
Page 117 Proline t-mass F 500 HART Commissioning "In-situ adjustment" submenu Navigation "Expert" menu → Sensor → In-situ adjustment ‣ In-situ adjustment Activate in-situ adjustment (17360) →  118 Input type reference value (17351) →  118 →  118 Delete values (17355) Confirm (17356) →...
Page 118 Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Description Selection / User interface / Factory setting User entry Activate in-situ adjustment Activate the in-situ adjustment. The points • No – stored by the user are used for the in-situ •...
Page 119 Proline t-mass F 500 HART Commissioning "Adjustment values in use" submenu Navigation "Expert" menu → Sensor → In-situ adjustment → Adjustment values in use ‣ Adjustment values in use Gas description 1/2 (17361) →  120 Gas description 2/2 (17362) →...
Page 120 Commissioning Proline t-mass F 500 HART Parameter overview with brief description Parameter Description User interface Factory setting Gas description 1/2 Shows the 1st part of the description of the set gas used in the in-situ adjustment. Gas description 2/2 Shows the 2nd part of the description of the set gas used in the in-situ adjustment.
Page 121: Configuration Management
Proline t-mass F 500 HART Commissioning Configuration management After commissioning, you can save the current device configurationor restore the previous device configuration. The device configuration is managed via the Configuration management parameter. Navigation "Setup" menu → Advanced setup → Configuration backup ‣...
Page 122: Simulation
Commissioning Proline t-mass F 500 HART Options Description Restore The last backup copy of the device configuration is restored from the device memory to the device' s HistoROM backup. The backup copy includes the transmitter data of the device. Compare The device configuration saved in the device memory is compared with the current device configuration of the HistoROM backup.
Page 123 Proline t-mass F 500 HART Commissioning Switch output simulation 1 to n →  123 Switch status 1 to n →  123 →  123 Relay output 1 to n simulation Switch status 1 to n →  124 Device alarm simulation →...
Page 124: Protecting Settings From Unauthorized Access
Commissioning Proline t-mass F 500 HART Parameter Prerequisite Description Selection / User entry Switch status 1 to n The On option is selected in the Switch Select status of the relay output for the • Open output simulation 1 to n parameter simulation.
Page 125 Proline t-mass F 500 HART Commissioning 3. Enter the access code again in the Confirm access code parameter (→  113) to confirm.  The  symbol appears in front of all write-protected parameters. • Disabling parameter write protection via access code →  59.
Page 126: Write Protection Via Write Protection Switch
Proline t-mass F 500 HART Via Web browser, FieldCare, DeviceCare (via CDI-RJ45 service interface), fieldbus You can only obtain a reset code from your local Endress+Hauser service organization. The code must be calculated explicitly for every device. 1. Note down the serial number of the device.
Page 127 Proline t-mass F 500 HART Commissioning 4. Enable or disable write protection: Setting the write protection (WP) switch on the main electronics module to the ON position enables hardware write protection/to the OFF position (factory setting) disables hardware write protection.
Page 128: Operation
Operation Proline t-mass F 500 HART Operation 10.1 Reading off the device locking status Device active write protection: Locking status parameter Operation → Locking status Function scope of the "Locking status" parameter Options Description None The access authorization displayed in the Access status parameter applies →...
Page 129: Process Variables
Proline t-mass F 500 HART Operation ‣ Output values →  132 ‣ Totalizer →  130 10.4.1 Process variables The Process variables submenu contains all the parameters needed to display the current measured values for each process variable. Navigation "Diagnostics"...
Page 130: System Values
Operation Proline t-mass F 500 HART Parameter Prerequisite Description User interface FAD volume flow The Air or compressed air option is Displays the FAD volume flow that is Signed floating-point selected in the Measurement currently calculated. number application parameter. Dependency The unit is taken from: FAD volume flow unit parameter (→...
Page 131: Input Values" Submenu
Proline t-mass F 500 HART Operation Parameter overview with brief description Parameter Description User interface Totalizer value 1 to n Displays the current totalizer counter value. Signed floating-point number Totalizer overflow 1 to n Displays the current totalizer overflow. Integer with sign 10.4.4...
Page 132: Output Values
Operation Proline t-mass F 500 HART Navigation "Diagnostics" menu → Measured values → Input values → Status input 1 to n ‣ Status input 1 to n Value status input →  132 Parameter overview with brief description Parameter Description...
Page 133 Proline t-mass F 500 HART Operation Parameter overview with brief description Parameter Description User interface Output current 1 Displays the current value currently calculated for the current 3.59 to 22.5 mA output. Measured current Displays the current value currently measured for the current 0 to 30 mA output.
Page 134: Adapting The Measuring Device To The Process
Operation Proline t-mass F 500 HART Parameter overview with brief description Parameter Description User interface Switch status Shows the current relay switch status. • Open • Closed Switch cycles Shows number of all performed switch cycles. Positive integer Max. switch cycles number Shows the maximal number of guaranteed switch cycles.
Page 135: Function Scope Of "Control Totalizer" Parameter
Proline t-mass F 500 HART Operation Parameter Prerequisite Description Selection / User entry / User interface Totalizer value – Displays the current totalizer counter Signed floating-point value. number Reset all totalizers – Reset all totalizers to 0 and start. • Cancel • Reset + totalize 10.6.1...
Page 136 Operation Proline t-mass F 500 HART • x-axis: depending on the number of channels selected displays 250 to 1000 measured values of a process variable. • y-axis: displays the approximate measured value span and constantly adapts this to the ongoing measurement.
Page 137 Proline t-mass F 500 HART Operation Parameter overview with brief description Parameter Prerequisite Description Selection / User entry / User interface Assign channel 1 The Extended HistoROM application Assign process variable to logging • Off package is available. channel. • Temperature • Mass flow •...
Page 138: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline t-mass F 500 HART Diagnostics and troubleshooting 11.1 General troubleshooting For local display Error Possible causes Remedial action Local display is dark, but signal output is within The cable of the display module is not plugged in...
Page 139 Proline t-mass F 500 HART Diagnostics and troubleshooting For access Error Possible causes Remedial action No write access to parameters. Hardware write protection is enabled. Set the write protection switch on the main electronics module to the OFF position (Verweisziel existiert nicht, aber @y.link.required=' t rue' )
Page 140 Diagnostics and troubleshooting Proline t-mass F 500 HART Error Possible causes Remedial action Operation with FieldCare or DeviceCare not Firewall of the PC or network prevents Depending on the settings of the firewall used possible via CDI-RJ45 service interface (port communication.
Page 141: Diodes
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.2 Diagnostic information via light emitting diodes 11.2.1 Transmitter Proline 500 – digital Different LEDs in the transmitter provide information on the device status. A0029689 Supply voltage Device status Not used Communication Service interface (CDI) active 1.
Page 142: Sensor Connection Housing
Diagnostics and troubleshooting Proline t-mass F 500 HART Color Meaning Communication Communication not active. White Communication active. Service interface (CDI) Not connected or no connection established. Yellow Connected and connection established. Flashing yellow Service interface active. 11.2.2 Sensor connection housing Proline 500 –...
Page 143: Diagnostic Information On Local Display
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.3 Diagnostic information on local display 11.3.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. Operational display in alarm condition...
Page 144 Diagnostics and troubleshooting Proline t-mass F 500 HART Diagnostic behavior Symbol Meaning Alarm • Measurement is interrupted. • Signal outputs and totalizers assume the defined alarm condition. • A diagnostic message is generated. Warning • Measurement is resumed. • The signal outputs and totalizers are not affected.
Page 145: Calling Up Remedial Measures
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.3.2 Calling up remedial measures X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2...
Page 146: Diagnostic Information In The Web Browser
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.4 Diagnostic information in the web browser 11.4.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on.
Page 147: Calling Up Remedy Information
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.4.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly. These measures are displayed in red along with the diagnostic event and the related diagnostic information.
Page 148: Diagnostic Options
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.5 Diagnostic information in FieldCare or DeviceCare 11.5.1 Diagnostic options Any faults detected by the measuring device are displayed on the home page of the operating tool once the connection has been established.
Page 149: Calling Up Remedy Information
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.5.2 Calling up remedy information Remedy information is provided for every diagnostic event to ensure that problems can be rectified quickly: • On the home page Remedy information is displayed in a separate field below the diagnostics information.
Page 150: Adapting The Diagnostic Information
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.6 Adapting the diagnostic information 11.6.1 Adapting the diagnostic behavior Each item of diagnostic information is assigned a specific diagnostic behavior at the factory. The user can change this assignment for specific diagnostic information in the Diagnostic behavior submenu.
Page 151 Proline t-mass F 500 HART Diagnostics and troubleshooting Symbol Meaning Maintenance required Maintenance is required. The measured value remains valid. A0013957 Has no effect on the condensed status. A0023076 Endress+Hauser...
Page 152: Overview Of Diagnostic Information
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.7 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. In the case of some items of diagnostic information, the status signal and the diagnostic behavior can be changed.
Page 153 Proline t-mass F 500 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] I/O 1 to n configuration 1. Apply I/O module configuration Warning changed (parameter ' A pply I/O configuration' ) 2.
Page 154 Diagnostics and troubleshooting Proline t-mass F 500 HART Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Current input 1 to n 1. Check process Warning 2. Check current input settings Flow override...
Page 155 Proline t-mass F 500 HART Diagnostics and troubleshooting Diagnostic Short text Remedy instructions Status Diagnostic number signal behavior [from the [from the factory] factory] Mass flow out of 1. Check process cond. Warning calibrated range 2. Increase system pressure Reverse flow detected...
Page 156: Pending Diagnostic Events
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.8 Pending diagnostic events The Diagnostics menu allows the user to view the current diagnostic event and the previous diagnostic event separately. To call up the measures to rectify a diagnostic event: •...
Page 157 Proline t-mass F 500 HART Diagnostics and troubleshooting / ../Diagnose list Diagnostics F273 Main electronic Diagnostics 2 Diagnostics 3 A0014006-EN  41 Taking the example of the local display To call up the measures to rectify a diagnostic event: • Via local display →  145 •...
Page 158: 11.10 Event Logbook
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.10 Event logbook 11.10.1 Reading out the event logbook A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics menu → Event logbook submenu → Event list / ../Eventlist...
Page 159: 11.10.3 Overview Of Information Events
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.10.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. Info number Info name I1000 --------(Device ok)
Page 160 Diagnostics and troubleshooting Proline t-mass F 500 HART Info number Info name I1626 Write protection deactivated I1627 Web server: login successful I1628 Display: login successful I1629 CDI: login successful I1631 Web server access changed I1632 Display: login failed I1633 CDI: login failed...
Page 161: 11.11 Resetting The Measuring Device
Proline t-mass F 500 HART Diagnostics and troubleshooting 11.11 Resetting the measuring device The entire device configuration or some of the configuration can be reset to a defined state with the Device reset parameter (→  114). 11.11.1 Function range of "Device reset" parameter...
Page 162: 11.12 Device Information
Diagnostics and troubleshooting Proline t-mass F 500 HART 11.12 Device information The Device information submenu contains all parameters that display different information for device identification. Navigation "Diagnostics" menu → Device information ‣ Device information Device tag →  162 Serial number →...
Page 163 Proline t-mass F 500 HART Diagnostics and troubleshooting Parameter Description User interface Factory setting Manufacturer Displays the manufacturer. Character string comprising – numbers, letters and special characters Order code Shows the device order code. Character string composed of – letters, numbers and certain punctuation marks (e.g.
Page 164: 11.13 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser web site: www.endress.com → Downloads • Specify the following details: •...
Page 165: Maintenance
Proline t-mass F 500 HART Maintenance Maintenance 12.1 Maintenance tasks No special maintenance work is required. 12.1.1 Exterior cleaning When cleaning the exterior of measuring devices, always use cleaning agents that do not attack the surface of the housing or the seals.
Page 166: Recalibration
12.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services.
Page 167: Repair
• The measuring devices have a modular design. • Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by appropriately trained customers. • Certified devices can only be converted to other certified devices by Endress+Hauser Service or at the factory.
Page 168: Disposal
Repair Proline t-mass F 500 HART 13.5 Disposal If required by the Directive 2012/19/EU on waste electrical and electronic equipment (WEEE), the product is marked with the depicted symbol in order to minimize the disposal of WEEE as unsorted municipal waste. Do not dispose of products bearing this marking as unsorted municipal waste.
Page 169: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 170: Communication-Specific Accessories
Accessories Proline t-mass F 500 HART Display guard Is used to protect the display against impact or scoring, for example from sand in Proline 500 – digital desert areas.  Order number: 71228792  Installation Instructions EA01093D Connecting cable The connecting cable can be ordered directly with the measuring device (order code Proline 500 –...
Page 171: Service-Specific Accessories
Accessories Description Applicator Software for selecting and sizing Endress+Hauser measuring devices: • Choice of measuring devices for industrial requirements • Calculation of all the necessary data for identifying the optimum flowmeter: e.g. nominal diameter, pressure loss, flow velocity and accuracy.
Page 172: Technical Data
Technical data Proline t-mass F 500 HART Technical data 15.1 Application The measuring device is intended only for the flow measurement of gases. To ensure that the device remains in proper operating condition for its service life, use the measuring device only for media against which the process-wetted materials are sufficiently resistant.
Page 173: Input
Proline t-mass F 500 HART Technical data 15.3 Input Measured variable Measured process variables • Mass flow • Temperature Calculated process variables • Corrected volume flow • Volume flow • FAD volume flow • Flow velocity • Calorific value • 2nd temperature heat difference •...
Page 174 Technical data Proline t-mass F 500 HART Calibration range [kg/h] Calibration range [Nm3/h] [mm] (Air, 20°C, 1.013 bar a) (Air, 0°C, 1.013 bar a) Minimum Maximum Minimum Maximum 1 450 11.6 1 122 2 030 15.5 1 570 3 750 2 900 Measuring range with order code for "Sensor option", option CS "1 flow conditioner"...
Page 175 Proline t-mass F 500 HART Technical data Measuring range without flow conditioners • Order code for "Sensor version; sensor; measuring tube", option SA "Unidirectional; stainless steel; stainless steel" • Order code for "Sensor version; sensor; measuring tube", option HA "Unidirectional; Alloy;...
Page 176 Technical data Proline t-mass F 500 HART Measuring range with order code for "Sensor option", option CT "2 flow conditioners" Calibration range [lb/h] Calibration range [SCFM] [in] (Air, 68°F, 14.7 psi a) (Air, 59°F, 14.7 psi a) Minimum Maximum Minimum Maximum 1 ½...
Page 177 Proline t-mass F 500 HART Technical data Current input The measured values are written from the automation system to the measuring device via the current input →  177. Current input 0/4 to 20 mA Current input 0/4 to 20 mA (active/passive) Current span •...
Page 178: Output
Technical data Proline t-mass F 500 HART 15.4 Output Output signal Current output 4 to 20 mA HART Order code "Output; input 1" (20): Option BA: current output 4 to 20 mA HART Signal mode Can be set to: • Active •...
Page 179 Proline t-mass F 500 HART Technical data Damping Configurable: 0 to 999.9 s Assignable measured • Mass flow variables • Volume flow • Corrected volume flow • FAD volume flow • Flow velocity • Temperature • Energy flow • Pressure •...
Page 180 Technical data Proline t-mass F 500 HART Open-circuit voltage DC 28.8 V (active) Voltage drop For 22.5 mA: ≤ DC 2 V Pulse output Maximum input values DC 30 V, 250 mA (passive) Maximum output current 22.5 mA (active) Open-circuit voltage DC 28.8 V (active)
Page 181 Proline t-mass F 500 HART Technical data Number of switching Unlimited cycles Assignable functions • Off • On • Diagnostic behavior • Limit value • Off • Mass flow • Volume flow • Corrected volume flow • FAD volume flow •...
Page 182 Technical data Proline t-mass F 500 HART Signal on alarm Depending on the interface, failure information is displayed as follows: Current output 0/4 to 20 mA 4 to 20 mA Failure mode Choose from: • 4 to 20 mA in accordance with NAMUR recommendation NE 43 •...
Page 183: Power Supply
Proline t-mass F 500 HART Technical data Interface/protocol • Via digital communication: HART protocol • Via service interface • CDI-RJ45 service interface • WLAN interface Plain text display With information on cause and remedial measures Web browser Plain text display...
Page 184 Technical data Proline t-mass F 500 HART Order code Terminal voltage Frequency range "Power supply" DC 24 V ±20% – Option I AC 100 to 240 V –15…+10% 50/60 Hz, ±4 Hz Power consumption Transmitter Max. 10 W (active power) switch-on current Max.
Page 185: Performance Characteristics
Proline t-mass F 500 HART Technical data 15.6 Performance characteristics Reference operating • Error limits based on ISO 11631 conditions • Dry air with +20 to +30 °C (+68 to +86 °F) at 0.8 to 1.5 bar (12 to 22 psi) •...
Page 186: Mounting
Technical data Proline t-mass F 500 HART The accuracy is specified in relation to the mass flow. ±1.0% ±(current measured value in % -100%) × 0.07 for 100% to 200% of the calibrated measuring range (under reference operating conditions) Accuracy of outputs The outputs have the following base accuracy specifications.
Page 187 ‣ If operating outdoors: Avoid direct sunlight, particularly in warm climatic regions. You can order a weather protection cover from Endress+Hauser→  169. Storage temperature –50 to +80 °C (–58 to +176 °F), preferably at +20 °C (+68 °F) Atmosphere If a plastic transmitter housing is permanently exposed to certain steam and air mixtures, this can damage the housing.
Page 188 Technical data Proline t-mass F 500 HART Transmitter • 10 to 200 Hz, 0.01 g • 200 to 2 000 Hz, 0.003 g • Total: 2.70 g rms Shock half-sine, according to IEC 60068-2-27 • Sensor 6 ms 30 g •...
Page 189: Process
Proline t-mass F 500 HART Technical data 15.9 Process Medium temperature range Sensor –40 to +180 °C (–40 to +356 °F) Medium pressure range Minimum 0.5 bar absolute. Maximum permitted medium pressure →  189 Pressure/temperature The following pressure/temperature diagrams apply to all pressure-bearing parts of the ratings device and not just the process connection.
Page 190: 15.10 Mechanical Construction
Technical data Proline t-mass F 500 HART Flange connection as per ASME B16.5 [psi] [bar] Class 300 Class 150 [°C] [°F] A0041064-EN  45 With flange material 1.4404/F316L/F316 Flow limit Measuring range →  173 The maximum flow depends on the gas type and the pipe nominal diameter used. The end of the measuring range is reached when the Mach number listed below is reached.
Page 191 Proline t-mass F 500 HART Technical data Weight in SI units DN [mm] Weight [kg] 13.1 16.8 25.6 Weight in US units DN [in] Weight [lbs] ½ 1½ 2½ Materials Transmitter housing Housing of Proline 500 – digital transmitter Order code for "Transmitter housing": •...
Page 192 Technical data Proline t-mass F 500 HART Cable entries/cable glands A0020640  46 Possible cable entries/cable glands Female thread M20 × 1.5 Cable gland M20 × 1.5 Adapter for cable entry with female thread G ½" or NPT ½" Cable entries and adapters Material Cable gland M20 ×...
Page 193: 15.11 Display And User Interface
Proline t-mass F 500 HART Technical data Accessories Protective cover Stainless steel, 1.4404 (316L) External WLAN antenna • Antenna: ASA plastic (acrylonitrile styrene acrylate) and nickel-plated brass • Adapter: Stainless steel and nickel-plated brass • Cable: Polyethylene • Plug: Nickel-plated brass •...
Page 194 Technical data Proline t-mass F 500 HART Service interface →  68 Supported operating tools Different operating tools can be used for local or remote access to the measuring device. Depending on the operating tool used, access is possible with different operating units and via a variety of interfaces.
Page 195 Proline t-mass F 500 HART Technical data Supported functions Data exchange between the operating unit (such as a notebook, for example,) and measuring device: • Upload the configuration from the measuring device (XML format, configuration backup) • Save the configuration to the measuring device (XML format, restore configuration) •...
Page 196 Technical data Proline t-mass F 500 HART Manual Additional parameter data record (complete parameter settings) in the integrated device memory HistoROM backup for: • Data backup function Backup and subsequent restoration of a device configuration in the device memory HistoROM backup •...
Page 197: 15.12 Certificates And Approvals
The device meets the legal requirements of the applicable EU Directives. These are listed in the corresponding EU Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. UKCA marking The device meets the legal requirements of the applicable UK regulations (Statutory Instruments).
Page 198 Technical data Proline t-mass F 500 HART Non-Ex / Ex ec Transmitter Sensor Category Type of protection Category Type of protection Non - Ex Non-Ex II3G Ex ec IIC T4…T1 Gc II3G Ex ec nC IIC T5…T1 Gc II3G Ex ec IIC T4…T1 Gc...
Page 199 Directive a) PED/G1/x (x = category) or b) PESR/G1/x (x = category) on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" a) specified in Annex I of the Pressure Equipment Directive 2014/68/EU or b) Schedule 2 of Statutory Instruments 2016 No. 1105.
Page 200 Technical data Proline t-mass F 500 HART Classification of process Endress+Hauser devices are designed in accordance with ANSI/ISA 12.27.01. allowing the sealing between electrical user to waive the use and save the cost of installing external secondary process seals in the systems and (flammable or conduit as required by the process sealing sections of ANSI/NFPA 70 (NEC) and CSA 22.1...
Page 201: 15.13 Application Packages
The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.
Page 202: 15.14 Accessories
For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Standard documentation Brief Operating Instructions...
Page 203 Proline t-mass F 500 HART Technical data Remote display and operating module DKX001 Contents Documentation code ATEX/IECEx Ex i XA01494D ATEX/IECEx Ex ec XA01498D cCSAus IS XA01499D cCSAus Ex nA XA01513D INMETRO Ex i XA01500D INMETRO Ex ec XA01501D NEPSI Ex i...
Page 204: Index
Index Proline t-mass F 500 HART Index Current consumption ......184 Access authorization to parameters Read access ......59 Date of manufacture .
Page 205 Proline t-mass F 500 HART Index Firmware history ......164 Flow conditioner ......23 Editing view .
Page 206 Index Proline t-mass F 500 HART Maintenance tasks ......165 Order code ......16, 17 Recalibration .
Page 207 Proline t-mass F 500 HART Index Pressure Equipment Directive ....199 Totalizer reset ......134 Process connections .
Page 208 Index Proline t-mass F 500 HART For diagnostic behavior ....49 Weight For locking ......49 SI units .
Page 210 *71620287* 71620287 www.addresses.endress.com...

Endress+Hauser Proline t-mass F 500 Operating Instructions Manual

Quick Links

Related Manuals for Endress+Hauser Proline t-mass F 500

Summary of Contents for Endress+Hauser Proline t-mass F 500

Table of Contents
