OPERATION AND ADJUSTMENT
THE PERFORMANT LUBE
TM
WALKING BELT
Your treadmill features a walking belt coated with PERFORMANT LUBE
TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such
substances will deteriorate the walking belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
This product must be earthed. If it should malfunction or break
down, earthing provides a path of least resistance for electric
current to reduce the risk of electric shock. This product is
equipped with a cord having an equipment-earthing conductor
and an earthing plug.
Two power cords are included. Select the one that will fit your
outlet. Refer to drawing 1. Plug the indicated end of the power
cord into the socket on the treadmill. Refer to drawing 2. Plug
the power cord into an appropriate outlet that is properly in-
stalled and earthed in accordance with all local codes and or-
dinances. Note: In Italy, an adapter (not included) must be
used between the power cord and the outlet. Important: The
treadmill is not compatible with GFCI-equipped outlets.
Use only a power cord type H05VV-F with a conductor of at least
1mm
, with a country recognised plug and an appliance coupler.
2
DANGER:
Improper connection of the
equipment-earthing conductor can result in an in-
creased risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to
whether the product is properly earthed. Do not mod-
ify the plug provided with the productÑif it will not fit
the outlet, have a proper outlet installed by a qualified
electrician.
8
TM
, a high-performance lubricant. IMPOR-
1
Socket on treadmill
Outlet
2
Follow your progress with the LED track and
8
the four displays.
See step 5 on page 10.
Measure your pulse, if desired.
9
See step 6 on page 11.
When the program is finished, remove the
10
key.
Step onto the foot rails and remove the key from
the console. Keep the key in a secure place. Note:
If the displays and various indicators on the
console remain lit after the key is removed, the
console is in the ÒdemoÓ mode. Refer to the in-
structions below and turn off the demo mode.
When you are finished using the treadmill, move
the on/off switch near the power cord to the off
position.
THE INFORMATION MODE/DEMO MODE
The console features an information mode that keeps
track of the total number of hours that the treadmill has
been operated and the total number of miles that the
walking belt has moved. The information mode also
allows you to switch the console from miles per hour to
kilometres per hour. In addition, the information mode
allows you to turn on and turn off the demo mode.
To select the information mode, hold down the stop
button while inserting the key into the console. When
the information mode is selected, the following informa-
tion will be shown:
The distance/laps display will
show the total number of miles
that the walking belt has moved.
The time/incline display will
show the total number of hours
the treadmill has been used.
An ÒE,Ó for english miles, or an
ÒM,Ó for metric kilometres, will
appear in the speed/min-mile
display. Press the speed
button to change the unit of
measurement.
IMPORTANT: The
calories/fat calories/pulse
display should be blank. If
a ÒdÓ appears in the display,
the console is in the ÒdemoÓ
mode. This mode is intended
to be used only when a tread-
mill is displayed in a store.
When the console is in the
demo mode, the power cord
can be plugged in, the key
can be removed from the
console, and the displays and
indicators on the console will
automatically light in a preset sequence, although the
buttons on the console will not operate. If a ÒdÓ ap-
pears in the calories/fat calories/pulse display
when the information mode is selected, press the
speed
button so the calories/fat calories/pulse
display is blank.
To exit the information mode, remove the key from the
console.
OPTIONAL HAND WEIGHTS
Optional hand weights
let you include upper-
body exercise in your
workouts. The hand
weights fit into conve-
nience holders in the
console. To purchase
the hand weights,
contact our Customer
Service Department.
at 0345-089009.
OPTIONAL CHEST PULSE SENSOR
An optional chest pulse sensor adds even more
features to the console. The chest pulse sensor offers
hands-free operation and continuously monitors your
heart rate during your workouts. To purchase the
optional chest pulse sensor contact our Customer
Service Department at 0345-089009.
17
