Getting Started

Unpacking the DVD Receiver

You should receive the following items:
BAND/APP SOURCE
RANDOM
mp3
SURROUND
POWER
P
One DVD receiver unit
One Pig-Tail
antenna wire

Unpacking The Speakers

• one set of speakers including 1 set of left and right front
speakers, 1 centre speaker, 1 subwoofer and 1 set of left
and right rear speakers.
FRONT SPEAKERS
SUBWOOFER
2
10:09 AM Page 6
D I G I T A L A / V R E C E I V E R
VOLUME
P R O G R E S S I V E S C A N
PHONES
One external AM loop
antenna
• one instruction book;
• one safety leaflet;
• one Quick Connection Guide
CENTER SPEAKER
REAR SPEAKERS
(SURROUND SOUND)
+ -
+ -
One pair of "AA"
batteries
one video cable (single wire)
with yellow connectors;
1 X green/black wire
for center speaker
1 X white/black wire for
front left speaker
1 X blue/black wire for
rear left speaker
VCR ON OFF TV
DVD•CD TAPE AM•FM SAT•CABLE
MUTE SURROUND
GO BACK
LEVEL
GUIDE INFO
OK
MENU CLEAR
1 2 3
4 5 6
7 8 9
WHO•INPUT ANT•FMS
0
REVERSE PLAY FORWARD
RECORD
STOP PAUSE
SUBTITLE AUDIO ANGLE ZOOM
u n i v e r s a l
One RCA Universal
Remote Control
(CRK76AJ1)
1 X red/black wire for
front right speaker
1 X purple/black wire
for subwoofer
1 X gray/black wire for
rear right speaker
