6 Pin Door Lock Output Harness

1 BROWN/BLACK
2 BLUE/BLACK
3 VIOLET/BLACK
4 WHITE/BLACK
5 GREEN/BLACK
6 VIOLET
The door lock / unlock outputs are designed to control several different types of
systems which may require additional parts.
3 Wire Ground Switched Door Locks:
Connect the GREEN/BLACK wire to the wire that provides a ground signal from
the factory door lock switch to the factory door lock control relay.
Connect the BLUE/BLACK wire to the wire that provides a ground signal from the
factory door unlock switch to the factory door lock control relay.
Connect the VIOLET and the VIOLET/BLACK wires to a solid chassis ground
point. The WHITE/BLACK and BROWN/BLACK wires are not required for this type
of door lock/unlock system.
3 Wire Positive Switched Door Locks:
Connect the GREEN/BLACK wire to the wire that provides a +12 volt signal from
the factory door lock switch to the factory door lock control relay.
Connect the BLUE/BLACK wire to the wire that provides a +12 volt signal from
the factory door unlock switch to the factory door lock control relay.
Connect the VIOLET and the VIOLET/BLACK wires to a +12 volt battery source.
The WHITE/BLACK and BROWN/BLACK wires are not required for this type of
door lock/unlock system.
