Pin Door Lock Harness - Code Alarm ca5153 Installation Manual

3 LT BLUE
This wire will supply a ( - ) 500mA pulse both upon arming the system and upon
successful completion of the remote start activation sequence and is typically
used to re-lock the vehicle's doors upon remote start if necessary.
This output is configurable in option programming.
4 LT GREEN/BLACK
This wire will supply a ( - ) 500mA pulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm
wire from the key cylinder inside the drivers door.
Verification: This wire registers ground if the key is turned to the unlock
position in the driver's door cylinder.
This output is configurable in option programming.

2 Pin Door Lock Harness

1 BLUE
2 GREEN
The door lock / unlock outputs are designed to control several different types of
systems which may require additional parts. Please review the wire and location
chart to see which type of door lock system is in your vehicle. The most common
types are shown in the following diagrams.
2012 Audiovox Electronics Corporation. All rights reserved.
FACTORY ARM /
PULSE AFTER START ( - )
FACTORY DISARM /
PULSE BEFORE START ( - )
UNLOCK ( - )
LOCK ( - )
11
