PROFESSIONAL
SERIES
Owner's Guide
For Model:
CA2RELCD5
AS9234E
RF Upgrade Kit
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
CA2RELCD5 / AS9234E 4280857 Owners rev A.
1

Advertisement

loading

Related Manuals for Code Alarm CA2RELCD5

Summary of Contents for Code Alarm CA2RELCD5

  • Page 1 IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information. CA2RELCD5 / AS9234E 4280857 Owners rev A.

  • Page 2: Table Of Contents

    Table of Contents Using Your Remote Control ............3 Additional 2 Way LCD Transmitter Functions ......9 2 Way LCD Transmitter Icon’s ..........11 Transmitter Programming ............12 Replacing Remote Control Batteries ........13 2017 Voxx Electronics Corporation. All rights reserved.

  • Page 3: Using Your Remote Control

    The vehicle will now be under control of the remote start system. Turn your ignition switch off, WITHOUT, stepping on the brake, and exit the vehicle. Lock the doors with the key to insure security. CA2RELCD5 / AS9234E 4280857 Owners rev A.
  • Page 4 Remote Start Shutdown: To cancel the remote vehicle start function, press and release the button 2 times within 2 seconds. Timed Start Program: The Remote Start unit has the ability to start the vehicle automatically at timed intervals. This feature is useful in extremely cold climates where starting the engine is the only means to keep the battery charged and fluids warm.
  • Page 5 To return to normal operation, press and release the Push-Button switch any time the ignition is on. NOTE: Always remember to return the vehicle to the valet off position. This will ensure that the vehicle remains protected at all times. CA2RELCD5 / AS9234E 4280857 Owners rev A.
  • Page 6 Manually Overriding Your Alarm System (Alarm Systems Only): Using the Dash Mounted PBLED Push-Button Valet/Override Switch your Security System can be disarmed without the use of the keychain transmitter. This is necessary, since you will need the ability to operate your vehicle if the transmitter is lost or its battery fails.
  • Page 7 NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5 seconds during any of the above steps, the unit will revert back to the last successfully stored code. CA2RELCD5 / AS9234E 4280857 Owners rev A.
  • Page 8 Manually Overriding Your system - Using the Custom Code: Assuming the override code programmed has not been changed, and the default override code of 11 is in the system’s memory. Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.

  • Page 9: Additional 2 Way Lcd Transmitter Functions

    NOTE: A second security system must be installed and the LCD transmitter must be learned to it before this feature will operate the additional system. CA2RELCD5 / AS9234E 4280857 Owners rev A.
  • Page 10 Parking Meter Countdown The parking meter countdown timer has 6 preset times, to access the preset times and begin countdown press and release then press and hold for 2 seconds, each additional press of will increase the countdown time. Adjusting the Clock and Timer Settings The clock, alarm clock and programmable countdown timer are accessed through the Function Menu.

  • Page 11: Way Lcd Transmitter Icon's

    VIBRATE/SILENT MODE TIME DISPLAY 2 CAR MODE ALARM CLOCK ENGINE RUNNING TIMER / TEMP. AUX MODE START MODES AUX 2 OUTPUT AUX 1 OUTPUT AUX 3 OUTPUT AUX 4 OUTPUT AUX 5 OUTPUT CA2RELCD5 / AS9234E 4280857 Owners rev A.

  • Page 12: Transmitter Programming

    Transmitter Programming Turn the ignition ON. Press and hold the valet/override button located on the antenna. Within 10 seconds the LED’s will begin to flash. Press 1 button of each transmitter you wish to program, the LED’s will flash to confirm each transmitter. Turn the ignition OFF NOTE: This system has 1 button programming which programs all channels of the system.

  • Page 13: Replacing Remote Control Batteries

    LCD screen shows 3 bars indicating charging is complete. It is recommended that the battery be fully charged before normal use. CA2RELCD5 / AS9234E 4280857 Owners rev A.
  • Page 14 Voxx Electronics Corporation. Customer Service 1-800-421-3209 WWW.CODE-ALARM.COM FCC COMPLIANCE This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.
