Section 2 - Specifications; Duty Cycle And Overheating - Hobart Handler 130 XL Owner's Manual

2-1. Specifications
Rated Welding Amperage
Output Range
90 A @ 19 Volts DC,
30 – 130
20% Duty Cycle
Solid/
Stainless
Wire Type Wire Type
And Dia
.023 – .030 in
(0.6 – 0.8 mm)
* While idling

2-2. Duty Cycle And Overheating

Overheating
SECTION 2 – SPECIFICATIONS
Maximum Open-
Circuit Voltage
DC
28
Flux Cored/
Aluminum
.030 – .035 in
(0.8 – 0.9 mm)
20% Duty Cycle At 90 Amperes
2 Minutes Welding
0
Minutes
Amperes Input at
Rated Load Output
KVA
115 V, 60 Hz, Single-
Phase
2.3
20 (0.59)*
0.57*
Wire Feed Speed Range At No Load
130 – 790 IPM (3.3 – 20 m/min)
8 Minutes Resting
15
Reduce Duty Cycle
Weight Overall
KW
W/ Gun Dimensions
Length: 19-1/8 in
(480 mm)
69 lb
Width: 10-1/2 in
2.4
(31 kg)
(264 mm)
Height: 14-1/2 in
(365 mm)
Duty Cycle is percentage of 10 min-
utes that unit can weld at rated load
without overheating.
If unit overheats, thermostat(s)
opens, output stops, and cooling
fan runs. Wait fifteen minutes for
unit to cool. Reduce amperage or
duty cycle before welding.
Y Exceeding duty cycle can
damage unit or gun and void
warranty.
A or V
OR
duty1 4/95 – SB-124 655-B
OM-210 082 Page 9
