J-200 ™ COLLECTION
OWNER'S MANUAL
2530-277K Rev A

Advertisement

Table of Contents
loading

Related Manuals for Jacuzzi J-200

Summary of Contents for Jacuzzi J-200

  • Page 1 • J-285 ™ • J-275 ™ • J-245 ™ • J-235 ™ • J-225 ™ • J-215 ™ J-200 ™ COLLECTION OWNER’S MANUAL 2530-277K Rev A...
  • Page 2 Attention New Spa Owner! Congratulations on the purchase of your new Jacuzzi ® spa! The following is a list of automated functions performed by your spa. These functions are listed below in an attempt to alleviate any operational concerns you may have during...

  • Page 3: Table Of Contents

    Adjusting and Setting the Time ............ 34 11.4 Invert the display................34 11.5 Locking the Spa ................34 11.6 Hold (Standby) ................35 11.7 Programming the Filtration Cycles..........36 11.8 Preferences ................. 38 11.9 Utilities ..................39 © Jacuzzi Hot Tubs, Inc. All Rights Reserved...
  • Page 4 12.0 Spa Maintenance ............... 40 12.1 Cleaning The Filters..............40 12.2 Draining and Refilling..............42 12.3 Pillow Care................... 43 12.4 Cleaning The Spa Interior ............43 12.5 Cover Care and Maintenance ............43 12.6 Maintaining The Synthetic Cabinet ..........44 12.7 Winterizing ................... 44 12.8 Restarting Your Spa in Cold Weather ..........

  • Page 5: Important Spa Owner Information

    J-200 Important Spa Owner Information Your Jacuzzi J-200 Collection spa is constructed to the highest standards and is capable of providing many years of trouble-free use. However, because heat retentive materials are utilized to insulate the spa for efficient operation, an uncovered spa surface and wall fittings directly exposed to sunlight and high temperatures for an extended period are subject to permanent damage.

  • Page 6: Important Safety Instructions For All Spa Owners

    J-200 Important Safety Instructions for all Spa Owners READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY! This spa was manufactured to meet the standards and specifications outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB Safety Act). When installing and using this spa, basic safety precautions...
  • Page 7 J-200 • A grounding wire connector is provided on this unit to connect a minimum No. 8 AWG (8.4 mm²) solid copper conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of the unit.
  • Page 8 J-200 WARNING: RISK OF SEVERE INJURY OR DEATH! • Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, if pregnant or possibly pregnant, consult your physician before using a spa. •...
  • Page 9 J-200 WARNING: In addition to maintenance of filters and water chemistry, proper ventilation is recommended to reduce the risk of contracting a waterborne illness (e.g., an infection, bacteria or virus) and/or respiratory ailments that could be present in the air or water.
  • Page 10 J-200 FOR CALIFORNIA RESIDENTS ONLY NUR FÜR EINWOHNER KALIFORNIENS POUR LES RÉSIDENTS DE LA CALIFORNIE SEULEMENT PARA RESIDENTES DE CALIFORNIA ÚNICAMENTE WARNING: Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer.

  • Page 11: Entrapment Risk

    J-200 Entrapment Risk The Consumer Products Safety Commission/USA has reported that users of pools and spas have become entrapped (stuck) to drain and/or suction fittings causing death, drowning, or serious injury (see diagram below). This spa was manufactured to meet the standards and specifica- tions outlined in the “Virginia Graeme Baker Pool and Spa Safety Act”...

  • Page 12: Hyperthermia

    A Warning Sign is provided in your warranty packet. Please install at a location near your spa, where it is visible to users of the spa. For additional or replacement Warning Signs please contact your local Jacuzzi dealer and reference item number #6530-082.

  • Page 13: Important Safety Instructions

    J-200 Important Safety Instructions When using this electrical equipment, basic safety precautions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS. 2. A green colored terminal or a terminal marked G, Gr, Ground, Grounding or the symbol* is located inside the supply terminal box or compartment.

  • Page 14: Choosing A Location

    Visit www.Jacuzzi.com for weight information. If the spa is placed on a surface which does not meet these requirements, damage to the skirt and/or the spa shell may result.

  • Page 15: Outdoor Location

    J-200 Outdoor Location In selecting the ideal outdoor location for your spa, we suggest that you take into consideration: • The proximity to changing area and shelter (especially in colder weather). • The pathway to and from your spa (this should be free of debris so that dirt and leaves are not easily tracked into the spa).
  • Page 16 J-200 • Proper Drainage: It is extremely important to have in place measures to sufficiently handle excessive water spillage. Be sure the flooring in which the spa rests on has adequate drainage and can handle the entire contents of the spa. Be sure to make provisions for ceilings and other structures that may be below the spa’s installation.

  • Page 17: General Electrical Safety Instructions

    Proper grounding is extremely important. Jacuzzi spas are equipped with a current collector system. A pressure wire connector is provided on the surface of the control box, located outside the equipment door (page 17) to permit connection of a bonding wire between this point and any ground metal equipment, metal water pipe or conduit within 5 feet (1.5m)

  • Page 18: Power Requirements

    J-200 Power Requirements Jacuzzi spas are designed to provide optimum performance and flexibility of use when connected to the maximum electrical service listed below. Minor circuit board modifications can be performed to allow your new spa to accept an electrical service other than the factory operation setting. The electrical wiring of this spa must meet the requirements of the National Electrical Code/USA (NEC) and/or any applicable state or local codes.

  • Page 19: Electrical Wiring Instructions

    J-200 Electrical Wiring Instructions IMPORTANT NOTICE: The electrical wiring of this spa must meet the requirements of the National Electrical Code/USA (NEC) and/or any applicable state or local codes. The electrical circuit must be installed by a qualified electrician and approved by a local building/electrical inspection authority.
  • Page 20 J-200 8. To gain access to the spa’s power terminal block (Figure 1): • Remove the corner panels. Grab the top of the panel and pull forward to unsnap it from the clips. Then lift the panel up to remove.
  • Page 21 J-200 Figure A Equipment Area Note: Equipment location (such as pumps, CLEARRAY unit, drain, heater etc.) varies by model. Control Box CLEARRAY® Unit Power Supply Inlet(s) CLEARRAY Ballast 2-Speed Pump Control Panel Heater 10. Drain Pump Drain Plug(s) 11. Optional SmartTub® System...
  • Page 22 J-200 Figure D (North American 60 Hz 120/240 VAC Convertible Models) A. 120V 3-Wire Connection (convertible models) F3 FUSE MUST BE 240V J24 JUMPERS MUST BE IN A 0.16A SLO-BLOW FUSE 120V POSITIONS AS SHOWN 120V 120V DEFAULT SETTING DEFAULT SETTING...
  • Page 23 J-200 B. 240V 4-Wire Connection (convertible models) 1. TB1 MUST BE WIRED WHT-1, BLK-2, RED-3 2. REMOVE JUMPER WIRE BETWEEN J4 AND J20. FAILURE TO DO SO WILL RESULT IN DAMAGE TO THE PWA. 3. MOVE J46 WIRE FROM AREA 3 TO AREA 1 4.

  • Page 24: Spa Fill Up Procedure

    Clear all debris from the spa. Although the spa shell has been polished at the factory, you may want to treat it with a specially formulated spa cleaner. Consult your authorized Jacuzzi dealer for additional information prior to filling spa.
  • Page 25 Turn on jets pump(s) to ensure proper mixing when adding start-up chemicals in step 5. 5. Add Start-Up Chemicals Add the spa water chemicals as recommended by your authorized Jacuzzi dealer. See Section 13.0 “Water Quality Maintenance” (page 45) for general guidance. WARNING: RISK OF POISONING OR DEATH.
  • Page 26 J-200 8. Place Cover On Spa • Keeping the insulating cover in place anytime the spa is not in use will reduce the time required for heating, thereby minimizing operating costs. • The time required for initial heat-up will vary depending on the starting water temperature.
  • Page 27 Water that is too soft can be corrosive to metal components. 13. Consult your authorized Jacuzzi dealer for chemical recommendations, then add chemicals to hot tub water to achieve a constant sanitizer reading within the levels recommended on the inside cover of this manual.
  • Page 28 J-200 WARNING: RISK OF PERSONAL INJURY. • To decrease the risk of injury, entrapment or drowning, never leave your hot tub unattended for any reason, especially if while the cover is open and accessible to small children and animals! •...

  • Page 29: Control Functions

    J-200 Control Functions Control Panel Buttons A. LCD Display: Can display current wa- ter temperature (default display), water 2-pump control panel shown temperature set point, selected menu functions, and error messages. B. Warmer Button ( ): Increases water temperature set point.
  • Page 30 J-200 (Jets 2 icon): Displays when Jets pump 2 is on. The pump activates for 20-minute then turns off. (Temperture High Range icon): Indicates that the spa is set to high range temperature between 80°F (26.5°C) and 104°F (40°C). (Temperture Low Range icon): Indicates that the spa is set to low range temperature between 65°F (18.5°C) and 99°F (37°C).

  • Page 31: General Spa Features And Controls

    J-200 General Spa Features and Controls J-285 model illustrated - Jet locations and features vary by model. 1. Control Panel 8. Filter lid with one underlying filter 2. Headrest Pillows (4) cartridge (Filter requires periodic 3. Air Controls (2) cleaning) 4.

  • Page 32: Operating Instructions

    J-200 10.0 Operating Instructions The spa control system has automatic functions that operate upon start up and normal operation to protect the system. Upon the first power up, the readout displays a sequence of information about the configuration of the hot tub. Then the Priming Mode will begin, page 20.

  • Page 33: Activate Jets Pump

    J-200 10.2 Activate Jets Pump The control panel JETS 1 button activates jets pump 1. The first press activates low speed, the second press activates high speed, and the third press shuts jets pump 1 off. The JETS 2 button activates jets pump 2.

  • Page 34: Air Controls

    J-200 10.5 Air Controls Certain jet systems have their own air control. Each control introduces air into the water lines that supply that specific jet group. Simply turn the air control of choice counterclockwise to open or clockwise to close.
  • Page 35 J-200 5. Follow the instructions on the app to begin enjoying the benefits of your internet connected hot tub. Note: The first year of data service is included. You will need to renew the subscription after the first year. Please refer to the terms of service and privacy policy links in the SmartTub®...

  • Page 36: Menu Features And Programming Instructions

    J-200 11.0 Menu Features and Programming Instructions Your hot tub is equipped with menus that allow you to program additional features. By continually pressing the Menu/Select ( ) button you will cycle through the menus as follows: Current temperature (Main Menu)

  • Page 37: Programming The Mode Setting

    J-200 1. Press the button to adjust the set temperature. The temperature numbers will start flashing to show the system is ready for adjustments. Once set to the preferred temperature, press program the change and return to the Main Menu.

  • Page 38: Adjusting And Setting The Time

    J-200 D. Ready-in-Rest Mode When the spa is in a Rest Mode “ ” and the Jets Pump 1 button is pressed, the spa will heat to either the set temperature or for one hour. Both icons will be shown on the display.

  • Page 39: Hold (Standby)

    J-200 • Panel lock: All automatic functions will still run but the control panel buttons will not activate. When the panel is locked, the display will show the current temperature but when any button is pressed “LOCK” will appear. A. Locking the Temperature 1.

  • Page 40: Programming The Filtration Cycles

    J-200 11.7 Programming the Filtration Cycles The filtration cycles and CLEARRAY® unit are important to ensure healthy water conditions. You can program up to 2 filter cycles. Note: Make sure to set the time so the cycles can run as programmed.
  • Page 41 J-200 B. Filter Cycle 2 Filter cycle 2 has a default start time for 8:00 AM for 4 hours. To change the setting follow the steps below. 1. From the Main Menu, press the button until you reach the Filter Cycle 2 Menu.

  • Page 42: Preferences

    J-200 11.8 Preferences This menu allows you select certain display preferences. A. Setting the temperature display 1. From the Main Menu, press the button until you reach “PREF.” 2. Press to enter the menu. The display will show “F/C.” 3. Pressing will toggle between °F or °C.

  • Page 43: Utilities

    J-200 1. From the Main Menu, press the button until you reach “PREF.” 2. Press to enter the menu. Then press the button until you get to the “M8” display. 3. Press to select and toggle between “ON” and “OFF.”...

  • Page 44: Spa Maintenance

    12.0 Spa Maintenance Proper and regular maintenance of your spa will help it retain its beauty and performance. Your authorized Jacuzzi dealer can supply you with all the information, supplies, and accessory products you will need to accomplish this. DANGER: RISK OF SEVERE INJURY OR DROWNING BY ENTRAPMENT! •...
  • Page 45 J-200 To Clean Filter: 1. Turn off power to the spa at the home’s breaker panel or select the “HOLD” option (page 35) to disable all spa functions. 2. Lift upward on filter skimmer grill to remove it from mating retainer clips, Figure A.

  • Page 46: Draining And Refilling

    Jacuzzi dealer. The average life expectancy of each filter is approximately two years with proper care and water quality maintenance.

  • Page 47: Pillow Care

    “skin” is attractive and durable. Regular monthly cleaning is strongly recommended and may increase the longevity of your cover. Jacuzzi chemicals are for use in the U.S. only. Note: It is highly recommended that you DO NOT put the seam over the control panel.

  • Page 48: Maintaining The Synthetic Cabinet

    12.7 Winterizing Your Jacuzzi spa is designed to automatically protect itself against freezing when operating properly. During periods of severe freezing temperatures, you should check periodically to be certain that the electrical supply to the spa has not been interrupted. In extreme, bitter cold weather less than 32°F (0°C), program the filtration cycles to run for...

  • Page 49: Restarting Your Spa In Cold Weather

    8. Re-install synthetic cabinet side panel and cover spa so that no casual moisture can enter into it. Consult your authorized Jacuzzi dealer if you have any questions regarding winter use or winterizing. 12.8...

  • Page 50: Ph Control

    Some are necessary to compensate for out-of-balance water, some aid in cosmetic water treatment and others simply alter the feel or smell of the water. Your authorized Jacuzzi dealer can advise you on the use of these additives. When adding spa shock (chlorine or non-chlorine) or pH balancing chemicals activate the jets pump(s) and leave the spa cover open for a minimum of 20 minutes.

  • Page 51: Clearray® System

    J-200 13.3 CLEARRAY® System Your new hot tub has the CLEARRAY unit installed. WARNING! DO NOT LOOK AT LIT BULB SEVERE EYE DAMAGE OR BLINDNESS CAN OCCUR The CLEARRAY System is an exclusive technology utilizing ultraviolet light to help keep your water clean*. The ballast is the power supply for the CLEARRAY unit;...

  • Page 52: Clearray® Lamp Replacement And Quartz Tube Maintenance

    J-200 13.4 CLEARRAY® Lamp Replacement and Quartz Tube Maintenance Important: It is MANDATORY that the UV bulb is replaced, and the quartz tube be cleaned every 12 months to maintain optimum performance. 9 10 FIGURE 1 DANGER: TURN THE SPA BREAKER TO THE OFF...
  • Page 53 J-200 FIGURE 5 FIGURE 3 FIGURE 4 FIGURE 6 3. Disconnect UV bulb socket (7) from the power cord socket (11), Figure 3. 4. Slowly remove the UV bulb (3) out of the quartz tube, Figure 4. 5. Remove the quartz seal compression nut (5) by turning it counterclockwise, Figure 5.
  • Page 54 J-200 14. System Test 2: Reconnect the CLEARRAY unit to the controller. Turn breaker back ON. Turn on the pump to circulate the water through the CLEARRAY unit. Wait for 5 minutes and assure no water is dripping. If water is visible, STOP, fix the leak by repeating quartz tube maintenance process from step 1 through step 13.

  • Page 55: Error Conditions And Messages

    Your spa has a self-diagnostic control system. The system will automatically display the following if a problem is detected. Always insist on genuine Jacuzzi replacement parts. A. General Messages Priming Mode - M019: Each time the spa is powered up, it will enter a Priming Mode.
  • Page 56 J-200 Change Filter: The change filter timer has expired. The filter needs to be inspected. It is time to clean or replace the filter. The display will alternate between “CHNG FLTR” and the normal display. The timer for this reminder will need to be reset, page 38.
  • Page 57 J-200 D. Sensor Related Messages Sensor Balance is Poor - M015: The temperature sensors may be out of sync by or 3°F (1.5°C). Call for Service. Sensor Balance is Poor - M026: The temperature sensors are out of sync. The Sensor Balance is Poor fault has been established for at least 1 hour.

  • Page 58: Troubleshooting Procedures

    15.0 Troubleshooting Procedures In the event your Jacuzzi spa is not working the way it should, please first review all the installation and operating instructions in this manual and check the message on the panel display. If you are still not satisfied it is working properly, please follow the appropriate troubleshooting instructions below.

  • Page 59: No Heat

    Nonetheless, we are always striving to improve the quality and features of our products. Your input as a Jacuzzi spa owner is a cherished part of this process. If you have any comments or suggestions, or if you wish to be informed on any new products for your spa, please write to us.

  • Page 60: Circuit Board Diagrams

    J-200 16.0 Circuit Board Diagrams 16.1 2-Pump Models A. This wiring diagram is used for the 240V 3-Wire 60 Hz spa models. DANGER RISK OF SHOCK OR ELECTROCUTION! WIRE STRIP LENGTH Turn power off 11/16” (0.69”, 17.5mm) before servicing. This...
  • Page 61 J-200 B. Jumper wires for 240V 2-Pump Models Location Device Volts Max Apms From 2-SP Pump 1 240V 12A Max Area 3 240V 2A Max Ozone 0.5A UV and Ozone Line 1 connection J51, J52 Area 2 TV / AV...

  • Page 62: J-215 And J-225 Convertible Power Models (For A 3-Wire 120V 60 Hz Connection)

    J-200 16.2 J-215 and J-225 Convertible Power Models (For a 3-wire 120V 60 Hz connection) A. This wiring diagram is used for all 1-Pump 120V 3-Wire 60 Hz convertible spa models. DANGER RISK OF SHOCK OR ELECTROCUTION! Turn power off before servicing.

  • Page 63: North American J-215 And J-225 Convertible Power Models (For A 4-Wire 240V 60 Hz Connection)

    J-200 16.3 North American J-215 and J-225 Convertible Power Models (For a 4-wire 240V 60 Hz connection) This wiring diagram is used for all North American 240V 60 Hz convertible power models. Dedicated 240V models must be permanently connected (hard-wired) to the power supply.
  • Page 64 J-200 A. Jumper wires for 1-Pump Convertible Models for a 4-Wire 240V connection. Location Device Volts Max Apms From 2-SP Pump 1 120V** 9A Max Area 3 120V** 0.5A Max Ozone 0.5A UV and Ozone Line 1 connection J51, J52...

  • Page 65: Dip Switch Settings And Wiring

    J-200 17.0 Dip Switch Settings and Wiring 17.1 Switch settings for Domestic 60Hz Models The dip switches are at the S1 location on the board. A. 2-Pump Models DEFAULT SETTING ON Position OFF Position SWITCH NOT ASSIGNED NOT ASSIGNED NOT ASSIGNED...
  • Page 66 J-200 B. 1-Pump Models DEFAULT SETTING ON Position OFF Position SWITCH NOT ASSIGNED NOT ASSIGNED NOT ASSIGNED NOT ASSIGNED MEMORY RESET* STORE SETTINGS* SPECIAL AMPERAGE RULE ON SPECIAL AMPERAGE RULE OFF 5 MIN HTR COOL DOWN (GAS) 1 MIN HTR COOL DOWN (ELEC) DON’T ADD 2 HS PUMPS W/...
