Setting Up an Echo Server

If your echo server contains a 3C509B NIC, select Echo
Server under the Test menu, and click the Start button to
make the computer an echo server.
If you are setting up an echo server using a 3Com NIC
other than a 3C509B NIC, follow these steps:
1 Select a computer to use as an echo server.
2 Insert the EtherDisk diskette in a floppy drive.
The diagnostic program comes on the EtherDisk diskette
that accompanied the NIC.
3 Start the diagnostic program on the echo server.
The diagnostic program that you use depends on the
NIC that is installed in the echo server. After the system
prompt of the drive containing the Configuration and
Diagnostic Program, enter the appropriate diagnostic
program name from Table 5-1.
Table 5-1 Diagnostic Programs
Diagnostic
Program Name
3C503.EXE
3C505.EXE
3C507.EXE
3C508CFG.EXE
3C5X9CFG.EXE
3C523.EXE
3C523TP.EXE
3C527.EXE
3C59XCFG.EXE
3C90XCFG.EXE
ROUBLESHOOTING
NIC Installed
in the Echo Server
EtherLink II
EtherLink Plus
EtherLink 16 or EtherLink 16 TP
3Com Red
EtherLink III family
EtherLink/MC
EtherLink/MC TP
EtherLink/MC 32
EtherLink III EISA/PCI bus master family
(including Fast EtherLink NIC running at
10 Mbps)
EtherLink XL and Fast EtherLink XL family of
NICs running at 10 Mbps
® or II TP, EtherLink II/16 or II/16 TP
®
