Smart Classroom Quick-Start Guide
1
VA
Getting Started
1. Locate the device port wall plate (Figure 1). The device port
connects your laptop to the overhead projector.
2. Locate the controller on the wall, sometimes behind the sliding
front doors (Figure 2). The controller will turn on/off the
projector.
3. Connect the laptop using a standard VGA monitor cable or
HDMI cable.
4. Turn projector on using the display buttons on the wall
mounted controller. (Figure 2)
File Storage: Instructors have 1 TB of file storage available on OneDrive. Must have Multi-Factor Authentication (MFA).
Please report problems to the Help Desk at 393-2640 or helpdesk@clarion.edu
Indicate the building, room number, Computer CSID # (on label), and identify it as a smart classroom.
Training: If you would like training on the Smart Classroom system, please contact the Learning Technology
Center (LTC) at x1848
Smart Classroom Web site: For more detailed documentation, resources, and contacts see:
http://www.clarion.edu/ltc/
Learning Technology Center, Center for Computing Services
Dec. 2021 - S. Homan
Figure 1
SMART CLASSROOM HELP
After 4:30 p.m. please contact Robert Hoover at 393-2743.
ITV or Mediasite questions, contact the LTC at 393-1848.
and navigate to Instructional Technologies > Classroom technology
Extron MLC 104 IP PLUS - BASIC POLE
5. Select the source (Laptop 1 or 2, DVD, HDMI or VGA, or
Document Camera.) Source button options will vary from
room to room. (Figure 2)
6. Optional: Connect the network cable to the white slot located
on the network connection box, if needed. See Figure 3
7. To adjust room audio as needed, use the volume control to
adjust the sound levels. There are speakers located in the
ceiling. (Figure 2)
Figure 2
CLASSROOM INFORMATION
Building _______________Room _____
Computer ID _____________________
GUEST LOGIN:
Username: _____________
Password: __________
Figure 3
