- Page 1 User Guide MediaLink ® MLC 60 Series MediaLink Controllers 68-2166-01 Rev. A 12 11 Get other manuals https://www.bkmanuals.com...
- Page 2 Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated on the product. This This symbol is intended to alert the user of important operating and equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third maintenance (servicing) instructions in the literature provided with the (grounding) pin is a safety feature, do not attempt to bypass or disable it.
- Page 3 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation.
- Page 4 From the menu, select File Click the button. Copyright © 2011 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. Get other manuals https://www.bkmanuals.com...
-
Page 5: Table Of Contents
Contents Introduction ............1 Accessing Covered Panel Features After Mounting ............38 About This Guide ..........1 Accessing the Covered MLC D Front Panel About the MLC 60 Series MediaLink Controllers . 1 Features ............38 MLC Models ........... 1 Accessing MLC 62 RS EU and Features ............ - Page 6 MLC 60 Series MediaLink Controllers • Contents Get other manuals https://www.bkmanuals.com...
-
Page 7: Introduction
Introduction This section gives an overview of the guide and describes the MLC 60 Series MediaLink ® Controllers and their features. Topics include: About This Guide • • About the MLC 60 Series MediaLink Controllers • System Requirements About This Guide This guide provides detailed information and best practice recommendations about cabling and configuring the Extron MLC 60 Series MediaLink Controllers. - Page 8 MLC 62 RS MK — UK model. Controls devices by RS-232, IR, relays, and digital input; has a standard MK sized frame and fits into a standard one-gang MK electrical box. MLC 64 RS VC D — US model. Controls devices by RS-232, IR, relays, and digital input; has a two-gang Decora faceplate and fits in a two-gang US electrical box.
-
Page 9: Features
The five MLC models have the same button functionality and use the same configuration software. All models can be controlled by pressing the front panel buttons or via a host device using RS-232 communication and simple ASCII commands (Simple Instruction Set, ). - Page 10 IR and RS-232 ports — The MLC 64 and the MLC 62 RS models each have a • dedicated serial port for communicating with most types of projectors or flat panel displays via unidirectional RS-232. They also have an IR/S port, which can be configured for IR or RS-232 control.
-
Page 11: Mlc Configuration Software
MLC Configuration Software The included MLC Configuration Program is used to configure the MLC buttons and ports via an RS-232 or USB connection. This software, provided on a DVD that is delivered with the product, enables you to set functions for the front panel buttons and to configure the MLC ports in order to control devices via the MLC. - Page 12 IR Projector Control Projector with Internal Speakers V I D Audio Video Audio Extron MLC 62 IR D MediaLink Controller • IR Display Control • On/Off Control • Input Switching • Volume Control Figure 3. MLC 62 IR D Controlling a Projector Audio RS-232 Display Control...
-
Page 13: System Requirements
RS-232 Display Control Audio Volume Control Audio Video Laptop Audio Projector with Switched Audio Output S-video Relay V I D Document Camera Screen Control Extron O UT IN G W IR O TE MPA 152 T GR R EM A 15 R OU IN PU Mini Power... -
Page 14: Features, Installation, And Operation
Features, Installation, and Operation This section describes the front, side, and rear panel features of the five MLC models, and provides procedures for installing and operating them. Topics include: • Installation Checklist • Panels and Connectors Installation • • Configuring the MLC via the USB Port Mounting the MLC 60 Series Controllers •... -
Page 15: Front And Left Side Panels
“Connecting Power to the MLC,” Wire and connect the MLC power supply (see later in this section). Connect all other power cords and turn on all the devices, including the MLC. Connect a configuration cable from the computer to the MLC by doing either of the following: Connect a USB A to mini B cable to the MLC USB configuration port and to a USB •... - Page 16 The numbered callouts below apply to all the following MLC D front panel drawings. Activity LED Input Selection buttons IR Learning sensor Display power On Reset LED On button identification nub and Off Buttons Reset button Mute button (MLC 64 only) Volume buttons and USB configuration port Volume control knob...
-
Page 17: Mlc 62 Rs Eu And Mlc 62 Rs Mk Front And Side Panels
Controls behind the wallplate The front panels of the MLC D controllers contain some controls and connectors that are located behind the wallplate when the controller is mounted. To access these features that “Accessing the are covered during normal operation, you must remove the wallplate (see Covered MLC D Front Panel Features,”... - Page 18 Front panel features Activity LED — This bicolored LED lights green when the MLC front panel buttons are pressed. It blinks red while enabling front panel lockout (executive mode). Display power On and Off buttons — After configuring these buttons, use them to turn the connected display device or switcher on and off.
-
Page 19: Buttons
USB configuration port — Connect a USB cable (USB A to mini B) between your computer and this port to configure the MLC via the configuration software and to update the firmware. This port can also provide power to the MLC during configuration. -
Page 20: Rear Panel Features
Setting the button flashing rate — Specify fast or slow flashing of a front panel • button and the number of seconds the button flashes. NOTE: While a button is flashing, all other front panel buttons are disabled. A user-defined RS-232 operation — Issue a non-driver-associated RS-232 command •... - Page 21 Host/Config port — This bidirectional RS-232 serial port can be used for configuration and firmware updates in the same way as the USB port ( in the “Front and Left Side Panels” section, earlier in this section). The baud rate is 9600 bps.
-
Page 22: Rear Panel Features On Mlc 62 Rs Eu And Mlc 62 Rs Mk Only
Rear Panel Features on MLC 62 RS EU and MLC 62 RS MK Only The items listed in this section are located on the rear panel of the MLC 62 RS EU and the MLC 62 RS MK only. On the MLC D models, these items are on the front panel, behind the wallplate (see “Rear Panel Features”... -
Page 23: Installation
Installation The MLC 60 Series can be installed as listed below: • The MLC 62 D models can be installed in a standard one-gang electrical wall box or a one-gang Decora mounting bracket (“mud ring”). • The MLC 64 RS VC D can be installed a two-gang electrical box or mounting bracket. •... - Page 24 DISPLAY VOLUME VIDEO Extron Figure 14. Removing the Faceplate (MLC 60 Series D Models) If you are switching faceplates, transfer the buttons from the faceplate you removed to the replacement one. Make any desired button changes (see “Replacing Buttons,” later in this section). To attach the faceplate, make sure that both the faceplate and the MLC board are upright and line up the pegs in upper-left and lower-right corners on the back of the faceplate with the two diagonal holes on the MLC board.
- Page 25 Removing and replacing the MLC 64 VCM module knob and faceplate The MLC 64 is provided with one black and one white VCM faceplate and volume control knob. You can change the faceplate, knob, or both on the volume control module as described in the following procedures.
- Page 26 VOLUME MUTE Figure 17. Removing the MLC 64 Volume Control Module Faceplate Making sure that both the faceplate and the volume control module board are upright, line up the pegs in the upper-left and lower-right corners of the new faceplate with the holes in the board. Press the faceplate onto the board until the tabs at the top and bottom of the faceplate snap into their slots on the board.
-
Page 27: Replacing Buttons
If you are switching faceplates, transfer the buttons from the faceplate you removed to the replacement. Make any desired button replacements (see “Replacing Buttons,” below). Replace the faceplate as follows: Hold the MLC with its board against the back of the faceplate, aligning the two tabs on each side of the unit with the two slots on each side of the faceplate. -
Page 28: Wiring For Rs-232 Control (Rs Models Only)
Press the two buttons into the faceplate until the pegs on the membrane are seated in the corresponding holes. Repeat steps 2 through 4 for any additional buttons that you want to replace, then reattach the faceplate. Wiring for RS-232 Control (RS Models Only) The MLC 60 Series RS models can send out RS-232 commands through the Port A RS-232 port (Port A) or the IR/S port (Port B) to control a display device or switcher that is connected to the port. -
Page 29: Wiring For Ir Control
Wiring for IR Control To control devices via infrared (IR) commands from the MLC, connect one or two IR emitters to the IR/S port (RS models) or the IR port (IR model). The IR and IR/S ports provide unidirectional IR signal output to control a display, projector, switcher, or other device such as a VCR or DVD player. -
Page 30: Wiring The Digital Input Port (Rs Models Only)
Power Supply GROUND GROUND Pin: Ground ( ) Ground ( ) COMMON Signal 110/220 V Low Voltage GROUND Motorized Tx/IR Screen Control Screen GROUND MLC RS D Rear Panel GROUND Figure 25. Connecting a Motorized Screen to the Relay Port of an MLC RS D +12 VDC To connect devices to both relay ports: Connect the ground wires of both devices to pin 3 of the provided 3-pole captive... -
Page 31: Wiring The Host/Config Port
Example: The diagram below shows a two-position switch connected to the Digital Input port of an MLC 62 RS D. Two-position Switch GROUND Pin: Ground ( ) GROUND Digital Input 1 COMMON MLC RS D Rear Panel GROUND Figure 26. Connecting a Two-position Switch to the Digital Input Port Tx/IR GROUND... -
Page 32: Wiring The Volume Control Module (Mlc 64 Rs Vc D Only)
Wiring the Volume Control Module (MLC 64 RS VC D Only) Connect the remote volume control port of an Extron amplifier to the 3-pole captive screw connector on the rear panel of the MLC 64 volume control module, as shown in the figure below. -
Page 33: Configuring The Mlc Via The Usb Port
GROUND GROUND COMMON Plug the connector into the rear panel Pwr connector. In the example below, a power supply is being connected to the Pwr connector of an MLC 62 RS D. GROUND Tx/IR GROUND Ground GROUND 12 VDC Input +12 VDC MLC Rear Panel External... - Page 34 Mini Type B Type A USB 1 USB Cable Ports MLC 62 RS EU or MLC 62 RS MK Left Side Panel Figure 32. USB Port Connection for MLC 62 RS EU and MLC 62 RS MK If this is the first time you have connected an MLC to this USB port on your computer, the Found New Hardware Wizard opens.
- Page 35 Click . On the next screen, make sure that the Install the software Next radio button is selected, then click . (You do automatically (Recommended) Next not need to insert a disc.) Figure 34. Selecting the Radio Button to Install the USB Driver Automatically Your computer locates the driver needed for it to communicate with the MLC via the USB port.
-
Page 36: Ir Learning
IR Learning The IR learning transceiver sensor on the MLC front or left side panel can receive and “learn” commands from the infrared remote controls of other devices via the MLC configuration software. IR Learning enables you to create an IR driver file to control the projector or input devices such as a VCR or DVD player. -
Page 37: Mounting The Mlc 60 Series Controllers
Mounting the MLC 60 Series Controllers When the system has been cabled, configured, and tested, the MLC can be installed in a wall or furniture. After you have any desired changes to the faceplate or front panel buttons and configured the buttons, mount the MLC as described in the following sections. - Page 38 Mounting an MLC 62 D to a Decora Mounting Bracket A one-gang, Decora style mounting bracket (“mud rings”) is provided with the MLC 62 D models. If desired, you can mount the MLC to this type of bracket instead of to an electrical box.
-
Page 39: Mounting The Mlc 64 Rs Vc D
Mounting the MLC 64 RS VC D Mounting an MLC 64 RS VC D to an electrical junction box CAUTION: Ensure that the junction box is grounded properly. Mount a two-gang electrical junction box in the wall or furniture, following the directions provided with the box. - Page 40 Mounting an MLC 64 RS VC D to a Decora Mounting Bracket A two-gang Decora mounting bracket is provided with the MLC 64. To mount the MLC 64 to this type of bracket: Cut a hole in the mounting surface large enough to accommodate the provided two-gang mounting bracket.
-
Page 41: Mounting The Mlc 62 Rs Eu And The Mlc 62 Rs Mk
Mounting the MLC 62 RS EU and the MLC 62 RS MK CAUTION: Ensure that the junction box is grounded properly. To mount the MLC 62 RS EU and MLC 62 RS MK to an electrical box: Attach the provided metal mounting bracket to the mounted electrical box using two of the included screws in the slots at the top and bottom of the bracket. -
Page 42: Mounting The Mlc Eu In A Raceway Using Spacers (Optional)
Wall Wall Box Metal Bracket V I D Frame MLC 62 MK Figure 42. Mounting the MLC 62 RS MK to an External Electrical Box Mounting the MLC EU in a Raceway Using Spacers (Optional) If you are experiencing difficulty with the MLC EU staying in place when installed in a cable raceway, this may be due to a gap between the metal mounting bracket and the wall frame. - Page 43 To mount the MLC EU to a raceway using the spacer: Raceway Mount the electrical box in the raceway. Attach the spacer to the electrical box using two Junction Box of the included screws in the holes at the sides of the spacer.
-
Page 44: Accessing Covered Panel Features After Mounting
Accessing Covered Panel Features After Mounting After the MLC is installed in the mounting surface, you can still access the covered front panel features on the MLC D and the side and rear panel features on the MLC 62 RS EU and MLC 62 RS MK, using the following procedures. Accessing the Covered MLC D Front Panel Features After the MLC D is mounted, the following front panel items are covered by the wallplate: IR sensor, DIP switches, Reset button, and USB connector. -
Page 45: Front Panel Security Lockout
Insert to line. V I D Figure 45. Inserting the Removal Tool in an MLC 62 EU Press the removal tool inward or toward the mounting surface to release the tab holding the MLC in place in the wall frame. If the MLC does not immediately come free of the frame, pry the unit outward (away from the wall) until it is free of the installation surface, then lift it out. -
Page 46: Resetting The Mlc Using The Reset Button
Resetting the MLC Using the Reset Button If it becomes necessary to reset the MLC to its default factory firmware or to the default configuration settings that were implemented at the factory, you can use either the Reset button (see below) or the configuration software (see the software help file). The Reset button is located on the front panel of the MLC D behind the wallplate, and on the rear panel of the MLC 62 RS EU and MK. -
Page 47: Software-Based Configuration
Software-based Configuration This section describes basic procedures for setting up the MLC using the MLC 60 Series Windows-based configuration program. The following topics are covered: About the MLC Configuration Program • • Installing the Configuration Software • Starting the Configuration Software Obtaining Device Drivers •... -
Page 48: Installing The Configuration Software
Installing the Configuration Software The software is provided on a DVD that is delivered with your MLC unit. You can also download it free of charge from the Extron website. Downloading and Installing the Software from the Web If you do not have the software on DVD, download it to your computer from the Extron website as follows: www.extron.com Visit the Extron website at... -
Page 49: Starting The Configuration Software
Open the MLC 60 Series software by selecting the MLC icon from the Start menu on your computer desktop. Select All Programs\Extron Electronics\MLC 60\MLC 60 The Start Options window opens in front of the MLC 60 Configuration Program main window. On the Start Options window, select the radio button. - Page 50 Select your MLC model from the drop-down menu. Select Model Figure 49. Add Device Window with Select Model Menu Displayed Click . The MLC 60 Series main window opens, with the device name you entered displayed in the device configuration tree (left column). Figure 50.
-
Page 51: Accessing The Help File
The MLC 60 Series main window is divided into the following major sections (see the illustration on the previous page): The device configuration tree enables you to view the list of devices that have been configured, and to organize and save all these device configurations in a single project file. -
Page 52: Obtaining Device Drivers
(You can do this at any time while the software is open, regardless of whether a project has been created.) Click or double-click Start > Programs > Extron Electronics > MLC 60 MLC software icon (shown at right) on your desktop to launch the MLC software application. The MLC Configuration Program main window opens, with the Start Options window displayed in front of it. - Page 53 The Driver Subscriptions window opens. In the Available Drivers Subscription section, select the device types for which you want to download drivers. Figure 52. Driver Subscription Window To select all device types available from a manufacturer, select the check box in •...
- Page 54 Click . The Driver Subscriptions Download window opens, displaying all Download drivers that have been selected or previously downloaded to your computer. Figure 53. Driver Subscription Download Screen If a driver on the list is new for your computer, it has the designation •...
-
Page 55: Downloading Drivers From The Disc
Downloading Drivers from the Disc The software DVD provided with the MLC contains the set of device drivers that are also available from the web. To load the drivers from the DVD to your computer: Load the Extron Software Products DVD into your CD or DVD drive. The disc should start automatically. - Page 56 The MLC 60 Series Device Drivers screen opens, displaying a list of all available drivers for use with the MLC 60 Series controllers (see the example below). Figure 57. MLC 60 Device Drivers Page on DVD From the DVD, you can download either the current Extron driver package (containing all IR and serial drivers that were available at the time the package was compiled), or an individual driver.
- Page 57 NOTE: The DVD may contain additional drivers that became available after the current driver package was created. These new drivers may be on the DVD, but have not been incorporated into the driver package. To ensure that you are getting all the drivers currently available, use the “Downloading the configuration program to download the drivers (see Drivers Using the Configuration...
-
Page 58: Downloading Drivers From The Web
Downloading Drivers from the Web Drivers can also be obtained directly from the Extron website as follows: Visit the Extron website at www.extron.com, and click the Download tab. Click the link on the left panel of the Download Center screen. Device Drivers From the drop-down menu on the Device Drivers screen, select MLC 60 Series. - Page 59 As you make each selection, the driver list below changes to display all available drivers meeting your selected criteria. Figure 60. Entering MLC 60 Series Driver Search Criteria Click on the device name whose driver you want to download. To download all the drivers in the current package, click the Download install for driver package (Version n) link.
-
Page 60: Sis Control
No response is required from the host. The MLC sends the following copyright message only when it first powers on. (c) Copyright 20nn, Extron Electronics, MLC nn, vn.nn, 60-nnnn-nn where MLC is the model name, v is the firmware version number and 60- n.nn... -
Page 61: Using The Command And Response Table
Using the Command and Response Table The Command and Response Table on the following pages lists valid ASCII command codes, the responses of the MLC to the host, and a description of the command function or the results of executing the command. The ASCII to HEX conversion table below is for use with the table. - Page 62 X1@ = Name of the MLC device. May be up to 24 alphanumeric characters. The first character must be alphabetic; the last character cannot be a hyphen or minus sign (-). No blank or space characters are permitted. X2# = Status = disengaged (default) = engaged X2% = Firmware compatibility version number (a 3-digit number listed to three...
- Page 63 On the MLC 64, the LEDs are numbered as follows: LED Number LED Location Transmit red Transmit green 3, 4, 5, 6 Four LEDs behind “Display” text Button row 1, first LED (button 1) Button row 1, second LED (button 2) 9, 10, 11 Button row 2, LEDs 1 through 3 12, 13, 14...
-
Page 64: Command And Response Table For Sis Commands
Command and Response Table for SIS Commands ASCII Command Response Command Additional Description (Host to Unit) (Unit to Host) Button Selection X! ] Trigger a button Execute the commands BTNO BtnoB* programmed to button . (This command produces the same results as pressing button the front panel). - Page 65 ASCII Command Response Command Additional Description (Host to Unit) (Unit to Host) Relay Functions (RS models only) X2# ] Pulse relay Set the length of the pulse specified for relay port . Values for represent increments of 0.5 seconds and can range from 1 (0.5 seconds) to 255 (approximately 130 seconds).
- Page 66 ASCII Command Response Command Additional Description (Host to Unit) (Unit to Host) Reset/Erase Configuration reset ZXXX ZapXXX Reset the MLC configuration to the factory default. Information Requests X* ] Query firmware version Display firmware version two decimal places. Example 1.00 The current firmware version is 1.00.
- Page 67 ASCII Command Response Command Additional Description (Host to Unit) (Unit to Host) Query LED status X5) ] View LED status is a 32-digit number, of which each digit represents the status of an LED on the MLC front panel. On MLC 62 models, the LEDs are numbered as follows: , the LEDs are represented in descending order from 32 1 =Transmit red...
-
Page 68: Reference Information
Reference Information This section contains the specifications for all models of the MLC and lists names and part numbers of included parts and optional accessories for the product. Topics include: Specifications • • Part Numbers and Accessories Specifications MLC 62 Series Specifications Control —... - Page 69 Control — digital input monitoring port (RS models) Number/type ........1 digital input (configurable) Connector ........(1) 3.5 mm captive screw connector, 2 pole Digital inputs Input voltage range ....0-24 VDC Input impedance ...... 12k ohms Programmable pullup ....2k ohms to +5 VDC Threshold low to high ....
- Page 70 MLC 62 RS EU MLC 62 RS EU Faceplate ......Fits the opening in a 1-gang EU, fits a Jung AS 500 wallplate or other European frame that accepts 55 mm x 55 mm modules. Wall frame ......3.2" H x 3.2" W x 0.4" D 8.1 cm H x 8.1 cm W x1.0 cm D Device ........
- Page 71 Product weight MLC 62 IR D, MLC 62 RS D ..1.0 lb (0.5 kg) MLC 62 RS EU ......1.0 lb (0.5 kg) MK models ......1.0 lb (0.5 kg) Shipping weight ......3 lbs (2 kg) Vibration ........ISTA 1A in carton (International Safe Transit Association) Regulatory compliance Safety ........
-
Page 72: Mlc 64 Rs Vc D Specifications
MLC 64 RS VC D Specifications Control — host ports Serial control port ......1 bidirectional RS-232 on a 3.5 mm captive screw connector, 3 pole Baud rate and protocol ....9600 baud, 8 data bits, 1 stop bit, no parity Serial control pin configuration .. - Page 73 General Power supply MLC 64 RS D ......External Input: 100-240 VAC, 50-60 Hz Output: 12 VDC, 1 A, 12.0 watts Remote volume control .... 10 VDC, supplied by the Extron device being controlled Power input requirements MLC 64 RS D ......12 VDC, 0.4 A, max. Remote volume control ....
- Page 74 MTBF ..........30,000 hours Warranty ........3 years parts and labor NOTES: • All nominal levels are at ±10%. • Specifications are subject to change without notice. MLC 60 Series MediaLink Controllers • Reference Information Get other manuals https://www.bkmanuals.com...
-
Page 75: Part Numbers And Accessories
Part Numbers and Accessories Included Parts These items are included with the MLC 60 Series controllers: MLC 62 RS D Included Parts Replacement Part Number MLC 62 RS D MediaLink Controller 60-1005-02 12 VDC, 1 A external power supply (PS 1210C) 70-775-01 Front faceplates, eight-button, 1 black and 1 white 70-688-12... - Page 76 MLC 62 RS EU Included Parts Replacement Part Number MLC 62 RS EU MediaLink Controller (RAL9010 white) 60-1005-35 12 VDC, 1 A external power supply (PS 1210C) 70-775-01 Front faceplate, 6 button (RAL9010 white) Front faceplate, 8 button (RAL9010 white) Jung AS500 wall frame (RAL9010 white) Extron Tweeker (slotted Philips #1 screwdriver) MLC 60 Series Setup Guide...
- Page 77 MLC 64 RS VC D Included Parts Replacement Part Number MLC 64 RS VC D MediaLink Controller 60-1182-02 12 VDC, 1 A external power supply (PS 1210C) 70-775-01 MLC 64 Front faceplate, black, six-button (Includes additional buttons with assorted labels) MLC 64 Front faceplate, white, six-button (Includes additional buttons with assorted labels) VCM front faceplates, 1 black and 1 white...
-
Page 78: Accessories
Accessories These optional items can be ordered separately: Accessories Part Number For Model English button kit MLC 62 RS EU, 70-728-01 (MLC 62 RS EU and MLC 62 RS MK models) MLC 62 RS MK French and German button kit MLC 62 RS EU, 70-728-11 (MLC 62 RS EU and MLC 62 RS MK models) - Page 79 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
