AP5010 Overview
AP5010 Features and Specifications
Antenna Information
Micro USB Console Port
Power Profile
Status LED Activity
The AP5010 is a high-performance 802.11ax Wi-Fi 6E, 6 GHz, 5 GHz band, and 2.4 GHz band access
point designed for high-density indoor environments. The access point supports IEEE 802.11ax
Orthogonal Frequency-Division Multiple Access (OFDMA) multi-user access.
The access point can be installed indoors on a ceiling rail, on a nonstandard ceiling, or on a wall.
AP5010 Features and Specifications
AP5010 access point features including hardware components and temperature specifications.
Access Point Features
The AP5010 access point has the following features:
•
One multicolor LED status light
For LED activity description, see
•
One light sensor located at the top of the device
•
Two Ethernet ports - Eth0 and Eth1
Ethernet ports (Eth0 and Eth1) automatically negotiate full-duplex connections with the connecting
device.
◦
Eth0 is 5/2.5/1GE/100 with Power over Ethernet (PoE)
◦
Eth1 is 2.5/1GE/100 with PoE power sourcing equipment (PSE)
These ports are auto-sensing and adjust to straight-through and crossover standard Cat6 or better
Ethernet cables automatically. The access point receives power through an Ethernet connection to
the ETH0 port from PSE that is compatible with the 802.3bt and 802.3at standards.
•
One USB port
Use the USB port to connect USB-based beacons such as iBeacon and Internet of Things (IoT)
devices. Remove the protective cover to access the USB port.
on page 9
on page 10
on page 11
on page 11
on page 12
Status LED Activity
ExtremeWireless™ AP5010 Access Point
9
