- Page 1 INSTRUCTION MANUAL 2kW DC Ceramic Tower Heater - Electronic Controls Model: DHCH20E For domestic household use only.
- Page 2 IMPORTANT THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/ OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your product for the first time and keep them in a safe place.
- Page 3 • Although this appliance complies with safety standards, we do not recommend its use on deep pile carpets or on long hair type of rugs. • The appliance must be positioned so that the plug is accessible. • If the supply cord is damaged it must be replaced by the manufacturer or service agent or a similarly qualified person in order to avoid a hazard.
- Page 4 WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN • Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. • If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons Information Centre on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for fast, expert advice.
- Page 5 Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children No extension leads or Where the power may be left unattended power boards cable may be damaged On a slope or Where there is risk Where it may be uneven surface...
-
Page 6: Specifications
Specifications Model no. DHCH20E Power supply 220-240V~, 50Hz Rated power 2000W Heat settings Thermostat 10-35°C Timer 0-8hrs Oscillation Weight (net) 2.7kg Dimensions (w x d x h) 170 x 200 x 530mm For greater precision, please always refer to the rating label placed on the product. - Page 7 Parts Handle Control Panel & Display Air Outlet Power Switch Base...
-
Page 8: Safety Features
Control Panel & Remote Power Temp Temp Up Down Timer Heat Timer Heat Power Temp Temp Down Oscillation Oscillation Safety Features This appliance incorporates a number of safety devices. In addition to the ‘Important Safety Advice’ section your attention is drawn to the following; Overheat Protection The heater is fitted with a temperature limiter which will turn OFF the heater should it overheat for any reason. -
Page 9: Operation
Operation Note: Before inserting the plug into an electrical outlet, make sure that the elec- trical supply in your area matches that on the rating label of the unit. 1. When the unit is plugged in, turn the POWER SWITCH on at the back of the unit to enter standby mode. -
Page 10: Remote Control
Remote Control Remote control WARNING: It takes time for the receiver to respond to the transmitter. Do not press the buttons more than once within two seconds for correct operation. 1. To activate the remote control remove the battery isolation strip, which is used to ensure your remote control reaches you fully charged. -
Page 11: Maintenance
Please refer to the warranty card in the box for warranty information. For any troubleshooting advice, please contact the relative Customer Care Centre below. Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd 8 Lakeview Drive, 38 Harris Road, East Tamaki,... - Page 12 Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 © Glen Dimplex Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Glen Dimplex Australia.
