AK2000S（FAQ）
1.Q： What is the maximum payload of the AK2000S？What cameras could
be mounted on it？
A：
Maximum payload is 2.2KG/4.85lb（requires well balanced before turning on）.
Common used SLR & Mirrorless cameras that fit the AK2000S ( more cameras will be
added through future updates, for details please see the camera list for AK2000s） ：
(1) SONY：A9 Series、A7 Series；A6300/A6400 Series, etc.
Lens: FE 24-70mm F4 ZA OSS, FE 16-35mm f/4 , FE28-70mm , E PZ 18–105mm , FE
85mm F1.4 GM, etc.
(2) CANON：EOS R, M50, M6 or other cameras with similar size；
Lens: RF 24-105mm F4L IS USM、RF 50mmF1.2L、RF 35mmF1.8 etc.
(3) Panasonic : GH4、GH5/GH5S series；GX9、GF9 Series；
Lens: LEICA DG Vario-Elmarit 12-60 f/2.8-4 Power OIS、LUMIX G 14-140mm f/4-5.8
OIS、LEICA DG Vario-Elmarit 8-18mm f/2.8-4.0 ASPH etc。
(4) Nikon：Z6、Z7 and other similar mirrorless cameras.
Lens：NIKKOR Z 24-70mm f/4 S，NIKKOR Z 14-30mm f/4 S.
(5) Fujifilm：XT3/XT2、X-T20 、X-T30、XH-1 and other similar mirrorless cameras.
Advertisement
Related Manuals for FEIYUTECH AK2000S
Summary of Contents for FEIYUTECH AK2000S
- Page 1 A： Maximum payload is 2.2KG/4.85lb（requires well balanced before turning on）. Common used SLR & Mirrorless cameras that fit the AK2000S ( more cameras will be added through future updates, for details please see the camera list for AK2000s） ： (1) SONY：A9 Series、A7 Series；A6300/A6400 Series, etc.
- Page 2 Lens：XF 16-55mm 1:2.8 R LM WR，XF 18-135mm f/3.5-5.6 R LM OIS WR etc. 2.Q：What is the weight of the AK2000S？What material is it made of？ A： 1.2KG/2.64lb（without camera or shutter cable or any other accessories） The AK2000s is made of aluminum alloy + unique light rosewood.
- Page 3 4.Q：How long is the battery life？ A： The battery for ak2000S is unremovable； When the gimbal work with stand by mode , which could work around 14 hours ; Using for shooting, which could work around 7 hours. Before turn the gimbal on, please make...
- Page 4 Slide the screen to the left --> Motor strength --> Auto adaptation --> confirm 7.Q：Is the AK2000s waterprofe？ A： It is not waterprofe. 8.Q：Can the AK2000s provide power to camera via USB？ A： The Camera2 port can provide 5V power to Sony camera.
- Page 5 ARCA panoramic gimbal tripod. The secondary plate with the camera could be easily slide in/out，no need to readjust for different cameras. 10.Q：What is the dimensions of the AK2000s？ A： 158.7*203.6*372.8mm （when working at the initial angle） ， 71*208.8*350.4mm （when the...
- Page 6 11.Q：what are the functions of the power button？ A： Long press：turning on/off Single press（when on the home page） ：Lock/Unlock； Single press（when not on home page） ：back to home page;...
- Page 7 Double press：Sleep mode. 12.Q：what are the functions of the mode button？ A： Single press：switch between pan follow mode and lock mode; Double press: pan&tilt follow mode; Triple press: All follow mode. Pan follow ：the camera only follows the movement left and right, while stays still on the tilt and roll direction .(keeps vertical for the tilt，and keeps level for the roll)。...
- Page 8 Note: when connect via USB cable, users will be able to switch between photo and video for cameras apart from Panasonic brand. When connect with the WiFi, users will be able to switch between photo and video for cameras apart from Sony brand. 14.Q：What function does the trigger button have？...
- Page 9 Note: 1) Only supports the compatible cameras from Sony, Canon and Panasonic. 2) Zoom and follow focus require camera support. See the list of compatible cameras for specific supported functions. 3) For Sony cameras, it is recommended to use the Sony Type C to Multi cable for faster and more stable control.
- Page 10 After successfully updating, you need to hold the power button for around 10 seconds til the screen fully light up to power on the gimbal. 22.Q：How to connect with Nikon camera? Nikon cameras are not supported by AK2000s for WiFi connection. Part of the Nikon cameras could be connected via USB cable (Z6/Z7/D850/D7500).
- Page 11 23.Q: What type of battery does the AK2000s use? What are the requirements for the charger? AK2000s uses 2 pairs of 18650 INR batteries ， they are built in to the gimbal and not removable，it should be charged with USB Type C cable with a powered adapter of which the power is less than 18W.
