- Page 1 3-Axis Stabilized Handheld Gimbal for Camera Instructions EN V 1.1...
-
Page 2: Table Of Contents
Catalogue www.feiyu-tech.cn 1. Overview 2. Start to Use 3. Gimbal Balance Balance Adjustment of the Tilt Axis Balance Adjustment of the Roll Axis Balance Adjustment of the Pan Axis 4. Function & Operation Working mode Touch Screen Joystick Function Button Operation Shutter Button Operation Power Button Operation Camera Mode Button Operation... -
Page 3: Catalogue
1. Catalogue Sliding Arm Thumb Screw Tilt Axis Position Lock Roll Axis Knob Ring Roll Axis Roll Axis Position Lock Pan Axis Knob Ring Pan Axis Display Joystick Multifunction Knob Function Button Shutter Button 1/4-20 inch Thread Hole www.feiyu-tech.cn... - Page 4 Quick Tilt Axis Fixed Release Knob Ring Plate Plate Tilt Axis Cross Arm Anti-drop Column Safety Lock Vertical Arm Pan Axis Position Lock 1/4-20 inch Thread Hole Type C Port Power Button Camera Trigger Button Mode Button Handle Accessories USB 2.0 to TypeC Sony Shutter Cable Panasonic Shutter Cable...
-
Page 5: Start To Use
2. Start to Use Charging Please fully charge the battery before powering on the gimbal at the first time. TIPS Charging with Type C USB cable, as the figure below shows: Note: DO NOT charge the gimbal via the Type C port on the fixed plate. Otherwise, the circuit board may be burnt. - Page 6 *Pull the safety lock to left to unlock, and pull it to right to lock it when the safety lock is locking as the figure 4. Pull the safety lock to left to lock it, and pull it to right to unlock when the safety lock is unlocked as the figure 5.
-
Page 7: Gimbal Balance
Position Lock Each of the three rotating axis has one position lock, take the pan axis lock for example. Unlock Unlock Lock Lock 解锁状态 3 Axis position lock Lock status Unlock status 3. Gimbal Balance ( Before powering on ) TIPS If the gimbal is not well balanced, it will decrease the performance of stabilization or even cannot balance the camera. -
Page 8: Balance Adjustment Of The Roll Axis
(3) Loosen the tilt axis knob ring, rotate the tilt axis to any angle, and slide the sliding arm slightly, until the camera can stay stable. Then tighten the tilt axis knob ring to finish the balance. （If the camera cannot be parallel with the horizontal plane after balancing, repeat the steps above until it is parallel.）... -
Page 9: Balance Adjustment Of The Pan Axis
Loosen move Roll Axis Knob Cross Arm Ring (3) If the camera cannot be parallel with the horizontal plane after balancing, please unlock the safety lock, and slide the quick release plate until the camera is parallel with move the horizontal plane, then lock the safety lock. Quick Release * Please lock the safety lock after balanced Plate... -
Page 10: Function & Operation
4. Function & Operation Working mode Pan Mode （Default mode） The roll and tilt direction are fixed, and the lens moves according to the left-right movements of the user's hand. Follow Mode The roll direction is fixed, and the lens moves according to the left-right movements, up-down movements of the user's hand. -
Page 11: Touch Screen
Touch Screen Display icon Mode / Status Display icon Mode / Status Pan Mode Photo mode All Follow Mode Video mode Follow Mode Battery Level Lock Mode Tilt axis enabled Pan axis enabled Bluetooth is connected Roll axis enabled Bluetooth is not connected Zoom WiFi is connected WiFi is not connected... -
Page 12: Function Button Operation
Function Button Operation After connecting to Feiyu ON APP, users can customize the function button operations of lock/pan/follow/all follow mode. Single tap in pan mode to switch to Default Single tap Pan/Lock mode lock mode. Single tap in lock mode to switch to pan mode. -
Page 13: Trigger Button Operation
Trigger Button Operation Users can customize the trigger button operations of lock/fast follow/ follow mode via Feiyu ON APP. Press and hold trigger button in pan/ Press and hold Fast follow Default follow mode to enter fast follow mode, release it to return to previous mode. Return to pan mode, three axis return to Trigger Reset... -
Page 14: Download And Connect App
Download and connect App Feiyu ON Timer Photo/Video Zooming Track time-lapse photography Light tracking Ultra-wide angle Object tracking Face tracking photography panorama Overlapping Slow motion Filter Beauty images Landscape and Firmware ..Video editing portrait switching upgrade Please download Feiyu ON at your smartphone app store or scan the QR code below. -
Page 15: Timelapse Mode
Timelapse mode It is convenient to make gimbal move at a constant speed through timelapse mode. It can be used to record normal video or timelapse photography. Set time parameters on Feiyu ON App Enter the Feiyu ON App to set the timelapse mode parameters. Enter the parameter setting interface to select the timelapse mode for setting. -
Page 16: Inception Mode
Inception mode Single tap Inception Mode on screen, the camera lens will rotate to upward. Holding the gimbal horizontally, and set rotation direction/speed, rotates one circle or continuous rotating. The camera will automatically rotate 360 degree to take inception footage with pre-set speed and direction after setup. -
Page 17: Firmware Upgrade
Firmware Upgrade Firmware Upgrade Upgrade the firmware through the Feiyu ON App. (1) Click the icon Latest version:*** (2) Select upgrade type. Current version:*** (3) Follow the prompts to upgrade the firmware. Please read the following notices CAREFULLY: 1. Please KEEP your phone screen ON during upgrade progress. - Page 18 Connect Camera with Wi-Fi (1) Power on the gimbal. (2) Turn on Bluetooth and Feiyu ON App, APP automatically connects to gimbal with the stron- gest signal of Bluetooth. The Bluetooth icon on display will be lighted after successfully connected. (3) How to Obtain camera’s Wi-Fi name and password.
- Page 19 Camera :SONY a6300，A7S II, A7 etc. Gain Wi-Fi name and password at "smart remote embedded" in the Application list. Smart Remote Embedded Application Wi-Fi Operate smartphone to connect to PlayMemories Application Smart Remote this divice via Wi-Fi Application List Camera Apps Management Embedded Introduction...
- Page 20 (4) Switch on Feiyu ON App , select the camera connection icon in the virtual joystick interface, select corresponding camera brand and camera you used, choose right camera Wi-Fi name and input password. Remote Control FY_G6Max_xx Connect Camera Waiting for 5~10 seconds, After the connection is suc- cessful, the camera interface will display corresponding tips and changes.(Canon camera is needed to tap "con- firm"), And automatically return to the main shooting...
-
Page 21: Gimbal Initialization
Gimbal Initialization You can initialize your gimbal when （1） When camera is not balance. （2） If not use for a long period of time. （3） In case of extreme temperature variations. STEPS (1) Select Calibration on the display by joystick to enter the gimbal initialization. Motor Setup Initialize Konb Setup... -
Page 22: Specifications
6. Specifications 114.03mm 143.6mm 299.41mm Specifications Max. Tilt Range 280° Max. Roll Range 330° Max. Pan Range 360° Theoretical Battery Life 9 Hours Net weight 665g ( not including camera、lens and other accessories ） Payload Capability 1200g （After balancing ） Compatible Cameras Sony RX100 / Sony a6300 (16-50 or 28-70mm) / Sony a6500 for Reference... -
Page 23: Compatible Cameras For Reference
Compatible Cameras for Reference Model Brand Canon EOS M50 Canon Canon EOS RP Canon G7X MarkIII Canon 200D Sony RX0 Sony RX100Ⅳ Sony RX100 V Sony RX100 VI Sony a6300+16-50 Sony a6500+28-70 Sony a6000 Sony a5100 sony AS50 Sony SONY X3000 sony QX1 sony RX1RⅡ... - Page 24 Model Brand Sony α7sII/7SM2 Sony Sony α7RII Sony α9 Panasonic DC-GF9KGK Panasonic ZS70 Panasonic ZS220 Panasonic GX9K+12-32 Panasonic GF10K+12-32 Panasonic DMC-ZS110 Panasonic Panasonic GH3 Panasonic GH4 Panasonic GF9X Panasonic LX10 Panasonic LX100 Panasonic DMC-GX85 SJcam SJcam SJ6 LEGEND RICCA RICCA GoPro gopro 5/6/7 YI 4K...
- Page 25 FeiyuTech has made and may make available. FeiyuTech accepts no liability for damage, injury or any legal responsibility incurred directly or indirectly from the use of product.
- Page 26 Guilin Feiyu Technology Incorporated Company For more information, please visit our official website www.feiyu-tech.com E-mail: service@feiyu-tech.com Tel: +86 773 2320865 Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual from the official website.
