3-axis stabilized handheld gimbal for camera (24 pages)
Summary of Contents for FEIYUTECH G6 MAX
Page 1
2) How do I know if the three axes are balanced? 3) How do I initialize the G6 Max? 4) How many ways can the G6 Max connect to a camera and control it? 5) How do I enter the camera’s Wi-Fi interface?
Page 2
(a standard accessory) on the fixed plate by 1/4inch thumb screw. 2) How do I know if the three axes are balanced? Unlock axis motor: G6 Max has 3-axis motor locks, unlock the tilt/roll axis to release storage status firstly. Place the cross and slide arm to its working position, then lock the axis motor for mounting and balancing the camera.
Page 3
FAQ • G6 MAX 4) How many ways can the G6 Max connect to a camera and control it? There are two ways to connect and control a camera with the G6 Max: Shutter release cable: The port on the G6...
Page 4
Yes, but the cable is an optional accessory and is not included in the package of the G6 Max. The output voltage for the Type C port to control cameras is 5V/500mA. Since the input voltage for Sony is 5V, the G6 Max cannot supply...
Page 5
GoPro itself, smart remote, and phone’s Wi-Fi etc. Once you have ascertained the above, please check if you had set up the bands for the GoPro to 2.4GHz. The G6 Max only detects the GoPro if it is set up at 2.4 Ghz.
Page 6
FAQ • G6 MAX 5) The G6 Max still vibrates when set up in “Auto Adaption” and reboot? How do I fix it? 1 Please make sure the three axes are balanced properly, then turn the gimbal on. 2 Once the gimbal is on, please DO NOT hold the camera with your hand.
