Summary of Contents for FEIYUTECH AK2000
- Page 1 3-Axis Stabilized Handheld Gimbal for Camera Instructions Guilin Feiyu Technology Incorporated Company U s e r M a n u a l V 2 . 0...
-
Page 2: Table Of Contents
3.Gimbal Balancing 3.1Balance Adjustment of the Tilting Axis 3.2Balance Adjustment of the Rolling Axis 3.3Balance Adjustment of the Panning Axis 4.AK2000 Function / Operation 4.1Handle - Function / Operation 4.2Function 5.App - Download and Connecting 5.1Download and Install Feiyu ON App 5.2Connecting App... -
Page 3: Product Overview
1.Product Overview 1/4 Inch Thread Hole Tilt Lock Screw Quick Release Plate Fixed Plate Roll Lock Screw Tilt Axis Safety Lock Sliding Arm anti-column Screw Roll Axis Cross Arm Lens Support Frame Vertical Arm Pan Lock Screw Pan Axis Knob Ring Retaining Ring Touch Screen 1/4 Inch Thread Hole... -
Page 4: Installation
2.Installation TIPS (1) Please mount the camera before powering on the gimbal. (2) When the battery is low, please charge the gimbal. (3) When not in use, turn off the gimbal and then remove the batteries. Battery Charging Please fully charge the batteries before powering on the gimbal for the first time. Charge the batteries with the charger. -
Page 5: Camera Installation
Camera Installation 1. Lock the lens support frame with the screw to the quick release plate; 2. Use the thumb screw to lock the camera from the bottom slot of the quick release plate, and slightly adjust the lens support frame after locking the camera; (Select the long/short thumb screw according to the position of the camera to be mounted on the quick release plate) Thumb Screw... -
Page 6: Gimbal Balancing
Gimbal Balancing Balance Adjustment of the Tilting Axis Adjust the center of gravity of the camera in two steps to the axis of rotation of the tilting axis. Adjust the center of gravity position of the tilting axis up and down: point the camera lens down, adjust cross arm to maintain the level, as shown in figure ①, let go and observe the state of rotation. - Page 7 Adjust the center of gravity position of the tilting axis forward and backward: point the camera lens horizontal forward, adjust cross arm to maintain the level as shown in figure ①,let go and observe the state of rotation. Loosen the safety lock on the right side of the camera, and adjust the balance by sliding up and down the quick release plate on the bottom of the camera (refer to Figure ②...
-
Page 8: Balance Adjustment Of The Rolling Axis
Balance Adjustment of the Rolling Axis When the balance adjustment of tilting axis completed, the balance of the rolling axis can be adjusted:keep the gimbal socket connector vertical to the ground with the hand -held control handle as shown in figure ①, leave the gimbal powered off and observe the balance. -
Page 9: Balance Adjustment Of The Panning Axis
Balance Adjustment of the Panning Axis When the balance adjustment of tilting axis and rolling axis is completed, the balance of the panning axis can be adjusted. Keep the gimbal socket connector in the horizontal position,adjust hand-held panning axis as shown in figure ①,let go and observe the state of rotation. -
Page 10: Ak2000 Function / Operation
4.AK2000 Function / Operation Handle - Function / Operation 1.Touch Screen * Click the option to switch or select the function mode, and slide the screen to the left or right to switch the page. Single tap the power button in the panning follow mode to enter the panning follow mode and rolling follow (rolling follow angle ≤... - Page 11 Screen Interface The load setting is performed according to the camera. Click on the 0-300 g 1500-2500g Custom 2 Slide the touch- Payload Capture touch-screen Setting screen interface Mode 300-600 g >2500g Custom 3 up and down Rotation Auto 600-1000g Auto-adapt Time Rotation...
- Page 12 2.Mode Button Note: The firmware upgrade may occur manual operation function and the actual product features do not match. Please find the latest manual on the official website. Panning Mode / Single tap to switch between panning Single click Lock Mode mode and lock mode Under follow mode, single tap to switch to Double click...
- Page 13 5.Recording Button * Need to connect to the shutter release cable or the camera WiFi (for Camera with WiFi function). Single tap Start shooting / Stop shooting Video Button 6.Shortcut button Long time press the shortcut button, Long time Fast follow mode enter the fast follow mode.
- Page 14 8.Function Button Single tap Return / Lock / Unlock On other interfaces, single tap the function button to return Function Button to the main interface. Single tap the function key on the main interface to enter the locked/unlocked state. 9. Multifunction Knob Rotate Control the current axial rotation / Rotate...
-
Page 15: Function
Function Modes Panning Mode（Default mode） The roll and tilt direction are fixed, and the camera moves according to the left-right movements of the user's hand. Follow Mode The roll direction is fixed, and the camera moves according to the left-right movements, up- down movements of the user's hand. - Page 16 Auto-rotation Mode Auto-rotation Mode Parameter Setting Method 1. Enter the Feiyu ON App to set the auto-rotation mode parameters. Enter the parameter setting interface to select the auto-rotation mode for setting. The maximum time setting for panning and tilting rotation time is less than 8 hours, and the maximum setting time for photographing stop time and photographing interval is 59 seconds.
- Page 17 Auto- rotation mode setting (1) Select auto-rotation to enter the auto-rotation (2) Set rotation start position mode on the display interface. Rotate the panning axis or tilting axis to the start position and stay for half a second, and click OK option on the screen to record the start position.
-
Page 18: App - Download And Connecting
Connecting App 1. Turn on the mobile phone Bluetooth and start the gimbal； 2. Open the App, and connect to AK2000 according to the App prompts. After the connection is successful, you can control AK2000 on the App. www. fei yu -tech .com... -
Page 19: Advanced Operation
6.Advanced Operation Gimbal Initialization You can initialize your gimbal when: (1) When camera is not balance. (2) If not use for a long period of time. (3) In case of extreme temperature variations. (1) Select system settings on the display screen to enter the gimbal calibration. (2) Place the gimbal on the table, and the gimbal automatically initializes. -
Page 20: Firmware Upgrade
Firmware Upgrade Connect the gimbal to the Feiyu ON App, to upgrade the firmware through the App. Settings Update Query Update Your Gimbal version is ***, The latest version is ***, do you want to upgrade? Feiyu ON Later Download www. -
Page 21: Parameters
7.Specifications 211.7mm 182.5mm 128mm 40mm 56mm 360° Max. Tilting Range 360° Max. Rolling Range 360° Max. Panning Range 2°/s ~ 75°/s Tilting Speed 3°/s ~ 150°/s Panning Speed Operation Time 12 Hours Weight About 1252g (not including the batteries) Payload 2800g ( In center of gravity balanced state ) ww w. -
Page 22: Compatible Cameras For Reference
8.Compatible Cameras for Reference Brand Model Can be equipped with a lens CanonEF 100mm f/2.8L IS USM +Camera hood CanonEF 135mm f/2L USM+Camera hood Canon5DMarkIV CanonEF 85mm f/1.2 L II USM+Camera hood CanonEF 50mm f/1.2L USM+Camera hood CanonEF 35mm f/2 IS USM+Camera hood Canon CanonEF 85mm f/1.2 L II USM+Camera hood Canon5DMarkIII... - Page 23 Brand Model Can be equipped with a lens Sony E 50mm F1.8 Sony E PZ 18-105mm F4 OSS Sony FE 85mm F1.8 Sony α7R3 Sony FE 35mm F1.4 Sony sony FE 24-240mm F3.5-6.3 Sony FE 24-105mm f/4 G OSS Sony FE 12-24mm f/4.0 G Sony A6500 SonyFE 28-70mm f/3.5-5.6 OSS 25mm f/1.4...
- Page 24 firmware and use the corresponding user manual. You can get the latest user manual from the official website: www.feiyu-tech.com FeiyuTech reserves the right to amend this manual and the terms and conditions of use the gimbal at any time.
