AMD Vega 10 Data Book page 108

96
Ball Reference
T30
T31
T32
T33
T34
T35
T36
T37
T38
T39
T40
T41
T42
T43
T44
T45
U1
U2
U3
U4
U5
U6
U7
U8
U9
U10
U11
U12
U13
U14
U15
U16
U17
U18
U19
U20
U21
U22
U23
U24
U25
U26
"Vega 10" Databook
56006_1.00
Signal Name
VDDCR_SOC
VDDCR_SOC
VDDCR_SOC
VDDCR_SOC
VDDCR_SOC
VDDCR_SOC
VDDCR_SOC
TEST6
DFTIO_322
VDDCR_SOC
DFTIO_303
DFTIO_277
DFTIO_268
VDDCR_SOC
DFTIO_285
VDDCR_SOC
TX1P_DPD1P
TX1M_DPD1N
VSS
RSVD
RSVD
VSS
GPIO_1
GPIO_SVT0
VSS
RSVD
RSVD
VSS
VDDCR_SOC
VDDCR_SOC
VSS
VSS
VDDCR_SOC
VDDCR_SOC
VSS
VSS
VDDCR_SOC
VDDCR_SOC
VSS
VSS
VDDCR_SOC
VDDCR_SOC
Pin Listings
