- Page 1 3-Axis Handheld Gimbal for Smartphone Quick start guide EN V1.0...
- Page 2 1. Overview [14] [19] [20] [21] [16] [22] [15] [17] [23] [18] [10] [24] [11] [13] [25] [12] [26] [27] [1] Roll axis [10] Limitation [20] Battery indicator [2] Cross arm [11] Mark A button [21] Album button [22] Mode button [3] Tilt axis [12] Mark B button [4] Vertical arm...
- Page 3 2. Quick Experience Step1：Unfold and fold Step2：Smartphone Installation It is recommended to remove the smartphone case before installation. Keep the logo of the smartphone holder upward. Keep the smartphone holder in center. If the smartphone tilted, please move the smartphone left or right to make it horizontal.
- Page 4 Type-C端口 3. Charging Please fully charge the battery before power on the gimbal for the first time. Connect the USB 2.0 to USB-C cable to charge. The indicator light is red while charging, and turn green after charging complete. 4. Landscape & Portrait Mode Switching Double click the function button or manually rotate the smartphone holder (according to the picture below) to switch between landscape and portrait mode.
- Page 5 6. Tripod The tripod is connected to the bottom of the main unit in a rotating manner. According to the needs of shooting and storage, choose whether to install it. 7. Connection 7. 1 Bluetooth Connection Turn on the gimbal. Method one: Download and install Feiyu ON App, run the App, follow the prompts to turn on and connect with the bluetooth.
- Page 6 7.2 App Connection Download the Feiyu ON App Scan the QR code to download the app, or search for "Feiyu ON" in the App Store or Google Play. * Requires iOS 9.0 or above, Android 6.0 or above. Android 8. Indicator Status indicator Battery indicator 8.1 Status indicator...
-
Page 7: Specifications
Medium level of battery Low power Low power, will auto power off 9. Specifications Product name: Feiyu Vimble 3 3-Axis Handheld Gimbal for Smartphone Product model: VB3 Max. Tilt Range: -35° ~ +35° Max. Roll Range: -50° ~ +50° Max. Pan Range:-80° ~ +174°... - Page 8 The relevant costs are borne by user. 4.Prolonged continuous operation may cause the product surface temperature to rise, please operate carefully. 5.DO NOT drop or strike the product. If the product is abnormal, contact FeiyuTech after- sales support. Storage and Maintenance: 1.Keep the product out of the reach of children and pets.
- Page 9 Official Social Media ■ Website Facebook Youtube Twitter Instagram This document is subject to change without notice. Manufactured by: Guilin Feiyu Technology Incorporated Company Website: www.feiyu-tech.com | Tel: +86 773-2320865 | E-mail: support@feiyu-tech.com...
- Page 10 FCC regulatory conformance FCC ID: 2AHW7-VB3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
