Chapter 2 — Spare Parts List

Print Mechanism, PF4i

9
8
Callout Part Number
1 1-010043-90
1 1-010043-91
1 1-010044-90
1 1-010044-91
1 1-010045-90
2 1-206276-02
3 1-206423-90
4 1-206301-90
5 1-206284-01
6 1-206275-02
7 1-206248-01
8 1-206203-95
9 1-206278-04
1-975587-01
1-206118-90
12
1
ROHS Part
Number Description
1-010043-900 Thermal printhead assembly
(8 dots/mm)
1-010043-910 Thermal printhead assembly
(8 dots/mm)
1-010044-900 Thermal printhead assembly
(11.81 dots/mm)
1-010044-910 Thermal printhead assembly
(11.81 dots/mm)
1-010045-900 Thermal printhead assembly
(8 dots/mm) 3mm offset
1-206276-03 Guide cover 4"
1-206423-90 Spring thermal printhead kit
1-206301-90 Cam handle
Edge guide
Paper guide (upper)
Guide link
1-206203-95 Platen roller/Line drive roller
Tear bar
Label stop sensor assembly
Paper guide assembly
EasyCoder PF2i, PF4i, and PF4i Compact Industrial Printers Spare Parts Catalog
2
3
4
5
6
7
Remarks
Media thickness max 175µm
Media thickness 170-220µm
Media thickness max 175µm
Media thickness 170-220µm
PF4i
Includes installation instructions
Includes bearing
Refer to page 16
Paper guide (upper), LSS
assembly, guide cover
