Keyboard and Cover, PF4i

2
1
Callout Part Number
1 1-206461-10
1 1-206461-30
2 1-206222-01
3 1-206453-90
4 1-206113-01
4 1-206113-10
5 1-971633-95
6 1-206223-90
6 1-206223-95
7 1-206468-90
7 1-206468-95
1-206452-50
EasyCoder PF2i, PF4i, and PF4i Compact Industrial Printers Spare Parts Catalog
6
7
ROHS Part
Number Description
PF4i (IPL) overlay
PF4i (Fingerprint) overlay
Keyboard
1-206453-90 Door magnet assembly
Cover assembly
(Light gray for PF2i and PF4i)
Cover assembly
(Metallic gray for PF4i Compact
Industrial)
1-971133-900 Console PCB assembly
1-206223-90 Print button assembly
(Dark gray, for PF2i and PF4i)
1-206223-95 Print button assembly (Blue/gray,
for PF4i Compact Industrial)
1-206468-90 PF4i (IPL) and PF4i Compact
Industrial keyboard assembly
1-206468-95 PF4i (Fingerprint) and PF4i
Compact Industrial keyboard
Badge "Compact Industrial"
Chapter 2 — Spare Parts List
3
5
Remarks
Excludes overlay
Includes screw
Includes cable and two locking
washers
Includes two locking washers
Includes two locking washers
Excludes console PCB
Excludes console PCB
4
9
