Panasonic AW-HE145WP Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Digital Camera
  5. AW-HE145WP
  6. Operating instructions manual

Panasonic AW-HE145WP Operating Instructions Manual

Hd integrated camera
Hide thumbs Also See for AW-HE145WP:
Table of Contents

Advertisement

Quick Links

Download this manual
Before operating this product, please read the instructions carefully and save this manual for future use.
Please carefully read the "Read this first!" (pages 2 to 5) of this Manual before use.
PJ EJ
W0721RA2052 -FJ
Operating Instructions
  AW‑HE145WP
Model No.
  AW‑HE145KP
Model No.
  AW‑HE145WE
Model No.
  AW‑HE145KE
Model No.
HD Integrated Camera
ENGLISH
DVQP2560XA

Advertisement

Table of Contents
loading

Related Manuals for Panasonic AW-HE145WP

Summary of Contents for Panasonic AW-HE145WP

  • Page 1 Operating Instructions HD Integrated Camera   AW‑HE145WP Model No.   AW‑HE145KP Model No.   AW‑HE145WE Model No.   AW‑HE145KE Model No. Before operating this product, please read the instructions carefully and save this manual for future use. Please carefully read the “Read this first!” (pages 2 to 5) of this Manual before use. ENGLISH PJ EJ DVQP2560XA...

  • Page 2: Read This First! (For Aw-He145Wp, Aw-He145Kp)

    FCC NOTICE (USA) Supplier’s Declaration of Conformity Model Number: AW-HE145WP/AW-HE145KP Trade Name: Panasonic Responsible Party: Panasonic Corporation of North America Two Riverfront Plaza, Newark, NJ 07102 Support contact: 1-800-524-1448 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Read This First! (For Aw-He145We, Aw-He145Ke)

    Read this first! (For AW‑HE145WE, AW‑HE145KE) WARNING: CAUTION: • To reduce the risk of fire or electric shock, do not expose this Do not remove panel covers by unscrewing. equipment to rain or moisture. To reduce the risk of electric shock, do not remove the covers. •...
  • Page 4 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Importer: Panasonic Connect Europe GmbH Authorized Representative in EU: Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Importer for UK: Panasonic Connect UK, a branch of Panasonic Connect Europe GmbH, Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT...
  • Page 5 Read this first! (For AW‑HE145WE, AW‑HE145KE) (continued) Інформація для покупця Виробник: Panasonic Connect Co., Ltd. Панасонік Коннект Ко., Лтд. Адреса виробника: Fukuoka, Japan Фукуока Японія Країна походження: China Китай Імпортер: ТОВ “ПАНАСОНІК УКРАЇНА ЛТД” вул. Васильківська, буд. 30, м. Київ...

  • Page 6: Read This First

    Model number of unit manual • Intel and Intel Core™ are trademarks or registered trademarks ® ® AW-HE145WP of Intel Corporation in the United States and other countries. AW-HE145KP • Adobe and Reader are either registered trademarks or ® ®...

  • Page 7: Table Of Contents

    Contents Read this first! (For AW‑HE145WP, AW‑HE145KP) ......2 Picture 6/7 screen ................50 Picture 7/7 screen ................51 Read this first! (For AW‑HE145WE, AW‑HE145KE) ......3 Matrix 1/5 screen ................51 Read this first! ..................6 Matrix 2/5 screen ................52 Note on grounding ................

  • Page 8: Before Use

    Safari 14.01 it can be operated via a web browser. macOS 11.0.1 Google Chrome • Connection with a Panasonic camera controller is also possible via Panasonic's proprietary serial communication format. macOS 10.15 Google Chrome • The unit is available in white (AW-HE145WP/AW-HE145WE) or black macOS 10.14...

  • Page 9: Disclaimer Of Warranty

    Panasonic does not accept any responsibility for damage of this type. https://pro-av.panasonic.net/ • Use the unit in a network secured by a firewall, etc.

  • Page 10: Features

    The unit can also be used together with the cameras and pan-tilt • If the external DC power supply and a PoE++ power supply are head unit systems currently available from Panasonic Connect connected simultaneously, the external DC power supply will have Co., Ltd.

  • Page 11: Accessories

    Accessories Check that the following accessories are present and accounted for. • After removing the product from its container, dispose of the power cable cap (if supplied) and packing materials in an appropriate manner. Mount bracket for installation surface Main unit mounting screw (with flat washer, spring (Hanging/Desktop) (1) washer) M3×6 mm (1/4 inches) (1)

  • Page 12: Operating Precautions

    Operating precautions Do not use the unit in oily‑smoky or dusty When using the automatic functions „ „ „ „ • In the [Scene] such as the camera menu, the initial settings on places. some items has been set to auto, making it impossible for these Performance may be adversely affected if small particles or other items to be operated manually.
  • Page 13 This product includes MIT Licensed software. This product includes BSD Licensed software. For details on obtaining the source codes, visit the following website. http://pro-av.panasonic.net/ However, do not contact Panasonic for questions regarding obtained source codes.

  • Page 14: Wireless Remote Control (Optional Accessory)

    Wireless remote control (optional accessory) This unit can be operated by remote control using a wireless <Layout of wireless remote control signal light‑sensing areas> remote control (model number: AW-RM50AG) purchased separately. <NOTE> Check out the following points before using the wireless remote •...

  • Page 15: Parts And Their Functions

    Parts and their functions Camera unit Mount bracket for installation surface (supplied accessory) Mount this bracket onto the installation surface, and then attach the camera main unit to the bracket. Drop‑prevention wire This wire is screwed down to the bottom panel of the camera main unit.
  • Page 16 Parts and their functions (continued) RS‑422 connector <RS‑422> Service switches <SERVICE> This RS-422 connector (RJ-45) is connected when exercising serial Perform switch settings before turning the unit on. control over the unit from an external device. Use a cable with the following specifications for the connection to this connector.
  • Page 17 Parts and their functions (continued) G/L IN connector <G/L IN> • Make sure of the pin alignment of the DC output terminal of the This is the external sync signal input connector. external DC power supply and the camera DC IN connector, and This unit supports BBS (Black Burst Sync) and tri-level connect the polarity correctly.
  • Page 18 Parts and their functions (continued) Output conditions for each video format „ „ Frequency System Format HDMI 3G SDI OUT 1080/59.94p 1080/59.94p 1080/59.94p 1080/59.94i 1080/59.94i 1080/59.94i 1080/59.94i 1080/29.97p 1080/29.97p 1080/29.97p 59.94Hz 1080/29.97PsF 1080/29.97p 1080/29.97PsF 1080/23.98p over 59.94i 1080/23.98p over 59.94p 1080/23.98p over 59.94i 720/59.94p 720/59.94p...
  • Page 19 Parts and their functions (continued) IP video transmission output (multi‑channel display) „ „ • When “Streaming mode” is set to “H.265” Settings H.265(1) H.265(2) H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 1920×1080 1920×1080 1920×1080 1280×720 1280×720 1280×720 Resolution — — —...
  • Page 20 Parts and their functions (continued) • When “Streaming mode” is set to “RTMP” Settings H.265(1) H.265(2) H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 1920×1080 1920×1080 1280×720 1280×720 Resolution — — — — — 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps...
  • Page 21 Parts and their functions (continued) • When “Streaming mode” is set to “SRT(H.264)” Settings H.265(1) H.265(2) H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 1920×1080 1920×1080 1280×720 1280×720 Resolution — — — — — 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps...
  • Page 22 Parts and their functions (continued) • When “Streaming mode” is set to “MPEG2-TS over UDP” Settings H.265(1) H.265(2) H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 1920×1080 1920×1080 1280×720 1280×720 Resolution — — — — — 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps...

  • Page 23: Wireless Remote Control: Aw-Rm50Ag (Optional Accessory)

    Parts and their functions (continued) CAMERA buttons <1> to <4> Wireless remote control: AW-RM50AG (optional Selects a camera to be operated. accessory) Once a button has been selected, the unit corresponding to the selected button can be operated. SET button <SET> If this button is held down for 2 seconds when the [AWB A] memory or MENU [AWB B] memory has been selected for the white balance adjustment,...
  • Page 24 Parts and their functions (continued) Pan‑tilt buttons and menu operation buttons HOME button <HOME> <4> <5> <b> <a> <M> When this is pressed for 2 seconds, the unit’s direction (panning or tilting) returns to the reference position. 1) These are used to change the unit’s direction. The unit is tilted in the up/down direction using the <4>...

  • Page 25: Setting The Remote Control Ids

    Setting the remote control IDs The wireless remote control (optional accessory) is capable of operating up to four units. IDs are used to set which units are selected when the CAMERA buttons <1>, <2>, <3> and <4> on the wireless remote control have been pressed.

  • Page 26: Network Settings

    Easy IP Setup Software. You can obtain Easy IP Setup Software (EasyIPSetup.exe) by downloading it from the following website. https://pro-av.panasonic.net/ To establish the settings for a multiple number of units, the settings must be selected for each camera involved. If the settings cannot be established using the Easy IP Setup Software, select the settings separately for the unit and personal computer on the Network setup screen [Network] of the setting menu.

  • Page 27: Setting The Initial Account

    Network settings (continued) Setting the initial account Installing the plug‑in viewer software Set the initial account. To view IP images from the unit on Windows Internet Explorer 11, the "Network Camera View 4S" plug-in viewer software (ActiveX ) must be ®...

  • Page 28: Basic Shooting Operations

    Basic shooting operations Set the subject brightness to the appropriate level. Turn on the power of all the units and devices in the system. Select the unit to be operated. Even when using only one unit, it must still be selected from the wireless remote control or controller.

  • Page 29: How To Turn The Power On And Off

    How to turn the power on and off Turning the power on Turning the power off When performing operations from a wireless When performing operations from a wireless remote control remote control Set all the power switches of the units and devices Press one of the CAMERA buttons <1>...

  • Page 30: Selecting The Units

    Selecting the units Select the unit (or units) to be operated from the wireless remote control or controller. Even when using only one unit, it must still be selected. When performing operations from a wireless remote control Up to four units can be operated using one wireless remote control. To select the unit using the wireless remote control, the IR ID switches on the unit’s back panel must be set.

  • Page 31: Selecting The Shooting Modes (Scene Files)

    Selecting the shooting modes (scene files) Press and hold the <MENU> button for about 2 seconds. Types of shooting modes The Top Menu is displayed. One of four shooting modes (Scene1, Scene2, Scene3 or Scene4) — whichever one will best suit the shooting conditions — can be selected. T o p M e n u The shooting modes are set by the user.

  • Page 32: Shooting

    Shooting When performing operations from a wireless When performing operations from a controller remote control Changing the camera’s direction „ „ Changing the camera’s direction Moving the camera toward the left or right (panning): „ „ Tilt the <PAN/TILT> lever toward L or R. Moving the camera toward the left or right (panning): Press the <b>...

  • Page 33: What To Do When Encountering Problems In The Basic Shooting Operations

    What to do when encountering problems in the basic shooting operations When performing operations from a controller If the trouble is not resolved by taking the action suggested below, refer to “Troubleshooting” (→ page 140). The unit does not move. When performing operations from a wireless •...

  • Page 34: More Advanced Operations

    More advanced operations Manual shooting (→ page 35) • Manually adjusting the focus • Manually adjusting the iris • Manually adjusting the shutter speed • Manually adjusting the gain Preset memories (→ page 36) • Up to 100 settings for the camera direction (panning and tilting), zoom, focus, iris, gain up and white balance can be registered in the preset memories, and called.

  • Page 35: Manual Shooting

    Manual shooting Manually adjusting the focus Manually adjusting the shutter speed The lens focus can be adjusted manually. The shutter speed can be set using two methods. One is a method that specifies the time (where a time such as 1/250 sec. is designated), and When performing operations from a wireless the other is a method that specifies the frequency (where synchro scan, 60.15 Hz, etc.

  • Page 36: Preset Memories

    Preset memories When performing operations from a wireless This unit enables up to 100 settings for the camera direction (panning and tilting), zoom, focus, iris, gain and white balance to be registered in remote control its preset memories, and called. However, the number of settings that can be registered and called Twelve settings (preset No.1 to No.12) can be registered and called depends on the type of wireless remote control or controller that is used...

  • Page 37: White Balance Adjustment

    White balance adjustment Adjust the ratio between the three primary colors (RGB) to reproduce Automatic adjustment (AWB: AWB A or AWB B) white accurately. If the white balance is out of adjustment, not only will When performing operations from a wireless white be reproduced poorly, but the color tones of the screen as a whole will also be degraded.

  • Page 38: Auto Tracking White Adjustment (Atw)

    White balance adjustment (continued) Press the <SET> button for about 2 seconds. 3200K and 5600K presets The auto white balance adjustment (AWB) and auto black balance When [3200K] or [5600K] is selected for the white balance, the white adjustment (ABB) are performed, and the white balance setting is balance is set using a color temperature of 3200 K (equivalent to entered.

  • Page 39: Black Balance Adjustment

    Black balance adjustment When performing operations from a controller Adjust the zero levels of the three primary colors (RGB) to reproduce black accurately. If the black balance is out of adjustment, not only will black be reproduced poorly, but the color tones of the screen as a whole When using an AW-RP150 or AW-RP60 will also be degraded.

  • Page 40: Black Level (Master Pedestal) Adjustment

    Black level (master pedestal) adjustment When performing operations from a controller The black level can be adjusted when using a multiple number of cameras including the unit. Ask your dealer to perform this adjustment. (Use an oscilloscope or waveform monitor for the adjustment.) When using an AW-RP150 or AW-RP60 Adjust the black level in accordance with the units and devices used.

  • Page 41: Genlock Adjustment

    Genlock adjustment Press the <4> or <5> button to bring the cursor to The genlock adjustment is performed to achieve phase alignment by applying external synchronization (genlock) when a multiple number of [Genlock], and press the <M> button. cameras will be used or when the unit will be used in combination with other devices.

  • Page 42: Basic Setup Operations

    Basic setup operations Camera menus are displayed on the monitor when the unit’s settings are When performing the operations using the to be selected. wireless remote control The monitor is connected to the video signal output connector. The basic camera menu operations involve displaying sub-menus from Press the CAMERA button <1>, <2>, <3>...

  • Page 43: Camera Menu Items

    Camera menu items Setting the camera menu items Top Menu screen Camera menus are displayed on the monitor when the unit’s settings are T o p M e n u to be selected. Connect the monitor to the 3G SDI OUT connector <3G SDI OUT> or C a m e r a the HDMI connector <HDMI>.

  • Page 44: Camera Screen

    Camera menu items (continued) Camera screen Brightness 1/2 screen This menu is used for the camera image settings. This menu item is selected to set the brightness of the pictures. C a m e r a B r i g h t n e s s 1 / 2 S c e n e Scene1 P i c t u r e L e v e l...

  • Page 45: Brightness 2/2 Screen

    Camera menu items (continued) Shutter Mode [Off, Step, Synchro, ELC] Brightness 2/2 screen Select for camera shutter mode. The shutter is set to OFF. B r i g h t n e s s 2 / 2 Step The step shutter is set (the steps can be changed). Synchro The synchro shutter is set (the setting can be changed G a i n...

  • Page 46: Picture 1/7 Screen

    Camera menu items (continued) ND Filter [Through, 1/4, 1/16, 1/64] Picture 1/7 screen Set the transmittance of the lens' built-in ND (neutral density) filter. The filter switches when the setting is fixed. P i c t u r e 1 / 7 Through Do not set ND filter.

  • Page 47: Color Temp. Setting Screen

    Camera menu items (continued) ATW Speed [Normal, Slow, Fast] Color TEMP. Setting screen Set the control speed of the ATW function. Normal Tracks at normal speed. C o l o r T E M P . S e t t i n g Slow Tracks at a speed slower than [Normal].

  • Page 48: Picture 2/7 Screen

    Camera menu items (continued) Picture 2/7 screen Picture 3/7 screen P i c t ure 2/7 P i c t u r e 3 / 7 C h r o m a L eve l D e t a i l C h r o m a P has e M a s t e r D e t a i l M a s t e r P ede stal...

  • Page 49: Picture 4/7 Screen

    Camera menu items (continued) Picture 4/7 screen Picture 5/7 screen P i c t u re 4/7 P i c t u r e 5 / 7 S k i n D e t a il G a m m a M o d e S k i n D e t ail Eff ect G a m m a 0 .

  • Page 50: Picture 6/7 Screen

    Camera menu items (continued) Black Gamma [–8 to +8] Picture 6/7 screen Set the gamma curve for dark areas. –8 to –1 Compresses dark parts. P i c t u r e 6 / 7 1 to 8 Expands dark parts. K n e e M o d e A u t o A u t o K n e e R e s p o n s e...

  • Page 51: Picture 7/7 Screen

    Camera menu items (continued) Picture 7/7 screen Matrix 1/5 screen P i c t ure 7/7 M a t r i x 1 / 5 W h i t e C l ip M a t r i x T y p e N o r m a l W h i t e C lip Lev el 109%...

  • Page 52: Matrix 2/5 Screen

    Camera menu items (continued) Matrix 2/5 screen Matrix 3/5 screen M a t r ix 2/5 M a t r i x 3 / 5 [Li near M atrix] [ C o l o r C o r r e c t i o n 1 / 3 ] R - G S a t u r a t i o n P h a s e...

  • Page 53: Matrix 4/5 Screen

    Camera menu items (continued) Matrix 4/5 screen Matrix 5/5 screen M a t r i x 4 /5 M a t r i x 5 / 5 [ Colo r Corr ection 2/3] [ C o l o r C o r r e c t i o n 3 / 3 ] Sa tura tion Phase S a t u r a t i o n...

  • Page 54: Lens Screen

    Camera menu items (continued) Lens screen System screen L e n s S y s t e m F o c u s M o de Auto F r e q u e n c y 5 9 . 9 4 H z Z o o m M o d e Op t.Zoom F o r m a t...
  • Page 55 Camera menu items (continued) Fan1 [Auto, Low, Mid, High] Set the operation of the cooling fan near the lens. Auto Enable automatic control of the cooling fan. Operate the cooling fan at low speed. Operate the cooling fan at medium speed. High Operate the cooling fan at high speed.
  • Page 56 Camera menu items (continued) Changing the frequency Changing the format „ „ „ „ When the currently selected frequency is changed in the [System] When the currently selected format is changed in the [System] screen, screen, the pre-frequency-change confirmation screen appears. the pre-format-change confirmation screen appears.

  • Page 57: Output 1/5 Screen

    Camera menu items (continued) HDMI Output 1/5 screen Make the settings for output from the HDMI connector. O u t p u t 1/5 Format Set the output format. 3 G S D I The following format settings are possible depending on the [Format] F o r m a t 1080 /59.9 4p setting in the [System] screen.

  • Page 58: Output 2/5 Screen

    Camera menu items (continued) Output 2/5 screen Output 3/5 screen O u t p u t 2/5 O u t p u t 3 / 5 B a r Came ra O S D M i x C o l o r B a r Typ e Typ e2 3 G S D I T o n e...

  • Page 59: Output 4/5 Screen

    Camera menu items (continued) Output 4/5 screen Output 5/5 screen O u t p u t 4/5 O u t p u t 5 / 5 O S D O f f W i th R -Tally O ff S t a t u s L a m p E n a b l e O S D S t a t u s O ff...

  • Page 60: Pan/Tilt Screen

    Camera menu items (continued) Focus Adjust With PTZ. [Off, On] Pan/Tilt screen [Off] or [On] is set here for the function which compensates for out-of- focusing when it occurs during panning, tilting or zooming operations. P a n / T ilt When [Off] is set, adjust the focus as required after zooming or set [Focus Mode] to [Auto].

  • Page 61: Preset 1/2 Screen

    Camera menu items (continued) Preset Scope [Mode A, Mode B, Mode C] Preset 1/2 screen Selected here are the setting items to be recalled when the contents of the preset memory are regenerated. P r e s e t 1/ 2 Pan, Tilt, Zoom (including digital zoom), Focus, Iris, Gain, Mode A white balance adjustment value...

  • Page 62: Preset 2/2 Screen

    Camera menu items (continued) Preset Iris [Off, On] Preset 2/2 screen When the preset memory is played back, set whether the reproduction of the values in the various menus related to Iris is off/ P r e s e t 2 /2 When set to [On], the values set in the various menus below are P r e s e t T hum bnai l Upda te reproduced when preset memory is played back.

  • Page 63: Maintenance Screen

    Camera menu items (continued) Maintenance screen Firmware Version 1/2 screen M a i n t e nan ce F i r m w a r e V e r s i o n 1 / 2 F i r m w a r e Ver sion S y s t e m V e r s i o n V 0 1 .

  • Page 64: Firmware Version 2/2 Screen

    Camera menu items (continued) Firmware Version 2/2 screen IP Network screen F i r m war e Ve rsion 2/2 I P N e t w o r k E E P R O M I P A d d r e s s M a i n / N e two rk V01.00 1 9 2 .

  • Page 65: Hour Meter Screen

    Camera menu items (continued) Concerning initialization „ „ Hour Meter screen When [Initialize] is selected on the [Maintenance] screen, the [Initialize] screen appears. H o u r M e t e r Initialize screen O p e r a t i o n 0 0 0 0 0 0 0 0 F a n 1 0 0 0 0 0 0 0 0...

  • Page 66: Hdmi Status Screen

    Camera menu items (continued) Monitor HDMI Status screen Displays the status of the device or monitor connected to the HDMI connector. H D M I St atus One of the following is displayed according to the product specifications of the device or monitor connected. 　...

  • Page 67: Error Status Screen

    Camera menu items (continued) Error Status screen E r r o r St atus L e n s No Error P a n / T i l t No Error F a n No Error T e m p e r a t u re No Error R e t u r n Lens [No Error, Error]...

  • Page 68: Camera Menu Item Table

    Camera menu item table Camera menu Item Factory setting Selection items Top Menu Camera Scene Scene Scene1 Scene1, Scene2, Scene3, Scene4 Brightness Brightness Picture Level –50 to +50 (step: 1) Iris Mode Auto Manual, Auto Auto Iris Speed Normal Slow, Normal, Fast Auto Iris Window Normal1 Normal1, Normal2, Center...
  • Page 69 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Camera Scene Picture Picture 2/7 Chroma Level Off, –99% to 99% (step: 1%) Chroma Phase –31 to +31 Master Pedestal –200 to +200 (step: 1) R Pedestal –100 to +100 (step: 1) G Pedestal –100 to +100 (step: 1)
  • Page 70 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Camera Scene Matrix Matrix 3/5 [Color Correction 1/3] Normal EBU NTSC User B_Mg Saturation –63 to +63 B_Mg Phase –63 to +63 Mg Saturation –63 to +63 Mg Phase –63 to +63 Mg_R Saturation...
  • Page 71 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Output Output 1/5 3G SDI AW‑HE145WP/AW‑HE145KP: [System Format] [3G SDI] Format 1080/59.94p 1080/59.94p 1080/59.94p AW‑HE145WE/AW‑HE145KE: 1080/59.94i 1080/50p 1080/59.94i 1080/59.94i 1080/29.97p 1080/29.97p 1080/29.97PsF 1080/29.97PsF 1080/23.98p(59.94i)   1080/23.98p(59.94i)  ...
  • Page 72 Camera menu item table (continued) Camera menu Item Factory setting Selection items Top Menu Pan/Tilt Install Position Desktop Desktop, Hanging Smart Picture Flip Off, Auto Flip Detect Angle 90deg 60deg to 120deg (Step: 1deg) P/T Speed Mode Normal(60deg/s) Normal(60deg/s), Fast(180deg/s), Quick(60deg/s) Speed With Zoom Off, On...

  • Page 73: Displaying The Web Screen

    Displaying the web screen With a personal computer connected to the unit, it is possible to view the Displaying the web screen using a personal camera’s IP videos or select various settings from the web browser. computer The LAN crossover cable is used when connecting a personal computer The procedure is explained here using Windows screens (Internet Explorer).
  • Page 74 Displaying the web screen (continued) Set the initial account. Display the live screen [Live]. In the initial state, the initial account setting screen is displayed when The web screen appears. the web screen is displayed. The live screen [Live] (→ page 76) is displayed initially. You Set a user name and password.

  • Page 75: Switching Between The Live Screen [Live] And Web Setup Screen [Setup]

    Displaying the web screen (continued) Switching between the Live screen [Live] and Logging into the Web screen Web setup screen [Setup] When user authentication is enabled When displaying the live screen [Live] When the live screen [Live] You need to enter account information for a user with Camera control displayed, click the [Setup] button at the top of the or Administrator privileges.

  • Page 76: Web Screen Operations

    Web screen operations Live screen [Live] You can display images from the camera on a personal computer and perform camera operations, such as pan, tilt, zoom, and focus control. The items displayed on the screen will differ depending on whether the [H.264] or [JPEG] button is selected under [Compression]. When [H.264] is selected Operation screen display buttons (for touch Expansion panel display button...
  • Page 77 Web screen operations (continued) Menu switching [Stream Menu]/[Other Menu] When JPEG is selected These buttons appear only when JPEG images are displayed. Switch between menu displays. Clicking [Other Menu] when the Stream menu is displayed displays When selected, the button turns gray, and the images the Other menu.
  • Page 78 14 users. using a Panasonic controller (AW-RP150, AW-RP60) or release • When [Disable] is selected for [Tally] (→ page 59, page 87), [Lock(CAM)] from the web browser while the camera is locked.
  • Page 79 Web screen operations (continued) Zoom [Zoom] Control pad and its buttons [T]: Use this to adjust the zoom (magnification) in the “Tele” direction. To adjust the image in the horizontal or vertical [W]: Use this to adjust the zoom (magnification) in direction (panning or tilting), left-click the pad and the “Wide”...
  • Page 80 Web screen operations (continued) Scene [Scene] Shutter [Shutter] Switch the shutter mode in the order [Off], [Step], Click Scene1-Scene4 to switch the shooting [Synchro], [ELC]. [Scene1] [Scene2] mode. Switch the shutter mode in the order [ELC], [Synchro], [Scene3] [Scene4] [Step], [Off]. Display button for scene expansion panel The [Scene1], [Scene2], [Scene3], and [Scene4] <NOTE>...

  • Page 81: Web Screen Configurations

    Web screen configurations Web setup screen [Setup] The settings for the unit are selected on this screen. <NOTE> • The setting menu operations can be performed only by users whose access level is “1.Administrator”. For the procedure used to set the access level, refer to page 111. •...

  • Page 82: Setting Status Screen [Setting Status]

    Web screen configurations (continued) Collaboration capability [Linkage] Setting status screen [Setting status] P2 Cast connection setting button [P2 Cast] P2 Cast connection setting screen [P2 Cast] is displayed when the button is clicked. → “P2 Cast connection setting screen [P2 Cast]” (→ page 110) User management settings [User mng.] User authentication button [User auth.] The user authentication screen [User auth.] is displayed when the...

  • Page 83: Basic Screen [Basic]

    Frequency [59.94Hz, 50Hz, 24Hz, 23.98Hz] Shooting Mode This item is selected to switch the frame frequency. The shooting mode setting is displayed. The setting is confirmed with the [Set] button. Factory settings: 59.94Hz (AW-HE145WP/AW-HE145KP) Genlock 50Hz (AW-HE145WE/AW-HE145KE) Horizontal Phase <NOTE>...
  • Page 84 Web screen configurations (continued) z Shooting Mode z Wireless Control „ „ Shooting Mode [Normal, High Sens.] Wireless Control [Enable, Disable] Select the shooting mode according to the shooting environment. [Enable] or [Disable] is set here for operations conducted from the The setting is confirmed with the [Set] button.
  • Page 85 23.98Hz 1080/23.98p 1080/23.98p 1080/23.98PsF 1080/23.98PsF It denotes “1080/23.98p over 59.94i”. Factory settings: 1080/59.94p (AW-HE145WP/AW-HE145KP) 1080/50p (AW-HE145WE/AW-HE145KE) HDR Output Select [SDR, HDR(2020), HDR(709)] Select the signal to be output when [Gamma Mode] is [HLG]. SDR output HDR(2020) HDR output (BT.2020 equivalent color gamut) HDR(709) HDR output (BT.709 equivalent color gamut)
  • Page 86 It denotes “1080/23.98p over 59.94i”. This is only enabled when [Bar] is set to [Colorbar]. It denotes “1080/23.98p over 59.94p”. Factory settings: Normal Factory settings: 1080/59.94p (AW-HE145WP/AW-HE145KP) 1080/50p (AW-HE145WE/AW-HE145KE) OSD Mix Select whether to turn off/on camera menu, status, and other displays HDR Output Select [SDR, HDR(2020), HDR(709)] Select the signal to be output when [Gamma Mode] is [HLG].
  • Page 87 Web screen configurations (continued) Tally z Pan/Tilt „ [Disable, Enable] The setting is confirmed with the [Set] button. [Disable] or [Enable] is set here for the function which turns on or turns off the tally lamp using the tally control signal. Factory settings: Enable Tally LED Limit Sets whether to limit the lighting of the tally lamp for each of the tally...
  • Page 88 Web screen configurations (continued) Speed With Zoom Position [Off, On] Date & time screen [Date&Time] „ „ [Off] or [On] is set here for the function used to adjust the pan-tilt Make clock settings. adjustment speed in conjunction with the zoom magnification. You can set using one of three types [PC Synchronization], [NTP], or When [On] is set, the panning and tilting operations will become [Manual].

  • Page 89: Image Screen [Image/Audio]

    Web screen configurations (continued) Live page screen [Live page] „ „ Image screen [Image/Audio] IP video settings screen [Video over IP] „ „ The JPEG image and H.264 image settings as well as the settings related to image quality are selected on this screen. <NOTE>...
  • Page 90 Web screen configurations (continued) z Streaming mode z Initial display setting „ „ It is possible to perform IP transmission operations suited to the Set initial display settings for the Live screen [Live]. application by switching the [Streaming mode] on this unit. The setting is confirmed with the [Set] button.
  • Page 91 Web screen configurations (continued) z JPEG Refresh interval [1fps, 4fps, 5fps, 12fps, 12.5fps, 15fps, „ Set JPEG image settings. 24fps, 25fps, 30fps] The setting is confirmed with the [Set] button. Select the frame rate for JPEG images. There are a total of 3 channels available for JPEG image setting. 59.94Hz 1fps/5fps/15fps/30fps 50Hz...
  • Page 92 Web screen configurations (continued) z H.264 Image capture size [1920×1080, 1280×720, 640×360, „ Set H.264 image settings. 320×180] The setting is confirmed with the [Set] button. Select the resolution for H.264 images. Selectable options will vary depending on the selected resolution setting.
  • Page 93 Web screen configurations (continued) Max bit rate(per client) Unicast port(Image) [1024 to 50000] Enter the unicast port number (used when sending images from the [512kbps, 768kbps, 1024kbps, 1536kbps, 2048kbps, unit). 3072kbps, 4096kbps, 6144kbps, 8192kbps, 10240kbps, Only even numbers can be specified. 12288kbps, 14336kbps, 16384kbps, 20480kbps, 24576kbps] The port number cannot be set to 10670.
  • Page 94 Web screen configurations (continued) z H.265 Frame rate [24fps, 25fps, 30fps, 50fps, 60fps] „ Set H.265 image settings. Set the frame rate for H.265 images. The setting is confirmed with the [Set] button. 59.94Hz 30fps, 60fps 50Hz 25fps, 50fps 24/23.98Hz 24fps Factory settings: For 59.94Hz: 30fps...
  • Page 95 Web screen configurations (continued) z RTMP Streaming format „ Make RTMP/RTMPS transmission settings. Make settings for H.264 images for use in RTMP/RTMPS transmission. Server setup The setting is confirmed with the [Set] button. Refer to the explanation for H.264 (→ page 92) for information The setting is confirmed with the [Set] button.
  • Page 96 Web screen configurations (continued) z SRT Client(Caller) port [1 to 65535] „ When [Listener] is set in [Mode], enter the port number (used when Make SRT transmission settings. this unit is waiting for a connection). <NOTE> The following port numbers are used by the unit so they cannot be •...
  • Page 97 Web screen configurations (continued) z NDI|HX V2 Subnet(IPv4) „ Enter the subnet mask. Make NDI|HX V2 transmission settings. Factory settings: 244.0.0.0 The setting is confirmed with the [Set] button. <NOTE> • [Address (IPv4)] and [Subnet (IPv4)] clarify the multicast address NDI|HX V2 ranges randomly set during multicast transmissions.
  • Page 98 Web screen configurations (continued) z MPEG2‑TS over UDP Streaming format „ Make settings for MPEG2-TS over UDP transmission. Make settings for H.264 images used for MPEG2-TS over UDP <NOTE> transmission. • In order to receive the images being transmitted by the camera, enter The setting is confirmed with the [Set] button.
  • Page 99 Web screen configurations (continued) Audio setting screen [Audio] z Audio „ „ „ The setting is confirmed with the [Set] button. Configure audio settings. <NOTE> • Images and audio are not synchronized. Therefore, images and audio may be slightly out of sync. •...

  • Page 100: Auto Iris Window Normal1

    Web screen configurations (continued) Image adjust screen [Image adjust] Picture Level [–50 to +50] „ „ This menu item is selected to set the target picture level for automatic Adjust the image quality. exposure compensation. The settings in this screen (with the exception of [Scene] and [Matrix]) Its setting takes effect when [Auto] or [ELC] has been selected as are applied immediately.

  • Page 101: Shutter Mode Off

    Web screen configurations (continued) Shutter Mode [Off, Step, Synchro, ELC] Gain Select for camera shutter mode. [When [Super Gain] is [Off]: Auto, –3dB to 36dB, When [Super Gain] is [On]: Auto, –3dB to 42dB] The shutter is set to OFF. The image gain is adjusted here.
  • Page 102 Web screen configurations (continued) z Picture „...

  • Page 103: Var

    Web screen configurations (continued) White Balance Mode Color Temperature Setting [ATW, AWB A, AWB B, 3200K, 5600K, VAR] Color Temperature [2000K to 15000K] Set the white balance mode. This displays the color temperature when [White Balance Mode] is Select the mode when the coloring is not natural because of the [AWB A] or [AWB B].
  • Page 104 Web screen configurations (continued) ATW Speed [Slow, Normal, Fast] Detail [Off, On] Set the control speed of the ATW function. Turn on/off the contour (sharpness of images) adjustment of images. Factory settings: On Slow Tracks at a speed slower than [Normal]. Normal Tracks at normal speed.
  • Page 105 Web screen configurations (continued) Gamma Mode Black Gamma [–8 to +8] Set the gamma curve for dark areas. [HD, FILMLIKE1, FILMLIKE2, FILMLIKE3, FILM REC, VIDEO REC, HLG] –8 to –1 Compresses dark parts. Select the type of gamma curve. 1 to 8 Expands dark parts.
  • Page 106 Web screen configurations (continued) HLG Knee [Off, On] z Matrix „ Enable or disable the operation of the HLG knee. This is only enabled when [Gamma Mode] is set to [HLG]. Factory settings: Off HLG Knee Point [55% to 100%] Set the position of the HLG knee point.
  • Page 107 Web screen configurations (continued) Matrix Type [Normal, EBU, NTSC, User] Lens setting screen [Lens] „ „ Select the type of color matrix. The setting is confirmed with the [Set] button. The setting is confirmed with the [Set] button. Normal This item is used to load the preset color matrix data and compensate for the saturation and color phase.

  • Page 108: Preset Preset 1/2 Preset Speed Unit Speed Table

    Web screen configurations (continued) Preset position screen [Preset position] z Preset „ „ „ The setting is confirmed with the [SET] button. When a preset thumbnail is clicked, the camera moves to face towards a preset position that was registered beforehand. You can select Home and Preset001 to Preset100.

  • Page 109: Preset Speed Table Fast

    Web screen configurations (continued) z Limitation Setting Preset Acceleration [Manual, Auto] „ This establishes the up, down, left and right limit settings of the pan-tilt Sets whether to set the acceleration and deceleration when starting or head. stopping preset playback. First, use the control pad to rotate the pan-tilt head to the position you Manual Make settings for acceleration when starting or...

  • Page 110: Collaboration Capability [Linkage]

    Web screen configurations (continued) Preset Name [Reset, Hold] Collaboration capability [Linkage] When registering a preset memory, set whether to reset the P2 Cast connection setting screen [P2 Cast] previously registered preset name or keep it. „ „ Sets whether to enable or disable connection to P2 Cast, as well as the Reset When registering a preset memory, reset the destination server URL and the user account.

  • Page 111: User Management Screen [User Mng.]

    Web screen configurations (continued) z Add user „ User management screen [User mng.] The users and personal computers (IP addresses) that can access the unit from personal computers and mobile terminals are registered in the User management screen [User mng.]. The User management screen [User mng.] consists of [User auth.] and [Host auth.].
  • Page 112 Web screen configurations (continued) Host authentication screen [Host auth.] z Add host „ „ „ Click the [Host auth.] of User management screen [User mng.]. Configure the host authentication settings that restrict the personal computers (IP addresses) that can access the unit. z Setting status „...

  • Page 113: Network Setup Screen [Network]

    Web screen configurations (continued) z IPv4 network „ Network setup screen [Network] Configure network settings in the Network setup screen. DHCP [On, Off] The Network setup screen [Network] consists of [Network] and Select the method in which the IP address is configured. [Advanced].
  • Page 114 Web screen configurations (continued) z IPv6 network z Common (to IPv6/IPv4) „ „ Manual [On, Off] HTTP port [1 to 65535] Enable or disable manual configuration of the IPv6 address. Port numbers are allocated separately. The following port numbers are used by the unit so they cannot be Enter the IPv6 address manually.
  • Page 115 Web screen configurations (continued) Easy IP Setup accommodate period Recommended network setting for internet [20min, Unlimited] Perform the recommended settings to connect the camera to the Internet. Select [20min] or [Unlimited] as the time for enabling the operation of When the [Execute] button is clicked, a dialog box will be displayed. the network settings from the Easy IP Setup Software.
  • Page 116 Web screen configurations (continued) Advanced network setting screen [Advanced] z NTP „ „ „ Settings relating to the NTP server address and port No. are performed Click the [Advanced] in the network setup screen [Network]. here. Settings relating to the NTP, UPnP and HTTPS functions are performed The setting is confirmed with the [Set] button.
  • Page 117 Web screen configurations (continued) z UPnP z HTTPS „ „ This unit supports UPnP (Universal Plug and Play). Using the UPnP Using the HTTPS function enables access to the camera to be function allows the following to be set automatically. encrypted and communication safety to be improved.
  • Page 118 Web screen configurations (continued) CA Certificate ‑ Generate Certificate Signing Request HTTPS port [1 to 65535] When using a security certificate issued by the Certificate Authority This sets the Port No. to be used with HTTPS. (CA) as a security certificate for HTTPS, a Certificate Signing Request The following port numbers are used by the unit so they cannot be (CSR) is generated for application to the Certificate Authority (CA).
  • Page 119 Web screen configurations (continued) z RTSP z SNMP „ „ This performs settings related to the RTSP function. The RTSP function Make SNMP functionality related settings. You can check the status of sets the RTSP transmission port and RTSP request URL used during IP the unit by using the SNMP manager to connect.
  • Page 120 Web screen configurations (continued) System name z Referrer check „ Enter the device name used to manage this unit using SNMP By enabling Referrer check, you can confirm that the device requesting functionality. access to the camera is legitimate. Access is refused if it is determined that the device attempting access is Maximum number 1 to 32 characters unauthorized.
  • Page 121 Makes settings for the client certificate method used with TLS Alphanumeric characters, symbols : - be entered authentication. Factory settings: panasonic-ptz This unit supports the PEM and PKCS#12 methods. <NOTE> <NOTE> • Proper operation cannot be guaranteed if there is another camera with •...
  • Page 122 Web screen configurations (continued) PEAP Makes settings for when the PEAP authentication method is used. User name Sets a user name permitted by PEAP authentication. <NOTE> • Consult the network administrator regarding valid user names. Password Sets the password attached to the User name in PEAP authentication. <NOTE>...
  • Page 123 Web screen configurations (continued) HTTPS settings [HTTPS] „ „ This encrypts access to the camera and sets HTTPS to improve communication safety. Setting HTTPS is performed by following the procedures below. The setting is confirmed with the [Set] button. 1. Generating a CRT key (SSL encryption key) (→...
  • Page 124 Web screen configurations (continued) Generating a CRT key (SSL encryption key) Generating a self‑signed certificate (security „ „ „ „ [CRT key generate] certificate) <NOTE> [Self‑signed Certificate ‑ Generate] • A CRT key cannot be generated when self-signed certificates and <NOTE>...
  • Page 125 Web screen configurations (continued) Click the [OK] button after inputting the address. Click the [Execute] button in [CA Certificate ‑ Generate A self-signed certificate is generated. Certificate Signing Request]. <NOTE> The [CA Certificate - Generate Certificate Signing Request] dialog is •...
  • Page 126 Web screen configurations (continued) Installing a Server Certificate Setting the Connection Method „ „ „ „ [CA Certificate ‑ CA Certificate install] [Connection] <NOTE> • A server certificate (security certificate) cannot be installed if a Set the method to access the camera in [Connection]. Certificate Signing Request (CSR) has not been generated.
  • Page 127 Web screen configurations (continued) z Install the security certificate Click [Certificate error] in the URL and then click [View „ When using HTTPS to access the camera, the security warning certificates]. screen will be displayed if the security certificate of the said camera has not been installed in your personal computer.
  • Page 128 Web screen configurations (continued) Select [Place all certificates in the following store] and Click [Finish]. click [Browse...]. Click [Yes]. Select [Trusted Root Certification Authorities] and click [OK]. Click [Next]. When importing is finished, the “The import was successful.” screen is displayed. Click [OK].

  • Page 129: Maintenance Screen [Maintenance]

    Web screen configurations (continued) [Error log] Maintenance screen [Maintenance] Among the various maintenance operations performed on this screen Displays the log sequence numbers. are system log checks, system version upgrading and initialization of the “1” indicates the latest information, and up to 32 logs can be saved. unit.
  • Page 130 Web screen configurations (continued) Product information screen [Product info.] FPGA „ „ The versions of the unit’s software can be checked on this screen. Display the FPGA version for communications. The [Model no.], [MAC address], [Serial no.], [Firmware version] and other information about the unit is displayed.
  • Page 131 - All settings under [Network - Network] check the precautions to be observed, and follow the instructions. - [HTTPS - Connection] • Use the following files specified by Panasonic Connect Co., Ltd. as the - [HTTPS - HTTPS port] software used for version upgrading.
  • Page 132 Web screen configurations (continued) Back up screen [Backup] Upload „ „ Config data type On this screen, the unit’s settings can be saved to a personal computer [Camera(ALL), Camera (SCENE1) to Camera (SCENE4), Camera or settings saved in a personal computer can be loaded into the unit for (SYSTEM), Network] use.

  • Page 133: Displaying The Web Screen Using A Personal Computer Equipped With A Touch Panel

    Displaying the web screen using a personal computer equipped with a touch panel PTZ operation screen for touch panels „ „ Button for restoring the screen from the touch panel operation screen Press this button to return to the usual live screen. Buttons for switching the touch panel operation screen Button for displaying the PTZ operation screen for touch Use these to switch the [PTZ]/[Preset]/[Image adjust] operation...
  • Page 134 Displaying the web screen using a personal computer equipped with a touch panel (continued) Preset operation screen for touch panels Image adjust operation screen for touch panels „ „ „ „ Preset operation area for touch panels Image adjust operation area for touch panels This is the area where buttons for preset operations are located that This is the area where buttons for iris, gain, balance adjustments, are suitable for use with touch panels.

  • Page 135: Displaying The Web Screen Using A Mobile Terminal

    Displaying the web screen using a mobile terminal It is possible to perform operations using a design suited to mobile terminals in the live screen in a web browser. Access the unit from the mobile terminal. As when accessing the unit from a personal computer, enter [http://IP address/] in the address bar of the web browser on the mobile terminal. The screen for mobile terminals is displayed automatically.
  • Page 136 Displaying the web screen using a mobile terminal (continued) Button for displaying the operation menu for the live Home button screen Move to the preset home position. Use this to display the operation menu for the live screen. Preset thumbnail operation area When a preset thumbnail is clicked, the camera moves to face towards a preset position that was registered beforehand.

  • Page 137: Limiters

    Limiters This unit comes with settings (referred to as “limiters”) that restrict the panning and tilting movement ranges. Depending on the installation location, obstacles that may come into contact with the remote camera may exist within its movement range. In such cases, setting the limiters before the obstacles will prevent contact.

  • Page 138: Setting/Releasing The Limiters

    Setting/releasing the limiters Basic limiter operations Releasing the limiters Press the <MENU> button. The limiter positions that are set can be released by following the steps below. Tap the button (rather than pressing it). When it is pressed for 2 When the position is released, the tally lamp blinks twice.

  • Page 139: Safe Mode

    Safe mode Concerning the safe mode The unit goes into the safe mode when the pan-tilt head is forcibly moved by an external force or when something impedes its rotation. Once the safe mode has been established, some or all of the operations will no longer be acknowledged to ensure safety and prevent equipment damage.

  • Page 140: Troubleshooting

    – – – → For details on upgrading, visit the support page on the following website. https://pro-av.panasonic.net/ • Has the stand‑alone (Desktop) installation setting been selected correctly? page 60, page 87 The unit turns in the opposite •...
  • Page 141 Troubleshooting (continued) Symptom Cause and solution Reference pages • Has a LAN cable of category 5e or above been connected to the LAN connector Installation Instructions for IP control <LAN LINK/ACT>? → “Connections” • Is the [LINK] LED of the LAN connector for IP control lit? →...
  • Page 142 Troubleshooting (continued) Symptom Cause and solution Reference pages For Windows: • Press the [F5] key on the keyboard of the personal computer to request that the settings be acquired. – – – For Mac: • Press the [Command] + [R] key on the personal computer's keyboard to request that the settings be acquired.
  • Page 143 Troubleshooting (continued) Symptom Cause and solution Reference pages • Is the [Status Lamp] setting set to [Disable]? Status display lamp does not light → If [Status Lamp] is set to [Disable], the status display lamp does not light when this page 59, page 87 unit is working properly.
  • Page 144 Troubleshooting (continued) Video „ „ Symptom Cause and solution Reference pages Installation Instructions • Has the unit been connected properly to the other connected devices? → “Connections” • If the system is configured in such a way that the picture is also switched when page 30 the unit to be operated is selected, has the correct unit been selected? No pictures are displayed or the...
  • Page 145 Troubleshooting (continued) Symptom Cause and solution Reference pages • Activate the ATW (Auto tracking white adjustment) function. page 38 Something is wrong with the • In some situations, the proper colors may not be reproduced using the ATW coloring of the pictures function.
  • Page 146 Troubleshooting (continued) IP images „ „ Symptom Cause and solution Reference pages For Windows: • Is the plug‑in viewer software installed? page 27 → Install the plug‑in viewer software. For Windows: • If [Check for newer versions of stored pages] is not set to [Every time I visit the webpage] in the temporary Internet file settings, IP images may not appear in the Images are not displayed live screen [Live].
  • Page 147 Troubleshooting (continued) Symptom Cause and solution Reference pages • If the “Network Camera View 4S” plug-in viewer software is deleted in an environment where the “Network Camera View 3” plug-in viewer software is installed, display of H.264 images will become impossible. –...
  • Page 148 "This website wants to run the • Select [Allow]. – – – following add‑on: 'WebVideo Module' from 'Panasonic System Networks Co., Ltd.'." The following message appears in the information bar. "This website wants to install the • Select [Install]. When the security warning window appears, click the [Install] –...

  • Page 149: Specifications

    (8-3/8 inches × 10-1/2 inches × 8-5/8 inches) • Sampling frequency: ( excluding protrusions, direct ceiling mount bracket) 48 kHz • Quantization bit rate: Finish: AW-HE145WP/AW-HE145WE: Pearl white 24bit (SDI, HDMI), 16bit (IP) AW-HE145KP/AW-HE145KE: Black FUNCTIONS AND PERFORMANCE Controller supported: „...
  • Page 150 Specifications (continued) Standard sensitivity: Output format Shooting Mode [Normal] FHD SDI: [HD format] 1080/59.94p, 1080/50p, 1080/59.94i, 1080/50i, F9, 2000lx Shooting Mode [High Sens.] 1080/29.97p   , 1080/23.98p   , 1080/25p   , F12, 2000lx 1080/29.97PsF, 1080/23.98PsF, 1080/25PsF, 1080/24p   , 1080/23.98p  ...

  • Page 151: Index

    Index Numerics ×1.0 button ..................CA Certificate 3G SDI ............... CA Certificate install ............3G SDI Out ..................Generate Certificate Signing Request ......3G SDI OUT connector ............... Information ................802.1X ....................CA Certificate install ................3200K ....................Camera ................5600K ....................
  • Page 152 Index (continued) Home button ..................Horizontal Phase ..............Horizontal phase adjustment ............... EAP authentication method ............... Host auth................... Easy IP Setup accommodate period ..........Host IP address ................. Easy IP Setup Software ............... Hour Meter ..................Easy IP Setup Tool Plus ..............HTTP max segment size (MSS) ............
  • Page 153 Index (continued) Plain text usage ................. Plugin Power ................. Plug-in viewer software ............... MAC address ..................Power ....................Main area ..................... Power ON .................... Main/Network ................ Power On Position ................. Maintenance ................. Preset ..............Manual ..................Preset Acceleration ..............Manual shooting .................. Preset Digital Extender ..............
  • Page 154 Index (continued) Shooting ..................Shooting mode ..................Shooting Mode ............... VAR ..................... Shutter ....................V Detail Level ................Shutter Mode ................Ventilation holes .................. Shutter speed ..................Video over IP ..................Skin Detail ................... Video Sampling ................Skin Detail Effect ................. Viewer software installation counter ..........
  • Page 155 MEMO...
  • Page 156 Panasonic Connect Co., Ltd. Web Site: https://pro-av.panasonic.net/en/ © Panasonic Connect Co., Ltd. 2021 - 2022...

This manual is also suitable for:

Aw-he145kpAw-he145weAw-he145keAw-he145wpj

Table of Contents
