4.10 Test Print,
cont'd.
Nozzle check test label #1.
Nozzle check test label #2.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
. Press the <Cursor right> key to bypass this option.
10
NOZ.CHK.PATTERN
. Press the <Enter> key.
11
EXPANDING DATA
NOW CLEANING
. Wait for 1 – 2 minutes, the the printing starts.
12
PRINTING
. The printer will produce two different test labels. One shows
13
printouts of the fonts installed in the printer, while the other label
is used to check if any nozzle is out of order.
When the printing is completed, the display shows:
TEST PRINT
. Press the <Menu> key twice until the display shows:
14
OFF LINE
. After the test printing operation is completed...
15
• evaluate the test labels (see chapter 4.11),
• adjust the position of the vertical and horizontal registers (see
chapter 4.12), and
• adjust the stop position (see chapter 4.13).
Chapter 4
Installation
28
