Summary of Contents for Zeiss Transillumination top 450 mot.
- Page 3 You have purchased a high quality product from Zeiss. Before using the instrument the first time, please read this operating manual in order to maintain the high quality of the instrument and ensure reliable work with it for a long time.
- Page 4 Persons in contravention of this copyright shall be liable to pay compensation for damages. All rights reserved in the event of a patent grant or registration of a utility patent. Published by: Carl Zeiss Microscopy GmbH Carl-Zeiss-Promenade 10 07745 Jena, Germany microscopy@zeiss.com www.zeiss.com/microscopy...
-
Page 5: Table Of Contents
CONTENTS Transillumination top 450 mot. Carl Zeiss CONTENTS Page INTRODUCTION ......................6 General information ....................... 6 Notes on instrument safety .................... 7 Notes on warranty ......................8 DESCRIPTION ....................... 9 Indication for use ......................9 Package check list with accessories ................. 9 Microscope system with transillumination top 450 mot. -
Page 6: Introduction
INTRODUCTION Carl Zeiss General information Transillumination top 450 mot. INTRODUCTION General information The transillumination top 450 mot. has been designed, manufactured and tested in compliance with DIN EN 61010-1 (IEC 61010-1) and IEC 61010-2-101 Safety requirements for electrical equipment for measurement, control and laboratory use. -
Page 7: Notes On Instrument Safety
If it is determined that protective measures are no longer effective, the instrument must be switched off and secured against inadvertent operation. Please contact a Zeiss service agency or the Carl Zeiss Microscopy Service to repair the instrument. -
Page 8: Notes On Warranty
With the exception of the work described in this operating manual, no maintenance or repair work is to be carried out on these microscopes. Repairs may only be performed by Carl Zeiss service staff or personnel specifically authorized by Carl Zeiss. In the event of a problem with the instrument, please contact the Carl Zeiss microscopy service team or your local Carl Zeiss overseas representative. -
Page 9: Description
DESCRIPTION Transillumination top 450 mot. Indication for use Carl Zeiss DESCRIPTION Indication for use In conjunction with the selected microscope the transillumination top 450 mot. is for examining translucent preparations by the transmitted light process. Package check list with accessories Name/Order No. -
Page 10: Microscope System With Transillumination Top 450 Mot
DESCRIPTION Carl Zeiss Microscope system… Transillumination top 450 mot. Microscope system with transillumination top 450 mot. Axio Zoom.V16 microscope system A Microscope body (Axio Zoom.V16) with control unit (HIP) B Binocular photo tube C Eyepiece D Objective E Nosepiece Intermediate tube (Fluar Illuminator Z mot.) -
Page 11: Technical Data
DESCRIPTION Transillumination top 450 mot. Mounting the … Carl Zeiss Technical data Dimensions Transillumination top 450 mot. (length x width x height) ........595 mm x 342 mm x 86 mm Weight (shipping contents without packaging) Transillumination top 450 mot....................... 4.74 kg Power supply Separate power supply ...................... -
Page 12: Set-Up
SET-UP Carl Zeiss Connecting the Transillumination top 450 mot. SET-UP General information Read the Notes on instrument safety carefully prior to set-up and operation (see Section 1.2, page 7). The transillumination top 450 mot. is normally delivered together with the required tools and optional accessories in several packages. - Page 13 SET-UP Transillumination top 450 mot. Mounting the … Carl Zeiss • Switch off the Axio Zoom.V16 microscope and illumination. • Remove the base insert plate (Fig. 2/1). To do this loosen the short socket head screws (Fig. 2/2), lift the insert plate (use recessed grip (Fig. 2/4) on the right edge of stand base for the purpose) and lift securely with both hands.
-
Page 14: Connecting The Transillumination Top 450 Mot
SET-UP Carl Zeiss Connecting the Transillumination top 450 mot. Connecting the transillumination top 450 mot. Connecting to the microscope system • Use the CAN cable RJ 45 to connect the CAN (Fig. 4/3) socket of the transillumination top to one of the CAN sockets on the rear side of the focusing motor 3 (Fig. -
Page 15: Operation
Operation Transillumination top 450 mot. Control elements Carl Zeiss OPERATION In addition to lighting control, the illumination method can also be selected, varies and saved at the touch of a button with the transillumination top 450 mot. Control elements LED SYCOP Control (Fig. 5/1): −... - Page 16 Operation Carl Zeiss Control elements Transillumination top 450 mot. Best Mode button − Depending on the optical configuration of the microscope, in illumination methods BF, BF+ and RC the method that delivers the best results in terms of contrast and homogeneity is automatically set.
-
Page 17: Switching On
Operation Transillumination top 450 mot. Switching on Carl Zeiss Switching on Adjust the antiglare shield correctly to avoid eye injuries. The position of the limit switch for the focusing drive must be checked prior to the first-time use of the transmitted illumination adapter and reset if necessary (see AxioZoom.V16 operating manual, Section Adjusting the range of travel of the motorized focusing drive) to avoid collisions during the focusing movement. -
Page 18: Troubleshooting
Operation Carl Zeiss Troubleshooting Transillumination top 450 mot. Troubleshooting Error description Error cause Remedy No image visible. Transillumination top not switched Switch the transillumination top on by the on /off switch (rear side). The shutter is closed. Press the Shutter key. The shutter is closed when the integral LED is lit.
