General Information

LED Status

A Status LED
B Relay LEDs
Relay Pairing
C
LEDs
WiFi / Ethernet
D
Status LED
G Grid State LED
4
Off No power is available to the unit.
Relay or unit is not operating normally. See
Red
more information.
Flashing Orange Mode Selector Knob is not in normal position.
Unit is powered by the PWRcell system and no issues are
Blue
detected.
Green Unit is powered by the grid and no issues are detected.
Off Relay is open.
Green Relay is closed (load is enabled).
Relay is not operating normally and remained in its last state
Red
(closed or open). See
Off Relays not paired.
Green Relays are paired as 240 V circuit.
Relays are paired, but at least one relay is not operating normally.
Red
See
Green Connected to Generac server.
Unit is either connected to the Internet using local WiFi or Ethernet
Blue
connection, but it is not connected to the Generac server.
Flashing Blue Connecting to local router via WiFi.
Red Unable to connect to local router or Internet.
Flashing Green Access Point (AP) mode broadcasting.
Green Grid power is available. Unit is powered by grid.
Blue Grid power is not available. Unit is powered by PWRcell system.
Orange Grid status is unknown.
Troubleshooting
Troubleshooting for more information.
Owner's Manual for Generac PWRmanager 12 Relay Load Controller
for
Troubleshooting
for more information.
