OPERATION AND PARTS MANUAL
GloBug SERIES
GB3LED (Tripod with Lamp)
SERIAL NO. G3200105 AND ABOVE
GB3LEDB (Lamp Only)
SERIAL NO. G3300046 AND ABOVE
Revision #0 (07/09/15)
www.discount-equipment.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading

Related Manuals for MULTIQUIP G3200105

Summary of Contents for MULTIQUIP G3200105

  • Page 1 OPERATION AND PARTS MANUAL GloBug SERIES GB3LED (Tripod with Lamp) SERIAL NO. G3200105 AND ABOVE GB3LEDB (Lamp Only) SERIAL NO. G3300046 AND ABOVE Revision #0 (07/09/15) www.discount-equipment.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 One of our experienced staff members will get back to you with a quote for the right part that your machine needs. We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mayco, Toro/Stone, Diamond Products, Magnum, Airman, Mustang, Power Blanket, Nifty Lift, Atlas Copco,...

  • Page 3: Table Of Contents

    GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15) — PAGE 3...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS GB3LED/B LIGHTING SYSTEM Component Drawings Nameplate And Decals ........30-31 Table Of Contents ............ 4 Electrical Assy........... 32-33 Parts Ordering Procedures ........5 Tripod Assy............34-35 Safety Information ..........6-9 Mast Assy............36-37 Specifications ............10 Dimensions ............

  • Page 5: Safety Information

    SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 6  NEVER use accessories or attachments that are not  NEVER operate this equipment when not recommended by Multiquip for this equipment. Damage feeling well due to fatigue, illness or when to the equipment and/or injury to user may result.
  • Page 7 SAFETY INFORMATION LIGHTING SYSTEM SAFETY NOTICE WARNING  NEVER leave any grease or oil residue on lamp surface when replacing or removing lamp. This can create hot  NEVER disconnect any emergency or safety devices. spots, reducing the service life of the lamp. These devices are intended for operator safety.
  • Page 8 SAFETY INFORMATION BALLOON SAFETY ELECTRICAL SAFETY WARNING DANGER  To prevent serious burns, NEVER touch  Lighting system is equipped with a ground pin on the or unzip the balloon envelope when the power plug. For your protection, ALWAYS complete the lamp is on.

  • Page 9: Specifications

    SPECIFICATIONS Table 1. Specifications Globug Lighting System Model GB3LED Input Voltage 100 VAC Frequency 50 Hz/ 60 Hz Max. Current 3.3 Amps (100 V @300 W) Lamp Fixture 18.74 lb (8.5 kg) Mast 4.85 lb (2.2 kg) Tripod 12.13 lb (5.5 kg) Weight Balloon Cover 1.32 lb (0.6 kg)

  • Page 10: Dimensions

    DIMENSIONS Figure 1. Dimensions (GB3LED) Table 2. Dimensions Reference Reference Dimension in. (mm.) Dimension in. (mm.) Letter Letter Upper Position - 44.7 in. (1,135 mm.) 33.5 in. (850 mm.) Lower Position - 52.4 in. (1,330 mm.) Upper Position - 52.2 in. (1,325 mm.) 21.1 in.

  • Page 11: Illumination Range

    ILLUMINATION RANGE tripod 1st Stage Two stage mast 20ft tripod 2nd Stage Two stage mast 20ft Figure 2. Illumination Range (Foot Candles) PAGE 12 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)

  • Page 12: General Information

    GENERAL INFORMATION TRANSPORT The Multiquip GloBug GB3LED is a general purpose, portable, glare-free lighting systems Typical applications for The GB3LED lighting system can be transported (Figure 3) these types of lighting systems include construction sites, quite easily in two carrying cases.

  • Page 13: Components

    COMPONENTS COVER CARRYING CASE Figure 4. Major Components PAGE 14 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)
  • Page 14 COMPONENTS 7. Tripod — Unbuckle velcro strap securing tripod legs Figure 4 shows the location of the components for the GloBug lighting system. The function of each component (3), push down on any tripod leg until all tripod legs is described below: are fully deployed.

  • Page 15: Setup

    SETUP TRIPOD DEPLOYMENT 1. Place the tripod on a firm level surface so that it will not slide or turn over. Make sure there is enough space around the unit for the tripod legs to be deployed. 2. Remove tripod from its carrying case. The tripod legs are secured by a black velcro strap (Figure 5).
  • Page 16 SETUP BALLOON ASSEMBLY PLACEMENT 3. Next, fold the protective cover (Figure 10) into itself and zip. 1. Place balloon assembly (Figure 8) onto mast and tighten Upper T-handle. PROTECTIVE COVER ZIPPER UPPER T-HANDLE MAST PROTECTIVE COVER LOWER T-HANDLE Figure 10. Folding Protective Cover 4.
  • Page 17 SETUP RAISING THE MAST 5. To improve stability and to prevent tipping of the light unit, place sand bags or similar type weight over the Before raising the mast, make sure the upper T-handle bolt tripod legs or weight hook as shown in Figure 12. lock (Figure 12) is securely tightened.

  • Page 18: Operation

    OPERATION APPLYING POWER 2. Zip up the bottom of the balloon completely after use of the dimmer switch. 1. Connect the AC power cable to the 120 VAC receptacle SILENT MODE on the generator used. See Figure 13. 120 VAC Noise coming from the unit during operation can be RECEPTACLE eliminated.
  • Page 19 OPERATION STORAGE 4. Unhook lamp AC power cable from washer eyelet (Figure 11). Fully zip protective cover and fold velcro 1. Loosen the lower T-handle by turning handle tab in place (Figure 18). counterclockwise (Figure 16). Push down on mast until mast is fully inserted into mast housing.
  • Page 20 OPERATION 7. To retract tripod legs (Figure 20) and place in the 9. Place tripod (Figure 22) inside protective carrying case. stow position, lift up on mast while pulling up on the velcro strap. Continue pulling upward on the mast until the tripod legs are fully retracted and are in the stow PROTECTIVE position.

  • Page 21: Maintenance

    3. Slide the new balloon (Figure 25) envelope over the top of the lamp guard assembly. NOTICE BALLOON LAMP Contact Multiquip Technical Support Department for ENVELOPE GUARD assistance in replacing LED lamps. REPLACING BALLOON ENVELOPE 1. Unzip the zipper (Figure 38) at the top and bottom of the balloon envelope (cover).
  • Page 22 MAINTENANCE FILTER REPLACEMENT 6. Turn the three locking tabs inwards to lock the air plate in place. See Figure 29. 1. Remove the balloon as described in the STORAGE section. 2. Turn the balloon/lamp assembly upsidedown to access the filter. See Figure 27. LOCK TAB AIR PLATE LOCKING...
  • Page 23 MAINTENANCE Figure 30. Maintenance Check Points PAGE 24 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)
  • Page 24 MAINTENANCE For a prolonged life cycle an extended quality follow the recommended GloBug lighting system service guidelines as referenced in Figure 30 and Table 3. Table 3. Periodic Check and Maintenance Figure Part Check Item Solution Lamp Guard Dirty, rusty or damaged? Clean/Replace Lamp LED Lamp...

  • Page 25: Wiring Diagram

    WIRING DIAGRAM Dimmer Switch Indicator Lamp Figure 31. Electrical Wiring Diagram PAGE 26 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)

  • Page 26: Troubleshooting

    TROUBLESHOOTING Troubleshooting Symptom Possible Problem Solution Is plug connected? Plug in correctly. Is generator’s main switch turned off? Turn on switch. Are any wire cables disconnected? Connect disconnected wire cable. Are any other electric appliances Lamp does not light. (other than light tower) plugged into Unplug all other appliances.

  • Page 27: Explanation Of Code In Remarks Column

    A blank entry generally indicates that the item is not sold assembly/kit that can be purchased, or is not available separately or is not sold by Multiquip. Other entries will for sale through Multiquip. be clarified in the “Remarks” Column.

  • Page 28: Suggested Spare Parts

    SUGGESTED SPARE PARTS GLOBUG LIGHTING SYSTEM 1 TO 3 UNITS Qty. Description 3....A300260400 ..LED HEATSINK ASSY 2....A100015901 ..BALLOON CLOTH GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15) — PAGE 29...

  • Page 29: Nameplate And Decals

    NAMEPLATE AND DECALS ★LIGHT CONTROL Push the button. (300W→200W→100W→OFF) ★SILENT MODE Push the button for 2 seconds. A-4003409-01 CAUTION / ATTENTION ・AC ONLY ・SUITABLE FOR WET LOCATIONS ・DO NOT SUBMERSE ・C.A. SEULEMENT ・CONVIENT AUX EMPLACEMENTS MOUILLÉS ・NE PAS IMMERGER A-4003250-01 Upper position Lower...
  • Page 30 NAMEPLATE AND DECALS PART NO. PART NAME QTY. REMARKS A400325101 DECAL; ELECTRIC SHOCK/BURN A400340901 DECAL; LIGHT CONTROL A400325001 DECAL; CAUTION, CSA A400287600 DECAL; DIMMER SWITCH LEDS A400324801 DECAL; MAST A400166701 DECAL; HOOK LATCH (ENGLISH) A400324100 DECAL; HOOK LATCH (FRENCH) A400194100 DECAL;...

  • Page 31: Electrical Assy

    ELECTRICAL ASSY. PAGE 32 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)
  • Page 32 ELECTRICAL ASSY. PART NO. PART NAME QTY. REMARKS A300260400 LED HEATSINK ASSY A100015901 BALLOON CLOTH CP 0014808025 BUTTON SCREW (M8x25) A300257000 PLATE (TOP) A300162400 SEAL (PACKING) A100106100 BALLOON COVER (BLACK-LED) CP A300160301 SHEET (TOP) CP 2214500230 SEAL (FLAT) A300238101 VESSEL (TOP) A300280600 FAN MOTOR ASSY A300281401...

  • Page 33: Tripod Assy

    TRIPOD ASSY. PAGE 34 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)
  • Page 34 TRIPOD ASSY. PART NO. PART NAME QTY. REMARKS A300131500 TRIPOD CASE A300171601 PIPE (BASE) A300113103 STAY A300199600 BASE PIPE 2 A300199500 BASE PIPE 1 A400205901 SPRING (SHACKLE) A300108700 SHACKLE CP 1641000330 RUBBER FOOT A300106500 TRIPOD BAND 2212780310 LEVER 0043108000 WASHER (M8) 0033206000 SELFLOCK NUT (M6) GB3LED/B LIGHTING SYSTEM •...

  • Page 35: Mast Assy

    MAST ASSY. PAGE 36 —GB3LED/B LIGHTING SYSTEM • OPERATION AND PARTS MANUAL — REV. #0 (07/09/15)
  • Page 36 MAST ASSY. PART NO. PART NAME QTY. REMARKS A300200300 FIRST MAST (φ45*1050) ASSY SECOND MAST (φ38*1200) ASSY A300200600 A400187601 KNOB A400229900 BOTTOM PLATE (φ33.6) 0024705008 SET SCREW (M5x8) A400092801 WASHER (SECOND MAST) A400200700 RUBBER (MAST) A400110200 WASHER (MAST) 1 A400200500 WASHER (M8) 0013108030 BOLT (M8x30)
