OPERATION AND PARTS MANUAL
GloBug
MODELS GB12BW/BS/BP
LIGHTING SYSTEM
Revision #2 (11/03/08)
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading

Related Manuals for MULTIQUIP GLOBUG GB12BW

Summary of Contents for MULTIQUIP GLOBUG GB12BW

  • Page 1 OPERATION AND PARTS MANUAL GloBug MODELS GB12BW/BS/BP LIGHTING SYSTEM Revision #2 (11/03/08) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

  • Page 2: Table Of Contents

    @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MQ GLOBUG LIGHTING MQ GLOBUG LIGHTING COMPONENT DRA COMPONENT DRA WINGS WINGS MQ GLOBUG LIGHTING MQ GLOBUG LIGHTING MQ GLOBUG LIGHTING COMPONENT DRA COMPONENT DRAWINGS COMPONENT DRA WINGS WINGS SYSTEM SYSTEM SYSTEM SYSTEM SYSTEM Nameplate and Decals Assembly ...... 34-35 Table Of Contents .............

  • Page 4: Mq Globug Lighting

    GB12BW/BS/BP LIGHTING SYSTEM — SAFETY MESSAGE ALERT SYMBOLS Potential hazards associated with any of the GloBug FOR YOUR SAFETY AND THE SAFETY OF OTHERS! Lighting Systems operation will be referenced with Hazard Safety precautions should be followed Symbols which appear throughout this manual, and will be at all times when operating this referenced in conjunction with Safety Message Alert equipment.

  • Page 5: Rules For Safe Operation

    ■ NEVER use accessories or attachments, which are not recommended by Multiquip for this equipment. Damage to the equipment and/or injury to user may result. GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08) — PAGE 5...
  • Page 6 GB12BW/BS/BP LIGHTING SYSTEM — RULES FOR SAFE OPERATION ■ When transporting the tripod lighting system, always BALLOON SAFETY AND CARE place tripod in the stow position, then place tripod into ■ To prevent serious burns, NEVER touch or unzip the its carrying case.
  • Page 7 GB12BW/BS/BP LIGHTING SYSTEM — RULES FOR SAFE OPERATION Maintenance Safety DANGER - Electric Shock Hazards ■ NEVER lubricate components or attempt service on any ALWAYS keep electrical cords in good condition. Worn, running GloBug lighting system. bare or frayed wiring can cause electrical ■...

  • Page 8: Specifications

    GB12BW/BS/BP LIGHTING SYSTEM — SPECIFICATIONS i f i o i t i t h a t l a l l c e l o r t c i n s a l e r r t t a l a t i l a ) °...

  • Page 9: Dimensions (Gb12Bw)

    GB12BW/BS/BP LIGHTING SYSTEM — DIMENSIONS (GB12BW) Figure 1. Dimensions (GB12BW) r e f r e f . n i . n i r e t r e t . n i . n i . n i . n i .

  • Page 10: Dimensions (Gb12Bs)

    GB12BW/BS/BP LIGHTING SYSTEM — DIMENSIONS (GB12BS) Figure 2. Dimensions (GB12BS) r e f r e f . n i . n i r e t r e t . n i . n i . n i . n i .

  • Page 11: Dimensions (Gb12Bp)

    GB12BW/BS/BP LIGHTING SYSTEM — DIMENSIONS (GB12BP) Figure 3. Dimensions (GB12BP) r e f . n i r e t . n i . n i GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08) — PAGE 11...

  • Page 12: Floodlight Footcandle Plot

    GB12BW/BS/BP LIGHTING SYSTEM — FOOTCANDLE PLOT 360 degree coverage Values listed as footcandles Scale: Grid = 50 ft. (15.25 meters) Figure 4. Floodlight Footcandle Plot (BAL 85-Drum Shaped) PAGE 12 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)

  • Page 13: General Information

    GB12BW/BS/BP LIGHTING SYSTEM — GENERAL INFORMATION The Multiquip GloBug GB12W, GB12BS and GB12BP are general purpose portable glare-free lighting systems. Typical applications for these types of lighting systems include construction sites, emergency road crews and backyard parties. Balloon Envelopes The GloBug lighting system can be configured with a variety of balloon envelopes (canopy).

  • Page 14: Major Components

    GB12BW/BS/BP LIGHTING SYSTEM — COMPONENTS COVER CARRYING CASE GB12BP GB12BW GB12BS Figure 7. Major Components PAGE 14 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 15 GB12BW/BS/BP LIGHTING SYSTEM — COMPONENTS 9. Lamp Guard – This guard (cage) protects the lamp from Figure 7 shows the location of the components for the GloBug being hit by objects. lighting system. The function of each component is described below: 10.
  • Page 16 GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BW) CAUTION - READ MANUAL Please read this entire manual carefully before attempting to operate any of the GloBug Lighting Systems referenced in this manual. Failure to read this manual could cause damage to the equipment and serious bodily injury to the operator.
  • Page 17 GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BW) 3. Next, fold the protective cover (Figure 13) into itself and Balloon Assembly Placement (GB12BW) zip. 1. Place balloon assembly (Figure 11) onto mast and tighten Upper T-handle. PROTECTIVE ZIPPER COVER UPPER PROTECTIVE...
  • Page 18 GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BW) 5. Attach the S-type hook (Figure 15) on the AC power 2. To improve stability and to prevent tipping of the light cable onto the washer-eylet located on the bottom plate unit, place sand bags or similar type weight over the of the light assembly.

  • Page 19: Operation (Gb12Bw)

    GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — OPERATION (GB12BW) Applying Power (GB12BW) 3. Disconnect lamp power connector (Figure 18) from the AC power cable. 1. If using a portable generator, start the generator as referenced in the "Start-up Section" of the supplied generator manual.
  • Page 20 GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — STORAGE (GB12BW) LATCH ZIPPER MAST UPPER LOWER PROTECTIVE COVER Figure 20. Unzipping the Protective Cover 3. Un-hook lamp AC power cable from washer eyelet (Figure 15). Place the AC power cable inside the Figure 23. Retracting Tripod Legs protective cover (Figure 21).

  • Page 21: Setup (Gb12Bs)

    GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BS) The pole clamp assembly used 9. Using 17 mm wrench, tighten both bolts (M) on the offset in this setup procedure is a dual adapter clamp (K) securely. type clamp. One side of the NOTE 10.
  • Page 22 GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BS) Removing the Protective Covering (GB12BS) Connecting Power Cable (GB12BS) 1. Expose the balloon by pulling down on the velcro tab and 1. Connect 15 ft. (4.6 meters) AC power cable (Figure 29) unzipping the protective cover as shown in Figure 27. Also to the lamp power cable.

  • Page 23: Operation (Gb12Bs)

    GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — SETUP (GB12BS) Applying Power (GB12BS) Raising the Mast (GB12BS) 1. If using a portable generator, start the generator as 1. Before raising the mast, make sure the T-handle bolt referenced in the "Start-up Section" of the supplied lock (see Figure 26-O) is securely tightened.

  • Page 24: Maintenance

    GLOBUG GB12BW/BS/BP LIGHTING SYSTEM — MAINTENANCE 4. Roll the balloon envelope (Figure 33) upwards to expose CAUTION - READ SAFETY GUIDELINES the lamp. Before performing any maintenance procedures, be sure to READ the lamp, balloon, and general safety guidelines in...
  • Page 25 GLOBUG SOLO Jr. LIGHTING SYSTEM — MAINTENANCE 7. Remove lamp (Figure 36) from lamp scocket by turning 2. Slide the old or worn balloon envelope (Figure 39) over lamp in a counterclockwise direction. the top of the lamp guard assembly. BALLOON LAMP ENVELOPE...
  • Page 26 GB12BW/BS/BP LIGHTING SYSTEM — MAINTENANCE Filter Replacement 5. Install a new filter over the brace as shown in Figure 44. Be sure to align the cut of the filter over the brace. WARNING - HOT SURFACE (LAMP FRAME) BRACE DO NOT replace filter immediately, allow a FILTER sufficient amount of time for the lamp assembly to cool down before changing filter.
  • Page 27 GB12BW/BS/BP LIGHTING SYSTEM — MAINTENANCE (WIRING DIAGRAM) FAN MOTOR Figure 46. Electrical Wiring Diagram TABLE 5. REFERENCE DESIGNATIONS REF. DESCRIPTION PART NUMBER DESC. CABLE (MAIN-1A) CP A300135500 CABLE (MAIN-2A) CP A300135600 ELE-BALLAST (A-400W-Y)CP A300135300 Lamp WIRE CP A300075200 SOCKET ASSY. E000009601 400W (MH400/C/U) E000031700...
  • Page 28 GB12BW/BS/BP LIGHTING SYSTEM — MAINTENANCE GB12BP GB12BW GB12BS Figure 47. Maintenance Check Points PAGE 28 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 29 GB12BW/BS/BP LIGHTING SYSTEM — MAINTENANCE For a prolonged life cycle an extended quality follow the recommended GloBug lighting system service guidelines as referenced in Figure 47 and Table 6. ❖ y l e ❖ r o t c s i y l e ❖...

  • Page 30: Troubleshooting (Lamps)

    GB12BW/BS/BP LIGHTING SYSTEM — TROUBLESHOOTING (LAMPS) If the problem cannot be remedied, please leave the unit Practically all breakdowns can be prevented by proper just as it is and consult or company's service department. handling and maintenance inspections, but in the event of a breakdown, please take a remedial action following the diagnosis based on the Lamp Troubleshooting (Table 7) information shown below.

  • Page 31: Troubleshooting (Mast)

    GB12BW/BS/BP LIGHTING SYSTEM — TROUBLESHOOTING (MAST) Practically all breakdowns can be prevented by proper If the problem cannot be remedied, please leave the unit handling and maintenance inspections, but in the event of a just as it is and consult or company's service department. breakdown, please take a remedial action following the diagnosis based on the Mast Troubleshooting (Table 8) information shown below.

  • Page 32: Explanation Of Codes In Remarks Column

    A blank entry generally indicates that the item is not sold assembly/kit that can be purchased, or is not available for separately or is not sold by Multiquip. Other entries will be sale through Multiquip. clarified in the “Remarks” Column.

  • Page 33: Suggested Spare Parts

    GB12BW/BS/BP LIGHTING SYSTEM — SPARE PARTS GloBug LIGHTING SYSTEM 1 TO 3 UNITS Qty. Description 2 ..E000031700 ..BULB 2 ..A300135300 ..ELECTRICAL BALLAST 2 ..A100015901 ..BALLOON CLOTH GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08) — PAGE 33...

  • Page 34: Component Dra Component Drawings Component Dra Wings Nameplate And Decals Assembly

    GB12BW/BS/BP LIGHTING SYSTEM — NAMEPLATE AND DECALS NAMEPLATE AND DECALS. DANGER DANGER GloBug INFORMATION Make sure the power cable from the generator is To prevent tipping, NEVER use connected to the lamp in winds that exceed 16 mph power cable securely. ( 7 m/ sec).
  • Page 35 GB12BW/BS/BP LIGHTING SYSTEM— NAMEPLATE AND DECALS NAMEPLATE AND DECALS. PART NO. PART NAME QTY. REMARKS DCL1260 DECAL; DANGER, CAUTION, WARNING INFO. DCL1002 DECAL; DANGER, PIPE CLAMP DCL1261 DECAL; DANGER, ELECTRICAL SHOCK HAZ. WARNING, BURN HAZARD (LAMP) DANGER, HIGH VOLTAGE DCL1263 DECAL;...

  • Page 36: Mast/Tripod Assembly (Gb12Bw)

    GB12BW/BS/BP LIGHTING SYSTEM — MAST/TRIPOD ASSY. (GB12BW) MAST/TRIPOD ASSY. (GB12BW) PAGE 36 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 37 GB12BW/BS/BP LIGHTING SYSTEM — MAST /TRIPODASSY. (GB12BW) MAST/TRIPOD ASSY. (GB12BW) PART NO. PART NAME QTY. REMARKS A000019600 TRIPOD, ASSY..........1 ... INCLUDES ITEM W/ A200039900 TRIPOD, FOOT ONLY ........1 ... INCLUDES ITEM W/# A300106500 TRIPOD, BAND A300108700 SHACKLE, CP E000042900 BOLT, (M10 X 20) A000018700 LOW NUT, M10...

  • Page 38: Fan Blower/Lamp Base Assembly (Gb12Bp)

    GB12BW/BS/BP LIGHTING SYSTEM — FAN BLOWER/LAMP BASE ASSY. FAN BLOWER/LAMP BASE ASSY. (GB12BP) PAGE 38 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 39 GB12BW/BS/BP LIGHTING SYSTEM — FAN BLOWER/LAMP BASE ASSY. FAN BLOWER/LAMP BASE ASSY. (GB12BP) PART NO. PART NAME QTY. REMARKS 2214500130 SEAL, PACKING 2214500230 SEAL, FLAT 0043210000 WASHER, LOCK (M10) 0043110000 WASHER, FLAT A300135300 ELECTRICAL BALLAST 0023304055 SCREW AND WASHER (M4 X 55) A400074801 POLE JOINT, 1 A300063001...

  • Page 40: Balloon/Lamp Guard Assembly (Gb12Bp)

    GB12BW/BS/BP LIGHTING SYSTEM — BALLOON/LAMP GUARD ASSY. BALLOON/LAMP GUARD ASSY. (GB12BP) PAGE 40 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 41 GB12BW/BS/BP LIGHTING SYSTEM — BALLOON/LAMP GUARD ASSY. BALLOON/LAMP GUARD ASSY. (GB12BP) PART NO. PART NAME QTY. REMARKS E000031700 LAMP, MH400/C/U 2214420411 LAMP GUARD A100015901 BALLOON CLOTH, CP E000009601 SOCKET ASSY. 0025304025 SCREW AND WASHER (M4 X 25) 2214401230 FRAME PIPE A400071400 POLE JOINT, 2 00243040008...

  • Page 42: Offset Pole Assembly (Gb12Bs)

    GB12BW/BS/BP LIGHTING SYSTEM — OFFSET POLE ASSY. (GB12BS) OFFSET POLE ASSY. (GB12BS) PAGE 42 — GLOBUG LIGHTING SYSTEM — OPERATION AND PARTS MANUAL — REV. #2 (11/03/08)
  • Page 43 GB12BW/BS/BP LIGHTING SYSTEM — OFFSET POLE ASSY. (GB12BS) OFFSET POLE ASSY. (GB12BS) PART NO. PART NAME QTY. REMARKS A200019103 OFFSET POLE A200018303 ADAPTER (OFFSET PIPE) 0013512045 BOLT AND WASHER (M12X45) 0014210025 WING BOLT (M10X25) 0013510025 BOLT AND WASHER (M10X25) 0043110026 WASHER (M10) E000028100 17/19 MM WRENCH...
