- Page 1 AG250 Application Gateway Server Hardware Installation Guide Release 2.1 (Service Pack) 16-300260 Issue 2.1 April 2006...
- Page 2 • Mischief (troubling, but apparently innocuous, tampering) Warranty • Harm (such as harmful tampering, data loss or alteration, Avaya Inc. provides a limited warranty on this product. Refer to your regardless of motive or intent) sales agreement to establish the terms of the limited warranty. In Be aware that there may be a risk of unauthorized intrusions addition, Avaya’s standard warranty language as well as information...
-
Page 3: Table Of Contents
Contents Preface Audience Organization Conventions Related Documentation Installing the Application Gateway C H A P T E R Preparing for Installation Verifying the Box Contents Materials and Information Needed for Installation Locating Application Gateways in Your Enterprise Network Rack Mounting the Application Gateway Separating the Rail Sections Connecting the Chassis Rails to the Server Connecting the Rack Rails to the Rack... - Page 4 Contents Application Gateway Hardware Installation Guide...
-
Page 5: Preface
Preface This preface describes who should read the Application GatewayHardware Installation Guide, how it is organized, and its document conventions. Audience This installation guide is intended for service technicians who will install the Application Gateway and for administrators who need to troubleshoot the hardware. -
Page 6: Conventions
Conventions Conventions This guide uses the following conventions: Convention Description boldface font Commands and HTML element names are in boldface. Information you must enter is in boldface screen boldface screen font font. Notes use the following conventions: Means reader take note. Notes contain helpful suggestions or other Note important information. -
Page 7: Chapter 1 Installing The Application Gateway
Chapter 1 Chapter Installing the Application Gateway The Avaya Application Gateway Server is an appliance that transforms and delivers data and enhanced voice applications to a variety of microbrowser devices, including IP phones, Wireless Application Protocol (WAP) phones, and Personal Digital Assistants (PDAs). The Application... -
Page 8: Preparing For Installation
Locating Application Gateways in Your Enterprise Network, page 3 • Verifying the Box Contents The box in which your Application Gateway is shipped contains the following components. If something is missing, please contact support at http://www.avaya.com/support. Application Gateway device • Power cord •... -
Page 9: Materials And Information Needed For Installation
Chapter 1 Installing the Application Gateway Preparing for Installation Materials and Information Needed for Installation Before installing the Application Gateway, collect the following materials: One network cable to connect the Application Gateway to a LAN (two • cables are required if the Application Gateway will straddle two networks) A computer capable of hosting terminal console communication •... - Page 10 Chapter 1 Installing the Application Gateway Preparing for Installation Regardless of the network deployment chosen, the only requirements that must be met to ensure correct operation are as follows: The client devices (IP telephones; mobile devices) must be able to see •...
- Page 11 Chapter 1 Installing the Application Gateway Preparing for Installation Figure 2 Application Gateway Connected to Switch The switch is set up to direct requests for transformed applications according to browser type or requested URLs, as follows. Browser-detection routing • URL requests, which are the same from desktop and microbrowser users, are directed by the switch to an application server.
-
Page 12: Rack Mounting The Application Gateway
Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Rack Mounting the Application Gateway The enclosed rack-mounting kit can be used to install the Application Gateway in a four-post or two-post rack. Separating the Rail Sections The rack-mounting kit includes two sets of rail assemblies, two rail mounting brackets, and the mounting screws that you will need to install the system into the rack. -
Page 13: Connecting The Chassis Rails To The Server
Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Connecting the Chassis Rails to the Server Both chassis rails have a locking tab, which serves two functions. The first function is to lock the server into place when installed and pushed fully into the rack, which is its normal position. -
Page 14: Connecting The Rack Rails To The Rack
Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Connecting the Rack Rails to the Rack Determine where you want to place the server in the rack. Position the fixed rack rail/sliding rail guide assemblies (B) at the desired location in the rack, keeping the sliding rail guide facing the inside of the rack. - Page 15 Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you may have to depress the locking tabs when inserting). Refer to the illustration below. When the server has been pushed completely into the rack, you should hear the locking tabs click.
-
Page 16: Installing The Server Into A Two-Post Rack
Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Installing the Server into a Two-Post Rack If you are installing the server into a two-post (Telco) rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack. - Page 17 Chapter 1 Installing the Application Gateway Rack Mounting the Application Gateway Application Gateway Hardware Installation Guide...
-
Page 18: Installing The Application Gateway
Chapter 1 Installing the Application Gateway Installing the Application Gateway Installing the Application Gateway When installing the Application Gateway, refer to the following illustration for port locations. To install the Application Gateway: Install the Application Gateway in a rack (if rack-mounted). Connect the power cord to the AC power receptacle. -
Page 19: Configuring The Application Gateway For The First Time
Chapter 1 Installing the Application Gateway Configuring the Application Gateway for the First Time On the computer, start a terminal emulation application. For example, start HyperTerminal. When you create a connection using HyperTerminal, you will be prompted for Port Settings. Set the serial connection to 9600 bits per second, 8 data bits, no parity, and 1 stop bit;... -
Page 20: Third-Party Software
Chapter 1 Installing the Application Gateway Configuring the Application Gateway for the First Time If they are correct, type y when asked to commit your changes. The Application Gateway restarts and displays the login prompt. If they are not correct, type n when asked to commit your changes, then type 0 (Express Setup) to change settings. -
Page 21: Chapter 2 Specifications And Bios Self-Test Messages
Chapter 2 Chapter Specifications and BIOS Self-Test Messages Specifications Pentium 4 2.8Ghz HyperThreading 800MHz front side bus Processor Intel i875 chipset Motherboard 1 gigabyte PC3200 (400MHz) Memory 260W, Power supply 100 - 240V, 60-5 Hz, 5-3 Amp AC Voltage 887.15 Maximum BTU/hr 1 x 90mm blower fan System cooling fan... -
Page 22: Bios Self-Test Messages
Chapter 2 Specifications and BIOS Self-Test Messages BIOS Self-Test Messages BIOS Self-Test Messages During the Power-On Self-Test (POST), the BIOS checks for errors. If the BIOS detects an error that requires correction, the BIOS activates an alarm or display a message, as follows: POST beep codes •... - Page 23 Chapter 2 Specifications and BIOS Self-Test Messages BIOS Self-Test Messages DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP The type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. DISPLAY SWITCH IS SET INCORRECTLY The display switch on the motherboard can be set to either monochrome or color.
- Page 24 Chapter 2 Specifications and BIOS Self-Test Messages BIOS Self-Test Messages Memory parity Error at ... Indicates a memory parity error at a specific location. You can use this location along with the memory map for your system to find and replace the bad memory chips.
- Page 25 Chapter 2 Specifications and BIOS Self-Test Messages BIOS Self-Test Messages Hard Disk(s) fail (80) HDD reset failed ® Hard Disk(s) fail (40) HDD controller diagnostics failed. ® Hard Disk(s) fail (20) HDD initialization error. ® Hard Disk(s) fail (10) Unable to recalibrate fixed disk. ®...
- Page 26 Part Number: 300-60-00...
