6.4.2 Component overview: Single phase without backup heater

a b
m
l
a Safety valve
b Manual air purge valve
c Expansion vessel
d Heat exchanger (middle) thermistor R5T
e Heat exchanger
f Air thermistor R1T
g Water pressure sensor B1PW
h Heat exchanger thermistor R4T
i Water outlet
j Water inlet
k Refrigerant liquid thermistor R3T
l Inlet water thermistor R4T
m Outlet water after plate type heat exchanger
thermistor R1T
EBLA09~16DA + EDLA09~16DA
Daikin Altherma 3 M
ESIE20-06A – 2021.03
d
c
k j i
n
o p
e
f
g
h
y
n Fan
o Fan motor M1F
p Switch box with noise filter PCB A2P on back side
q Main PCB A1P
r Hydro box
s Hydro PCB A1P
t Water pump
u Water flow sensor B1L
v Drain valve
w Plate type heat exchanger
x Gas stop valve with service port
y Liquid stop valve with service port
6 Technical data
|
q r s
x
b
t
g
u
v
w
