User reference guide
Daikin Altherma – Low temperature split
EABH16DA6V
EABH16DA9W
EABX16DA6V
EABX16DA9W
EAVH16S18DA6V(G)
EAVH16S23DA6V(G)
EAVH16S18DA9W(G)
EAVH16S23DA9W(G)
EAVX16S18DA6V(G)
EAVX16S23DA6V(G)
User reference guide
EAVX16S18DA9W(G)
English
Daikin Altherma – Low temperature split
EAVX16S23DA9W(G)
Advertisement
Table of Contents
Related Manuals for Daikin Altherma
Summary of Contents for Daikin Altherma
- Page 1 User reference guide Daikin Altherma – Low temperature split EABH16DA6V EABH16DA9W EABX16DA6V EABX16DA9W EAVH16S18DA6V(G) EAVH16S23DA6V(G) EAVH16S18DA9W(G) EAVH16S23DA9W(G) EAVX16S18DA6V(G) EAVX16S23DA6V(G) User reference guide EAVX16S18DA9W(G) English Daikin Altherma – Low temperature split EAVX16S23DA9W(G)
-
Page 2: Table Of Contents
▪ This appliance can be used by children aged from 8 years and commissioning................18 above and persons with reduced physical, sensory or mental 8 Relocation capabilities or lack of experience and knowledge if they have been User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 3: About This Document
▪ Do NOT place any objects containing water on the unit. Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. NOTICE The original documentation is written in English. All other languages ▪... -
Page 4: Components In A Typical System Layout
The unit is in operation. Blinking red Malfunction A malfunction occurred. "7.1 To display the help text in case of a malfunction" on page 17 for more information. User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 5: Home Screen
: Fancoil unit ▪ : Radiator – g2 Leaving water temperature setpoint g3 Room thermostat type: ▪ : Daikin user interface used as room Home screen Main menu screen thermostat Lower level screens: c1: Setpoint screen ▪ : External control c2: Detailed screen with values ▪... -
Page 6: Setpoint Screen
Minimum temperature limit Fixed by the unit 2 Set operation to On or Off. Restricted by the installer To turn tank heating operation ON or OFF User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 7: Space Heating/Cooling Control
1 Go to [4.1]: Space heating/cooling > Operation mode Check the number of heat emitters displayed on the home screen: If… Then… One heat emitter symbol is displayed There is only one zone. EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 8: To Change The Desired Room Temperature
1 Go to one of the following: temperature shown on the home screen (example: 50°C). ▪ [2.1]: Main zone > Schedule ▪ [3.1]: Additional zone > Schedule User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 9: Scheduled Mode
To change the user permission level minimum amount of hot water is available at all times. You can change the user permission level as follows: Example: EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 10: Using Quiet Mode
1 Go to [7.4.1]: User settings > Quiet > Activation. thermostat and the LAN adapter. 2 Select Most quiet. User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 11: To Configure Time And Date
Gas price=Actual gas price+(Incentive/kWh×0.9) To set the electricity price Gas price=4.08+(5×0.9) Gas price=8.58 1 Go to [7.5.1]/[7.5.2]/[7.5.3]: User settings > Electricity price > High/Medium/Low. EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 12: Using And Programming Schedules
[7.5.4] User settings > Program when a certain electricity tariff Electricity price > is valid. Schedule Example of programming a schedule "4.7.4 Schedule screen: Example" on page 12. User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... - Page 13 1 Program 3 room temperature schedules in heating mode and give them appropriate names. Example: EarlyShift, DayShift and LateShift 2 Select the schedule that you currently want to use. EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10...
-
Page 14: Weather Dependent Operation
The symbol shown here corresponds to the heat emitter for that zone: ▪ : Underfloor heating ▪ : Fan coil unit ▪ : Radiator ▪ : Domestic hot water tank User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 15: Menu Structure: Overview User Settings
Connection status User profile Operation Room Space heating/cooling Tank Setpoint screen INFORMATION Depending on the selected installer settings and unit type, settings will be visible/invisible. EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 16: Installer Settings: Tables To Be Filled In By Installer
NOT let the room temperature drop too low. It will take more time and energy to heat up the room again. The refrigerant inside this unit is mildly flammable. User reference guide EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 17: To Find The Contact/Helpdesk Number
You see a list of the most recent malfunctions. When the heat pump fails, will appear on the user interface. EABH/X16DA+9W + EAVH/X16S18+23DA6V+9W User reference guide Daikin Altherma – Low temperature split 4P556071-1 – 2018.10... -
Page 18: Symptom: The System Is Making Gurgling Noises After Commissioning
Reason: Refrigerant Field supply might leak into the water circuit, and subsequently into Equipment NOT made by Daikin that can be combined with the room when you purge air from the heat emitters or product... - Page 20 4P556071-1 2018.10...
