- Page 1 500001099 EDL170-520RF Air Source Heat Pump Water Heater Installation and User Instructions RD01151-1 Important - This manual must be left with user after Installation! Requires Dimplex Hub, sold separately...
- Page 2 The Hot Water Association (HWA) Charter is a code of Practice which requires that all members adhere to the following: • supply fit for purpose products clearly and honestly described • supply products that meet, or exceed appropriate standards and building and water regulations • provide pre and post sales technical support •...
-
Page 3: Table Of Contents
2.1 User Safety Control Box 2.2 General Safety Setting the Language Setting the Time 3 Introduction Setting the Water Temperature 3.1 Dimplex Control Holiday Mode BOOST Function 4 Scope of Delivery (for occasional use) Electric Mode 5 Pre-Installation Advice (to operate with electrical backup) 17 Handling 7.10 Programming... -
Page 4: Manual Warnings
1 Manual Warnings Before removing the cover from the immersion heater isolate the Electrical Warnings appliance using isolating switch! Danger of electrical shock! Only Indicates any hazard of an electrical nature. use suitable electrically insulat- ed equipment when working in- Information side immersion housing. -
Page 5: Introduction
*A Dimplex Hub is required for this product to connect to Dimplex Control. For instruction on setting up Dimplex Hub, Permitted transport positions: please refer to the manual online or section 9 in this manu- Transport and handling of the appliance al. -
Page 6: Storage
5.2 Storage The water heater may be located on any flat and level Admissible storage and transport temperatures of the surface, provided it is sufficiently robust to support the heat pump water heater are from -5°C to +35°C weight of the water heater when full of water (please see technical data) and suitably accessible for 5.3 Unpacking replacement/maintenance without specialist tools or lift... -
Page 7: Installation
For satisfactory and safe performance of the water Dimplex strongly recommends the use of metal pipework heater the water supply must meet the following only and Dimplex does not take responsibility for any dam- criteria: age caused from discharges. Minimum dynamic pressure 150Kpa (1.5 bar) -
Page 8: Worked Example
Value Minimum size Minimum size Maximum Length to be - Be continuously marked with a warning that no outlet of discharge of discharge allowed length subtracted for sanitary appliances should be connected to the size pipe before pipe after of pipe after each elbow or pipe. -
Page 9: Installation
5.Drain* Figure 5: Inlet connections 6.2.2 Expansion Vessel The expansion vessel is mandatory on the Dimplex water heater and can be connected directly to the cold water inlet group, utilising the flexible hose supplied with the ves- sel. The expansion vessel should always be fitted in accord- ance with the manufacturer’s instructions, see Figure 5. -
Page 10: Balanced Cold Water Supply
Note: The T&P valve is pre-sealed and if moved the seal will be broken, should this occur, it will need to be resealed with an appropriate sealant (Dimplex part number R00836-1). 6.4.2 Discharge Pipe D2 For a detailed description of the discharge pipework D2 (see Section 5.10.1). -
Page 11: Air Connection
Failure to use the concentric ducting supplied will prevent the product working properly. Dimplex only recommend using the ducting supplied and maintaining the shortest possible duct runs. Ducting Design It is essential to maintain a minimum air flow rate through the ducting for correct operation of the appliance. -
Page 12: Ducting Installation
Figure 9. 6.8.2 Offset access Dimplex offer a basic vent kit is provided with the prod- uct to accommodate installations as per 6.8.1 and 6.8.2. Should it be necessary to install the product further away from the nearest outside wall the vent extension kit is required. -
Page 13: Distanced Access
NOTE: For distanced access, an extension kit can be supplied by Dimplex, see Section 8.7 This kit provides enough parts to add. It is possible to source parts from a merchant to make the... -
Page 14: Condensates Draining
6.10 Draining the Condensate The condensates tube should not be directly connected to a drain. It must terminate into open air through a U-bend which has been added and contains water. To stop the electrical back-up immersion running during - Do not use an elbow on the flexible hose peak time, connect the voltage-free contact from your electricity meter to terminal n°1, please refer to Figure - Contact open... -
Page 15: Set-Up And Use
Make final mains connection on combination Please register the appliance on our website valve and check all connections and joints. www.dimplex.co.uk/register ensure they have been tightened and secured correctly. Voltage-free Contacts to PV Inverter Tair Tdégiv... -
Page 16: Using Your Hot Water Heat Pump
7.2 Using your Hot Water Heat Pump Setting the Language The language must be selected when the appliance is The hot water heat pump mainly operates with the heat turned on for the first time. Turn the dial to the left, pump, as long as the air intake temperature remains in select ‘English’... -
Page 17: Setting The Water Temperature
BOOST Function Setting the Water Temperature (for occasional use) The water temperature can be adjusted between 30°C The ‘BOOST’ function temporarily uses both the and 65°C. The heat pump alone heats the water up immersion heater and the heat pump to increase the until 55°C. -
Page 18: Programming
7.10 Programming Programming enables you to define the periods of time the appliance runs in ‘Economy’, ‘Comfort’ or ‘Off’ mode (freeze protection mode). Electrical backup is not allowed while the appliance is in ‘Economy’ mode. To access the program menu: - Press the ‘Clock’. -
Page 19: Installer Menu
7.11 Installer Menu 3. Select ‘Yes’. It may be necessary to adjust certain settings to 4. Press the dial to confirm. optimise the performance of the heat pump water heater, depending on how the appliance is installed. 5. Press the ‘Menu’ key. Accessing the Installer Menu: 6. -
Page 20: Anti-Bacteria
7.11.3 Anti-Bacteria (Anti-Bact) 7.11.5 Minimum Temperature It is possible to allow the operation of the immersion heater along with the heat pump to prevent the Example: Anti-Bact 8 = the legionella water temperature falling below a minimum comfort ANTI-BACT ANTI-BACT cycle every 8 days Example: temperature of 38°C. -
Page 21: Maximum Time
7.11.9 Resetting Parameters 7.11.7 Maximum Time Resetting the parameters enables you to go back to the A period of time can be chosen where the electrical default settings. Go to the ‘Installer’ Menu and turn the back-up will run at the same time as the heat pump to dial to ‘Reset’. -
Page 22: Maintenance
8 Maintenance When draining the tank, ensure that The maintenance of this appliance covers the critical ar- there is a large enough air inlet at eas of the Domestic Hot Water Cylinder, the Heat Pump Module, Air Connections and Electrical Connections. the top to avoid any depression in the tank;... -
Page 23: Air Intake & Exhaust
Heat Pump Any work on the refrigerant circuit The pressure limiting device must be switched must be carried out by a qualified on regularly to eliminate limescale and check for professional with an F Gas Category 1 blockages. certificate of aptitude. Check that all hydraulic connections on the heat pump water heater are watertight. -
Page 24: Troubleshooting
Troubleshooting Issue Check The Heat Pump is not - That the desired water temperature is higher than working the temperature of the water in the tank. - There is power supply to the appliance. - The green light is on. - That the appliance is not in holiday mode (see Sec- tion 7.7) - That the air intake or ambient temperature is under... -
Page 25: Spare Parts
Spare Parts Description Image Part No Description Image Part No 22mm x 3bar Inlet con- X-R00041-1 Sensor Ig 460 X-B1244576 trol group Inlet control group PRV X-R00009-1 Sensor Ig 1200 X-B1244575 cartridge 18 litre expansion vessel X-R00045-2 Defrosting sens kit X-B4993072 Expansion vessel fixing X-R00094-2 RF module 500000710 DN16 3/4” BSP x 1000 X-R00095-1 Fan 140 500001242... -
Page 26: Error Message Codes
Error Message Codes: Errors, Solutions and Operating in case of Error Errors can be dismissed by briefly pressing the dial (manual reset). Temporary operation measures while Display Error Probable causes Solutions waiting for problem to be solved • Voltage too high on electrical network. - Page 27 Temporary operation measures while Display Error Probable causes Solutions waiting for problem to be solved • Domestic hot water • Defective water sensor • Check that sensor is in • Heat pump is OVER- overheat (water • Water sensor removed the right wposition in the non-functional HEAT...
-
Page 28: Control App
9 Control App Hygiene Mode Home Screen • Select mode • Select to run that the Edel is hygiene mode operating in. on the app, • Use boost and define the function for frequency of immediate hot hygiene mode water. up to 99 days. -
Page 29: Warranty
- Placing the appliance where it can be subject to ice or of purchase. The appliance must be registered other bad weather conditions. with Dimplex and can be done so quickly online - Non-compliance with the instructions in the manual by visiting www.dimplex.co.uk/register. In the when installing the appliance. -
Page 30: Technical Data And Product Fiche
Technical Data and Product Fiche View from below View from above Figure 19: Edel Air Source Water Heater Dimensions (for reference Technical Data and Product Fiche... - Page 31 Edel Air Source Water Heater - Dimensions Reference EDL170L Capacity [l] Hot Water Capacity [l]* Weight - Empty [kg] Weight - Full [kg] Heat Up Time [hh:mm]* 10:24 Heat Loss [kWh/24h] 1.95 Height [mm] 1760 Outer Diameter [mm] Condensate Pipe [mm] 1025 Hot Water Outlet [mm] T&P Valve [mm]...
- Page 32 Edel Air Source Water Heater - Product Features Materials Inner cylinder Stainless steel Outer cylinder Plastic Inlet/outlet Stainless steel Insulation 50mm PU foam (GWP=1, ODP=0) Maximum Operating Conditions Potable water temperature 65°C via immersion, 55°C via compressor alone Operating pressure 3 bar Maximum design pressure 6 bar...
- Page 33 5 µF Capacitor green/yellow Supply black blue blue blue ellow Bus connection MENU �...
- Page 34 MAINS PRESSURE HOT WATER STORAGE SYSTEM COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the storage system as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission this equipment to the manufacturer's instructions will invalidate the warranty, but does not affect statutory rights.
- Page 35 SERVICE RECORD It is recommended that your hot water system is serviced regularly and that the appropriate Service Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.
- Page 36 Disregarding the instructions given in this manual in its entirety and any relevant regulations, standards and codes of practice will void the guarantee of this product. Glen Dimplex reserve the right to revise products, literature and guarantee terms without prior notice due to a policy of continuous improvement.
