Hydraulic Control Manifold Service

36 in–lb
(4.1 N–m)
4
3
5
22 ft–lb
(30 N–m)
1. Check valve
2. Demand solenoid (S2 port)
NOTE: The ports on the manifold are marked for easy
identification of components. Example: P is the pump
connection port (See Hydraulic Schematics to identify
the function of the hydraulic lines and cartridge valves
at each port).
Hydraulic System
4
36 in–lb
(4.1 N–m)
22 ft–lb
(30 N–m)
5
6
Figure 14
3. Solenoid coil
4. Nut
Page 3 – 20
22 ft–lb
(30 N–m)
3
5
20 to 25 ft–lb
(27 to 34 N–m)
1
5. Solenoid valve (S1, S3 and S4 ports)
6. Hydraulic lift control manifold
36 in–lb
(4.1 N–m)
4
3
22 ft–lb
(30 N–m)
2
Pro Sweep 5200
