- Page 1 User’s Manual OL1000RTXL2U OL1500RTXL2U OL2200RTXL2U OL3000RTXL2U OL3000RTXL2UHV Cyber Power Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.cyberpower.com K01-0000500-02...
-
Page 2: Important Safety Instructions
CAUTION! Make sure everything is turned off and disconnected (OL3000RTXL2UHV) maximum over-current protection in accordance completely before conducting any maintenance, repairs or shipment. with the National Electric Code, ANSI/NFPA 70. CAUTION! Connect the Protection Earth (PE) safety conductor before CAUTION! The AC outlet where the UPS is connected should be close any other cables are connected. - Page 3 Left hanging bracket Right hanging bracket Software download card * PowerPanel® Business Edition software is available on our website. Please visit www.cpsww.com and go Rackmount ears (Stands) (2) to the Software Section for FREE download. Copyright © 2017 CyberPower Systems, Inc.
-
Page 4: Hardware Installation
Tighten the front rail screws on the rack. Step 2: Rackmount ears & hanging brackets installation Attach two rackmount ears to the UPS using the provided M5X7L*8pcs screws and tighten two hanging brackets with the M5X6L*6pcs screws. Copyright © 2017 CyberPower Systems, Inc. - Page 5 Slide the hanging brackets on the UPS into the rails mounted in the rack with the front of the unit facing toward you. Secure the UPS to your rack with four M5X12L*4pcs screws at the front of the rack. (Located in position 2 & position 5) Copyright © 2017 CyberPower Systems, Inc.
-
Page 6: Vertical/Tower Installation
CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2017 CyberPower Systems, Inc. -
Page 7: Installing Your Ups System
Make sure your equipment carries a load current within the unit’s safe temperature occurs, please check the Trouble Shooting section on page range, (refer to the technical specifications). 16. If the condition persists, please contact CyberPower for technical support. This UPS is equipped with an auto-charge feature. When the UPS is plugged into an AC outlet, the battery will automatically charge, even when the unit is switched off. -
Page 8: Basic Operation
11. Expansion slot Slot to install optional remote management card. 12. Extended Runtime Battery Module Connector Connection for additional CyberPower External Battery modules. 13. EPO (Emergency Power Off) Connector OL3000RTXL2UHV Enables an emergency UPS Power-Off from a remote location. -
Page 9: Led Indicators - Ups Status
Press this button to scroll up in the LCD menu. ▼ Press this button to scroll down in the LCD menu. ENTER Press this button to select an option. Press this button to cancel or return to previous LCD menu. Copyright © 2017 CyberPower Systems, Inc. -
Page 10: Lcd Setup Functions
Next BATT Change Displays the next Battery Change Date & Time XXX / XXXX XXXXXX Display the device IP address XXX.XXX.XXX.XXX Subnet Mask Display the device Subnet Mask XXX.XXX.XXX.XXX Gateway Display the device Gateway XXX.XXX.XXX.XXX Copyright © 2017 CyberPower Systems, Inc. -
Page 11: Lcd Event Log
You may be prompted to save the selection, if so press the “ENTER” button to save the setting. Some options are saved and started automatically. (See the following table for additional details.) Press the “ESC” button to cancel or return to the previous LCD menu. Copyright © 2017 CyberPower Systems, Inc. - Page 12 This function can’t be set when Manual Bypass, Generator Mode or Converter Mode is enabled. UPS has no bypass when Generator Mode is enabled. UPS has no bypass when Converter Mode is enabled. This function can only be set before the UPS is on. Copyright © 2017 CyberPower Systems, Inc.
-
Page 13: Silencing Audible Alarms
The LCD screen displays the battery capacity during charging with a graphical icon while on Line Mode. Discharging Capacity The LCD screen displays the remaining battery capacity with a graphical icon while on Battery Mode. Copyright © 2017 CyberPower Systems, Inc. -
Page 14: Lcd Module Remote Control And Wall-Mounting Instructions
Step 4: Mount LCD Module on the Wall SAFETY PRECAUTIONS CAUTION! It must be done by qualified personnel. CAUTION! To avoid electric shock, turn off and unplug the unit before installing REMOTE CONTROL or WALL-MOUNTING INSTRUCTIONS. Copyright © 2017 CyberPower Systems, Inc. -
Page 15: Maintenance
Only use replacement batteries which are certified by proper disposal and recycling of batteries. Do not dispose of batteries CyberPower Systems. Use of incorrect battery type is an electrical in fire. hazard that could lead to explosion, fire, electric shock, or short circuit. -
Page 16: Technical Specifications
(60 x 43.3 x 8.8cm) Net Weight 39.6lbs(18Kg) 68.2lbs(31Kg) Safety Conformance Approvals CE, UL1778, FCC part 15 Class B CE, UL1778, FCC part 15 Class A For OL1500/2200/3000RTXL2U, 100V is derated by 20%, 110/115V is derated by 10% Copyright © 2017 CyberPower Systems, Inc. -
Page 17: Troubleshooting
Internal Fan has failed. CyberPower Systems Inc. www.cpsww.com © Entire contents copyright 2017 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part ® ® without permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of CyberPower Systems Inc. -
Page 18: Product Registration
If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 19 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums.
-
Page 20: Conformance Approvals
Cet appareil numerique de la class B respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
