Page 1 Wasp WWS650 2D Handheld Wireless Barcode Reader Product Reference Guide...
Page 2 Wasp Technologies website (www.waspbarcode.com) or provided on appropriate media. If you visit our website and would like to make comments or sugges- tions about this or other Wasp Technologies publications, please let us know via the "Con- tact WaspTechnologies" page.
Page 3: Table Of Contents
Table of Contents INTRODUCTION......................................1 About this Manual ........................................1 Overview ........................................... 1 Manual Conventions ....................................... 2 Services and Support ...................................... 2 About the Reader ........................................3 Programming the Reader ......................................4 Configuration Methods ....................................4 Cordless Models ........................................5 Using the Radio Base ......................................
Page 4 Partial Label Reading Control ..............................82 Decode Negative Image ................................82 MULTIPLE LABEL READING ................................. 83 Multiple Labels per Frame ................................. 83 Multiple Labels Ordering by Code Symbology .......................... 84 Multiple Labels Ordering by Code Length ..........................84 1D Symbologies ....................................85 Wasp WWS650...
Page 5 Contents 1D Code Selection ........................................85 DISABLE ALL SYMBOLOGIES ................................86 CODE EAN/UPC ....................................87 Coupon Control .................................... 87 UPC-A ......................................88 UPC-A Enable/Disable ................................88 UPC-A Check Character Transmission ............................88 Expand UPC-A to EAN-13 ................................89 UPC-A Number System Character Transmission ........................89 UPC-A 2D Component .................................
Page 6 Codabar Start/Stop Character Transmission ......................... 143 Codabar Start/Stop Character Set ............................144 Codabar Start/Stop Character Match ............................. 144 Codabar Quiet Zones ................................145 Codabar Length Control ................................145 Codabar Set Length 1 ................................146 Codabar Set Length 2 ................................147 Wasp WWS650...
Page 7 Contents ABC CODABAR ....................................148 ABC Codabar Enable/Disable ..............................148 ABC Codabar Concatenation Mode ............................148 ABC Codabar Dynamic Concatenation Timeout ........................149 ABC Codabar Force Concatenation ............................150 CODE 11 ....................................... 151 Code 11 Enable/Disable ................................151 Code 11 Check Character Calculation ............................151 Code 11 Check Character Transmission ..........................
Page 8 CONFIGURATION UPDATES ................................215 Automatic Configuration Update ............................. 215 Copy Configuration to Scanner ..............................215 Copy Configuration to Base Station ............................216 BATCH FEATURES ....................................216 Batch Mode ....................................216 Send Batch ....................................217 Erase Batch Memory ................................217 Wasp WWS650...
Page 9 Contents RF Batch Mode Transmit Delay ............................... 217 DIRECT RADIO AUTOLINK .................................. 218 Bluetooth-Only Features................................219 RF ADDRESS STAMPING ..................................219 Source Radio Address Transmission ............................219 Source Radio Address Delimiter Character ..........................220 BT SECURITY FEATURES ..................................221 BT Security Mode ..................................221 BT PIN Code ....................................
Page 10 Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE ......................296 Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode ........................298 Digital Interface ........................................300 IBM31xx 102-key .........................................301 IBM XT ...........................................302 Microsoft Windows Codepage 1252 ..................................303 viii Wasp WWS650...
Page 11: Introduction
Chapter 1 Introduction About this Manual This Product Reference Guide (PRG) is provided for users seeking advanced technical informa- tion, including connection, programming, maintenance and specifications. The Quick Reference Guide (QRG) and other publications associated with this product are downloadable free of charge from the website listed on the back cover of this manual.
Page 12: Manual Conventions
Wasp website. Services and Support Wasp provides several services as well as technical support through its website. Log on to www.waspbarcode.com and click on the links indicated for further information.
Page 13: About The Reader
The Wasp WWS650 imager reads typical printed linear bar codes as well as complex 2D bar codes displayed on the screen of a mobile device or loyalty cards. The WWS650 imager is an elegant and robust imager that provides fast, reliable scanning.
Page 14: Programming The Reader
ENTER/EXIT bar code a second time, which will then accept your changes, exit Programming Mode and return the reader to normal operation. There are some exceptions to the typical programming sequence described above. Please read the description and setting instructions carefully when configuring each programma- ble feature. NOTE Wasp WWS650...
Page 15: Cordless Models
Cordless Models Using the Radio Base Radio Base LEDs LEDs on the Base provide information about the Base as well as battery charging status, as shown. Figure 1. Base LEDs Red LED / Green LED Yellow LED STATUS Yellow On = Base is powered Yellow Blinking = Base receives data and ...
Page 16: Charging The Batteries
Micro-USB Connector Alternatively, simply insert the WWS650 into the base. When the scanner is fully seated in the cradle, it will sound a “chirp” to indicate that the cradle has detected the scanner connection. The LEDs on the base will indicate the status of the battery.
Page 17 Always charge the battery at 32° – 104°F (0° - 40°C) temperature range. Use only the authorized power supplies, battery pack, chargers, and docks supplied by your reseller. The use of any other power supplies can damage the device and void your war- CAUTION ranty.
Page 18: Replacing The Battery Pack
2. Rotate the battery pack downward while pressing the bottom side of the battery pack (to seat securely into the contacts springs) so that the edges of the pack and the handle board are aligned, while replacing the screw in the bottom of the handle. Wasp WWS650...
Page 19: Setup
Unpacking Check carefully to ensure the reader and any accessories ordered are present and undamaged. If any damage occurred during shipment, contact Wasp. KEEP THE PACKAGING. Should the unit ever require service, it should be returned in its original shipping container.
Page 20: Configuring The Base Station
Host. When the base is powered from the Host, it automati- cally selects a slow charge rate. The Wasp WWS650 can also be Powered by the Terminal. When powered by the Terminal, the battery charger is automatically set as Slow charge.
Page 21: Base Station Connection And Routing
Base Station Connection and Routing 1. Remove the rubber Cable Stopper from the bottom of the Base Station. 2. Securely plug the Power Cable and Interface (I/F) Cable connectors into their respective ports in the underside of the Base Station. Power Cable I/F Cable Cable Stopper...
Page 22 Figure 3. Connecting to the Host or... or... or... Plug the AC Adapter into an approved AC wall socket with the cable facing Power Connection: downwards (as shown in Figure 2) to prevent undue strain on the socket. Wasp WWS650...
Page 23: System And Network Layouts
4. Power up the host. The reader will link to the Base 5. When the host completely powers up, a new custom Security Pin Code may be sent to the reader and Base, depending on host configuration. Contact Wasp Technical Support for more information.
Page 24: Linking The Reader To A Base Station
2. Scan the bar code below to make the scanner visible to the host computer. Link to a PC in Server Mode 3. Use the host computer’s Bluetooth manager to “Discover new devices” and select "Wasp Scanner." If you receive an error message, it may be necessary to disable security on the device.
Page 25 2. Scan the label below. Link to PC in HID 3. Use the host computer’s Bluetooth manager to “Discover new devices” and select "Wasp Scanner." If you receive an error message, it may be necessary to disable security on the device.
Page 26: Interface Selection
Set RS-232 Interface Select RS232-WN Features starting on $P,HA13,P(CR) page 25 RS-232 for use with OPOS/UPOS/JavaPOS Select RS-232 OPOS $P,HA47,P(CR) USB Com to simulate RS-232 standard interface Select USB-COM-STD a. Download the correct USB Com driver from www.waspbarcode.com Wasp WWS650...
Page 27 USB-OEM FEATURES Set USB-OEM $P,HA45,P(CR) Interface USB-OEM Features (can be used for OPOS/UPOS/JavaPOS) starting on page 47 Select USB-OEM KEYBOARD FEATURES $P,HA2B,P(CR) USB Keyboard with alternate key encoding Select USB Alternate Keyboard $P,HA29,P(CR) AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/Standard Key Encoding Select KBD-AT $P,HA11,P(CR)
Page 28 Set KEYBOARD $P,HA1B,P(CR) WEDGE Interface Keyboard Wedge for DIGITAL Features Terminals VT2xx, VT3xx, VT4xx starting on page 37 Select KBD-DIG-VT $P,HA35,P(CR) USB Keyboard with standard key encoding Select USB Keyboard $P,HA2C,P(CR) USB Keyboard for Apple computers Select USB-KBD-APPLE Wasp WWS650...
Page 29: Customizing Configuration Settings
Customizing Configuration Settings Configure Interface Settings If after scanning the interface bar code from the previous table, your installation requires you to select options to further customize your reader, turn to the appropriate section for your inter- face type in "Configuration Parameters"...
Page 30: Resetting The Product Configuration To Defaults
“Label ID Control” section on page 57 of this manual. $P,AE,P(CR) Restore USA Factory Configuration $P,Ae,P(CR) Restore EU Factory Configuration The programming items listed in the following sections show the factory default settings for each of the menu commands. Wasp WWS650...
Page 31: Configuration Using Bar Codes
Chapter 3 Configuration Using Bar Codes This and following sections provide programming bar codes to configure your reader by chang- ing the default settings. For details about additional methods of programming, see "Configura- tion Methods" on page You must first enable your reader to read bar codes in order to use this section. If you Setup, starting on page 9 have not done this, go to and complete the appropriate...
Page 32 By default, the handheld will decode bar code labels only when they are close to the center of the aiming pattern. This allows the handheld to accurately target labels Pick when they are placed close together, such as on a pick sheet. See Mode, starting on page 76 NOTE Wasp WWS650...
Page 33: Global Interface Features
Enter/Exit Programming Mode GLOBAL INTERFACE FEATURES The following interface features are configurable by all interface types. Host Commands — Obey/Ignore This option specifies whether the reader will obey or ignore host commands. When set to ignore, the reader will ignore all host commands except for those necessary for: •...
Page 34 Enter/Exit Programming Mode Global Interface Features NOTES Wasp WWS650...
Page 35: Rs-232 Interface
RS-232 INTERFACE on page 26 on page 27 on page 27 on page 28 ARITY on page 29 ANDSHAKING ONTROL Use the programming bar codes in this section if modifications to the standard RS-232 inter- face settings are necessary to meet your system’s requirements. Additional settings which apply to both the RS-232 and USB interfaces are available in the next section, "RS-232/USB- Com Interfaces"...
Page 36: Baud Rate
Baud Rate = 1200 $CR2BA01(CR) Baud Rate = 2400 $CR2BA02(CR) Baud Rate = 4800 $CR2BA03(CR) DEFAULT Baud Rate = 9600 $CR2BA04(CR) Baud Rate = 19,200 $CR2BA05(CR) Baud Rate = 38,400 $CR2BA06(CR) Baud Rate = 57,600 $CR2BA07(CR) Baud Rate = 115,200 Wasp WWS650...
Page 37: Data Bits
RS-232 Interface Enter/Exit Programming Mode Data Bits This parameter allows the reader to interface with devices requiring a 7-bit or 8-bit ASCII pro- tocol for sending and receiving data. $CR2DA00(CR) 7 Data Bits $CR2DA01(CR) DEFAULT 8 Data Bits Stop Bits Set the number of stop bits to match host device requirements.
Page 38: Parity
This feature specifies parity required for sending and receiving data. Select the parity type according to host device requirements. See page 234 for more information. $CR2PA00(CR) DEFAULT Parity = None $CR2PA01(CR) Parity = Even $CR2PA02(CR) Parity = Odd Wasp WWS650...
Page 39: Handshaking Control
RS-232 Interface Enter/Exit Programming Mode Handshaking Control page 234 for more information about this feature. $CR2HC00(CR) DEFAULT Handshaking Control = RTS $CR2HC01(CR) Handshaking Control = RTS/CTS $CR2HC02(CR) Handshaking Control = RTS/XON/XOFF $CR2HC03(CR) Handshaking Control = RTS On/CTS $CR2HC04(CR) Handshaking Control = RTS/CTS Scan Control Product Reference Guide...
Page 40: Rs-232/Usb-Com Interfaces
RS-232/USB-COM INTERFACES on page 31 NTERCHARACTER ELAY on page 31 ASCII BEL on page 32 OT ON on page 32 ACK NAK O PTIONS on page 33 ACK C HARACTER on page 33 NAK C HARACTER on page 34 ACK NAK T IMEOUT ALUE on page 34...
Page 41: Intercharacter Delay
RS-232/USB-Com Interfaces Enter/Exit Programming Mode Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments.
Page 42: Beep On Not On File
$CR2AE00(CR) DEFAULT ACK/NAK Protocol = Disable ACK/NAK $CR2AE01(CR) ACK/NAK Protocol = Enable for label transmission $CR2AE02(CR) ACK/NAK Protocol = Enable for host-command acknowledge $CR2AE03(CR) ACK/NAK Protocol = Enable for label transmission and host- command acknowledge Wasp WWS650...
Page 43: Ack Character
RS-232/USB-Com Interfaces Enter/Exit Programming Mode ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See page 236 for more information. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with Data Bits normal operation of these characters.
Page 44: Ack Nak Timeout Value
End by scanning the ENTER/EXIT bar code again. Select ACK NAK Retry Count Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 003 = 3 Retries DEFAULT Wasp WWS650...
Page 45: Ack Nak Error Handling
RS-232/USB-Com Interfaces Enter/Exit Programming Mode ACK NAK Error Handling This feature specifies the method the reader uses to handle receive errors detected while wait- ing for an ACK character from the host. $CR2EH00(CR) DEFAULT ACK NAK Error Handling = Ignore Errors Detected $CR2EH01(CR) ACK NAK Error Handling = Process Error as Valid ACK Character...
Page 46: Disable Character
8-bit data is not recognized when the Data Bits on page 27 option has been set as 7 Data Bits. NOTE page 241 in “References” for more information on setting this feature. $CR2EC Select Enable Character Setting 0x45 = Enable Character is ‘E’ DEFAULT Wasp WWS650...
Page 47: Keyboard Settings
KEYBOARD SETTINGS on page 38 OUNTRY on page 42 ONTROL HARACTERS on page 43 EDGE UIET NTERVAL on page 43 NTERCODE ELAY on page 44 TATE on page 44 UMLOCK on page 45 USB K EYBOARD PEED on page 46 USB K EYBOARD UMERIC...
Page 48: Country Mode
Mode feature description. Country Mode = Croatia $CKBCO0E(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Czech Republic $CKBCO03(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Denmark Wasp WWS650...
Page 49 Keyboard Settings Enter/Exit Programming Mode Country Mode (continued) $CKBCO04(CR) Country Mode = France $CKBCO13(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = French Canadian $CKBCO05(CR) Country Mode = Germany $CKBCO0D(CR) Supports only the interfaces listed in the Country Mode feature description.
Page 50 Country Mode = Portugal $CKBCO10(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Romania $CKBCO0F(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Slovakia Wasp WWS650...
Page 51 Keyboard Settings Enter/Exit Programming Mode Country Mode (continued) $CKBCO09(CR) Country Mode = Spain $KBCO0A(CR) Country Mode = Sweden $CKBCO0B(CR) Supports only the interfaces listed in the Country Mode feature description. Country Mode = Switzerland Product Reference Guide...
Page 52: Send Control Characters
Control Character 02 : are intended as an extended ASCII table (see "Microsoft Windows Codepage 1252" page 303). $CKBSC00(CR) DEFAULT Wedge Send Control Characters = 00 $CKBSC01(CR) Wedge Send Control Characters = 01 $CKBSC02(CR) Wedge Send Control Characters = 02 Wasp WWS650...
Page 53: Wedge Quiet Interval
Keyboard Settings Enter/Exit Programming Mode Wedge Quiet Interval Specifies amount of time to look for keyboard activity before scanner breaks keyboard connec- tion in order to transmit data to host. The selectable range for this setting is 00 to 990 millisec- onds (00-0x63 by 01) in increments of ten milliseconds.
Page 54: Caps Lock State
Caps Lock State = Caps Lock ON $CKBCL02(CR) Caps Lock State = AUTO Caps Lock Enable Numlock This option specifies the setting of the NUMLOCK key in the Keyboard Wedge interface. $CKBNL00(CR) DEFAULT Numlock = NUMLOCK key unchanged $CKBNL01(CR) Numlock = Numlock key toggled Wasp WWS650...
Page 55: Usb Keyboard Speed
Keyboard Settings Enter/Exit Programming Mode USB Keyboard Speed This option specifies the USB poll rate for a USB keyboard. This feature applies ONLY to the USB Keyboard interface. NOTE $CKBSP01(CR) DEFAULT USB Keyboard Speed = 1ms $CKBSP02(CR) USB Keyboard Speed = 2ms $CKBSP03(CR) USB Keyboard Speed = 3ms $CKBSP04(CR)
Page 56: Usb Keyboard Numeric Keypad
USB Keyboard Speed = 9ms $CKBSP0A(CR) USB Keyboard Speed = 10ms USB Keyboard Numeric Keypad This option Controls whether numeric characters will be sent using standard keys or the numeric keypad. $CKBKP00(CR) DEFAULT Standard Keys $CKBKP01(CR) Numeric Keypad Wasp WWS650...
Page 57: Usb-Oem Interface
USB-OEM INTERFACE on page 48 USB-OEM D EVICE SAGE on page 48 USB I NTERFACE PTIONS Feature settings for USB interfaces differ depending upon which host type the reader will be connected with. Use the feature settings in this chapter to specifically configure for the USB- OEM interface.
Page 58: Usb-Oem Device Usage
USB-OEM Device Usage = Table Top Scanner $CIBUT01(CR) DEFAULT USB-OEM Device Usage = Handheld Scanner USB Interface Options This feature provides for an interface-specific control mechanism. $CIFIH00(CR) DEFAULT Obey Scanner Configuration Host Commands $CIFIH01(CR) Ignore Scanner Configuration Host Commands Wasp WWS650...
Page 59: Transmit Labels In Code 39 Format
USB-OEM Interface Enter/Exit Programming Mode Transmit Labels in Code 39 Format This feature enable/disables translation to Code 39 before transmitting label data to a USB- OEM host. Only the symbology identifier is modified for the translation. The data is not con- verted to Code 39 or verified to be valid for Code 39.
Page 60: Interface Options
Enter/Exit Programming Mode Interface Options This feature provides for an interface-specific control mechanism. $CIFO101(CR) DEFAULT Obey Scanner Configuration Host Commands $CIFO102(CR) Ignore Scanner Configuration Host Commands Wasp WWS650...
Page 61: Data Format
DATA FORMAT starting on page 52 LOBAL REFIX UFFIX starting on page 53 AIM ID LOBAL starting on page 56 ABEL Label ID: Pre-Loaded Sets on page 56 • Individually Set Label ID on page 57 • Label ID Control on page 57 •...
Page 62: Global Prefix/Suffix
$CLFSU Set Global Suffix Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL No Global Prefix DEFAULT Global Suffix = 0x0D (CR) Wasp WWS650...
Page 63: Global Aim Id
Data Format Enter/Exit Programming Mode Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. NOTE AIM label identifiers (as opposed to custom characters you select yourself as with label identifi- ers) can be included with scanned bar code data. See Table 2 on page 3-53 for a listing of AIM IDs.
Page 64 EAN128 EAN128 COMPOSITE EAN13 EAN13 P2 EAN13 P5 EAN13 COMPOSITE EAN8 EAN8 P2 EAN8 P5 EAN8 COMPOSITE FOLLET 2OF5 I2OF5 IATA INDUSTRIAL 2OF5 INDUSTRIAL 2OF5 ISBN ISBT128 CONCAT ISSN MAXICODE MICRO QR MICRO PDF PDF417 PLESSEY POSTAL AUSTRALIAN Wasp WWS650...
Page 65: Set Aim Id Individually For Gs1-128
Data Format Enter/Exit Programming Mode AIM ID code ASCII Tag Name AIM ID code character value POSTAL IMB POSTAL JAPANESE POSTAL KIX POSTAL PLANET POSTAL PORTUGAL POSTAL POSTNET BB POSTAL ROYAL MAIL POSTAL SWEDISH POSTNET QR CODE TRIOPTIC UPCA UPCA P2 UPCA P5 UPCA COMPOSITE UPCE...
Page 66: Label Id
Any custom configuration or custom defaults will be lost. CAUTION $AE(CR) Label ID Pre-loaded Set = USA Set $Ae(CR) DEFAULT Label ID Pre-loaded Set = EU Set Wasp WWS650...
Page 67: Individually Set Label Id
Data Format Enter/Exit Programming Mode Individually Set Label ID This feature configures a Label ID individually for a single symbology. To set, first define whether you want it as a prefix or suffix by scanning a label below. Then turn to Label ID Sym- bology Selection −...
Page 68: Label Id Symbology Selection − 1D Symbologies
Set EAN 13 Label ID Character(s) Set Code 11 Label ID Character(s) $C3MID $CC8ID Set EAN 13 Composite Label ID Character(s) Set Code 128 Label ID Character(s) $C32ID $CC3ID Set EAN 13 P2 Label ID Character(s) Set Code 39 Label ID Character(s) Wasp WWS650...
Page 69 Data Format Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies (continued) $CCCID $C35ID Set EAN 13 P5 Label ID Character(s) Set Code 39 CIP Label ID Character(s) $CXCID $C8BID Set EAN 8 Label ID Character(s) Set GS1 DataBar Expanded Composite Label ID Character(s) $C8MID $CU8ID...
Page 70 Set ISBN Label ID Character(s) Set Portugal Postal Code Label ID Character(s) $CINID $CPNID Set ISSN Label ID Character(s) Set Postnet Label ID Character(s) $CPKID $CPJID Set Japan Postal Code Label ID Character(s) Set Kix Postal Code Label ID Character(s) Wasp WWS650...
Page 71 Data Format Enter/Exit Programming Mode Label ID Symbology Selection − 1D Symbologies (continued) $CPZID $CAMID Set PZN Code Label ID Character(s) Set UPC-A Composite Label ID Character(s) $CPRID $CA2ID Set Royal Postal Code Label ID Character(s) Set UPC-A P2 Label ID Character(s) $CS2ID $CA5ID Set Standard 2 of 5 Label ID Character(s)
Page 72 Set China Sensible Label ID Character(s) Set PDF 417 Label ID Character(s) $CDMID $CMIID Set Data Matrix Label ID Character(s) Set Micro PDF 417 Label ID Character(s) $CMQID $CQRID Set Micro QR Label ID Character(s) Set QR Code Label ID Character(s) Wasp WWS650...
Page 73: Advanced Formatting: User Label Edit
Data Format Enter/Exit Programming Mode Advanced Formatting: User Label Edit Advanced formatting is available to create user label edit scripts. Contact Technical Support for more information. Case Conversion This feature allows conversion of the case of all alphabetic characters to upper or lower case. Case conversion affects ONLY scanned bar code data, and does not affect Label ID, Prefix, Suffix, or other appended data.
Page 74: Character Conversion
FF, then no conversion is done. If less than the expected string of 16 characters are selected, scan the ENTER/EXIT bar code twice to accept the selections and exit Programming Mode. NOTE $CLFCH Configure Character Conversion 0xFFFFFFFFFFFFFFFF DEFAULT (No character conversion) Wasp WWS650...
Page 75: Reading Parameters
READING PARAMETERS starting on page 66 OUBLE IMEOUT starting on page 68 EEPER NDICATORS Power On Alert on page 68 • Good Read: When to Indicate on page 68 • Good Read Beep Type on page 69 • Good Read Beep Frequency on page 69 •...
Page 76: Double Read Timeout
Double Read Timeout = 0.2 Second $CSNDR1E(CR) Double Read Timeout = 0.3 Second $CSNDR28(CR) Double Read Timeout = 0.4 Second $CSNDR32(CR) Double Read Timeout = 0.5 Second $CSNDR3C(CR) DEFAULT Double Read Timeout = 0.6 Second $CSNDR46(CR) Double Read Timeout = 0.7 Second Wasp WWS650...
Page 77 Reading Parameters Enter/Exit Programming Mode Double Read Timeout (continued) $CSNDR50(CR) Double Read Timeout = 0.8 Second $CSNDR5A(CR) Double Read Timeout = 0.9 Second $CSNDR64(CR) Double Read Timeout = 1 Second Product Reference Guide...
Page 78: Led And Beeper Indicators
This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a bar code. $CBPIN00(CR) DEFAULT Indicate Good Read = After Decode $CBPIN01(CR) Indicate Good Read = After Transmit $CBPIN02(CR) Indicate Good Read = After CTS goes inactive then active Wasp WWS650...
Page 79: Good Read Beep Type
Reading Parameters Enter/Exit Programming Mode Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound. $CBPTY00(CR) DEFAULT Good Read Beep Type = Mono $CBPTY01(CR) Good Read Beep Type = Bitonal Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable from the list below.
Page 80: Good Read Beep Length
Good Read Beep Length = 120 msec $CBPLE0E(CR) Good Read Beep Length = 140 msec $CBPLE10(CR) Good Read Beep Length = 160 msec $CBPLE12(CR) Good Read Beep Length = 180 msec $CBPLE14(CR) Good Read Beep Length = 200 msec Wasp WWS650...
Page 81: Good Read Beep Volume
Reading Parameters Enter/Exit Programming Mode Good Read Beep Volume Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels. $CBPVO00CR) Good Read Beep Volume = Beeper Off $CBPVO01CR) Good Read Beep Volume = Low $CBPVO02CR) Good Read Beep Volume = Medium $CBPVO03CR)
Page 82: Good Read Led Duration
Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 003 = Good Read LED DEFAULT stays on for 300 ms. Indicators are dimmed during sleep. NOTE Wasp WWS650...
Page 83: Scanning Features
Reading Parameters Enter/Exit Programming Mode SCANNING FEATURES Scan Mode Selects the reader’s scan operating mode. See page 256 in “References” for descriptions. $CSNRM00(CR) DEFAULT Scan Mode = Trigger Single $CSNRM01(CR) Scan Mode = Trigger Hold Multiple $CSNRM02(CR) Scan Mode = Trigger Pulse Multiple $CSN- Scan Mode = Flashing $CSNRM04(CR)
Page 84: Stand Mode Indication
Base Station (cordless models) and switches out of Stand Mode into Trig- gered Mode, blinking will stop until Stand Mode is active again. $CSMFL00(CR) DEFAULT Stand Mode Indication = Disable $CSMFL01(CR) Stand Mode Indication = Enable Wasp WWS650...
Page 85: Stand Operation
Reading Parameters Enter/Exit Programming Mode Stand Operation Specifies the behavior of the reader when stationary in a stand. There are two conditions which cause the reader to switch to Stand Mode: 1. The reader is manually configured to switch to Stand Mode or when inserted into the spe- cial Stand support which automatically enables the Stand Mode.
Page 86: Pick Mode
Pick Mode = Enable Stand Mode Sensitivity Sets the sensitivity level for stand mode wakeup. Choices are low, medium and high. $CSMSE00(CR) Stand Mode Sensitivity = Low $CSMSE01(CR) DEFAULT Stand Mode Sensitivity = Medium $CSMSE02(CR) Stand Mode Sensitivity = High Wasp WWS650...
Page 87: Stand Mode Illumination Off Time
Reading Parameters Enter/Exit Programming Mode Stand Mode Illumination Off Time Specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 sec- onds).
Page 88: Stand Illumination Control
Select Flash ON Time Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 10 = Flash is ON for 1 Second DEFAULT Wasp WWS650...
Page 89: Flash Off Time
Reading Parameters Enter/Exit Programming Mode Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. See page 261 in “References”...
Page 90: Aiming Duration Timer
End by scanning the ENTER/EXIT bar code. Set Aiming Duration Timer Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL Wasp WWS650...
Page 91: Green Spot Duration
Reading Parameters Enter/Exit Programming Mode Green Spot Duration Specifies the duration of the good read pointer beam after a good read. $CLSSP00(CR) Green Spot Duration = Disable (Green Spot is Off) $CLSSP01(CR) DEFAULT Green Spot Duration = Short (300 msec) $CLSSP02(CR) Green Spot Duration = Medium (500 msec) $CLSSP03(CR)
Page 92: Partial Label Reading Control
Decode Negative Image bar code. NOTE When this feature is enabled, you will be unable to read other programming labels in this manual. CAUTION $P,CIPVR00,P(CR) DEFAULT Decode Negative Image = Disable $P,CIPVR01,P(CR) Decode Negative Image = Enable Wasp WWS650...
Page 93: Multiple Label Reading
Reading Parameters Enter/Exit Programming Mode MULTIPLE LABEL READING In standard (default) mode, when the reader’s aiming system is activated (by a trigger pull, motion or other method depending on the mode), it then acquires and processes each image in the area in front of it (the Volume). In this case, the scanner stops processing the image once it decodes a label.
Page 94: Multiple Labels Ordering By Code Symbology
DEFAULT Multiple Labels Ordering by Code Length Specifies the transmission ordering by code length, when Multiple Labels per Frame is enabled. $CSNMT00(CR) DEFAULT Multiple Labels Ordering = Disable $CSNMT01(CR) $CSNMT02(CR) Transmit Increasing Length Order Transmit Decreasing Length Order Wasp WWS650...
Page 95: 1D Symbologies
1D SYMBOLOGIES 1D Code Selection The reader supports the following 1D symbologies (bar code types). See "2D Symbologies" starting on page 177 for 2D bar codes. Symbology-dependent options are included in each chapter. • Disable All Symbologies, page 86 • GS1-128, page 123 •...
Page 96: Disable All Symbologies
1. Scan the ENTER/EXIT PROGRAMMING Mode bar code. 2. Scan the Disable All Symbologies bar code. 3. Complete the programming sequence by scanning the ENTER/EXIT PROGRAMMING bar code. $AD(CR) Disable All Symbologies This does not disable the reading of programming labels. NOTE Wasp WWS650...
Page 97: Code Ean/Upc
1D Symbologies Enter/Exit Programming Mode CODE EAN/UPC Coupon Control This feature is used to control the reader’s method of processing coupon labels. $CCPLC00(CR) Coupon Control = Allow all coupon bar codes to be decoded $CCPLC01(CR) DEFAULT Coupon Control = Enable only UPCA coupon decoding $CCPLC02(CR) Coupon Control = Enable only GS1 DataBar™...
Page 98: Upc-A
DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A bar code data. $CABCT00(CR) UPC-A Check Character Transmission = Don’t Send $CABCT01(CR) DEFAULT UPC-A Check Character Transmission = Send Wasp WWS650...
Page 99: Expand Upc-A To Ean-13
1D Symbologies Enter/Exit Programming Mode Expand UPC-A to EAN-13 Expands UPC-A data to the EAN-13 data format. Selecting this feature also changes the sym- bology ID to match those required for EAN-13. $CAB3B00(CR) DEFAULT UPC-A to EAN-13 = Don’t Expand $CAB3B01(CR) UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission...
Page 100: Upc-A 2D Component
EAN-13 2D Component = 2D component must be decoded UPC-E The following options apply to the UPC-E symbology. UPC-E Enable/Disable When disabled, the reader will not read UPC-E bar codes. $CEBEN00(CR) UPC-E = Disable $CEBEN01(CR) DEFAULT UPC-E = Enable Wasp WWS650...
Page 101: Upc-E Check Character Transmission
1D Symbologies Enter/Exit Programming Mode UPC-E Check Character Transmission Enable this option to transmit the check character along with UPC-E bar code data. $CEBCT00(CR) UPC-E Check Character Transmission = Don’t Send $CEBCT01(CR) DEFAULT UPC-E Check Character Transmission = Send UPC-E 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded.
Page 102: Expand Upc-E To Ean-13
UPC-E to EAN-13 = Don’t Expand $CEB3B01(CR) UPC-E to EAN-13 = Expand Expand UPC-E to UPC-A Expands UPC-E data to the UPC-A data format. $CEBAB00(CR) DEFAULT UPC-E to UPC-A = Don’t Expand $CEBAB01(CR) UPC-E to UPC-A = Expand Wasp WWS650...
Page 103: Upc-E Number System Character Transmission
1D Symbologies Enter/Exit Programming Mode UPC-E Number System Character Transmission This feature enables/disables transmission of the UPC-E system number character. $CEBNS00(CR) UPC-E Number System Character = Do not transmit $CEBNS01(CR) DEFAULT UPC-E Number System Character = Transmit GTIN FORMATTING This feature enables/disables the ability to convert UPC-E, UPC-A, EAN 8, and EAN 13 labels into the GTIN 14-character format.
Page 104: Ean 13 (Jan 13)
EAN 13 Check Character Transmission Enable this option to transmit the check character along with EAN 13 bar code data. $C3BCT00(CR) EAN 13 Check Character Transmission = Don’t Send $C3BCT01(CR) DEFAULT EAN 13 Check Character Transmission = Send Wasp WWS650...
Page 105: Ean-13 Flag 1 Character
1D Symbologies Enter/Exit Programming Mode EAN-13 Flag 1 Character Enables/disables transmission of an EAN/JAN13 Flag1 character. The Flag 1 character is the first character of the label. $C3BF100(CR) EAN-13 Flag 1 Char= Don’t transmit $C3BF101(CR) DEFAULT EAN-13 Flag 1 Char= Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels.
Page 106: Ean-13 2D Component
EAN-13 2D Component = 2D component must be decoded ISSN The following options apply to the ISSN symbology. ISSN Enable/Disable Enables/disables conversion of EAN/JAN13 Bookland labels starting with 977 to ISSN labels. $C3BIN00(CR) DEFAULT ISSN = Disable $C3BIN01(CR) ISSN = Enable Wasp WWS650...
Page 107: Ean 8 (Jan 8)
1D Symbologies Enter/Exit Programming Mode EAN 8 (JAN 8) The following options apply to the EAN 8 (Jan 8) symbology. EAN 8 Enable/Disable When disabled, the reader will not read EAN 8/JAN 8 bar codes. $C8BEN00(CR) EAN 8 = Disable $C8BEN01(CR) DEFAULT EAN 8 = Enable...
Page 108: Expand Ean 8 To Ean 13
This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. $C8B2D00(CR) DEFAULT EAN 8 2D Component = Disable (2D component not required) $C8B2D01(CR) EAN 8 2D Component = 2D component must be decoded Wasp WWS650...
Page 109: Upc/Ean Global Settings
1D Symbologies Enter/Exit Programming Mode UPC/EAN GLOBAL SETTINGS This section provides configuration settings for UPC-A, UPC-E, EAN 13 and EAN 8 symbologies, and affects all of these unless otherwise marked for each feature description. UPC/EAN Price Weight Check This feature enables/disables calculation and verification of price/weight check digits. $CPWEN00(CR) DEFAULT Price Weight Check = Disabled...
Page 110: Upc/Ean Quiet Zones
10 times the width of the narrowest bar or space in the label. The property applies to all EAN-UPC symbologies globally and to the ADDONs. $CUNLO02(CR) DEFAULT UPC/EAN Quiet Zones = Two Modules $CUNLO03(CR) UPC/EAN Quiet Zones = Three Modules Wasp WWS650...
Page 111: Add-Ons
1D Symbologies Enter/Exit Programming Mode ADD-ONS Contact Customer Support for advanced programming of optional and conditional add-ons. Optional Add-ons The reader can be enabled to optionally read the following add-ons (supplementals): If a UPC/EAN base label and an add-on are both decoded, the reader will transmit the base label and add-on.
Page 112: Optional Add-On Timer
(Also see "Optional GS1-128 Add-On Timer" page 105.) $CADOT01(CR) Optional Add-on Timer = 10ms $CADOT02(CR) Optional Add-on Timer = 20ms $CADOT03(CR) Optional Add-on Timer = 30ms $CADOT04(CR) Optional Add-on Timer = 40ms $CADOT05(CR) Optional Add-on Timer = 50ms Wasp WWS650...
Page 113 1D Symbologies Enter/Exit Programming Mode Optional Add-On Timer (continued) $CADOT06(CR) Optional Add-on Timer = 60ms $CADOT07(CR) DEFAULT Optional Add-on Timer = 70ms $CADOT0A(CR) Optional Add-on Timer = 100ms $CADOT0C(CR) Optional Add-on Timer = 120ms $CADOT0E(CR) Optional Add-on Timer = 140ms $CADOT10(CR) Optional Add-on Timer = 160ms Product Reference Guide...
Page 114 Optional Add-on Timer = 180ms $CADOT14(CR) Optional Add-on Timer = 200ms $CADOT16(CR) Optional Add-on Timer = 220ms $CADOT18(CR) Optional Add-on Timer = 240ms $CADOT1A(CR) Optional Add-on Timer = 260ms $CADOT1C(CR) Optional Add-on Timer = 280ms $CADOT1E(CR) Optional Add-on Timer = 300ms Wasp WWS650...
Page 115: Optional Gs1-128 Add-On Timer
1D Symbologies Enter/Exit Programming Mode Optional GS1-128 Add-On Timer This option sets the timer expiration value to read the added part after reading the linear EAN/ UPC part. For UPC/EAN add-ons other than those of that type, see "Optional Add-On Timer" page 102.
Page 116 Optional GS1-128 Add-On Timer = 60ms $CADUT07(CR) Optional GS1-128 Add-On Timer = 70ms $CADUT0A(CR) Optional GS1-128 Add-On Timer = 100ms $CADUT0C(CR) Optional GS1-128 Add-On Timer = 120ms $CADUT0E(CR) Optional GS1-128 Add-On Timer = 140ms $CADUT10(CR) Optional GS1-128 Add-On Timer = 160ms Wasp WWS650...
Page 117 1D Symbologies Enter/Exit Programming Mode Optional GS1-128 Add-On Timer (continued) $CADUT12(CR) Optional GS1-128 Add-On Timer = 180ms $CADUT14(CR) Optional GS1-128 Add-On Timer = 200ms $CADUT16(CR) Optional GS1-128 Add-On Timer = 220ms $CADUT18(CR) Optional GS1-128 Add-On Timer = 240ms $CADUT1A(CR) Optional GS1-128 Add-On Timer = 260ms $CADUT1C(CR) Optional GS1-128 Add-On Timer = 280ms $CADUT1E(CR)
Page 118: Code 39
When disabled, any check character in the label is treated as a data character $CC3CC00(CR) Code 39 Check Character Calculation = Don’t Calculate $CC3CC01(CR) DEFAULT Code 39 Check Character Calculation = Calculate Std Check $CC3CC02(CR) Code 39 Check Character Calculation = Calculate Mod 7 Check Wasp WWS650...
Page 119: Code 39 Check Character Transmission
1D Symbologies Enter/Exit Programming Mode Code 39 Check Character Calculation (continued) $CC3CC04(CR) Code 39 Check Character Calculation = Enable Italian Post Check $CC3CC08(CR) Code 39 Check Character Calculation = Enable Daimler Chrysler Check Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 bar code data. $CC3CT00(CR) Code 39 Check Character Transmission = Don’t Send $CC3CT01(CR)
Page 120: Code 39 Start/Stop Character Transmission
Code 39 Start/Stop Character Transmission = Transmit Code 39 Full ASCII Enables/disables the translation of Code 39 characters to Code 39 full-ASCII characters. $CC3FA00(CR) DEFAULT Code 39 Full ASCII = Disable $CC3FA01(CR) Code 39 Full ASCII = Enable Wasp WWS650...
Page 121: Code 39 Quiet Zones
1D Symbologies Enter/Exit Programming Mode Code 39 Quiet Zones This feature specifies the number of quiet zones for Code 39 labels. Quiet zones are blank areas at the ends of a bar code, typically 10 times the width of the narrowest bar or space in the label.
Page 122: Code 39 Set Length 1
Select Code 39 Set Length 1 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 02 = Length 1 is 2 Characters DEFAULT Wasp WWS650...
Page 123: Code 39 Set Length 2
1D Symbologies Enter/Exit Programming Mode Code 39 Set Length 2 This feature specifies one of the bar code lengths for Code 39 Length Control on page 111. Length 2 is the maximum label length if in Variable Length on page 111 Mode, or the second fixed length if in Fixed Length on page 111...
Page 124: Trioptic Code
CODE 32 (ITAL PHARMACEUTICAL CODE) The following options apply to the Code 32 (Italian Pharmaceutical Code) symbology. Code 32 Enable/Disable When disabled, the reader will not read Code 32 bar codes. $CP3EN00(CR) DEFAULT Code 32 = Disable $CP3EN01(CR) Code 32 = Enable Wasp WWS650...
Page 125: Code 32 Feature Setting Exceptions
1D Symbologies Enter/Exit Programming Mode Code 32 Feature Setting Exceptions The following features are set for Code 32 by using these Code 39 set- tings: "Code 39 Quiet Zones" on page 111 NOTE "Code 39 Length Control" on page 111 "Trioptic Code"...
Page 126: Code 39 Cip (French Pharmaceutical)
The following options apply to the Code 39 Danish PPT symbology. Code 39 Danish PPT Enable/Disable Enables/Disables AIM ID for Code 39 Danish PPT Codes. $CDPEN00(CR) DEFAULT Code 39 Danish PPT = Disable $CDPEN01(CR) Code 39 Danish PPT = Enable Wasp WWS650...
Page 127: Code 39 Laposte
1D Symbologies Enter/Exit Programming Mode CODE 39 LAPOSTE The following options apply to the Code 39 LaPoste symbology. Code 39 LaPoste Enable/Disable Enables/disables the ability of the scanner to decode Code39 La Poste labels. $CLPEN00(CR) DEFAULT Code 39 LaPoste = Disable $CLPEN01(CR) Code 39 LaPoste = Enable CODE 39 PZN...
Page 128: Code 128
Code 128 = Enable Expand Code 128 to Code 39 This feature enables/disables expansion of Code 128 labels to Code 39 labels. $CC8C300(CR) DEFAULT Code 128 to Code 39 = Don’t Expand $CC8C301(CR) Code 128 to Code 39 = Expand Wasp WWS650...
Page 129: Code 128 Check Character Transmission
1D Symbologies Enter/Exit Programming Mode Code 128 Check Character Transmission Enable this option to transmit the check character along with Code 128 bar code data. $CC8CT00(CR) DEFAULT Code 128 Check Character Transmission = Don’t Send $CC8CT01(CR) Code 128 Check Character Transmission = Send Code 128 Function Character Transmission Enables/disables transmission of Code128 function characters 1, 2, 3, and 4.
Page 130: Code 128 Quiet Zones
This feature specifies either variable length decoding or fixed length decoding for the Code 128 symbology. See page 245 for more information. $CC8LC00(CR) DEFAULT Code 128 Length Control = Variable Length $CC8LC01(CR) Code 128 Length Control = Fixed Length Wasp WWS650...
Page 131: Code 128 Set Length 1
1D Symbologies Enter/Exit Programming Mode Code 128 Set Length 1 Specifies one of the bar code lengths for Code 128 Length Control on page 120. Length 1 is the minimum label length if in Variable Length on page 245 Mode, or the first fixed length if in Fixed Length on page 245 Mode.
Page 132: Code 128 Set Length 2
Select Code 128 Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 80 = Length 2 is 80 Characters DEFAULT Wasp WWS650...
Page 133: Gs1-128
1D Symbologies Enter/Exit Programming Mode GS1-128 The following options apply to the GS1-128 symbology. (Also known as USS-128, GS1-128, GTIN-128, UCC-128, EAN-128.) GS1-128 Enable This option enables/disables the ability of the reader to translate GS1-128 labels to the GS1- 128 data format. Options are: •...
Page 134: Code Isbt 128
When enabled, this feature forces concatenation for ISBT. ISBT 128 Concatenation on page 124 This option is only valid when is enabled. NOTE $CI8FC00(CR) DEFAULT ISBT 128 Force Concatenation = Disable $CI8FC01(CR) ISBT 128 Force Concatenation = Enable Wasp WWS650...
Page 135: Isbt 128 Concatenation Mode
1D Symbologies Enter/Exit Programming Mode ISBT 128 Concatenation Mode Specifies the concatenation mode between Static and Dynamic. ISBT 128 This option is only valid when ISBT 128 Concatenation is enabled (see " Concatenation" on page 124 NOTE $CI8CM00CR) DEFAULT ISBT 128 Concatenation Mode = Static $CI8CM01CR) ISBT 128 Concatenation Mode = Dynamic Product Reference Guide...
Page 136: Isbt 128 Dynamic Concatenation Timeout
ISBT 128 Dynamic Concatenation Timeout = 100 msec DEFAULT $CI8DT14(CR) ISBT 128 Dynamic Concatenation Timeout = 200 msec $CI8DT32(CR) ISBT 128 Dynamic Concatenation Timeout = 500 msec $CI8DT4B(CR) ISBT 128 Dynamic Concatenation Timeout = 750 msec $CI8DT64(CR) ISBT 128 Dynamic Concatenation Timeout = 1 second Wasp WWS650...
Page 137: Isbt 128 Advanced Concatenation Options
1D Symbologies Enter/Exit Programming Mode ISBT 128 Advanced Concatenation Options To set up pairs of label types for concatenation, contact Technical Support. NOTE INTERLEAVED 2 OF 5 (I 2 OF 5) The following options apply to the I 2 of 5 symbology. I 2 of 5 Enable/Disable When disabled, the reader will not read I 2 of 5 bar codes.
Page 138: I 2 Of 5 Check Character Calculation
I 2 of 5 Check Character Calculation = Check DHL $CI2CC08(CR) I 2 of 5 Check Character Calculation = Check Daimler Chrysler $CI2CC10(CR) I 2 of 5 Check Character Calculation = Check Bosch $CI2CC20(CR) I 2 of 5 Check Character Calculation = Italian Post Wasp WWS650...
Page 139: I 2 Of 5 Check Character Transmission
1D Symbologies Enter/Exit Programming Mode I 2 of 5 Check Character Transmission Enable this option to transmit the check character along with I 2 of 5 bar code data. $CI2CT00(CR) I 2 of 5 Check Character Transmission = Don’t Send $CI2CT01(CR) DEFAULT I 2 of 5 Check Character Transmission = Send...
Page 140: I 2 Of 5 Set Length 1
Select I 2 of 5 Length 1 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 06 = Length 1 is 6 Characters DEFAULT Wasp WWS650...
Page 141: I 2 Of 5 Set Length 2
1D Symbologies Enter/Exit Programming Mode I 2 of 5 Set Length 2 This feature specifies one of the bar code lengths for I 2 of 5 Length Control on page 129. Length 2 is the maximum label length if in Variable Length on page 245 Mode, or the second fixed length if in...
Page 142: Interleaved 2 Of 5 Cip Hr
The following options apply to the Follett 2 of 5 symbology. Follett 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Plessey labels. $CF2EN00(CR) DEFAULT Follett 2 of 5 = Disable $CF2EN01(CR) Follett 2 of 5 = Enable Wasp WWS650...
Page 143: Standard 2 Of 5
1D Symbologies Enter/Exit Programming Mode STANDARD 2 OF 5 The following options apply to the Standard 2 of 5 symbology. Standard 2 of 5 Enable/Disable When disabled, the reader will not read Standard 2 of 5 bar codes. $CS2EN00(CR) DEFAULT Standard 2 of 5 = Disable $CS2EN01(CR) Standard 2 of 5 = Enable...
Page 144: Standard 2 Of 5 Check Character Transmission
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CS2LC00(CR) DEFAULT Standard 2 of 5 Length Control = Variable Length $CS2LC01(CR) Standard 2 of 5 Length Control = Fixed Length Wasp WWS650...
Page 145: Standard 2 Of 5 Set Length 1
1D Symbologies Enter/Exit Programming Mode Standard 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Standard 2 of 5 Length Control on page 134. Length 1 is the minimum label length if in Variable Length on page 134 Mode, or the first fixed length if in...
Page 146: Standard 2 Of 5 Set Length 2
Select Standard 2 of 5 Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT Wasp WWS650...
Page 147: Industrial 2 Of 5
1D Symbologies Enter/Exit Programming Mode INDUSTRIAL 2 OF 5 The following options apply to the Industrial 2 of 5 symbology. Industrial 2 of 5 Enable/Disable Enables/Disables ability of reader to decode Industrial 2 of 5 labels. $CU2EN00(CR) DEFAULT Industrial 2 of 5 = Disable $CU2EN01(CR) Industrial 2 of 5 = Enable Industrial 2 of 5 Check Character Calculation...
Page 148: Industrial 2 Of 5 Check Character Transmission
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CU2LC00(CR) DEFAULT Industrial 2 of 5 Length Control = Variable Length $CU2LC01(CR) Industrial 2 of 5 = Fixed Length Wasp WWS650...
Page 149: Industrial 2 Of 5 Set Length 1
1D Symbologies Enter/Exit Programming Mode Industrial 2 of 5 Set Length 1 This feature specifies one of the bar code lengths for Industrial 2 of 5 Length Control on page 138. Length 1 is the minimum label length if in Variable Length on page 111 Mode, or the first fixed length if in...
Page 150: Industrial 2 Of 5 Set Length 2
Select Industrial 2 of5 Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT Wasp WWS650...
Page 151: Code Iata
1D Symbologies Enter/Exit Programming Mode CODE IATA The following options apply to the IATA symbology. IATA Enable/Disable Enables/Disables the ability of the reader to decode IATA labels. $CIAEN00(CR) DEFAULT IATA = Disable $CIAEN01(CR) IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.
Page 152: Codabar
When disabled, any check character in the label is treated as a data character $CCBCC00(CR) DEFAULT Codabar Check Character Calculation = Don’t Calculate $CCBCC01(CR) Codabar Check Character Calculation = Enable AIM standard check char. $CCBCC02(CR) Codabar Check Character Calculation = Enable Modulo 10 check char. Wasp WWS650...
Page 153: Codabar Check Character Transmission
1D Symbologies Enter/Exit Programming Mode Codabar Check Character Transmission Enable this option to transmit the check character along with Codabar bar code data. $CCBCT00(CR) Codabar Check Character Transmission = Don’t Send $CCBCT01(CR) DEFAULT Codabar Check Character Transmission = Send Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters $CCBSS00(CR) Codabar Start/Stop Character Transmission = Don’t Trans-...
Page 154: Codabar Start/Stop Character Set
Codabar Check Character Set = abcd/abcd Codabar Start/Stop Character Match When enabled, this option requires that start and stop characters match $CCBSM00(CR) DEFAULT Codabar Start/Stop Character Match = Don’t Require Match $CCBSM01(CR) Codabar Start/Stop Character Match = Require Match Wasp WWS650...
Page 155: Codabar Quiet Zones
1D Symbologies Enter/Exit Programming Mode Codabar Quiet Zones Specifies the number of quiet zones for Codabar labels. Quiet zones are blank areas at the ends of a bar code and are typically 10 times the width of the narrowest bar or space in the label. $CCBLO02(CR) Codabar Quiet Zones = Quiet Zones on two sides $CCBLO03(CR)
Page 156: Codabar Set Length 1
Select Codabar Length 1 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 03 = Length 1 is 3 Characters DEFAULT Wasp WWS650...
Page 157: Codabar Set Length 2
1D Symbologies Enter/Exit Programming Mode Codabar Set Length 2 This feature specifies one of the bar code lengths for Codabar Length Control on page 145Cod- abar Length Control on page 145. Length 2 is the maximum label length if in Variable Length on page 245 Mode, or the second fixed length if in...
Page 158: Abc Codabar
$CCBAB00(CR) DEFAULT ABC Codabar = Disable $CCBAB01(CR) ABC Codabar = Enable ABC Codabar Concatenation Mode Specifies the concatenation mode between Static and Dynamic. $CCBCM00(CR) DEFAULT ABC Codabar Concatenation Mode = Static $CCBCM01(CR) ABC Codabar Concatenation Mode = Dynamic Wasp WWS650...
Page 159: Abc Codabar Dynamic Concatenation Timeout
1D Symbologies Enter/Exit Programming Mode ABC Codabar Dynamic Concatenation Timeout Specifies the timeout in 10-millisecond ticks used by the ABC Codabar Dynamic Concatenation Mode. $CCBDT05(CR) ABC Codabar Dynamic Concatenation Timeout = 50 msec $CCBDT0A(CR) ABC Codabar Dynamic Concatenation Timeout = 100 msec $CCBDT14(CR) DEFAULT...
Page 160: Abc Codabar Force Concatenation
Enter/Exit Programming Mode ABC Codabar ABC Codabar Force Concatenation Forces labels starting or ending with D to be concatenated. $CCBFC00(CR) DEFAULT ABC Codabar Force Concatenation = Disable $CCBFC01(CR) ABC Codabar Force Concatenation = Enable Wasp WWS650...
Page 161: Code 11
1D Symbologies Enter/Exit Programming Mode CODE 11 The following options apply to the Code 11 symbology. Code 11 Enable/Disable When disabled, the reader will not read Code 11 bar codes. $CC1EN00(CR) DEFAULT Code 11 = Disable $CC1EN01(CR) Code 11 = Enable Code 11 Check Character Calculation This option enables/disables calculation and verification of optional Code 11 check character.
Page 162: Code 11 Check Character Transmission
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CC1LC00(CR) DEFAULT Code 11 Length Control = Variable Length $CC1LC01(CR) Code 11 Length Control = Fixed Length Wasp WWS650...
Page 163: Code 11 Set Length 1
1D Symbologies Enter/Exit Programming Mode Code 11 Set Length 1 This feature specifies one of the bar code lengths for Code 11 Length Control on page 152. Length 1 is the minimum label length if in Variable Length on page 245 Mode, or the first fixed length if in Fixed Length on page 245...
Page 164: Code 11 Set Length 2
Select Code 11 Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT Wasp WWS650...
Page 165: Gs1 Databar™ Omnidirectional
1D Symbologies Enter/Exit Programming Mode GS1 DATABAR™ OMNIDIRECTIONAL The following options apply to the GS1 DataBar™ Omnidirectional (formerly RSS-14) symbol- ogy. GS1 DataBar™ Omnidirectional Enable/Disable When disabled, the reader will not read GS1 DataBar™ Omnidirectional bar codes. $C4BEN00(CR) DEFAULT GS1 DataBar™ Omnidirectional = Disable $C4BEN01(CR) GS1 DataBar™...
Page 166: Gs1 Databar™ Omnidirectional 2D Component
The following options apply to the GS1 DataBar™ Expanded (formerly RSS Expanded) symbol- ogy. GS1 DataBar™ Expanded Enable/Disable When disabled, the reader will not read GS1 DataBar™ Expanded bar codes. $CXBEN00(CR) DEFAULT GS1 DataBar™ Expanded = Disable $CXBEN01(CR) GS1 DataBar™ Expanded = Enable Wasp WWS650...
Page 167: Gs1 Databar™ Expanded Gs1-128 Emulation
1D Symbologies Enter/Exit Programming Mode GS1 DataBar™ Expanded GS1-128 Emulation When enabled, GS1 DataBar™ Expanded bar codes will be translated to the GS1-128 label data format. $CXBU800(CR) DEFAULT GS1 DataBar™ Expanded GS1-128 Emulation = Disable $CXBU801(CR) GS1 DataBar™ Expanded GS1-128 Emulation = Enable GS1 DataBar™...
Page 168: Gs1 Databar™ Expanded Length Control
For variable-length decoding, a minimum length may be set. Variable Length: For fixed-length decoding, two different lengths may be set. Fixed Length: $CXBLC00(CR) DEFAULT GS1 DataBar™ Expanded Length Control = Variable Length $CXBLC01(CR) GS1 DataBar™ Expanded Length Control = Fixed Length Wasp WWS650...
Page 169: Gs1 Databar™ Expanded Set Length 1
1D Symbologies Enter/Exit Programming Mode GS1 DataBar™ Expanded Set Length 1 This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control on page 158. Length 1 is the minimum label length if in Variable Length on page 245 Mode, or the first fixed length if in Fixed Length on page 245...
Page 170: Gs1 Databar™ Expanded Set Length 2
Select GS1 DataBar™ Expanded Set Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 74 = Length 2 is 74 Characters DEFAULT Wasp WWS650...
Page 171: Gs1 Databar™ Limited
1D Symbologies Enter/Exit Programming Mode GS1 DATABAR™ LIMITED The following options apply to the GS1 DataBar™ Limited (formerly RSS Limited) symbology. GS1 DataBar™ Limited Enable/Disable When disabled, the reader will not read GS1 DataBar™ Limited bar codes. $CLBEN00(CR) DEFAULT GS1 DataBar™ Limited = Disable $CLBEN01(CR) GS1 DataBar™...
Page 172: Gs1 Databar™ Limited 2D Component
2D component must be decoded CODE 93 The following options apply to the Code 93 symbology. Code 93 Enable/Disable Enables/Disables ability of reader to decode Code 93 labels. $CC9EN00(CR) DEFAULT Code 93 = Disable $CC9EN01(CR) Code 93 = Enable Wasp WWS650...
Page 173: Code 93 Check Character Calculation
1D Symbologies Enter/Exit Programming Mode Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character. $CC9CC00(CR) Code 93 Check Character Calculation = Disable $CC9CC01(CR) Code 93 Check Character Calculation = Enable Check C $CC9CC02(CR) Code 93 Check Character Calculation = Enable Check K $CC9CC03(CR) DEFAULT...
Page 174: Code 93 Length Control
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CC9LC00(CR) DEFAULT Code 93 Length Control = Variable Length $CC9LC01(CR) Code 93 = Fixed Length Wasp WWS650...
Page 175: Code 93 Set Length 1
1D Symbologies Enter/Exit Programming Mode Code 93 Set Length 1 Specifies one of the bar code lengths for Code 93 Length Control on page 164. Length 1 is the minimum label length if in Variable Length on page 245 Mode, or the first fixed length if in Fixed Length on page 245 Mode.
Page 176: Code 93 Set Length 2
Select Code 93 Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT Wasp WWS650...
Page 177: Code 93 Quiet Zones
1D Symbologies Enter/Exit Programming Mode Code 93 Quiet Zones Enables/disables quiet zones for Code 93. $CC9LO02(CR) Code 93 Quiet Zones = Quiet Zones on two sides $CC9LO03(CR) DEFAULT Code 93 Quiet Zones = Small Quiet Zones on two sides The following options apply to the MSI symbology. MSI Enable/Disable Enables/Disables ability of reader to decode MSI labels.
Page 178: Msi Check Character Calculation
MSI Check Character Calculation = Enable Mod11/10 $CMSCC03(CR) MSI Check Character Calculation = Enable Mod10/10 MSI Check Character Transmission Enables/disables transmission of an MSI check character. $CMSCT00(CR) MSI Check Character Transmission = Disable $CMSCT01(CR) DEFAULT MSI Check Character Transmission = Enable Wasp WWS650...
Page 179: Msi Length Control
1D Symbologies Enter/Exit Programming Mode MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI sym- bology. For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CMSLC00(CR) DEFAULT...
Page 180: Msi Set Length 1
Select MSI Set Length 1 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 181: Msi Set Length 2
1D Symbologies Enter/Exit Programming Mode MSI Set Length 2 This feature specifies one of the bar code lengths for MSI Length Control on page 169. Length 2 is the maximum label length if in Variable Length on page 245 Mode, or the second fixed length if in Fixed Length on page 245 Mode.
Page 182: Plessey
$CPLCC01(CR) DEFAULT Plessey Check Character Calculation = Enable Plessey std. check char. verification $CPLCC02(CR) Plessey Check Character Calculation = Enable Anker check char. verification $CPLCC03(CR) Plessey Check Character Calculation = Enable Plessey std. and Anker check char verification Wasp WWS650...
Page 183: Plessey Check Character Transmission
1D Symbologies Enter/Exit Programming Mode Plessey Check Character Transmission Enables/disables transmission of an MSI check character. $CPLCT00(CR) Plessey Check Character Transmission = Disable $CPLCT01(CR) DEFAULT Plessey Check Character Transmission = Enable Plessey Length Control This feature specifies either variable length decoding or fixed length decoding for the Plessey symbology.
Page 184: Plessey Set Length 1
Select Plessey Set Length 1 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 185: Plessey Set Length 2
1D Symbologies Enter/Exit Programming Mode Plessey Set Length 2 This feature specifies one of the bar code lengths for Plessey Length Control on page 173. Length 2 is the maximum label length if in Variable Length on page 245 Mode, or the second fixed length if in Fixed Length on page 245 Mode.
Page 186 Enter/Exit Programming Mode Plessey NOTES Wasp WWS650...
Page 187: 2D Symbologies
2D SYMBOLOGIES 2D Global Features • 2D Maximum Decoding Time on page 178 • 2D Normal/Inverse Symbol Control on page 179 • 2D Structured Append on page 179 The reader supports the following 2D symbologies (bar code types). Symbology-dependent options for each symbology are included in this chapter. See "1D Code Selection"...
Page 188: 2D Maximum Decoding Time
2D Maximum Decoding Time = 350 msec $CDETM80(CR) 2D Maximum Decoding Time = 500 msec $CDETM16(CR) 2D Maximum Decoding Time = 1 Second $CDETMC8(CR) 2D Maximum Decoding Time = 2 Seconds $CDETMFF(CR) 2D Maximum Decoding Time = 2.55 Seconds Wasp WWS650...
Page 189: 2D Structured Append
2D Symbologies Enter/Exit Programming Mode 2D Structured Append Enables/disables ability of reader to append multiple 2D Codes labels in a structured format. The structured append property is globally applied to the following symbologies, if these are enabled: • Data Matrix •...
Page 190: Symbology Selection
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CAZLC00(CR) DEFAULT Aztec Code Length Control = Variable Length $CAZLC01(CR) Aztec Code Length Control = Fixed Length Wasp WWS650...
Page 191: Aztec Code Set Length 1
Symbology Selection Enter/Exit Programming Mode Aztec Code Set Length 1 Specifies one of the bar code lengths for Aztec Code Length Control on page 180. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 192: Aztec Code Set Length 2
Select Aztec Code Length 2 Setting bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 3,832 Characters DEFAULT Wasp WWS650...
Page 193: China Sensible Code
Symbology Selection Enter/Exit Programming Mode China Sensible Code China Sensible Code Enable / Disable Enables/disables the ability of the reader to decode China Sensible Code labels. $CCSEN00(CR) DEFAULT China Sensible Code = Disable $CCSEN01(CR) China Sensible Code = Enable China Sensible Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbol- ogy.
Page 194: China Sensible Code Set Length 1
Select China Sensible Code Length 1 Setting EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 195: China Sensible Code Set Length 2
Symbology Selection Enter/Exit Programming Mode China Sensible Code Set Length 2 This feature specifies one of the bar code lengths for China Sensible Code Length Control on page 183. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 196: Data Matrix
The configuration item can also be configured as a bit mask to filter one or more Data Matrix labels with different symbol size AND shape styles. $CDMDM3FFF0BDF) Data Matrix Dimensions Mask = Square Style $CDMDM0000420 Data Matrix Dimensions Mask = Rectangular Style $CDMD03FFFFFF DEFAULT Data Matrix Dimensions Mask = Both Square and Rectangular Style Wasp WWS650...
Page 197: Data Matrix Length Control
Symbology Selection Enter/Exit Programming Mode Data Matrix Length Control This feature specifies either variable length decoding or fixed length decoding for this symbol- ogy. For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CDMLC00(CR) DEFAULT...
Page 198: Data Matrix Set Length 2
EXIT bar code again. Select Data Matrix Length 2 Setting Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 3,116 Characters DEFAULT Wasp WWS650...
Page 199: Maxicode
Symbology Selection Enter/Exit Programming Mode Maxicode Maxicode Enable / Disable Enables/disables ability of reader to decode Maxicode labels. $CMXEN00(CR) DEFAULT Maxicode = Disable $CMXEN01(CR) Maxicode = Enable Maxicode Primary Message Transmission Enables/disables the transmission of only the Primary Message when the Secondary Message is not readable.
Page 200: Maxicode Length Control
Select Maxicode Length 1 Setting EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 201: Maxicode Set Length 2
Symbology Selection Enter/Exit Programming Mode Maxicode Set Length 2 This feature specifies one of the bar code lengths for Maxicode Length Control on page 190. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 202: Pdf417
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CP4LC00(CR) DEFAULT PDF417 Length Control = Variable Length $CP4LC01(CR) PDF417 Length Control = Fixed Length Wasp WWS650...
Page 203: Pdf417 Set Length 1
Symbology Selection Enter/Exit Programming Mode PDF417 Set Length 1 Specifies one of the bar code lengths for PDF417 Length Control on page 192. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 204: Pdf417 Set Length 2
Select PDF417 Length 2 Setting EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 2,710 Characters DEFAULT Wasp WWS650...
Page 205: Micro Pdf417
Symbology Selection Enter/Exit Programming Mode Micro PDF417 Micro PDF417 Enable / Disable Enables/disables the ability of the reader to decode Micro PDF417 labels $CMIEN00(CR) DEFAULT Micro PDF417 = Disable $CMIEN01(CR) Micro PDF417 = Enable Micro PDF417 Code 128 GS1-128 Emulation Specifies which AIM ID to use for MicroPDF labels when doing Code 128 or GS1-128 emulation.
Page 206: Micro Pdf417 Length Control
Select Micro PDF417 Length 1 Setting EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 207: Micro Pdf417 Set Length 2
Symbology Selection Enter/Exit Programming Mode Micro PDF417 Set Length 2 This feature specifies one of the bar code lengths for Micro PDF417 Length Control on page 196. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length includes the bar code’s data characters only.
Page 208: Qr Code
For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: $CQRLC00(CR) DEFAULT QR Code Length Control = Variable Length $CQRLC01(CR) QR Code Length Control = Fixed Length Wasp WWS650...
Page 209: Qr Code Set Length 1
Symbology Selection Enter/Exit Programming Mode QR Code Set Length 1 Specifies one of the bar code lengths for QR Code Length Control on page 198. Length 1 is the Variable Length Mode, or the first fixed length if in Fixed Length minimum label length if in Mode.
Page 210: Qr Code Set Length 2
Select QR Code Length 2 Setting EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 7,089 Characters DEFAULT Wasp WWS650...
Page 211: Micro Qr Code
Symbology Selection Enter/Exit Programming Mode Micro QR Code Micro QR Code Enable/Disable Enables/disables the ability of the reader to decode Micro QR Code labels MQEN00 DEFAULT Micro QR Code = Disable MQEN01 Micro QR Code = Enable Micro QR Code Length Control This feature specifies either variable length decoding or fixed length decoding for this symbol- ogy.
Page 212: Micro Qr Code Set Length 1
Select Micro QR Code Length 1 Setting bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT Wasp WWS650...
Page 213: Micro Qr Code Set Length 2
Symbology Selection Enter/Exit Programming Mode Micro QR Code Set Length 2 This feature specifies one of the bar code lengths for Micro QR Code Length Control on page 201. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 214: Ucc Composite
Enables/disables the ability of the reader to decode the stacked part of a UCC Composite label. Global AIM ID" on This feature is not effective when Global AIM IDs are enabled (see " page 55 NOTE $CCMEN00(CR) DEFAULT UCC Composite = Disable $CCMEN01(CR) UCC Composite = Enable Wasp WWS650...
Page 215: Ucc Optional Composite Timer
UCC Optional Composite Timer Specifies the amount of time the system will wait for the stacked part of a UCC Composite label before transmitting the linear label without an add-on. $CCMOT00(CR) DEFAULT UCC Optional Composite Timer = Timer Disabled $CCMOT01(CR) UCC Optional Composite Timer = 100msec $CCMOT02(CR) UCC Optional Composite Timer = 200msec...
Page 216: Postal Code Selection
Postal Code Selection = Disable All Postal Codes $CPOEN01(CR) Postal Code Selection = Enable Postnet $CPOEN02(CR) Postal Code Selection = Enable Planet $CPOEN03(CR) Postal Code Selection = Enable Royal Mail $CPOEN04(CR) Postal Code Selection = Enable Kix $CPOEN05(CR) Postal Code Selection = Enable Australia Post Wasp WWS650...
Page 217: Postnet Bb Control
Postal Code Selection (continued) $CPOEN06(CR) Postal Code Selection = Enable Japan Post $CPOEN07(CR) Postal Code Selection = Enable IMB $CPOEN08(CR) Postal Code Selection = Enable Sweden Post $CPOEN09(CR) Postal Code Selection = Enable Portugal Post Postnet BB Control Controls the ability of the scanner to decode B and B' fields of Postnet labels. $CPOBB00(CR) DEFAULT Postnet BB Control = Disable...
Page 218 Symbology Selection NOTES Wasp WWS650...
Page 219: Wireless Features
WIRELESS FEATURES This section provides options and programming related to the reader’s wireless communication features. Reference Appendix B for a listing of standard factory settings. starting on page 210 IRELESS EEPER EATURES Good Transmission Beep on page 210 • Beep Frequency on page 210 •...
Page 220: Wireless Beeper Features
Adjusts radio-specific beep indications to sound at a low, medium or high frequency, selectable from the list below (controls the beeper’s pitch/tone). $CBTBF00(CR) DEFAULT Beep Frequency = Low $CBTBF01(CR) Beep Frequency = Medium $CBTBF02(CR) Beep Frequency = High Wasp WWS650...
Page 221: Beep Duration
WIRELESS FEATURES Enter/Exit Programming Mode Beep Duration This feature controls the duration of radio-specific beep indications. $CBTBD06(CR) Beep Duration = 60 msec $CBTBD08(CR) DEFAULT Beep Duration = 80 msec $CBTBD0A(CR) Beep Duration = 100 msec $CBTBD0C(CR) Beep Duration = 120 msec $CBTBD0E(CR) Beep Duration = 140 msec $CBTBD10(CR)
Page 222: Beep Volume
Enables/disables the beep indication that a handheld has become connected or disconnected from a Base Station. The defaults are different for the STAR and BT models. NOTE $CBTDB00(CR) Disconnect Beep = Disable $CBTDB01(CR) DEFAULT Disconnect Beep = Enable Wasp WWS650...
Page 223: Docking Beep
WIRELESS FEATURES Enter/Exit Programming Mode Docking Beep Enables/disables a beep indication when the handheld is placed in the Base Station. $CBTCB00(CR) Docking Beep = Disable $CBTCB01(CR) DEFAULT Docking Beep = Enable Leash Alarm This setting specifies the number of seconds to sound the Leash Mode beeps (three per second) when the handheld goes out of range.
Page 224 Leash Alarm (continued) $CBTLB03(CR) Leash Alarm = 3 Seconds $CBTLB04(CR) Leash Alarm = 4 Seconds $CBTLB05(CR) Leash Alarm = 5 Seconds $CBTLB0A(CR) Leash Alarm = 10 Seconds $CBTLB19(CR) Leash Alarm = 25 Seconds $CBTLB1E(CR) Leash Alarm = 30 Seconds Wasp WWS650...
Page 225: Configuration Updates
WIRELESS FEATURES Enter/Exit Programming Mode CONFIGURATION UPDATES page 264 in “References” for detailed information and examples of these features. Automatic Configuration Update When this feature is enabled, a reader and its linked Base Station can automatically ensure they stay in sync with regard to application hardware and/or configuration. $CBTCU00(CR) Automatic Configuration Update = Disable $CBTCU01(CR)
Page 226: Copy Configuration To Base Station
Manual — The handheld will always store labels to Flash memory. The user must manually send the stored labels to the remote device using a special "batch send" label. $CBTBM00(CR) DEFAULT Batch Mode = Disabled $CBTBM01(CR) Batch Mode = Automatic $CBTBM02(CR) Batch Mode = Manual Wasp WWS650...
Page 227: Send Batch
WIRELESS FEATURES Enter/Exit Programming Mode Send Batch When the scanner is configured in Manual Batch Mode, use the following bar code to initiate sending of labels stored in batch memory. Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunction with this bar code.
Page 228: Direct Radio Autolink
DIRECT RADIO AUTOLINK This feature enables/disables the ability to link a wireless handheld to a base station without scanning the Unlink label first. $CBTDL00(CR) DEFAULT Direct Radio Link = Unlink Label Required $CBTDL01(CR) Direct Radio Link = Automatic Unlinking Wasp WWS650...
Page 229: Bluetooth-Only Features
Bluetooth-Only Features Enter/Exit Programming Mode BLUETOOTH-ONLY FEATURES RF ADDRESS STAMPING These features allow configuration of source radio data inclusion. Source Radio Address Transmission Enables/disables the ability of source radio address information to be transmitted to the host and, if so, at what position with respect to the label data. See page 264 in “References”...
Page 230: Source Radio Address Delimiter Character
End by scanning the ENTER/EXIT bar code again. Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 00 = No Delimiter Character DEFAULT Wasp WWS650...
Page 231: Bt Security Features
Bluetooth-Only Features Enter/Exit Programming Mode BT SECURITY FEATURES On the BT system, it is possible to set a (configurable) PIN code to authenticate/connect BT devices, and encrypt the data. The BT PIN code can be enabled and configured by reading the bar codes in the following sec- tions.
Page 232: Bt Pin Code
Set 16-character BT PIN Code Make a mistake? Scan the CANCEL bar code to abort and not save the entry string. You can then start again at the beginning. CANCEL 31323334 = Default PIN Code is 1234 DEFAULT Wasp WWS650...
Page 233: Other Bt Features
Code. When attempting connection, the application presents a window that includes a PIN Code which is to be input using the Wasp WWS650. Scan the bar code "Variable PIN Code" below, then use the host computer’s Bluetooth manager to “Discover new devices” and select "Wasp Scan- ner."...
Page 234: Bluetooth Hid Alt Mode
Unknown character is selected, all barcode data is sent except for unknown characters, and an HID Send Unknown ASCII character error beep will sound. When is enabled, an unknown char- acter will be sent as a SPACE. DEFAULT HID Send Unknown ASCII character = Disable HID Send Unknown ASCII character = Enable Wasp WWS650...
Page 235: Bluetooth Friendly Name
Enter/Exit Programming Mode Bluetooth Friendly Name You can set a meaningful name for the Wasp WWS650 that will appear in the application during device discovery. To set a new Bluetooth Friendly Name, scan the barcode below and follow the instructions.
Page 236: Hid Country Mode
PC is localized. In order to do that, read one of the configuration com- mand labels below. Country Mode = U.S. Country Mode = Belgium Country Mode = Britain Country Mode = Croatia Country Mode = Czech Republic Country Mode = Denmark Country Mode = France Wasp WWS650...
Page 237 Bluetooth-Only Features Enter/Exit Programming Mode HID Country Mode (continued) Country Mode = French Canadian Country Mode = Germany Country Mode = Hungary Country Mode = Italy Country Mode = Japanese 106-key Country Mode = Lithuanian Country Mode = Norway Country Mode = Poland Product Reference Guide...
Page 238 Enter/Exit Programming Mode Other BT Features HID Country Mode (continued) Country Mode = Portugal Country Mode = Romania Country Mode = Spain Country Mode = Sweden Country Mode = Slovakia Country Mode = Switzerland Wasp WWS650...
Page 239: Powerdown Timeout
Bluetooth-Only Features Enter/Exit Programming Mode Powerdown Timeout The Powerdown Timeout feature sets the time for automatically switching the unit off when the imager has been idle. $CSLPS00(CR) Powerdown Timeout = Disable $CSLPS01(CR) Powerdown Timeout = 10 minutes $CSLPS02(CR) Powerdown Timeout = 20 minutes R)$CSLPS03(CR DEFAULT DEFAULT...
Page 240 Enter/Exit Programming Mode Other BT Features NOTES Wasp WWS650...
Page 241: Message Formatting
• Address stamping is necessary to correctly route the message to the WWS650, especially when more than one handheld is linked to the same base. Address stamping could be dis- abled if the system is in point to point configuration. If address stamping is not enabled, the messages are addressed to the first handheld linked to the base.
Page 242: Led And Beeper Control
LED. ESC [ 6 q ESC [ 5 q ESC Turns on the green LED for 100 ms and then turns off the green [ 7 q LED. Escape sequences different from those listed will be ignored. Wasp WWS650...
Page 243: References
Chapter 5 References This section contains explanations and examples of selected bar code features. See Configura- tion Using Bar Codes, starting on page 21 for the actual bar code labels used to configure the reader. starting on page 234 RS-232 P ARAMETERS RS-232 •...
Page 244: Rs-232 Parameters
RTS/XON/XOFF — RTS is asserted during transmissions. CTS is ignored. XON and XOFF gate transmissions. • RTS On/CTS — RTS is always asserted. CTS gates transmissions. RTS/CTS Scan Control — RTS is asserted during transmissions. CTS gates transmissions and controls enable and disable state of scanner. Wasp WWS650...
Page 245: Rs-232/Usb Com Parameters
RS-232/USB COM Parameters Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. To set the delay: 1.
Page 246 Hex equivalent from ASCII 0x06 0x24 0x40 0x3E Chart Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT ACK CHARACTER SETTING Scan Two Characters from ‘0’ and ‘6’ ‘2’ and ‘4’ ‘4’ and ‘0’ ‘3’ AND ‘E’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 247 NAK Character This setting specifies an ASCII character or hex value to be used as the NAK character. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 248 15,000ms (15 sec.) Divide by 200 Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT ACK NAK TIMEOUT VALUE SETTING Scan Two Characters From ‘0’ and ‘1’ ‘0’ and ‘5’ ‘2’ and ‘6’ ‘7’ and ‘5’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 249 ACK NAK Retry Count This feature specifies the number of times the reader retries a label transmission due to a retry condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries. To set this feature: 1.
Page 250 0x64 0x7D 0x44 0xFF Chart Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT DISABLE CHARACTER VALUE SETTING Scan Two Characters From ‘6’ and ‘4’ ‘7’ and ‘D’ ‘4’ and ‘4’ ‘F’ AND ‘F’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 251 Enable Character Specifies the value of the RS-232 host command used to enable the reader. ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host commands conflicts with normal operation of these characters.
Page 252: Keyboard Interface
Divide by 10 (and pad with leading zeroes) Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT WEDGE QUIET INTERVAL SETTING Scan Two Characters From ‘0’ and ‘1’ ‘1’ and ‘5’ ‘6’ and ‘0’ ‘8’ and ‘5’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 253: Intercharacter Delay
Intercharacter Delay This parameter specifies the intercharacter delay between the end of one character and the beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments. A setting of zero specifies no delay. This feature applies ONLY to the Keyboard Wedge interface.
Page 254: Intercode Delay
99 Seconds Pad with leading zero(es) Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT INTERCODE DELAY SETTING Scan Two Characters From ‘0’ and ‘0’ ‘0’ and ‘5’ ‘6’ and ‘0’ ‘9’ AND ‘9’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 255: Symbologies
Symbologies Set Length Length Control allows you to select either variable length decoding or fixed length decoding for the specified symbology. For variable length decoding, a minimum and maximum length may be set. Variable Length: For fixed length decoding, two different lengths may be set. Fixed Length: Set Length 1 This feature specifies one of the bar code lengths for Length Control.
Page 256: Data Editing
When enabled, this ID code will be transmitted before the scanned bar code data. 00 - 20 Characters (ASCII) Additional advanced editing is available. Contact Technical Support for information about advanced formatting features. NOTE Wasp WWS650...
Page 257: Global Prefix/Suffix
Please Keep In Mind... • Modifying a message string is not a mandatory requirement. Data editing is a sophisti- cated feature allowing highly customizable output for advanced users. Factory default set- tings for data editing is typically set to NONE. •...
Page 258: Global Aim Id
Code 11 a. UPC-A and UPC-E labels are converted to EAN 13 when adding AIM IDs. b. ISBN (X with a 0 modifier character) Figure 6. AIM ID Prefix Label ID AIM ID Bar Code Data Label ID Suffix Wasp WWS650...
Page 259: Label Id
Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01- 0xFF), used to identify a bar code (symbology) type. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled. This feature pro- vides options for configuring custom Label IDs as a pre-loaded set (see "Label ID: Pre-loaded Sets"...
Page 260 FOLLET 2OF5 4F0000 4F0000 GTIN 470000 244100 GTIN2 473200 244200 GTIN5 473500 244300 I2OF5 690000 4E0000 I2OF5 CIP HR IATA INDUSTRIAL 2OF5 494100 & 260000 INDUSTRIAL 2OF5 570000 570000 ISBN 490000 400000 ISBT128 CONCAT 660000 660000 ISSN 6E0000 6E0000 Wasp WWS650...
Page 261 USA Label ID set EU Label ID set Symbology Default Default Default Default Character ASCII Character ASCII MATRIX 2OF5 MAXICODE 4D4300 780000 MICRO QR 245100 245100 MICRO PDF 6D5000 380000 400000 5A0000 PDF417 500000 720000 PLESSEY 610000 610000 POSTAL AUSTRALIAN 244B00 244B00 POSTAL IMB...
Page 262 7. Scan the ENTER/EXIT bar code once again to exit Programming Mode. This completes the steps to configure a Label ID for a given symbology. Figure 7. Label ID Position Options Prefix Label ID Aim ID Bar Code Data Label ID Suffix Wasp WWS650...
Page 263 Table 36 . Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT bar code (Scanner enters Programming Mode) Determine placement of the Label ID characters BEFORE or AFTER with regard to scanned Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix data using Label ID Control, starting on page...
Page 264: Character Conversion
5. Scan the ENTER/EXIT bar code to exit Programming Mode. If less than the expected string of 16 characters are selected, scan the ENTER/EXIT bar code twice to accept the selections and exit Programming Mode. NOTE Wasp WWS650...
Page 265: Reading Parameters
Reading Parameters Good Read LED Duration This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 millisec- onds (0.001 to 2.55 seconds) in 100ms increments.
Page 266: Scanning Features
If you are using a SMART STAND, Stand Mode is turned on automatically when the scanner is positioned into the stand and, if the trigger is pulled, the reader acts as if it is in single read mode. NOTE Double Read Timeout prevents undesired multiple reads while in this mode. Wasp WWS650...
Page 267: Stand Mode Off Time
Stand Mode Off Time This feature specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 seconds). Follow these instructions to set this feature: 1.
Page 268: Scanning Active Time
Pad leading zero(es) Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT SCANNING ACTIVE TIME SETTING Scan Three Characters From ‘0’, ‘0’ and ‘1’ ‘0’, ‘9’ and ‘0’ ‘1’, ‘8’ and ‘0’ ‘2’, ‘5’ and ‘5’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 269: Aiming Duration Time
Aiming Duration Time Specifies the frame of time the aiming pointer remains on after decoding a label, when in trig- ger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Follow these instructions to set this feature: 1.
Page 270: Flash On Time
Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT FLASH ON TIME SETTING Scan Two Characters From ‘0’ and ‘5’ ‘1’ and ‘0’ ‘5’ and ‘2’ ‘9’ and ‘9’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 271: Flash Off Time
Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature. 1.
Page 272: Multiple Labels Ordering By Code Symbology
Scan Two Characters From ‘2’ and ‘4’ ‘0’ and ‘E’ ‘0’ and ‘C’ ‘4’ and ‘E’ Appendix D, Keypad RESULT 0x240E0C4E0000 Scan ENTER/EXIT PROGRAMMING MODE Table 44 on page 263 shows the hex value associated with each symbology. Wasp WWS650...
Page 273 Table 44 . Symbology Hex Values Value Symbology ID Value Symbology ID Don' t care GTIN5 UPC-A GTIN8 UPC-E S2OF5 EAN8 PDF417 EAN13 CODE11 UPC2 IATA UPC5 MICRO_PDF C128_ADDON GS1 DataBar_LIM_ID EAN128 GS1 DataBar_LIM_COMP C128_PROGRAMMING_LABEL GS1 DataBar_Omnidirectional_COMP CODE128 GS1 DataBar_EXP_COMP FNC3_C128_LABEL GENERIC_DATA DATA MATRIX...
Page 274: Rf Features
- (dash) / (slash) character Scan ENTER/EXIT PROGRAMMING MODE Scan SET SOURCE RADIO ADDRESS DELIMiTER CHARACTER Scan Two Characters From ‘0’ and ‘0’ ‘2’ and ‘C’ ‘2’ and ‘D’ ‘2’ AND ‘F’ Appendix D, Keypad Scan ENTER/EXIT PROGRAMMING MODE Wasp WWS650...
Page 275: Bt-Only Features
BT-Only Features BT Pin Code This option specifies the 4-character or 16-character pin code to be used for authentication of the BT link. To set the pin code: Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming Mode, then enable "BT Security Mode"...
Page 276 NOTES Wasp WWS650...
Page 277: Technical Specifications
Appendix A Technical Specifications This section contains Physical and Performance Characteristics, User Environment and Regula- tory information. Item Physical Characteristics Color Black & White Height 6.4"/163 mm Dimensions Length 3.6"/91 mm Width 1.6"/41 mm Approximately 200 g (reader) Weight (without cable) 230 g (base charger) Electrical Characteristics Voltage &...
Page 278 PDF-417 Minimum Resolution = 5 mil Data Matrix Minimum Resolution = 7.5 mil a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typi- cal environmental light, 20°C, label inclination 10° Wasp WWS650...
Page 279 Anker Plessey; Follett 2 of 5; GS1 DataBar Omnidirectional; GS1 DataBar Limited; GS1 DataBar Expanded; GS1 DataBar Truncated; DATABAR Expanded Coupon. 2D / Stacked Codes The Wasp WWS650 scanner is capable of decoding the following symbologies using mul- Decode Capability tiple frames (i.e. Multi-Frame Decoding): PDF-417; QR Code; Aztec; Data Matrix; Inverse Data Matrix;...
Page 280 UL 60950, CSA C22.2 No. 60950, IEC 60950 North America (FCC) : Part 15 Class B;  EMI/RFI Canada (IC) : ICES-003 Class B; Russia ( Gost); European Union EMC Directive; VCCI-Japan; Korean KCC; Taiwan EMC (BSMI); Australia (ACMA); Mexico (NOM) Wasp WWS650...
Page 281: Imager Labeling
Sample labels are shown here to illustrate their location only. Please view the labels on your product for actual details, as they may vary from those depicted. Scanner Regulatory Label The Wasp WWS650 Handheld Reader is not user-serviceable. Opening the case of the unit can cause internal damage and will void the warranty. CAUTION...
Page 282: Standard Cable Pinouts
Pin 10 To Host Pin 1 Cable Cable Clip (Latch) Interface Cable Port Figure 10. Standard Cable Pinouts: Base Station The signal descriptions in Table 46 apply to the connector on the reader and are for reference only. Wasp WWS650...
Page 283 Table 46. Standard Cable Pinouts Keyboard RS-232 Wedge RTS (out) CLKIN (KBD side) DATAIN (KBD side) IBM_B CLKOUT (PC side) IBM_A DATAOUT (PC side) CTS (in) Product Reference Guide...
Page 284: Led And Beeper Indications
Blue light flashes 2 times Image Capture When ready to capture image when updating Good Read LED Duration a. Except when in sleep mode or when a other than 00 is selected Wasp WWS650...
Page 285: Error Codes
Table 48 . Programming Mode Indications Programming Mode - The following indications ONLY occur when the reader is in Programming Mode. Label Program- A valid programming label has Reader sounds four low fre- LED blinks continuously ming Mode Entry been scanned. quency beeps.
Page 286: Base Station Indications
To push the button, insert a paper clip in the hole at the label in the bottom of the Base. NOTE BUTTON PUSH GREEN CORDLESS EVENT INDICATOR(**) INDICATOR(**) Slow blink Push at power-up force device connection Fast blink < 5 sec Paging Fast blink > 5 sec Unlink Slow blink Wasp WWS650...
Page 287: Standard Defaults
Appendix B Standard Defaults The most common configuration settings are listed in the “Default” column of the table below. Page references are also provided for feature descriptions and programming bar codes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features.
Page 288 Disable Case Conversion Disable Character Conversion No Char Conversion READING PARAMETERS Double Read Timeout 0.6 Second Power On Alert Power-up Beep Good Read: When to Indicate After Decode Good Read Beep Type Mono Good Read Beep Frequency High Wasp WWS650...
Page 289 Page Parameter Default Your Setting Number Good Read Beep Length 80 ms Good Read Beep Volume High Good Read LED Duration 300 ms SCANNING FEATURES Scan Mode Trigger Single Stand Mode Indication Disable Stand Operation Switch to Stand Mode Pick Mode Disable Stand Mode Sensitivity Medium...
Page 290 GTIN GTIN Formatting Disable EAN 13 (Jan 13) EAN 13 Enable/Disable Enable EAN 13 Check Character Transmission Send EAN-13 Flag 1 Character Transmit EAN-13 ISBN Conversion Disable 2D Component Not EAN-13 2D Component Required ISSN ISSN Enable/Disable Disable Wasp WWS650...
Page 291 Page Parameter Default Your Setting Number EAN 8 EAN 8 Enable/Disable Enable EAN 8 Check Character Transmission Send Expand EAN 8 to EAN 13 Disable 2D Component Not EAN 8 2D Component Required UPC/EAN Global Settings UPC/EAN Price Weight Check Disable UPC/EAN Quiet Zones Two Modules...
Page 292 GS1-128 2D Component Disable ISBT 128 ISBT 128 Concatenation Disable ISBT 128 Force Concatenation Disable ISBT 128 Concatenation Mode Static ISBT 128 Dynamic Concatenation Tim- 200 msec eout Interleaved 2 of 5 I 2 of 5 Enable/Disable Disable Wasp WWS650...
Page 293 Page Parameter Default Your Setting Number I 2 of 5 Check Character Calculation Disable I 2 of 5 Check Character Transmission Send I 2 of 5 Length Control Variable I 2 of 5 Set Length 1 I 2 of 5 Set Length 2 Interleaved 2 of 5 CIP HR Interleaved 2 of 5 CIP HR Enable/Dis- Disable...
Page 294 Code 11 Check Character Calculation Check C and K Code 11 Check Character Transmission Send Code 11 Length Control Variable Code 11 Set Length 1 Code 11 Set Length 2 GS1 DataBar™ Omnidirectional GS1 DataBar™ Omnidirectional Enable/ Disable Disable Wasp WWS650...
Page 295 Page Parameter Default Your Setting Number GS1 DataBar™ Omnidirectional GS1- Disable 128 Emulation GS1 DataBar™ Omnidirectional 2D 2D component not Component required GS1 DataBar™ Expanded GS1 DataBar™ Expanded Enable/Dis- Disable able GS1 DataBar™ Expanded GS1-128 Disable Emulation GS1 DataBar™ Expanded 2D Compo- 2D component not nent required...
Page 296 China Sensible Code Set Length 2 7,827 Data Matrix Enable / Disable Enable Both Square and Data Matrix Square/Rectangular Style Rectangular style Data Matrix Length Control Variable Data Matrix Set Length 1 Data Matrix Set Length 2 3,116 Wasp WWS650...
Page 297 Page Parameter Default Your Setting Number Maxicode Enable / Disable Disable Maxicode Primary Message Transmis- Disable sion Maxicode Length Control Variable Maxicode Set Length 1 Maxicode Set Length 2 0145 PDF417 Enable / Disable Enable PDF417 Length Control Variable PDF417 Set Length 1 PDF417 Set Length 2 2,710 Micro PDF417 Enable / Disable...
Page 298 Set PIN Code Default Pin Code is 1234 Bluetooth HID Variable PIN Code Static Bluetooth HID Alt Mode Bluetooth HID Send Unknown ASCII Disable Char WASP-WWS650 [SERI- Bluetooth Friendly Name AL_NUMBER_SCANNER] HID Country Mode Powerdown Timeout 30 minutes Wasp WWS650...
Page 299: Sample Bar Codes
Appendix C Sample Bar Codes The sample bar codes in this appendix are typical representations for their symbology types. 1D Bar Codes UPC-A EAN-13 978033029095 Code 39 Code 128 Code 128 Interleaved 2 of 5 Product Reference Guide...
Page 300 Sample Bar Codes (continued) Code 32 Codabar 13579 Code 93 Code 11 123456789 Wasp WWS650...
Page 301 GS1 DataBar™ (RSS) GS1 DataBar™ GS1 DataBar™ variants must be enabled to read the bar codes below (see " Omnidirectional" on page 155 NOTE GS1 DataBar™ Expanded Stacked 10293847560192837465019283746029478450366523 GS1 DataBar™ Expanded 1234890hjio9900mnb GS1 DataBar™ Limited 08672345650916 GS1 DataBar™-14 GS1 DataBar™ Omnidirectional Truncated 55432198673467 GS1 DataBar™...
Page 302 2D Bar Codes Aztec Datamatrix China Sensible Code MaxiCode Test Message PDF 417 Micro PDF 417 ABCabc BV17453 QR Code Micro QR Code 123456 35900G9 UCC Composite Wasp WWS650...
Page 303: Keypad
Appendix D Keypad Use the bar codes in this appendix to enter numbers as you would select digits/characters from a keypad. Product Reference Guide...
Page 304 Wasp WWS650...
Page 305: Scancode Tables
Appendix E Scancode Tables Control Character Emulation Control character emulation selects from different scancode tables as listed in this appendix. Each of the control character sets below are detailed by interface type in the tables. These apply to Wedge and USB Keyboard platforms.
Page 306: Interface Type Pc At Ps/2, Usb-Keyboard Or Usb-Keyboard For Apple
ñ ò ó ô õ ö ÷ ø ù ú û ü ý þ ÿ Extended characters (sky blue) are sent through dedicated keys (when available in the selected country mode) or by using an Alt Mode sequence. Wasp WWS650...
Page 307 Interface Type PC AT PS/2, USB-Keyboard or USB-Keyboard for APPLE (continued) Table 51. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  S+ Tab Enter Pg Up Keypd Pg Dwn Home...
Page 308: Interface Type Pc At Ps/2 Alt Mode Or Usb-Keyboard Alt Mode
A+0218 A+0219 A+0220 A+0221 A+0222 A+0223 A+0224 A+0225 A+0226 A+0227 A+0228 A+0229 A+0230 A+0231 A+0232 A+0233 A+0234 A+0235 A+0236 A+0237 A+0238 A+0239 A+0240 A+0241 A+0242 A+0243 A+0244 A+0245 A+0246 A+0247 A+0248 A+0249 A+0250 A+0251 A+052 A+0253 A+0254 A+0255 Wasp WWS650...
Page 309 Interface type PC AT PS/2 Alt Mode or USB-Keyboard Alt Mode (continued) Table 53. Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  S+ Tab Enter Pg Up Keypd Pg Dwn Home...
Page 310: Digital Interface
Sh↑ (keyp)     Cl ↓ Cl ↑ Table 55. Scancode Set When Control Character is 02 Enter Cl ↓ Cl ↑ à S+ Tab Enter Keypd    Space “ & ‘ < > Wasp WWS650...
Page 311: Ibm31Xx 102-Key
IBM31xx 102-key Table 56. Scancode Set When Control Character is 00 or 01 NULL C(S)+A C(S)+B C(S)+C C(S)+E C(S)+F C(S)+G C(S)+J C(S)+K C(S)+L Enter C(S)+N C(S)+O C(S)+P C(S)+Q C(S)+R C(S)+S C(S)+T C(S)+U C(S)+V C(S)+W C(S)+X C(S)+Y C(S)+Z C(S)+\ C(S)+^ C(S)+_ Space “...
Page 312: Ibm Xt
Table 59. Scancode Set when Control Character 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  S+ Tab Enter Pg Up Keypd Pg Dwn Home    Space “ & ‘ < > ‘ Wasp WWS650...
Page 313: Microsoft Windows Codepage 1252
Scancode Tables Microsoft Windows Codepage 1252 Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy components of Microsoft Windows in English and some other Western languages. Product Reference Guide...
Page 314 Scancode Tables NOTES Wasp WWS650...
Page 315 ASCII Chart ASCII ASCII ASCII ASCII Char. Char. Char. Char. ‘ “ & ’ < >...
Page 316 Wasp Barcode Technologies 1400 10 Street Plano, Texas USA 75074 ©2013-2018 Wasp Barcode Technologies 820059990 (Rev A) Sept 2018...

Wasp WWS650 Product Reference Manual

Quick Links

Related Manuals for Wasp WWS650

Summary of Contents for Wasp WWS650
