WWS110i
Quick Start Guide
1

Advertisement

Table of Contents
loading

Related Manuals for Wasp WWS110i

Summary of Contents for Wasp WWS110i

  • Page 1 WWS110i Quick Start Guide...

  • Page 2: Table Of Contents

    Table of Contents Quick Start 1. Unpack 2. Charging the WWS110i 3. Connecting the Scanner to a Bluetooth Device Setup & Configuration Factory Default Check Version Link Quality On/Off Set Connection Bluetooth SPP (Bluetooth COM) Bluetooth HID (Keyboard) Start and Stop Pin...

  • Page 3: Quick Start

    1. Unpack Open the box and remove all the pieces from their protective packaging. 2. Charging the WWS110i You must charge the scanner for 4 hours before first using it. To charge the scanner, plug the power supply into the bottom of the scanner.
  • Page 4 The scanner will show up in the list of Bluetooth devices found. Select Wasp Barcode and click Next. If Wasp Barcode does not show up in the available devices, check the following: 1. Make sure the scanner is on by pressing the trigger.
  • Page 5 The Complete Wizard screen appears. Click Finish to complete. When the wizard is complete, the scanner will show up as a Wasp Keyboard. Click OK to close the screen. You are now ready to use the WWS110i. Windows 7 Bluetooth Pairing Click the Start icon, then type “bluetooth”...
  • Page 6 4. Stop PIN A screen will appear confirming you have successfully added the scanner. When the wizard is complete, the scanner will show up as a Wasp Keyboard. Click OK to close the screen. You are now ready to use the WWS110i.

  • Page 7: Setup & Configuration

    (*). The default settings have been preprogrammed for the most common barcode configurations. Use the setup & configuration barcodes only to customize the WWS110i Freedom Scanner settings. If you need to configure the Scanner, the default settings will be overwritten.

  • Page 8: Factory Default

    Factory Default Use the Factory Default barcode to reset the scanner to the Default settings. Factory Default Check Version Scan the Check Version barcode to verify your current firmware’s version number. Check Version Link Quality On/Off Link Quality affects the transmission quality. When Link Quality is turned on (default setting), data transfer is more secure, but slower.

  • Page 9: Bluetooth Spp (Bluetooth Com)

    Bluetooth SPP (Bluetooth COM) The Bluetooth SPP (Serial Port Protocol) creates a virtual Bluetooth comport. This setting is not recommended. Only use this option if you have software capable of capturing data off of a comport. Bluetooth SPP (Bluetooth COM) Bluetooth HID Use this setting (on by default) to pair with most Bluetooth connections.
  • Page 10 connection Start Pin ENTER Stop Pin...

  • Page 11: Terminator

    Terminator The ‘Terminator’ option is used to specify the end-of-text message and is primarily used to denote the end of the barcode value. CR * None Space CR + LF iPad/iPhone Toggle Keyboard Scan this barcode to display or hide the on-screen keyboard when connected to an iPad or iPhone.

  • Page 12: Secure Simple Pairing

    Secure Simple Pairing If you will be pairing without a pin, you should use the SSP functionality. To enable SSP, please scan the Enable SSP barcode before scanning the Bluetooth HID barcode on page 8. Enable SSP...
  • Page 13 Wasp Barcode Technologies ® 1400 10th Street, Plano, Texas 75074 Tel: 214.547.4100 • Fax: 214.547.4101 www.waspbarcode.com...
