tion link wire to the TUC at the ICS terminal. Refer to the TUC installa-
tion literature (EMTX-IOP-1) for connection points.
Device addressing
Each UCM must have a unique address on each link. On the TUC, the
address is set with the SW1 address DIP switches, followed by a momen-
tary short between J11 and J12. For TUC DIP switch settings, refer to
Table 20.
Table 20. TUC address settings
UCM
address
DIP 1 DIP 2
33 OFF OFF
34 OFF OFF
35 OFF OFF
36 OFF OFF
37 OFF OFF
38 OFF OFF
39 OFF OFF
40 OFF OFF
41 OFF OFF
42 OFF OFF
43 OFF OFF
44 OFF OFF
45 OFF OFF
46 OFF OFF
47 OFF OFF
48 OFF OFF
49 OFF OFF
50 OFF OFF
51 OFF OFF
52 OFF OFF
53 OFF OFF
54 OFF OFF
55 OFF OFF
56 OFF OFF
57 OFF OFF
58 OFF OFF
59 OFF OFF
60 OFF OFF
61 OFF OFF
TUC DIP switch settings
DIP 3 DIP 4 DIP 5 DIP 6
on OFF OFF OFF
on OFF OFF OFF
on OFF OFF OFF
on OFF OFF
on OFF OFF
on OFF OFF
on OFF OFF
on OFF on OFF
on OFF on OFF
on OFF on OFF
on OFF on OFF
on OFF on
on OFF on
on OFF on
on OFF on
on on OFF OFF
on on OFF OFF
on on OFF OFF
on on OFF OFF
on on OFF
on on OFF
on on OFF
on on OFF
on on on OFF
on on on OFF
on on on OFF
on on on OFF
on on on
on on on
DIP 7 DIP 8
OFF on
on OFF
on on
on OFF OFF
on OFF on
on on OFF
on on on
OFF OFF
OFF on
on OFF
on on
on OFF OFF
on OFF on
on on OFF
on on on
OFF OFF
OFF on
on OFF
on on
on OFF OFF
on OFF on
on on OFF
on on on
OFF OFF
OFF on
on OFF
on on
on OFF OFF
on OFF on
