- Page 1 MCB 101 - General Purpose I/O Option Module Operating Instructions TR200 BAS-SVX28A-EN BAS-SVX28A-EN December 2008...
-
Page 2: Warnings, Cautions And Notices
Warnings, Cautions and Notices Note that warnings, cautions and notices appear at appropriate intervals throughout this manual. Warnings are provide to alert installing contractors to potential hazards that could result in personal injury or death. Cautions are designed to alert personnel to hazardous situations that could result in personal injury, while notices indicate a situation that could result in equipment or property-damage-only accidents. - Page 3 Introduction This instruction describes the General Purpose I/O option MCB 101 for use in the TR200 expanding the number of input/output in the frequency converter. The MCB 101 option includes 3 digital inputs, 2 analog inputs, 2 digital outputs and 1 analog output. SW firmware version to be installed in the drive control card must be version 3.00 or later versions for series, and version 1.1x for TR200 series.
- Page 4 Galvanic Isolation in the MCB 101 Digital/analog inputs are galvanically isolated from other inputs/outputs on the MCB 101 and in the control card of the frequency converter. Digital/analog outputs in the MCB 101 are galvanically isolated from other inputs/ outputs on the MCB 101, but not from these on the control card of the drive. If the digital inputs 7, 8 or 9 are to be switched by use of the internal 24 V power supply (terminal 9) the connection between terminal 1 and 5 which is illustrated in the drawing has to be established.
- Page 5 Digital Inputs - Terminal X30/1-4 Parameters for set-up: 5-16, 5-17 and 5-18 Number of Voltage Voltage levels Tolerance Max. Input impedance digital in- level puts 0-24 V DC PNP type: ± 28 V continuous Approx. 5 k ohm Common = 0 V ±...
-
Page 6: Mounting Of Option Modules In Slot B
Mounting of Option Modules in Slot B The power to the frequency converter must be disconnected. For A2, A3 and B3 enclosures: • Remove the keypad, the terminal cover, and the keypad frame from the frequency converter. • Fit the MCB 101 option card into slot B. •... - Page 7 Mounting Guidelines - Step By Step These step-by-step instructions describe how to mount the control cables: • The power to the frequency converter must be disconnected. • Remove the keypad, the terminal cover, and the keypad frame from the frequency converter. •...
- Page 8 December 2008 Supersedes www.trane.com For more information, contact your local Trane Trane has a policy of continous product and product data improvement and reserves the right to change design and specifications without notice. office or e-mail us at comfort@trane.com 130R0477...
