- Page 1 Crestron DTT-18 DualTouch™ Technology Touchpanel Operations Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2004 Crestron Electronics, Inc...
-
Page 3: Table Of Contents
DualTouch™ Technology Touchpanel Contents DualTouch™ Technology Touchpanel: DTT-18 Introduction ...1 Features and Functions ... 1 Specifications ... 3 Physical Description ... 4 Industry Compliance... 9 Setup...10 Mounting ... 10 Hardware Hookup... 11 Display Settings... 13 Using the Pen... 16 Cleaning... 17 Alternative Mounting ... -
Page 5: Dualtouch™ Technology Touchpanel: Dtt-18
Touchpanel: DTT-18 Introduction Features and Functions The DTT-18 is an 18-inch touchpanel designed for use with the UPX-2 Universal Presentation System. The Crestron pending) allows the DTT-18 to function both as a touchpanel and a pen-based annotation device to produce an amazingly flexible presentation solution. - Page 6 Crestron DTT-18 DualTouch™ Technology Touchpanel DTT-18 DualTouch Technology Touchpanel and UPX-2 Universal Presentation Processor Typical Application • DTT-18: DualTouch™ Technology Touchpanel Operations Guide – DOC. 6290...
-
Page 7: Specifications
DualTouch™ Technology Touchpanel Specifications The following table provides a summary of specifications for the DTT-18. DTT-18 Specifications Controls and Indicators Display Operating Environment Dimensions Operations Guide – DOC. 6290 SPECIFICATION Power Requirements 72 Watts (4 Amps @ 18 Volts DC) Power Supply Included... -
Page 8: Physical Description
Physical Description The electronic hardware is housed in a high impact, black molded plastic enclosure, shown in the following illustration. This touchpanel is designed for placement on a counter. It possesses an adjustable tilt stand that permits an angular adjustment range from 13 to 70 vertical degrees and rotation through 180 degrees. -
Page 9: Dualtouch™ Technology Touchpanel Crestron Dtt
Physical View – Front and Bottom 11.38 in (28.91 cm) 16.01 in (40.67 cm) 14.22 in (36.12 cm) 18.43 in (46.81 cm) 2.38 in (6.05 cm) 2.88 in (7.32 cm) DualTouch™ Technology Touchpanel: DTT-18 • 5 Operations Guide – DOC. 6290... - Page 10 Crestron DTT-18 DualTouch™ Technology Touchpanel Physical View – Side 17.02 in (43.23 cm) 8.53 in (21.67 cm) 7.60 in (19.30 cm) 15.81 in (41.16 cm) • DTT-18: DualTouch™ Technology Touchpanel Operations Guide – DOC. 6290...
- Page 11 DualTouch™ Technology Touchpanel The DTT-18 is shipped with the following accessories. One Mounting Stand One Pen (with tip replacements) and One Pen Stand One Power Supply and Power Cable One DVI/I to VGA Adaptor One Pair of Lock Brackets and...
- Page 12 The 9-pin female DB9HD connector is not used with the UPX-2. USB 2.0 The DTT-18 has one Universal Serial Bus (USB) “A” female connector, and is used to provide communications with the UPX-2. It may be connected to any one of the four USB connectors on the UPX-2.
-
Page 13: Industry Compliance
A status LED lights up green when the DTT-18 senses the annotation pen. Industry Compliance As of the date of manufacture, the DTT-18 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. -
Page 14: Setup
Setup Mounting Align the bearing hub on the back of the DTT-18 with the V-groove in the stand. With the back of the DTT-18 resting against the stand, lower the unit so that the bearing recess in the stand captures the bearing hub. -
Page 15: Hardware Hookup
(Not Connected) Connector to any USB port UPX-2 Operations Guide – DOC. 6290 VGA/DVI Switch Must Be DTT-18 DVI/I RGB Connector DVI/RGB Adaptor to RGB Output Port A DualTouch™ Technology Touchpanel: DTT-18 • 11 Crestron DTT-18 in the VGA Position... - Page 16 NOTE: The USB cable may be extended using up to four 16-foot active extensions. Each extension cable must contain a hub (repeater) to regenerate the USB signal (maximum of 64 feet). Crestron has tested and approved IOGEAR USB Extender model GUCE50, which allows up to 150 feet over CAT5.
-
Page 17: Display Settings
DualTouch™ Technology Touchpanel Display Settings Five controls are located on the upper rear side of the DTT-18 for display setup. Display Controls DVI/VGA Set the DVI/VGA switch to VGA for this system. The Menu button provides access to the following 11 adjustment menus. Use the (+)/(-) buttons to advance forward or backward through the 11 menus. - Page 18 Crestron DTT-18 • DTT-18: DualTouch™ Technology Touchpanel DualTouch™ Technology Touchpanel 2. Brightness – Use the (+)/(-) buttons to increase or decrease brightness, press the Enter button to save. Default is 70. 3. Phase – (VGA only) Use the (+)/(-) buttons to manually reduce horizontal distortion lines.
- Page 19 9. Color – Provides a color temperature selection of 9300K, 6500K, 5000K, and a user option that allows an independent adjustment of red, green and blue. Press Enter to save. DualTouch™ Technology Touchpanel: DTT-18 • 15 Crestron DTT-18 is used for automatic adjustment.
-
Page 20: Using The Pen
When the pen tip contacts the surface of the DTT-18, the tip switch is activated. The tip switch simulates clicking and holding a mouse button. Raising the tip above the surface of the DTT-18 is the same as releasing a mouse button. -
Page 21: Cleaning
Regular cleaning will help to prolong the life of your equipment. Alternative Mounting The DTT-18 may be removed from the adjustable stand and remounted to a VESA conforming mount arm or stand. The Video Electronics Standards Association (VESA) is an international non-profit corporation that supports and sets industry- wide interface standards for the PC, workstation, and computing environments. -
Page 22: Problem Solving
Crestron DTT-18 CAUTION: When attaching the DTT-18 to an alternate mounting platform, be sure to follow all instructions supplied by the manufacturer. Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. -
Page 23: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 24: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 25 DualTouch™ Technology Touchpanel Crestron DTT-18 This page intentionally left blank. DualTouch™ Technology Touchpanel: DTT-18 • 21 Operations Guide – DOC. 6290...
- Page 26 Crestron DTT-18 DualTouch™ Technology Touchpanel This page intentionally left blank. • DTT-18: DualTouch™ Technology Touchpanel Operations Guide – DOC. 6290...
- Page 27 DualTouch™ Technology Touchpanel Crestron DTT-18 This page intentionally left blank. DualTouch™ Technology Touchpanel: DTT-18 • 23 Operations Guide – DOC. 6290...
- Page 28 Crestron Electronics, Inc. Operations Guide – DOC. 6290 15 Volvo Drive Rockleigh, NJ 07647 07.04 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
