Crestron DTT-15V2 Operations Manual

Crestron electronics operations guide pda dtt-15v2.
Crestron DTT-15V2
DualTouch™ Technology Touchpanel
Operations Guide

   Related Manuals for Crestron DTT-15V2

   Summary of Contents for Crestron DTT-15V2

  • Page 1

    Crestron DTT-15V2 DualTouch™ Technology Touchpanel Operations Guide...

  • Page 2

    This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2005 Crestron Electronics, Inc...

  • Page 3: Table Of Contents

    DualTouch™ Technology Touchpanel Contents DualTouch™ Technology Touchpanel: DTT-15V2 Introduction ...1 Features and Functions ... 1 Specifications ... 3 Physical Description ... 4 Industry Compliance... 9 Setup...9 Hardware Hookup... 9 Display Settings... 11 The Kensington Using the Pen... 15 Cleaning... 16 Alternative Mounting ...

  • Page 5: Dualtouch™ Technology Touchpanel: Dtt-15v2, Introduction, Features And Functions

    Touchpanel: DTT-15V2 Introduction Features and Functions The DTT-15V2 is a 15-inch touchpanel designed for use with the UPX-2 Universal Presentation System. The Crestron pending) allows the DTT-15V2 to function both as a touchpanel and a pen-based annotation device to produce an amazingly flexible presentation solution.

  • Page 6

    Crestron DTT-15V2 DualTouch™ Technology Touchpanel DTT-15V2 DualTouch Technology Touchpanel and UPX-2 Universal Presentation Processor Typical Application DualTouch™ Technology Touchpanel: DTT-15V2 Operations Guide – DOC. 6342...

  • Page 7: Specifications

    DualTouch™ Technology Touchpanel Specifications The following table provides a summary of specifications for the DTT-15V2. DTT-15V2 Specifications Power Requirements Controls and Indicators Operations Guide – DOC. 6342 SPECIFICATION 24 Watts (2.0 Amps @ 12 Volts DC Power Supply Included) Connectors...

  • Page 8: Physical Description

    This does not qualify the device as defective. The quality control standards are based on internationally accepted standards for LCD monitors. Of the 786,432 pixels on each DTT-15V2, 99.999% are required to function perfectly, and no pixels are allowed to be always white or always black. A small number of pixels (10 or less) may acceptably display an incorrect color for some portion of the color spectrum.

  • Page 9

    DualTouch™ Technology Touchpanel Crestron DTT-15V2 DTT-15V2 Physical View – Front DTT-15V2 Physical View – Side (Maximum and Minimum Height) Operations Guide – DOC. 6342 DualTouch™ Technology Touchpanel: DTT-15V2...

  • Page 10

    Crestron DTT-15V2 DTT-15V2 Physical View – Rear (Stand Not Shown) The DTT-15V2 is shipped with the following accessories. One Pen (with five tip replacements) One USB Cable Approximately 6-feet long. One VGA to VGA Cable Approximately 6-feet long. One Power Supply and Power Cable DualTouch™...

  • Page 11

    DualTouch™ Technology Touchpanel One Pen Tether Ports The ports are located on the rear of the DTT-15V2. USB 2.0 One Universal Serial Bus (USB) type “B” female connector is provided for data transfer, and may be connected to any of the four USB ports on the UPX-2.

  • Page 12

    RGB IN Connector Pinout RGB OUT One DB15HD RGB (VGA) female connector is provided for video output to a projector device (not used in this application). DualTouch™ Technology Touchpanel: DTT-15V2 DualTouch™ Technology Touchpanel DESCRIPTION Red video input Green video input...

  • Page 13: Industry Compliance, Setup, Hardware Hookup

    Management Signaling (DPMS) compliant computer or graphics card, the DTT-15V2 automatically complies with the following power saving parameters. Industry Compliance As of the date of manufacture, the DTT-15V2 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling.

  • Page 14

    4. Plug the power adaptor cord into the DTT-15V2 DC IN port. 5. Power up the DTT-15V2. The power indicator should light up orange. 6. Power up the UPX-2. When a video signal is applied to the DTT-15V2, the power indicator will turn blue.

  • Page 15: Display Settings

    DualTouch™ Technology Touchpanel Connecting the DTT-15V2 to the UPX-2 Display Settings Four controls are located on the upper right front side of the DTT-15V2 for display setup. Display Controls The Menu button provides access to the following 11 adjustment menus. Use the Selection (-)/(+) buttons to select a menu or advance forward or backward through the 11 menus.

  • Page 16

    Crestron DTT-15V2 DualTouch™ Technology Touchpanel: DTT-15V2 DualTouch™ Technology Touchpanel 2. Brightness – Use the (-)/(+) buttons to decrease or increase brightness, press the Enter button to save. Default is 60. 3. Phase – Use the (-)/(+) buttons to manually reduce horizontal distortion lines.

  • Page 17

    Press Enter to save. Default is 50. 7. Menu Position – Use the (-)/(+) buttons to move the menu to one of the available nine positions. Press Enter to save. Default is center position. DualTouch™ Technology Touchpanel: DTT-15V2 Crestron DTT-15V2...

  • Page 18

    Crestron DTT-15V2 DualTouch™ Technology Touchpanel: DTT-15V2 DualTouch™ Technology Touchpanel 8. Reset – Use AUTO ADJUST to reset only the image parameters (menus 1 through 6). Use RECALL to reset all screen options to the factory default. Select the exit icon to leave this menu without making any changes.

  • Page 19: The Kensington ® Security Slot, Using The Pen

    (http://www.kensington.com). Using the Pen While working with the DTT-15V2, you can rest your hand on the surface of the display screen, just as if you were drawing on a sheet if paper. The pen is activated as soon as it enters proximity, about 0.2 inches (5 mm) above the surface. This allows you to position the screen cursor before touching the pen tip to the surface.

  • Page 20: Cleaning, Alternative Mounting

    The complete standard is available on the VESA website. The DTT-15V2 is VESA MIS-D, 100/75, C compliant, and is equipped with a 75 x 75 mm mounting hole pattern.

  • Page 21: Problem Solving, Troubleshooting

    Crestron customer service representative. DTT-15V2 Troubleshooting Operations Guide – DOC. 6342 TROUBLE POSSIBLE CAUSE(S) DTT-15V2 does not The DTT-15V2 is not function. receiving power. The Power LED is off. The DTT-15V2 is receiving power. The Power LED is on. Multiple images The video cable is displayed.

  • Page 22: Further Inquiries, Future Updates

    Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the DTT-15V2, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.

  • Page 23: Return And Warranty Policies, Merchandise Returns / Repair Service, Crestron Limited Warranty

    All brand names, product names, and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP and WindowsNT/2000 are trademarks of Microsoft Corporation. Operations Guide – DOC. 6342 Crestron DTT-15V2 DualTouch™ Technology Touchpanel: DTT-15V2...

  • Page 24

    Crestron Electronics, Inc. Operations Guide – DOC. 6342 15 Volvo Drive Rockleigh, NJ 07647 02.05 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
