Tappings and Openings
Tapping Loc.
1 1 1
2 3 ⁄
4
3 3 ⁄
4
5A ⁄
1
2
5B ⁄
1
2
6 1 ⁄
4
7 1 ⁄
2
13 1 1
Dimensions
Ratings
AHRI Burner
Capacity Oil
Input
Boiler Model* GPH
†
TRDV-30-0.85 0.85
TRDV-30-1.00 1.00
TRDV-30-1.10 1.10
Standard working pressure 30 psi water.
All boilers hydrostatically tested — A.S.M.E.
* For forced hot water heating systems where the boiler and all piping are located within
the area to be heated, the boiler may be selected on the basis of gross D.O.E. capacity
output. The net AHRI output ratings shown are based on an allowance for piping and
pickup of 1.15 (water). D.O.E. capacity gross output is divided by the allowance to obtain
net rating. The manufacturer should be consulted before selecting a boiler for unusual
piping and pickup requirements such as intermittent system operation, extensive piping,
etc.
Water Boiler
⁄ " supply
2
" air vent or expansion tank
" water relief valve
" tankless inlet
" tankless outlet
" pressure temp. gauge
" high limit, hi/lo or combination control
⁄ " return & 3 ⁄ " drain cock
2 4
D.O.E. Heating
Capacity MBH
BTUH Water
119,000 103
140,000 121
154,000 132
AHRI Net
Ratings
Boiler
MBH
AFUE% Length
Water Water "A"
90 87.22 14.875
105 86.57 14.875
115 86.12 14.875
† Ratings apply to the use of light oil at 140,000 Btu per gallon.
Dimensions (inches)
Front to Flue Circulator Overall
Flue Dia. Flange Length
"B" "C" "D"
10.062 6 1.25 27.625
10.062 6 1.25 27.625
10.062 6 1.25 27.625
INTREPID TRDV
Figure 1
Figure 2
Tankless
Boiler Heater
"E" Sect GPM
3 3.0
3 3.1
3 3.2
