Slant/Fin Intrepid TR Series Installation And Operating Instructions Manual

Oil-fired water and steam boilers/no.2 oil
Hide thumbs Also See for Intrepid TR Series:
Table of Contents

Advertisement

Quick Links

See also: User's Information Manual , Installation Instructions and Operating Manual
INTREPID
OIL-FIRED WATER AND STEAM BOILERS/NO. 2 OIL
INSTALLATION AND OPERATING INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
FOR REFERENCE
SAFETY WARNING:
KEEP BOILER AREA CLEAR AND FREE FROM COM -
BUSTIBLE MATERIALS, GASOLINE AND OTHER FLAM-
MABLE VAPORS AND LIQUIDS. FAILURE TO ADHERE TO
ABOVE SAFETY WARNING, MAY RESULT IN PERSONAL
INJURY OR DEATH AND PROPERTY DAMAGE.
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .PAGE
Ratings and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 3
Boiler Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 4
Chimney Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Blocked Vent Safety Switch . . . . . . . . . . . . . . . . . . . . . . . . .5
Air Supply and Venting . . . . . . . . . . . . . . . . . . . . . . . . . . .5 7
Controls and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Piping for Steam Boilers . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Cleaning Piping System . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Piping for Water Units . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 9
Piping for Tankless Heater . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installing Burner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Oil Supply Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Wiring the Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Vent Piping and Draft Regulator . . . . . . . . . . . . . . . . . . . . .10
Precautions Before Starting . . . . . . . . . . . . . . . . . . . . . . . .10
Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cleaning and Filling New Water Boiler . . . . . . . . . . . . . . . .10
Cleaning and Filling New Steam Boiler . . . . . . . . . . . .10 11
Blowing Off a Steam Boiler . . . . . . . . . . . . . . . . . . . . . . . . .11
Low Water Cut-off Check-out . . . . . . . . . . . . . . . . . . . . . . .12
Pressure Control Check-out . . . . . . . . . . . . . . . . . . . . . . . .12
Replacement of Steam Boiler . . . . . . . . . . . . . . . . . . . . . . .12
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 17
Burner Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 20
Extended Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Freezing Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Oil Burner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
General Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
C & D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
THIS MANUAL MUST BE LEFT WITH OWNER AND
SHOULD BE HUNG ON OR ADJACENT TO THE BOILER
FOR REFERENCE.
Heating Contractor
Address
Phone Number
IMPORTANT: The installation of this appliance must conform
to the requirements of the authority having jurisdiction or, in
the absence of such requirements, to the Installation of Oil
Burning Equipment, CSA B139. The installation must also
conform to the additional requirements in this Slant/Fin
Instruction Manual. Where there is any difference, the more
stringent requirement shall govern.
Do not use gasoline crankcase drainings or any oil contain-
ing gasoline.
Never burn garbage or paper in this unit, and never leave
combustible material around it.
IMPORTANT: This boiler must be installed, serviced and
repaired by a trained, experienced, service technician,
licensed for the installation and servicing of oil-burning hot-
water-heating or steam system equipment or otherwise quali-
fied by the authorities having jurisdiction over the installation.
Boiler Model Number
Boiler Serial Number
Installation Date
Printed in Canada
1014
Part No. 43 2764
3131567
CONFORMS TO UL STD 726
CERTIFIED TO CAN/CSA STD
B140.7-05
Publication No. TR 40
Revision
L
