Installation

Installing the UPC20+

To install the UPC20+ unit:
1. Mount the UPC20+ on a wall or solid surface in the location where it will be used; it can be
mounted either horizontally or vertically.
2. Remove the cover.
3. Prepare terminal block P1.
a. Set power switch S1.
b. Configure jumpers according to high voltage wiring requirements.
4. Install conduit. Provide conduit for high voltage, low voltage and control wiring requirements using
the 0.5 inch or 0.75 inch conduit connector knockouts.
5. Connect high voltage wiring to the terminal block P1.
6. Connect control wiring.
a. Set control mode DIP switch S2 and control jumper JP1. Refer to the Control Options
Modes section on page 4 for more detailed information.
b. Install wiring for contact closure or remote control mode.
7. Test low voltage and high voltage wiring. Conduct tests to confirm proper installation and functions
of desired control modes.
