BA00479C/07/EN/21.19
71458792
2019-11-08
Valid as of version
01.07.00
Products
Operating Instructions
Liquistation CSF33
Automatic sampler for liquid media
Solutions
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Liquistation CSF33

Summary of Contents for Endress+Hauser Liquistation CSF33

  • Page 1 Products Solutions Services BA00479C/07/EN/21.19 71458792 2019-11-08 Valid as of version 01.07.00 Operating Instructions Liquistation CSF33 Automatic sampler for liquid media...

  • Page 3: Table Of Contents

    Liquistation CSF33 Table of contents Table of contents Setting the operating language ... . 36 About this document ....5 Configuring the measuring device .
  • Page 4 Table of contents Liquistation CSF33 Index ....... . . 178...

  • Page 5: About This Document

    Liquistation CSF33 About this document About this document Warnings Structure of information Meaning This symbol alerts you to a dangerous situation. DANGER Failure to avoid the dangerous situation will result in a fatal or serious Causes (/consequences) injury. If necessary, Consequences of non-compliance (if applicable) ‣...

  • Page 6: Documentation

    Documentation The following manuals which are available on the complement these Brief Operating Instructions Operating Instructions: • Brief Operating Instructions for Liquistation CSF33, BA00479C • Guidelines for communication via fieldbus and web server • Special Documentation: Sampler application manual SD01068C •...

  • Page 7: Basic Safety Instructions

    Designated use Liquistation CSF33 is a stationary sampler for liquid media. The samples are taken discontinuously using a vacuum pump or peristaltic pump and are then distributed into sampling containers and refrigerated.

  • Page 8: Operational Safety

    Basic safety instructions Liquistation CSF33 Operational safety Before commissioning the entire measuring point: 1. Verify that all connections are correct. 2. Ensure that electrical cables and hose connections are undamaged. 3. Do not operate damaged products, and protect them against unintentional operation.

  • Page 9: Product Safety

    Liquistation CSF33 Basic safety instructions Product safety 2.5.1 State of the art The product is designed to meet state-of-the-art safety requirements, has been tested, and left the factory in a condition in which it is safe to operate. The relevant regulations and international standards have been observed.

  • Page 10: Product Description

    Product description Liquistation CSF33 Product description Device design A complete sampling unit comprises: • Controller with display, soft keys and navigator • Vacuum or peristaltic pump for sampling • PE or glass sample bottles for sample preservation • Sampling chamber temperature regulator (optional) for safe sample storage •...

  • Page 11: Equipment Architecture

    Liquistation CSF33 Product description Equipment architecture 3.2.1 Slot and port assignment The electronics configuration follows a modular concept: • There are several slots for electronics modules. • These slots are numbered consecutively in the housing. Slots 0 and 1 are always reserved for the basic module.

  • Page 12: Terminal Diagram

    Product description Liquistation CSF33 Terminal diagram The unique terminal name is derived from: Slot no. : Port no. : Terminal Example, NO contact of a relay Device with inputs for digital sensors, 4 current outputs and 4 relays • Base module BASE2-E (contains 2 sensor inputs, 2 current outputs) •...

  • Page 13: Incoming Acceptance And Product

    Liquistation CSF33 Incoming acceptance and product identification Incoming acceptance and product identification Incoming acceptance 1. Verify that the packaging is undamaged.  Notify the supplier of any damage to the packaging. Keep the damaged packaging until the issue has been resolved.

  • Page 14: Scope Of Delivery

    Incoming acceptance and product identification Liquistation CSF33 Scope of delivery The scope of delivery comprises: • 1 Liquistation CSF33 with: • The ordered bottle configuration • Optional hardware • Accessories kit • • Connection nipple for suction line with various angles (straight, 90°), Allen key (for version with vacuum pump only) •...

  • Page 15: Installation

    625 (24.6) 471 (18.5) 753 (29.7) 355 (14.0) 125 (4.9) 816 (32.1) A0014539  3 Dimensions of Liquistation CSF33 plastic version, dimensions in mm (in) Suction line connection 624 (24.6) 467 (18.4) 743 (29.3) 125 (4.9) 355 (14.0) 816 (32.1) A0014550 ...
  • Page 16 Installation Liquistation CSF33 5.1.2 Installation site For version with sample pump A0024411  5 Liquistation mounting conditions 1. Correct  The suction line must be routed with a downward slope to the sampling point. 2. Incorrect  The sampler should never be mounted in a place where it is exposed to aggressive gases.
  • Page 17 Liquistation CSF33 Installation 5.1.3 Mechanical connection Foundation plan 730 (28.7) 311 (12.2) 305 (12.0) 255 (10.0) 302 (11.9) 214 (8.43) 786 (30.9) A0024406  6 Foundation plan Fasteners (4 x M10) Cable inlet Outlet for condensate and overflow > DN 50 Sample supply from below >...

  • Page 18: Installation

    Installation Liquistation CSF33 Requirements for the sampling point: • Do not connect the suction line to pressurized systems. • Use the suction filter to impede coarse and abrasive solids and solids which can cause clogging. • Immerse the suction line in the direction of flow.
  • Page 19 Liquistation CSF33 Installation 2. As illustrated, guide the suction line upwards and through the opening towards the front. A0013704  7 Sample supply from below Gland for the suction line Suction line Connecting the suction line on version with vacuum pump...

  • Page 20: Post-Installation Check

    Installation Liquistation CSF33 Connecting the suction line on version with peristaltic pump A0013705 A0013706  10 Connecting the suction line from the side (as-delivered  11 Suction line state) Small thread adapter nut Hose Thread adapter nut Hose gland 1. Unscrew the thread adapter nut (item 3) and the hose fitting (item 4) from the side panel.

  • Page 21: Electrical Connection

    Liquistation CSF33 Electrical connection Electrical connection Connecting the sampler WARNING Device is live! Incorrect connection may result in injury or death! ‣ The electrical connection may be performed only by an electrical technician. ‣ The electrical technician must have read and understood these Operating Instructions and must follow the instructions contained therein.
  • Page 22 Electrical connection Liquistation CSF33 2. Using an 5mm Allen key, release the rear panel by turning the lock clockwise.  CLOSE OPEN A0012803 3. Lift up the rear upper panel and pull it off towards the back.  A0012826  12 Remove the rear panel.
  • Page 23 Liquistation CSF33 Electrical connection A0012824 ‣ Remove the bolt on the rear panel. 6.1.5 Removing the cover WARNING Device is live Incorrect connection may result in injury or death ‣ Make sure the device is disconnected from the power source before you remove the cover of the power unit.
  • Page 24 Electrical connection Liquistation CSF33 A0013237  13 Terminal assignment Assignment: 100 to 120 V/200 to 240 V AC ±10 % Assignment: 24 V DC +15/-9 % Rechargeable batteries (optional) Internal 24 V voltage Fuses (only for batteries) 6.1.7 Cable terminals After connection, make sure that every cable end is securely in place.

  • Page 25: Connecting Modules And Sensors

    Liquistation CSF33 Electrical connection Connecting modules and sensors 6.2.1 Connection compartment in the controller housing A0013238 A0012843 1 E base module Sampler controller The controller housing has a separate connection Display cover open, version with L base module compartment. Release the six cover screws to open the connection compartment: ‣...
  • Page 26 Electrical connection Liquistation CSF33 6.2.3 Sampler controller The connections for the sampler controller are located in the controller housing (→  25). Analog inputs and binary inputs/outputs 125 123 124 225 223 224 191 192 291292 145 146 245 246 A0012988 ...
  • Page 27 Liquistation CSF33 Electrical connection CSXxx FMU90 A0028653  21 With four-wire transmitter, e.g. Prosonic S FMU90 Binary inputs A0013381  22 Assignment of binary inputs 1 and 2 Binary input 1 (191/192) Binary input 2 (291/292) A0013404  23 Binary input with external voltage source When connecting to an internal voltage source, use the terminal connection on the rear of the dosing compartment.

  • Page 28: Terminal Assignment For Input/Output

    Electrical connection Liquistation CSF33 A0013407  25 Binary output with external voltage source When connecting to an internal voltage source, use the terminal connection on the rear of the dosing compartment. The connection is located on the lower terminal strip (on the far left, + and -) (→...

  • Page 29: Post-Connection Check

    Liquistation CSF33 Electrical connection Post-connection check WARNING Connection errors The safety of people and of the measuring point is at risk! The manufacturer does not accept any responsibility for errors that result from failure to comply with the instructions in this manual.

  • Page 30: System Integration

    System integration Liquistation CSF33 System integration Service interface You can connect the device to a computer via the service interface and configure it using "FieldCare" . Furthermore, configurations can also be saved, transferred and documented. 7.1.1 Connection 1. Connect the service connector to the interface on the Liquiline base module and connect it to the Commubox.

  • Page 31: Operation Options

    Liquistation CSF33 Operation options Operation options Overview 8.1.1 Display and operating elements Display (with red display background in alarm condition) EH_CSF Navigator (jog/shuttle and press/hold function) 09:11:05 31.03.2015 Soft keys (function depends on menu) MODE A0025501  27 Overview of operation 8.1.2...

  • Page 32: Access To The Operating Menu Via The Local Display

    Operation options Liquistation CSF33 Access to the operating menu via the local display 8.2.1 Operating concept MODE MODE Turningthe navigator: moving the cursor in the menu Pressingthe soft key: selecting the menu directly Menu/Language MODE Turningthe navigator: selecting a value (e.g. from a list)

  • Page 33: Configuration Options

    Liquistation CSF33 Operation options password. This password is set here: MenuSetupGeneral settingsExtended setupData managementChange lock password ‣ Choose whether you want to lock without or without a password.  The keys are locked. No more entries can be made. In the soft key bar, you will see symbol.
  • Page 34 Operation options Liquistation CSF33 8.3.3 Numerical values • You are changing a variable. • The maximum and minimum values for this variable are shown on the display. • Configure a value within these limits. • Example: Menu/Operation/Display/Contrast 8.3.4 Actions • You trigger an action with the appropriate function.
  • Page 35 Liquistation CSF33 Operation options 8.3.5 Free text • You are assigning an individual designation. • Enter a text. You can use the characters in the editor for this purpose (upper-case and lower-case letters, numbers and special characters). • Using the soft keys, you can: •...

  • Page 36: Commissioning

    Commissioning Liquistation CSF33 Commissioning Function check WARNING Incorrect connection, incorrect supply voltage Safety risks for staff and device malfunctions! ‣ Check that all connections have been established correctly in accordance with the wiring diagram. ‣ Ensure that the supply voltage matches the voltage indicated on the nameplate.
  • Page 37 Liquistation CSF33 Commissioning 9.3.2 Display behavior Menu/Operation/Display Function Options Info Contrast 5 to 95 % Adjust the screen settings to suit your working environment. Factory setting 50 % Backlight = Automatic The backlighting is switched off automatically Backlight Selection after a short time if a button is not pressed. It •...
  • Page 38 Commissioning Liquistation CSF33 Menu/Operation/User definable screens Function Options Info Line 1 ... 8 User interface Specify the content of Label in the submenu of Label each line. ‣ Source of data Selection Select a source of data. • None You can choose from the following: •...
  • Page 39 Liquistation CSF33 Commissioning 9.3.5 Sampling programs Difference between program types The following box provides an overview of the differences between the Basic, Standard and Advanced program types. Basic (1 sampling program) Start condition: • Immediate activation Stop condition: • Immediate •...
  • Page 40 Commissioning Liquistation CSF33 Manual sampling Menu/Manual sampling 15000 ml Distribution position Bottle 1 Multiplier MODE A0036865-EN 1. Manual sampling is triggered by the MAN soft key. This pauses any program currently running.  The current bottle configuration and the current sample volume are displayed.
  • Page 41 Liquistation CSF33 Commissioning 3. Stop condition: after program end or continuous operation. 4. Pressing the SAVE saves the program and ends data entry.  Example: 15000 ml 100 ml MODE A0029242-EN The program can be started. Endress+Hauser...

  • Page 42: Operation

    Operation Liquistation CSF33 Operation 10.1 Display 10.1.1 Measuring mode ‣ To display the measured values, press the soft key MEAS in the start screen, or during operation press STAT under Measurement. Press the navigator button to change the mode There are various display modes: •...

  • Page 43: General Settings

    Liquistation CSF33 Operation Icon Location Description At measured value The displayed measured value is simulated (for sensors) Header bar Controller is active Only pH or ORP measurement If two or more diagnostic messages occur simultaneously, only the icon for the message with the highest priority is shown on the display (for the order of priority according to NAMUR, →...
  • Page 44 Operation Liquistation CSF33 Menu/Setup/General settings Function Options Info Alarm delay 0 to 9999 s The software displays only the errors that are present longer than the set delay time. This Factory setting makes it possible to suppress messages that only occur briefly and are caused by normal process- specific fluctuations.
  • Page 45 Liquistation CSF33 Operation 10.2.3 Hold settings Menu/Setup/General settings/Hold settings Function Options Info Settings automatic Hold Hold release time 0...600 s The hold is maintained for the duration of the delay time when you switch to the measuring Factory setting mode.
  • Page 46 Operation Liquistation CSF33 Menu/Setup/General settings/Logbooks Function Options Info Logbook program Selection All program cycles are recorded • Off Ring buffer • Ring buffer If the memory is full, the most recent entry • Fill up buffer automatically overwrites the oldest entry.
  • Page 47 Liquistation CSF33 Operation Menu/Setup/General settings/Logbooks Function Options Info Start/stop Action Appears if you have created more than one data simultaneously logbook. With one mouse click, you can start or stop recording all the data logbooks. Logbook name The name of this submenu is based on the name of the logbook and only appears once you have created a logbook.
  • Page 48 Operation Liquistation CSF33 Menu/Setup/General settings/Logbooks Function Options Info Line plotter Menu to define the graphic display Axes Selection Should the axes (x, y) be displayed (On) or not • Off (Off)? • On Factory setting Orientation Selection You can choose whether the value curves should •...
  • Page 49 Liquistation CSF33 Operation Menu/Setup/General settings/ Function Options Info Sampling Number of bottles Choice of all possible bottle The bottle configuration you ordered combinations is preset in the device. Bottle volume 0 to 100000 ml If continuous operation is selected for...
  • Page 50 Operation Liquistation CSF33 Menu/Setup/General settings/ Function Options Info Liquid detection Selection Automatic • Automatic The last intake time determined is the • Semi automatic new purge time. • Manual Semi automatic Factory setting In Semi automatic purge times and Automatic intake times can be defined separately.
  • Page 51 Liquistation CSF33 Operation Menu/Setup/General settings/ Function Options Info Liquid detection Selection If "Semiautomatic" is selected, the • Automatic purge times and intake times can be • Semi automatic defined separately. • Off Off: Factory setting The definition of the purge times and...
  • Page 52 Operation Liquistation CSF33 Menu/Setup/General settings/ Function Options Info Sample temperature 2 to 20 °C Set the sample compartment temperature. Factory setting 4 °C Cooling control Selection The temperature regulator is switched • Standard operation off for a certain time if quick cool- •...
  • Page 53 Liquistation CSF33 Operation 10.2.6 Advanced setup Diagnostics settings The list of diagnostic messages displayed depends on the path selected. There are device- specific messages, and messages that depend on what sensor is connected. Menu/Setup/(General settings or Inputs<Sensor channel>)/Extended setup/Diagnostics settings/Diag.
  • Page 54 Operation Liquistation CSF33 Modbus Menu/Setup/General settings/Extended setup/Modbus Function Options Info Enable Selection You can switch off communication at this point. • Off The software can then only be accessed via local • On operation. Factory setting Termination Read only If the device is the last in the bus, you can terminate via the hardware.
  • Page 55 Liquistation CSF33 Operation 3. Select the desired update and select yes when asked the following: The current firmware will be overwritten. After this the device will reboot. Do you want to proceed?  The firmware is loaded and the device is then started with the new firmware.
  • Page 56 Operation Liquistation CSF33 4. Then select Export .  If you have already assigned the file name, you will be asked whether you want to overwrite the existing setup. 5. Use OK to confirm or cancel and assign a new file name.

  • Page 57: Programming

    Liquistation CSF33 Operation 10.3 Programming The following box provides an overview of the differences between the Basic, Standard and Advanced program types. Basic (1 sampling program) Start condition: • Immediate activation Stop condition: • Immediate • Time-paced, volume-paced or • Program end •...
  • Page 58 Operation Liquistation CSF33 10.3.1 Overview of the possible program types The graphic below explains the various ways sampling can be controlled on the basis of a flow curve: Flow curve Time-proportional sampling (CTCV) A constant sample volume (e.g. 50 ml) is taken at regular intervals (e.g.
  • Page 59 Liquistation CSF33 Operation The following table explains the various types of sampling using specific examples. Type of sampling Example Info Time-paced • Sampling interval: 5 min This type of sampling remains • Sampling volume: 50 ml constant over time and does not •...
  • Page 60 Operation Liquistation CSF33 Type of sampling Example Info Time/flow-paced (only Controlled via current input Samples are taken at set intervals possible with peristaltic • Signal: 0 to 20 mA with a variable sampling volume. pump) Time/flow-paced • Sampling interval: 10 min The sampling volume is calculated •...
  • Page 61 Liquistation CSF33 Operation Specific bottles can be assigned specific filling times with the bottle synchronization function. For example, bottle 1 is to be filled from midnight to 2 a.m., bottle 2 from 2 a.m. to 4 a.m. etc.. The following options are available for this: •...
  • Page 62 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Setup program A list of all the programs created is displayed. For this reason, it is often helpful to add a "B" for Basic in the program name. Program1, which is supplied with the device, is displayed, as is a list of all the programs already created (Basic, Standard or Advanced programs).
  • Page 63 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Bottle volume 0 to 100000 ml Set the bottle volume. The preset value depends on the bottle configuration Factory setting configured. The bottle volume is always 30 l • 30000 ml for individual containers. The preset value •...
  • Page 64 Operation Liquistation CSF33 Settings with a time-paced Basic program Settings with the Basic program type with 1 bottle Sampling mode = Time paced CTCV Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Sampling interval 00:01:00 ... 99:59:00 Set the sampling interval. (for version with vacuum pump or...
  • Page 65 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Bottle synchronization Selection None • None The sampling and bottle change times are • 1. bottle change time not synchronized. • 1. Time of change + 1. bottle change time bottle number Sampling starts with the first bottle.
  • Page 66 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Assignment bin. output Selection Assignment of the binary output to the • No binary output program cycle. configured • Binary output Sx Factory setting No binary output configured Inputs Settings for the inputs can be made as described in the "Inputs"...
  • Page 67 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Samples per bottle 1 ... 9999 Set the number of samples. If the bottle is full beforehand based on the Factory setting calculated level, the system prevents more samples being added to the bottle. Such samples are logged as failed samples in the program logbook.
  • Page 68 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Sample at start Selection • Yes The first sample is taken when the program • No is started. Factory setting The system waits for the interval to elapse before the first sample is taken.
  • Page 69 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Dosing volume (for version with Factory setting Set the dosing volume or the sampling vacuum pump or sampling Vacuum pump: volume. assembly) 20 to 350 ml In the version with a vacuum pump or...
  • Page 70 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Start date 01.01.2000 ... 31.12.2099 Set the start date for the sampling program. The format depends on the option Factory setting configured under general settings. DD.MM.YYYY Start time 00:00:00 ... 23:59:59 Set the time when the sampling program is started.
  • Page 71 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Multiplier 1 to 10 You can change the sampling volume using (for version with vacuum pump or the multiplier. For example, if the dosing Factory setting sampling assembly) volume is set to 200 ml, set the multiplier to 2 for a sampling volume of 400 ml.
  • Page 72 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Having selected Start condition Immediate Sample at start Selection • Yes The first sample is taken when the program • No is started. Factory setting The system waits for the interval to elapse before the first sample is taken.
  • Page 73 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info If is selected: Sampling volume input Binary input Sampling volume 10 to 10000 ml Set the sampling volume. The dosing accuracy and the repeatability of Factory setting a sample volume < 20 ml can vary, 20 ml depending on the specific application.
  • Page 74 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Stop condition Selection Program end • Program end The device stops sampling automatically • Continuous once it has run through the set program. Factory setting Continuous Program end The device runs through the set program continuously in an infinite loop.
  • Page 75 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Bottle change mode Selection The bottle can be changed after a specific • Number of samples number of samples, after a time or by an • Time external signal. • External signal...
  • Page 76 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Assignment bin. output Selection Assignment of the binary output to the • No binary output program cycle. configured • Binary output Sx Factory setting No binary output configured Inputs Settings for the inputs can be made as described in the "Inputs"...
  • Page 77 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Start condition Selection The sampling program can be started either • Immediate immediately or at a specific, configurable • Date/time time. Factory setting Immediate Having selected Start condition Immediate Sample at start Selection •...
  • Page 78 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Bottle change mode Selection The bottle can be changed after a specific • Number of samples number of samples, after a time or by an • Time external signal. • Number of samples...
  • Page 79 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New/Basic Function Options Info Stop condition Selection Program end • Program end The device stops sampling automatically • Continuous once it has run through the set program. Factory setting Continuous Program end The device runs through the set program continuously in an infinite loop.
  • Page 80 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Start condition Selection The sampling program can be started either • Immediate immediately, at a specific, configurable time, • Date/time or when a certain totalized flow is reached. • Volume Factory setting...
  • Page 81 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Sampling mode Selection Time paced CTCV • Time paced CTCV A constant sampling volume is taken at • Flow paced VTCV steady intervals. • Time/flow paced CTVV Flow paced VTCV • External signal...
  • Page 82 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Repetition mode Selection Daily interval • Daily interval Specify whether the subprogram should be • Weekly interval repeated every day. • Days of week Weekly interval Factory setting Specify whether the subprogram should be Daily interval repeated every week.
  • Page 83 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Sample at disable Selection Specify whether a sample should be taken • Yes when the subprogram is disabled. For • No example, with intervals, a sample is taken at the end of every activation interval.
  • Page 84 Operation Liquistation CSF33 Programming example: Program switchover The following example explains how to program a program change in the Standard program. Flow-paced sampling • Daily average sample • From Monday to Friday Time-paced sampling • In a composite container • On Saturday and Sunday...
  • Page 85 Liquistation CSF33 Operation Menu/Setup/Sampling programs/Setup program/New Function Entry for sample program Wednesday Thursday Friday Saturday Sunday Sample at enable Sample at disable "SAVE" ‐ saves the "MO ‐ FR" subprogram "ESC" ‐ "ESC" Setup subprogram: SAT ‐ SUN Edit Sampling mode...
  • Page 86 Operation Liquistation CSF33 Settings for the Advanced program Menu/Setup/Sampling programs Function Options Info Setup program A list of all the programs created is displayed. For this reason, it is often helpful to add an "S" for Standard in the program name.
  • Page 87 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Start flow sum 1000 to 9,999,000 m Set the start volume. Factory setting 10,000 m Having selected Start condition External start Start signal input Selection Select the program start input. The binary •...
  • Page 88 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Stop signal input Selection Select the program stop input. The binary • No program start input input must be configured for this function. configured Only the inputs configured as a program stop •...
  • Page 89 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Sampling volume 10 to 10000 ml Set the sampling volume. The dosing accuracy and the repeatability of Factory setting a sample volume < 20 ml may vary 100 ml depending on the specific application...
  • Page 90 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Event Editor 1 If you have more than one event editor, the "Event editor" menu item appears often. Use the "Link" menu item to configure the logical link between the signals. Source of data...
  • Page 91 Liquistation CSF33 Operation Menu/Setup/Sampling programs Function Options Info Auto Confirm 00:01 ... 23:59 Factory setting 01:00 Having selected Activation input External start Activation input Selection Select the input for start of the subprogram. • No program part start input The binary input must be configured for this configured function.
  • Page 92 Operation Liquistation CSF33 Menu/Setup/Sampling programs Function Options Info Bottle synchronization Selection Specific bottles can be assigned specific • None filling times with the bottle synchronization • 1. bottle change time function. For example, bottle 1 is to be filled • 1. Time of change + bottle from midnight to 2 a.m., bottle 2 from 2 a.m.
  • Page 93 Liquistation CSF33 Operation A0014126  30 Event-controlled sampling pH value: 8.0 pH value Sampling into individual bottles when pH value > 8.0 Sampling into composite container when pH value < 8.0 Menu/Setup/Sampling programs/Setup program/New Function Entry for sample program Advanced...
  • Page 94 Operation Liquistation CSF33 Menu/Setup/Sampling programs/Setup program/New Function Entry for sample program Multiple bottles Enable subprogram Event Start condition No delay Activation event Number of events Event Editor 1 Source of data CH1: 1:1 pH glass Measured value Operating mode Upper limit Limit value pH 8.00...

  • Page 95: Inputs

    %0V. In the simplest scenario, this could be the name of the measuring channel, for example. 10.4 Inputs As standard, Liquistation CSF33 has: • Two binary inputs • Two current inputs • Galvanically isolated from one another 10.4.1...
  • Page 96 Operation Liquistation CSF33 With the CSF33, the power supply of 24 V DC from the terminal block in the connection compartment of the sampler can be used for floating contacts (see the "Electrical connection" section). Menu/Setup/Inputs Function Options Info Binary input S:x...
  • Page 97 Liquistation CSF33 Operation Menu/Setup/Inputs Function Options Info Interval Selection Daily • Daily If a daily interval is selected, set the Time . • Weekly Weekly • Monthly If a weekly interval is selected, set the Day Factory setting of week and the Time .
  • Page 98 Operation Liquistation CSF33 Menu/Setup/Inputs Function Options Info Interval Selection Daily • Daily If a daily interval is selected, set the Time . • Weekly Weekly • Monthly If a weekly interval is selected, set the Day Factory setting of week and the Time .
  • Page 99 Liquistation CSF33 Operation Menu/Setup/Inputs Function Options Info Input mode Selection Select the input variable. • Flow rate Flow rate • Parameter The input can be used as the source for • Current time/flow-paced or flow-paced sampling Factory setting programs. Current...

  • Page 100: Outputs

    Operation Liquistation CSF33 Menu/Setup/Inputs Function Options Info Reset totalizer Selection Manual • Manual Reset the counter manually. • Automatic Automatic • At program start The counter is reset automatically at Factory setting intervals. Manual At program start The counter is reset at program start.
  • Page 101 Liquistation CSF33 Operation Menu/Setup/Outputs Function Options Info OutputBinary Function Selection The following functions depend on the • Off option selected. Function = "Off" switches off • Event the function of the binary output and means • Limit value no further settings are required.
  • Page 102 Operation Liquistation CSF33 Menu/Setup/Outputs Function Options Info Signal slope Selection Preselect the level change of the signal. • Low-High • High-Low Factory setting Low-High Source of data Selection Select the limit switch via which the status • None of the relay is to be output. The limit •...
  • Page 103 Liquistation CSF33 Operation Menu/Setup/Outputs/Current output x:y Function Options Info Current output Selection Use this function to activate or deactivate a • Off variable being output at the current output • On Factory setting Source of data Selection The sources of data on offer depend on your •...
  • Page 104 Operation Liquistation CSF33 Source of data Measured value Cond i Selection • Temperature Cond c • Conductivity • Resistance Cond c 4-pol (only Cond c) • Concentration (only Cond i and Cond c 4-pol) Disinfection Selection • Temperature • Sensor current •...
  • Page 105 Liquistation CSF33 Operation The following functions can be output via a relay: • Limit switch status • Controller manipulated variable for controlling an actuator • Diagnostic messages • Status of a cleaning function in order to control a pump or a valve You can assign a relay to multiple inputs in order to clean several sensors with just one cleaning unit, for example.
  • Page 106 Operation Liquistation CSF33 Function = Diagnostics Function Options Info Operating mode Selection as assigned • as assigned If this option is selected, the diagnostic messages • Namur M which you have individually assigned to the relay • Namur S are output via the relay.

  • Page 107: Additional Functions

    Liquistation CSF33 Operation 10.5.5 Modbus RS485 and Modbus TCP Specify which process values should be output via Modbus RS485 Communication or via Modbus TCP. In the case of Modbus RS485, you can switch between the RTU and the ASCII protocol.
  • Page 108 Operation Liquistation CSF33 Source of data Measured value Oxygen (amp.) Selection • Temperature Oxygen (opt.) • Partial pressure • Concentration liquid • Saturation • Raw value nA (only Oxygen (amp.)) • Raw value μs (only Oxygen (opt.)) Cond i Selection •...
  • Page 109 Liquistation CSF33 Operation Menu/Setup/Additional functions/Limit switches/Limit switch 1 ... 8 Function Options Info Cleaning program Selection Use this function to choose which cleaning • None instance should start when the limit switch is • Cleaning 1 ... 4 active. Factory setting...
  • Page 110 Operation Liquistation CSF33 Menu/Setup/Additional functions/Limit switches/Limit switch 1 ... 8 Function Options Info Range lower value Settings depend on the Operating mode = Out of range check or In measured value range check Range upper value A0028524  32 Range monitoring outside (A) and within (B) a range (without hysteresis and switch-on delay)
  • Page 111 Liquistation CSF33 Operation Menu/Setup/Additional functions/Limit switches/Limit switch 1 ... 8 Function Options Info Delta value Settings depend on the Operating mode = Change rate measured value The slope of the measured value (MV) is monitored in this mode. Delta time...
  • Page 112 Operation Liquistation CSF33 Standard cleaning Standard cleaning involves cleaning a sensor with compressed air, for instance, as performed with the ion-selective sensor CAS40D (connection of cleaning unit for CAS40D) Menu/Setup/Additional functions/Cleaning/Cleaning 1 ... 4/Standard clean Function Options Info Cleaning time...
  • Page 113 Liquistation CSF33 Operation Chemoclean Plus An example is the use of the CYR10 injector unit to clean pH glass sensors. (CYR10 connection ) Menu/Setup/Additional functions/Cleaning/Cleaning 1 ... 4/Chemoclean Plus/ChemoCleanPlus setup Function Options Info Cleaning steps setup Table to create a time...
  • Page 114 Operation Liquistation CSF33 Defining the cleaning cycle Menu/Setup/Additional functions/Cleaning/Cleaning 1 ... 4 Function Options Info ‣ Cleaning cycle Selection Choose from a cleaning routine that is • Off restarted at set intervals and a user- • Interval definable weekly program.
  • Page 115 Liquistation CSF33 Operation 10.6.3 Cleaning programs, sampling technology CAUTION Risk of injury due to medium or cleaning agent Cleaning not switched off during calibration or maintenance activities ‣ If a cleaning system is connected, switch if off before removing a sensor from the medium.
  • Page 116 Operation Liquistation CSF33 MenuSetup/Inputs/Binary input Function Entry for sample program MODE Input mode External signal -> Control of sampling functions via external signals Having selected input variable External signal: Operation Start cleaning -> A pulse triggers the cleaning. Signal slope Low-High Factory setting: Low-High.
  • Page 117 Liquistation CSF33 Operation Example of a cleaning phase table Duration (s) Water Info Arm at tundish Water valve Drip time The distribution arm only goes to the bottle at the next sampling. MenuSetup/Inputs/Additional functions/Cleaning/Cleaning 1/Chemoclean Plus/ChemoCleanPlus setup Function Entry for sample program Cleaning cycle Only active via external controller.
  • Page 118 Operation Liquistation CSF33 10.6.5 Mathematical functions In addition to "real" process values, which are provided by connected physical sensors or analog inputs, mathematical functions can be used to calculate a maximum of 6 "virtual" process values. The "virtual" process values can be: •...
  • Page 119 Liquistation CSF33 Operation Menu/Setup/Additional functions/Mathematical functions/MF1 to 6/Mode = Redundancy Function Options Info Deviation control Selection You can monitor the redundancy. Specify an • Off absolute limit value that must not be exceeded. • On Factory setting Deviation limit Depends on the selected...
  • Page 120 Operation Liquistation CSF33 Menu/Setup/Additional functions/Mathematical functions/MF1 to 6/Mode = Degassed conductivity Function Options Info Calculation Selection On/off switch for the function • Off • On Factory setting Cation conductivity Connected conductivity Cation conductivity is the sensor downstream sensor from the cation exchanger and upstream from the "degassing module", Degassed conductivity...
  • Page 121 Liquistation CSF33 Operation Calculated pH value The pH value can be calculated from the measured values of two conductivity sensors under certain conditions. Areas of application include power stations, steam generators and boiler feedwater. Menu/Setup/Additional functions/Mathematical functions/MF1 to 6/Mode = pH calculation from...
  • Page 122 Operation Liquistation CSF33 Symbol Operation Type of operands Type of result Example Sine Numerical Numerical SIN(A) Cosine Numerical Numerical COS(B) Exponential function e Numerical Numerical EXP(A) Natural logarithm Numerical Numerical LN(B) Decadic logarithm Numerical Numerical LOG(A) Maximum of two values...
  • Page 123 Liquistation CSF33 Operation Menu/Setup/Additional functions/Mathematical functions/MF1 to 6/Mode = Formula Function Options Info Result unit Free text You may enter a unit for the calculated value if desired. Result format Selection Select the number of decimal places. • # • #.# •...
  • Page 124 Operation Liquistation CSF33 5. Connect the valve or pump. 10.6.6 Measuring range switching A measuring range switching (MRS) configuration includes the following options for each of the four binary input states: • Operating mode (conductivity or concentration) • Concentration table •...
  • Page 125 Liquistation CSF33 Operation Menu/Setup/Additional functions/Measuring range switch Function Options Info MRS set 1 ... 2 If you enter both activation codes, you have two independent parameter sets available for measuring range switching. The submenus are the same for both sets.
  • Page 126 Operation Liquistation CSF33 Menu/Setup/Additional functions/Measuring range switch Function Options Info Current output Range lower unit Depends on the Operating Units are only queried for Operating mode = mode Conductivity . The other units are pre-defined Range lower value and cannot be modified.

  • Page 127: Diagnostics And Troubleshooting

    Liquistation CSF33 Diagnostics and troubleshooting Diagnostics and troubleshooting 11.1 General troubleshooting The sampler continuously monitors its functions itself. The color of the display background changes to red if a diagnostic message for error category "F" occurs. The LED beside the display flashes red if a diagnostic message for error category "M"...

  • Page 128: Diagnostic Information On Local Display

    Diagnostics and troubleshooting Liquistation CSF33 Problem Possible cause Tests and/or remedial measures Distribution arm stops Incorrect distribution selected in operation Check the distribution arm connection Distributor is defective, replace distributor or arrange for repair by E+H Service Incorrect bottle filled Incorrect distribution selected in operation ‣...
  • Page 129 Liquistation CSF33 Diagnostics and troubleshooting In accordance with Namur specification NE 107, the diagnostic messages are characterized • Message number • Error category (letter in front of the message number) • F = (Failure) a malfunction has been detected The cause of the malfunction is to be found in the sampling point/measuring point.

  • Page 130: Overview Of Diagnostic Information

    Diagnostics and troubleshooting Liquistation CSF33 Menu/Setup/Run the ../Extended setup/Diagnostics settings/Diag. behavior Function Options Info Diagnostic message Selection You can deactivate or reactivate a diagnostic • Off message here. • On Deactivating means: Factory setting • No error message in the measuring mode Depends on the •...
  • Page 131 Liquistation CSF33 Diagnostics and troubleshooting Message Factory settings Tests or remedial action Firmware failure Internal device error Update the software Firmware incomp. Contact the Service Department Firmware failure Replace the backplane (Service) Electronics module Electronics module defective Replace the module...
  • Page 132 Diagnostics and troubleshooting Liquistation CSF33 Message Factory settings Tests or remedial action Temperature sensor Temperature sensor PT3 for ambient temperature measurement is defective • Winter operation regulation not possible • Sampling and distribution arm blocked to protect against freezing Disable winter operation under Setup/...
  • Page 133 Liquistation CSF33 Diagnostics and troubleshooting Message Factory settings Tests or remedial action Liquid sensor Capacitance sensor adjusted incorrectly or defective • No medium detection possible in the dosing glass • No sampling possible Clean sensor Contact the Service Department Read sub-program...
  • Page 134 Diagnostics and troubleshooting Liquistation CSF33 Message Factory settings Tests or remedial action Cooling system Climate control module defective Replace the climate control module Contact the Service Department Fan defective Ventilator defective Replace the ventilator Contact the Service Department Pump hose warning...
  • Page 135 Liquistation CSF33 Diagnostics and troubleshooting Message Factory settings Tests or remedial action Overfill check Total capacity of bottle reached No further sampling to current bottle is triggered ‣ If desired, make changes to the sampling program under Select sampling program...
  • Page 136 Diagnostics and troubleshooting Liquistation CSF33 Message Factory settings Tests or remedial action SD card (80%) SD card 80% full Replace SD card with empty card. Clear SD card. Set the logbook properties to First In First Out ((Setup/General settings/Logbooks). SD card (100%) SD card 100% full.
  • Page 137 Liquistation CSF33 Diagnostics and troubleshooting Message Factory settings Tests or remedial action Cat.exchanger failure Invalid values for conductivity or flow Check for valid measured values in the menu of the mathematical function. Check sensors. Check minimum flow. Cat.exchanger warning Limit values exceeded for conductivity or flow.
  • Page 138 Diagnostics and troubleshooting Liquistation CSF33 Message Factory settings Tests or remedial action Inline armature Final sampling position (in the process) of sampling assembly not reached or detected • Assembly blocked • Final position switch is damaged • Supply cables are damaged...

  • Page 139: Pending Diagnostic Messages

    Liquistation CSF33 Diagnostics and troubleshooting Message Factory settings Tests or remedial action 961 - Diagnostic module 1 Diagnostic module is enabled (961) Diagnostic module 8 (968) Modbus Watchdog The device did not receive a Modbus telegram from the master within the specified time. The...

  • Page 140: Diagnosis List

    Diagnostics and troubleshooting Liquistation CSF33 All the other functions in the Diagnostics menu are described in the following chapters. Diagnostic messages associated with sampling are deleted under the following conditions: • Diagnostic messages caused by sampling are deleted automatically with the next successful sampling.
  • Page 141 Liquistation CSF33 Diagnostics and troubleshooting 11.7.2 Logbooks menu DIAG/Logbooks Function Options Info All events Chronological list of all the logbook entries, with information on the type of event Show Events are displayed Select a particular event to display more detailed information.
  • Page 142 Diagnostics and troubleshooting Liquistation CSF33 126.00 126.00 34.00 34.00 09.11.2011 09.11.2011 23.11.2011 23.11.2011 14:02:20 14:02:20 11:25:32 11:25:32 12.00 6.00 09.11.2011 09.11.2011 23.11.2011 23.11.2011 14:02:20 14:02:20 11:25:32 11:25:32 A0016688  37 Simultaneous display of two graphs, the top one is "selected"...
  • Page 143 Liquistation CSF33 Diagnostics and troubleshooting DIAG/Logbooks Function Options Info Program logbook Action, Use this function to save the logbook to an SD All data logbooks commences as soon as the card. Data logbook 1 ... 8 option is selected ‣...
  • Page 144 Diagnostics and troubleshooting Liquistation CSF33 Entry Example Info Sampling mode Time-paced CTCV Time-paced CTCV Time-paced Flow-paced VTCV Flow-paced Time/flow-paced CTVV Time/flow-paced Single sample Single sample Sample table Single sample Sampling mode Display of the sampling mode Sampling interval/unit 10 min...
  • Page 145 Liquistation CSF33 Diagnostics and troubleshooting Entry Example Info Running sample number Running sample number in the current program Flow sum since last sampling For flow-paced and time/flow-paced sampling: --> Flow since the last sampling For all other types of sampling: -->...

  • Page 146: Device Information

    Diagnostics and troubleshooting Liquistation CSF33 11.8 Device information 11.8.1 System information DIAG/System information Function Options Info Device tag Read only Individual device tag → General settings Order code Read only You can order identical hardware with this code. This code changes on account of...

  • Page 147: Simulation

    Liquistation CSF33 Diagnostics and troubleshooting DIAG/System information Function Options Info Heartbeat operation Heartbeat functions are only available with the appropriate device version or optional access code. Device Read only Availability • Total operating time Percentage of time no error with the •...
  • Page 148 Diagnostics and troubleshooting Liquistation CSF33 DIAG/Simulation Function Options Info Current output x:y Simulation of an output current This menu appears once for each current output. Simulation Selection If you simulate the value at the current output, • Off this is indicated on the display by a simulation •...

  • Page 149: 11.10 Device Test

    Liquistation CSF33 Diagnostics and troubleshooting 11.10 Device test Menu/Diagnostics/Systemtest Function Options Info Power Supply Read only The current supply voltage is displayed. Cooling system (only for version with sample compartment temperature regulation) Check cooling Power supply Read only The current supply voltage is displayed.
  • Page 150 Diagnostics and troubleshooting Liquistation CSF33 Menu/Diagnostics/Systemtest Function Options Info Start sampling Action Peristaltic pump Pump purge Action Pump purge, to stop Read only press ESC Current pump Read only operating time Power supply Read only The current supply voltage is displayed.

  • Page 151: 11.11 Resetting The Measuring Device

    Liquistation CSF33 Diagnostics and troubleshooting Menu/Diagnostics/Systemtest Function Options Info Medium LF1 Read only • Medium detection LF1 switchoff • Medium detection LF2 disconnection from Medium LF2 Read only protective circuit ‐> Both "No" at the start ‐> If "Yes", clean LF2...

  • Page 152: 11.13 Status Of Inputs/Outputs

    Diagnostics and troubleshooting Liquistation CSF33 • Vacuum pump (for version with vacuum pump): Displays the pump operating time in hours and minutes • Sample totalizer (for version with peristaltic pump): Number of all samples taken and sample errors • Pump tube life (for version with peristaltic pump): Displays how old the tube is in days, hours and minutes •...

  • Page 153: 11.14 Firmware History

    Liquistation CSF33 Diagnostics and troubleshooting 11.14 Firmware history Date Version Changes to firmware Documentation 05/2018 01.06.06 Improvement BA00444C/07/EN/22.18 • New soft keys ALL and NONE in multiple selection editors • Manual factor for CAS51D nitrate • Calibration timer and validity revised for pH, conductivity, oxygen and disinfection •...
  • Page 154 Diagnostics and troubleshooting Liquistation CSF33 Date Version Changes to firmware Documentation 04/2013 01.04.00 Expansion BA00444C/07/EN/16.13 07/2013 • Conductivity: BA01225C/07/EN/01.13 • Measuring range switching BA00445C/07/EN/16.13 • Temperature compensation ISO 7888 at 20 °C BA01227C/07/EN/01.13 • Support for DIO module BA00450C/07/EN/16.13 • Triggering of external hold BA00450C/07/EN/17.13...
  • Page 155 Liquistation CSF33 Diagnostics and troubleshooting Date Version Changes to firmware Documentation 12/2010 01.02.00 Expansion BA444C/07/EN/13.10 • Support for additional sensors: BA445C/07/EN/13.10 • Chlorine BA450C/07/EN/13.10 • ISE BA451C/07/EN/13.10 • SAC BA00486C/07/EN/01.11 • Interface • HART Communication • Mathematics functions Improvement • Modified software structures •...

  • Page 156: Maintenance

    Replacing wear parts Wear parts are replaced by Endress+Hauser Service at one- and two-year intervals. Please contact your local sales center in this regard. Endress+Hauser offers its customers a maintenance contract. A maintenance contract increases the operational safety of your device and reduces your staff' s workload.

  • Page 157: Calibration

    Liquistation CSF33 Maintenance 12.2 Calibration 12.2.1 Sensors All connected sensors can be calibrated while a sampling program is active. 12.2.2 Distribution arm The position of the distribution arm is set at the factory. It is only possible to calibrate the distribution arm in the version with multiple bottles.
  • Page 158 Maintenance Liquistation CSF33 A0013896  38 Vacuum pump Outflow hose Dosing glass Dosing chamber cover Air hose connection Lock for intake hose Thread adapter nut for intake hose 1. Check the sample volume set under Menu/Setup/General settings/Sampling/Dosing volume. 2. Release the thread adapter nut on the intake hose (item 6).
  • Page 159 Liquistation CSF33 Maintenance 4. Reinstall the parts in reverse order. Make sure that the contacts of the conductivity sensors are in the correct position. 5. Check that the dosing tube is set correctly by triggering manual sampling. Capacitance sensor (Only for version with vacuum pump) The capacitance sensor has already been preset at the factory for water.

  • Page 160: Replacing The Pump Tube

    Maintenance Liquistation CSF33 Proceed as follows to calibrate: Menu/Calibration active Function Options Info Sample volume 1-point calibration Distributor position Selection Select the distributor position. • Front • Bottle x • Back Sample volume 20 to 2000 m Set the sample volume.
  • Page 161 Liquistation CSF33 Maintenance Opening the peristaltic pump Retainer Pump tubing Fastening clip Pump bracket Pump head cover Positioning pin Knurled head screw A0014115  41 Opening the peristaltic pump 1. Take the sampler out of service by pausing a program that is currently running.

  • Page 162: Cleaning

    Maintenance Liquistation CSF33 8. To avoid incorrect metering, reset the tube life to zero under Menu/Diagnostics/ Operating time information/Pump tube life using the "Reset" function. Calibrate the sample volume each time you replace a pump tube. 12.4 Cleaning 12.4.1 Housing ‣...
  • Page 163 Liquistation CSF33 Maintenance A0013896  43 Vacuum pump Outflow hose Dosing glass Dosing chamber cover Air hose connection Lock for intake hose Thread adapter nut for intake hose 1. Release the thread adapter nut on the intake hose (item 6).
  • Page 164 Maintenance Liquistation CSF33 A0014004  44 Version with peristaltic pump Pump tubing Pressure sensor Hose connection 1. Release the sample supply at the tube connection (item 3). 2. Connect a container containing clear water to the tube connection. 3. Remove the bottles from the sample compartment.
  • Page 165 Liquistation CSF33 Maintenance 3. Remove the pump tube. 4. Remove any silicone deposits on the roller and the flexible pump bracket. 5. Make sure the roller turns smoothly and evenly Cleaning the distribution arm Clean the distribution arm as follows:...

  • Page 166: Technical Support

    Maintenance Liquistation CSF33 12.4.4 Ventilator and liquefier A0013898  47 Cleaning the climate control module Liquefier Ventilator ‣ Clean the liquefier and ventilator with compressed air. 12.4.5 Digital sensors CAUTION Cleaning not switched off during calibration or maintenance activities Risk of injury due to medium or cleaning agent! ‣...

  • Page 167: Repair

    Liquistation CSF33 Repair Repair 13.1 Spare parts Contact your Endress+Hauser Service if you have any questions regarding spare parts. 13.1.1 Peristaltic pump A0013813  48 Spare parts for version with peristaltic pump Item No. Description and contents Order number Spare parts kit...
  • Page 168 Repair Liquistation CSF33 13.1.2 Vacuum pump A0013811  49 Spare parts for version with vacuum pump (view in front of pump holder) A0013812  50 Spare parts for version with vacuum pump (view behind pump holder) Item No. Description and contents...
  • Page 169 Liquistation CSF33 Repair Item No. Description and contents Order number Spare parts kit Capacitance dosing chamber flange, complete 71103166 Dosing chamber inlet with sealing ring, 71111006 intermediate ring and pipe clamp Air filter for vacuum pump, 2 pcs. hose, silicone, 71103283 320 mm (12.6")

  • Page 170: Return

    The product must be returned if repairs or a factory calibration are required, or if the wrong product was ordered or delivered. As an ISO-certified company and also due to legal regulations, Endress+Hauser is obliged to follow certain procedures when handling any returned products that have been in contact with medium.

  • Page 171: Accessories

    Liquistation CSF33 Accessories Accessories The following are the most important accessories available at the time this documentation was issued. ‣ For accessories not listed here, please contact your Service or Sales Center. Order no. Bottle tray + bottles + cover 71111152 Bottle tray + 6 x 3 liter (0.79 US gal.) PE+ cover...
  • Page 172 Accessories Liquistation CSF33 Order no. Suction head 71111184 Suction head V4A for ID 10 mm (3/8"), 1 pc. 71111185 Suction head V4A for ID 13 mm (1/2"), 1 pc. Order no. Communication; software 71110815 SD card, 1 GB, Industrial Flash Drive...

  • Page 173: Technical Data

    Liquistation CSF33 Technical data Technical data 15.1 Input Input types • 2 analog inputs • 2 binary inputs 15.2 Binary input, passive Span 12 to 30 V, galvanically isolated Signal characteristics Minimum pulse width: 100 ms 15.3 Analog input, passive/active...

  • Page 174: Performance Characteristics

    Technical data Liquistation CSF33 Permitted cable diameter: • M20x1.5 mm: 7 to 13 mm (0.28 to 0.51") • M25x1.5 mm: 9 to 17 mm (0.20 to 0.67") Mains fuse Optional fuses: T3.15A (for 230V power supply) Power consumption • Version with vacuum pump: 290 VA •...

  • Page 175: Environment

    Liquistation CSF33 Technical data Hose length Max. 30 m (98 ft) Temperature control Temperature sensors: Sampling compartment temperature Cooling module: • Sample temperature range: 2 to 20 °C (36 to 68 °F) Factory setting: 4 °C (39 °F) • Automatic defrost system •...

  • Page 176: Mechanical Construction

    Technical data Liquistation CSF33 Medium properties Vacuum pump Capacitance level measurement used for: • Sample media has to be free of abrasive substances. • Media that tend to create a lot of foam or contain fats and grease • Media with a conductivity < 30 µS/cm Peristaltic pump Sample media has to be free of abrasive substances.
  • Page 177 Liquistation CSF33 Technical data Wetted parts Vacuum pump Peristaltic pump Distribution arm Plastic PP Distribution arm cover Plastic PE Distribution plate Plastic PS Composite container/bottles Plastic PE, glass (depending on version) Intake hose Plastic PVC, EPDM (depending on version) Hose connection...
  • Page 178 Index Liquistation CSF33 Index Accessories ....... 171 Firmware history ......153 Adapting the diagnostic behavior .
  • Page 179 Liquistation CSF33 Index Safety Occupational safety ......7 Safety instructions ......7 Sample volume .
  • Page 180 www.addresses.endress.com...

Table of Contents
