- Page 1 Products Solutions Services BA00489C/07/EN/15.13 71217984 Valid as of: Softwareversion 01.04.00 Operating Instructions Liquistation CSF33 Automatic sampler for liquid media Calibration...
- Page 2 About this manual This manual describes how to calibrate the distribution arm and the sample volume. This manual does not include the following: • Setup/General settings --> Operating Instructions BA00479C "Commissioning" • Display/Operation --> Operating Instructions BA00479C "Commissioning" • Inputs -->...
-
Page 3: Table Of Contents
Liquistation CSF33 Table of contents Calibrating the distribution arm ......4 Calibrating the sample volume 5 Vacuum pump ..... . 5 Peristaltic pump . -
Page 4: Calibrating The Distribution
Calibrating the distribution arm Liquistation CSF33 Calibrating the distribution arm It is only possible to calibrate the distribution arm in the version with multiple bottles. The distribution arm must be calibrated if: • The distribution arm motor has been replaced •... -
Page 5: Calibrating The Sample Volume
Liquistation CSF33 Calibrating the sample volume Calibrating the sample volume Vacuum pump The desired sample volume is set by manually adjusting the dosing tube. a0013896 Fig. 1: Vacuum pump Outlet hose Dosing chamber Dosing chamber cover Air hose connection Lock for intake hose... - Page 6 Calibrating the sample volume Liquistation CSF33 Dosing tube Allen screw Air hose connection a0014128 Fig. 2: Vacuum pump Release the 2mm Allen screw with the key provided. Set the sample volume by adjusting the dosing tube. Secure the dosing tube with the screw.
-
Page 7: Peristaltic Pump
Liquistation CSF33 Calibrating the sample volume Peristaltic pump In order to calibrate the sample volume, a measurement beaker with a volume of at least 200 ml is required. Proceed as follows to calibrate: Path: Menu/Calibration active Function Options Info Sample volume... -
Page 8: Index
