10 Enterprise Management Engine Quick Start Guide
Figure 3 Installing the EME into the CoreBuilder 9000 16-slot Chassis
6 To engage the EME connectors and backplane connectors, apply pressure
to the module front panel with both hands while you push the ejector
handles inward toward the front panel with your thumbs. You feel a
slight resistance as the connectors engage.
CAUTION: If the resistance is too great, the EME connectors and
backplane connectors may not be aligned. Forcing the EME inward can
damage the module's connectors or the backplane connectors. If
necessary, remove and reinsert the EME, ensuring that the connectors are
properly aligned. Do not tighten the spring-loaded screws to seat the
module.
Ensure that the module remains fully seated in the backplane connector
while you close the ejector handles. Push the end of each ejector handle
inward toward the front panel until the ejector handle is parallel with the
front panel.
Ejector handle
Spring-loaded
screw
EME module
Spring-loaded
screw
Ejector handle
